URL
A Uniform Resource Locator (URL), commonly informally termed a web address (a term which is not defined identically)[1] is a reference to a web resource that specifies its location on a computer network and a mechanism for retrieving it. A URL is a specific type of Uniform Resource Identifier (URI),[2] although many people use the two terms interchangeably.[3] A URL implies the means to access an indicated resource and is denoted by a protocol or an access mechanism, which is not true of every URI.[4][3] Thus http://www.example.com is an URL, while www.example.com is not.[5] URLs occur most commonly to reference web pages (http), but are also used for file transfer (ftp), email (mailto), database access (JDBC), and many other applications.
Most web browsers display the URL of a web page above the page in an address bar. A typical URL could have the form http://www.example.com/index.html, which indicates a protocol (http), a hostname (www.example.com), and a file name (index.html).
History
Uniform Resource Locators were defined in Request for Comments (RFC) 1738 in 1994 by Tim Berners-Lee, the inventor of the World Wide Web, and the URI working group of the Internet Engineering Task Force (IETF),[6] as an outcome of collaboration started at the IETF Living Documents "Birds of a Feather" session in 1992.[7][8]
The format combines the pre-existing system of domain names (created in 1985) with file path syntax, where slashes are used to separate directory and file names. Conventions already existed where server names could be prefixed to complete file paths, preceded by a double slash (//).[9]
Berners-Lee later expressed regret at the use of dots to separate the parts of the domain name within URIs, wishing he had used slashes throughout,[9] and also said that, given the colon following the first component of a URI, the two slashes before the domain name were unnecessary.[10]
Syntax
Every HTTP URL conforms to the syntax of a generic URI. A generic URI is of the form:
scheme:[//[user:password@]host[:port]][/]path[?query][#fragment]It comprises:
The scheme, consisting of a sequence of characters beginning with a letter and followed by any combination of letters, digits, plus (+), period (.), or hyphen (-). Although schemes are case-insensitive, the canonical form is lowercase and documents that specify schemes must do so with lowercase letters. It is followed by a colon (:). Examples of popular schemes include http(s), ftp, mailto, file, data, and irc. URI schemes should be registered with the Internet Assigned Numbers Authority (IANA), although non-registered schemes are used in practice.[a]Two slashes (//): This is required by some schemes and not required by some others. When the authority component (explained below) is absent, the path component cannot begin with two slashes.[12]An authority part, comprising: An optional authentication section of a user name and password, separated by a colon, followed by an at symbol (@)A "host", consisting of either a registered name (including but not limited to a hostname), or an IP address. IPv4 addresses must be in dot-decimal notation, and IPv6 addresses must be enclosed in brackets ([ ]).[13][b]An optional port number, separated from the hostname by a colonA path, which contains data, usually organized in hierarchical form, that appears as a sequence of segments separated by slashes. Such a sequence may resemble or map exactly to a file system path, but does not always imply a relation to one.[15] The path must begin with a single slash (/) if an authority part was present, and may also if one was not, but must not begin with a double slash. The path is always defined, though the defined path may be empty (zero length)Query delimiterExampleAmpersand (&)key1=value1&key2=value2Semicolon (;)[c][incomplete short citation]key1=value1;key2=value2An optional query, separated from the preceding part by a question mark (?), containing a query string of non-hierarchical data. Its syntax is not well defined, but by convention is most often a sequence of attribute–value pairs separated by a delimiter.An optional fragment, separated from the preceding part by a hash (#). The fragment contains a fragment identifier providing direction to a secondary resource, such as a section heading in an article identified by the remainder of the URI. When the primary resource is an HTML document, the fragment is often an idattribute of a specific element, and web browsers will scroll this element into view.A web browser will usually dereference a URL by performing an HTTP request to the specified host, by default on port number 80. URLs using the https scheme require that requests and responses will be made over a secure connection to the website.
Internationalized URL
Internet users are distributed throughout the world using a wide variety of languages and alphabets and expect to be able to create URLs in their own local alphabets. An Internationalized Resource Identifier (IRI) is a form of URL that includes Unicode characters. All modern browsers support IRIs. The parts of the URL requiring special treatment for different alphabets are the domain name and path.[17][18]
The domain name in the IRI is known as an Internationalized Domain Name (IDN). Web and Internet software automatically convert the domain name into punycode usable by the Domain Name System; for example, the Chinese URL http://例子.卷筒纸 becomes http://xn--fsqu00a.xn--3lr804guic/. The xn-- indicates that the character was not originally ASCII.[19]
The URL path name can also be specified by the user in the local alphabet. If not already encoded, it is converted to Unicode, and any characters not part of the basic URL character set are converted to English letters using percent-encoding; for example, the Japanese URL http://example.com/引き割り.html becomes http://example.com/%E5%BC%95%E3%81%8D%E5%89%B2%E3%82%8A.html. The target computer decodes the address and displays the page.[17]
Protocol-relative URLs
Protocol-relative links (PRL), also known as protocol-relative URLs (PRURL), are URLs that have no protocol specified. For example, //example.com will use the protocol of the current page, either HTTP or HTTPS.[20][21]
See also
Notes
Citations
References
External links
This page was last modified on 25 March 2017, at 17:53.
This text is based on the Wikipedia article URL: https://en.wikipedia.org/wiki/Uniform_Resource_Locator which is released under the Creative Commons Attribution-ShareAlike 3.0 Unported License available online at: http://creativecommons.org/licenses/by-sa/3.0/legalcode List of authors: https://tools.wmflabs.org/xtools/wikihistory/wh.php?page_title=Uniform_Resource_LocatorContents
Web Resource
The concept of a web resource is primitive in the web architecture, and is used in the definition of its fundamental elements. The term was first introduced to refer to targets of uniform resource locators (URLs), but its definition has been further extended to include the referent of any uniform resource identifier (RFC 3986), or internationalized resource identifier (RFC 3987). In the Semantic Web, abstract resources and their semantic properties are described using the family of languages based on Resource Description Framework (RDF).
History
The concept of a web resource has evolved during the web history, from the early notion of static addressable documents or files, to a more generic and abstract definition, now encompassing every 'thing' or entity that can be identified, named, addressed or handled, in any way whatsoever, in the web at large, or in any networked information system. The declarative aspects of a resource (identification and naming) and its functional aspects (addressing and technical handling) were not clearly distinct in the early specifications of the web, and the very definition of the concept has been the subject of long and still open debate involving difficult, and often arcane, technical, social, linguistic and philosophical issues.
From documents and files to web resources
In the early specifications of the web (1990–1994), the term resource is barely used at all. The web is designed as a network of more or less static addressable objects, basically files and documents, linked using uniform resource locators (URLs). A web resource is implicitly defined as something which can be identified. The identification deserves two distinct purposes: naming and addressing; the latter only depends on a protocol. It is notable that RFC 1630 does not attempt to define at all the notion of resource; actually it barely uses the term besides its occurrence in URI, URL and URN, and still speaks about "Objects of the Network".
RFC 1738 (December 1994) further specifies URLs, the term 'Universal' being changed to 'Uniform'. The document is making a more systematic use of resource to refer to objects which are 'available', or 'can be located and accessed' through the internet. There again, the term resource itself is not explicitly defined.
From web resources to abstract resources
The first explicit definition of resource is found in RFC 2396, in August 1998:
A resource can be anything that has identity. Familiar examples include an electronic document, an image, a service (e.g., "today's weather report for Los Angeles"), and a collection of other resources. Not all resources are network "retrievable"; e.g., human beings, corporations, and bound books in a library can also be considered resources. The resource is the conceptual mapping to an entity or set of entities, not necessarily the entity which corresponds to that mapping at any particular instance in time. Thus, a resource can remain constant even when its content---the entities to which it currently corresponds---changes over time, provided that the conceptual mapping is not changed in the process.
Although examples in this document were still limited to physical entities, the definition opened the door to more abstract resources. Providing a concept is given an identity, and this identity is expressed by a well-formed URI (uniform resource identifier, a superset of URLs), then a concept can be a resource as well.
In January 2005, RFC 3986 makes this extension of the definition completely explicit: '…abstract concepts can be resources, such as the operators and operands of a mathematical equation, the types of a relationship (e.g., "parent" or "employee"), or numeric values (e.g., zero, one, and infinity).'
Resources in RDF and the Semantic Web
First released in 1999, RDF was first intended to describe resources, in other words to declare metadata of resources in a standard way. A RDF description of a resource is a set of triples (subject, predicate, object), where subject represents the resource to be described, predicate a type of property relevant to this resource, and object can be data or another resource. The predicate itself is considered as a resource and identified by a URI. Hence, properties like "title", "author" are represented in RDF as resources, which can be used, in a recursive way, as the subject of other triples. Building on this recursive principle, RDF vocabularies, such as RDFS, OWL, and SKOS will pile up definitions of abstract resources such as classes, properties, concepts, all identified by URIs.
RDF also specifies the definition of anonymous resources or blank nodes, which are not absolutely identified by URIs.
Using HTTP URIs to identify abstract resources
URLs, particularly HTTP URIs, are frequently used to identify abstract resources, such as classes, properties or other kind of concepts. Examples can be found in RDFS or OWL ontologies. Since such URIs are associated with the HTTP protocol, the question arose of which kind of representation, if any, should one get for such resources through this protocol, typically using a web browser, and if the syntax of the URI itself could help to differentiate "abstract" resources from "information" resources. The URI specifications such as RFC 3986 left to the protocol specification the task of defining actions performed on the resources and they don't provide any answer to this question. It had been suggested that an HTTP URI identifying a resource in the original sense, such as a file, document, or any kind of so-called information resource, should be "slash" URIs — in other words, should not contain a fragment identifier, whereas a URI used to identify a concept or abstract resource should be a "hash" URI using a fragment identifier.
For example: http://www.example.org/catalogue/widgets.html would both identify and locate a web page (maybe providing some human-readable description of the widgets sold by Silly Widgets, Inc.) whereas http://www.example.org/ontology#Widget would identify the abstract concept or class "Widget" in this company ontology, and would not necessarily retrieve any physical resource through HTTP protocol. But it has been answered that such a distinction is impossible to enforce in practice, and famous standard vocabularies provide counter-examples widely used. For example, the Dublin Core concepts such as "title", "publisher", "creator" are identified by "slash" URIs like http://purl.org/dc/elements/1.1/title.
The general question of which kind of resources HTTP URI should or should not identify has been formerly known in W3C as the httpRange-14 issue, following its name on the list defined by the Technical Architecture Group (TAG). The TAG delivered in 2005 a final answer to this issue, making the distinction between an "information resource" and a "non-information" resource dependent on the type of answer given by the server to a "GET" request:
2xx Success indicates resource is an information resource.303 See Other indicates the resource could be informational or abstract; the redirection target could tell you.4xx Client Error provides no information at all.This allows vocabularies (like Dublin Core, FOAF, and Wordnet) to continue to use slash instead of hash for pragmatic reasons. While this compromise seems to have met a consensus in the Semantic Web community, some of its prominent members such as Pat Hayes have expressed concerns both on its technical feasibility and conceptual foundation. According to Patrick Hayes' viewpoint, the very distinction between "information resource" and "other resource" is impossible to find and should better not be specified at all, and ambiguity of the referent resource is inherent to URIs like to any naming mechanism.
Resource ownership, intellectual property and trust
In RDF, "anybody can declare anything about anything". Resources are defined by formal descriptions which anyone can publish, copy, modify and publish over the web. If the content of a web resource in the classical sense (a web page or on-line file) is clearly owned by its publisher, who can claim intellectual property on it, an abstract resource can be defined by an accumulation of RDF descriptions, not necessarily controlled by a unique publisher, and not necessarily consistent with each other. It's an open issue to know if a resource should have an authoritative definition with clear and trustable ownership, and in this case, how to make this description technically distinct from other descriptions. A parallel issue is how intellectual property may apply to such descriptions.
See also
References
This page was last modified on 15 January 2017, at 02:33.
This text is based on the Wikipedia article Web Resource: https://en.wikipedia.org/wiki/Web_resource which is released under the Creative Commons Attribution-ShareAlike 3.0 Unported License available online at: http://creativecommons.org/licenses/by-sa/3.0/legalcode List of authors: https://tools.wmflabs.org/xtools/wikihistory/wh.php?page_title=Web_resourceContents
Computer Network
A computer network or data network is a telecommunications network which allows nodes to share resources. In computer networks, networked computing devices exchange data with each other using a data link. The connections between nodes are established using either cable media or wireless media. The best-known computer network is the Internet.
Network computer devices that originate, route and terminate the data are called network nodes.[1] Nodes can include hosts such as personal computers, phones, servers as well as networking hardware. Two such devices can be said to be networked together when one device is able to exchange information with the other device, whether or not they have a direct connection to each other.
Computer networks differ in the transmission medium used to carry their signals, communications protocols to organize network traffic, the network's size, topology and organizational intent.
Computer networks support an enormous number of applications and services such as access to the World Wide Web, digital video, digital audio, shared use of application and storage servers, printers, and fax machines, and use of email and instant messaging applications as well as many others. In most cases, application-specific communications protocols are layered (i.e. carried as payload) over other more general communications protocols. This formidable collection of information technology requires skilled network management to keep it all running reliably.
History
The chronology of significant computer-network developments includes:
In the late 1950s, early networks of computers included the military radar system Semi-Automatic Ground Environment (SAGE).In 1959, Anatolii Ivanovich Kitov proposed to the Central Committee of the Communist Party of the Soviet Union a detailed plan for the re-organisation of the control of the Soviet armed forces and of the Soviet economy on the basis of a network of computing centres.[2]In 1960, the commercial airline reservation system semi-automatic business research environment (SABRE) went online with two connected mainframes.In 1962, J.C.R. Licklider developed a working group he called the "Intergalactic Computer Network", a precursor to the ARPANET, at the Advanced Research Projects Agency (ARPA).In 1964, researchers at Dartmouth College developed the Dartmouth Time Sharing System for distributed users of large computer systems. The same year, at Massachusetts Institute of Technology, a research group supported by General Electric and Bell Labs used a computer to route and manage telephone connections.Throughout the 1960s, Leonard Kleinrock, Paul Baran, and Donald Davies independently developed network systems that used packets to transfer information between computers over a network.In 1965, Thomas Marill and Lawrence G. Roberts created the first wide area network (WAN). This was an immediate precursor to the ARPANET, of which Roberts became program manager.Also in 1965, Western Electric introduced the first widely used telephone switch that implemented true computer control.In 1969, the University of California at Los Angeles, the Stanford Research Institute, the University of California at Santa Barbara, and the University of Utah became connected as the beginning of the ARPANET network using 50 kbit/s circuits.[3]In 1972, commercial services using X.25 were deployed, and later used as an underlying infrastructure for expanding TCP/IP networks.In 1973, Robert Metcalfe wrote a formal memo at Xerox PARC describing Ethernet, a networking system that was based on the Aloha network, developed in the 1960s by Norman Abramson and colleagues at the University of Hawaii. In July 1976, Robert Metcalfe and David Boggs published their paper "Ethernet: Distributed Packet Switching for Local Computer Networks"[4] and collaborated on several patents received in 1977 and 1978. In 1979, Robert Metcalfe pursued making Ethernet an open standard.[5]In 1976, John Murphy of Datapoint Corporation created ARCNET, a token-passing network first used to share storage devices.In 1995, the transmission speed capacity for Ethernet increased from 10 Mbit/s to 100 Mbit/s. By 1998, Ethernet supported transmission speeds of a Gigabit. Subsequently, higher speeds of up to 100 Gbit/s were added (as of 2016). The ability of Ethernet to scale easily (such as quickly adapting to support new fiber optic cable speeds) is a contributing factor to its continued use.[5]Properties
Computer networking may be considered a branch of electrical engineering, telecommunications, computer science, information technology or computer engineering, since it relies upon the theoretical and practical application of the related disciplines.
A computer network facilitates interpersonal communications allowing users to communicate efficiently and easily via various means: email, instant messaging, chat rooms, telephone, video telephone calls, and video conferencing. Providing access to information on shared storage devices is an important feature of many networks. A network allows sharing of files, data, and other types of information giving authorized users the ability to access information stored on other computers on the network. A network allows sharing of network and computing resources. Users may access and use resources provided by devices on the network, such as printing a document on a shared network printer. Distributed computing uses computing resources across a network to accomplish tasks. A computer network may be used by computer crackers to deploy computer viruses or computer worms on devices connected to the network, or to prevent these devices from accessing the network via a denial of service attack.
Network packet
Computer communication links that do not support packets, such as traditional point-to-point telecommunication links, simply transmit data as a bit stream. However, most information in computer networks is carried in packets. A network packet is a formatted unit of data (a list of bits or bytes, usually a few tens of bytes to a few kilobytes long) carried by a packet-switched network.
In packet networks, the data is formatted into packets that are sent through the network to their destination. Once the packets arrive they are reassembled into their original message. With packets, the bandwidth of the transmission medium can be better shared among users than if the network were circuit switched. When one user is not sending packets, the link can be filled with packets from other users, and so the cost can be shared, with relatively little interference, provided the link isn't overused.
Packets consist of two kinds of data: control information, and user data (payload). The control information provides data the network needs to deliver the user data, for example: source and destination network addresses, error detection codes, and sequencing information. Typically, control information is found in packet headers and trailers, with payload data in between.
Often the route a packet needs to take through a network is not immediately available. In that case the packet is queued and waits until a link is free.
Network topology
The physical layout of a network is usually less important than the topology that connects network nodes. Most diagrams that describe a physical network are therefore topological, rather than geographic. The symbols on these diagrams usually denote network links and network nodes.
Network links
The transmission media (often referred to in the literature as the physical media) used to link devices to form a computer network include electrical cable ( Ethernet, HomePNA, power line communication, G.hn), optical fiber (fiber-optic communication), and radio waves (wireless networking). In the OSI model, these are defined at layers 1 and 2 — the physical layer and the data link layer.
A widely adopted family of transmission media used in local area network ( LAN) technology is collectively known as Ethernet. The media and protocol standards that enable communication between networked devices over Ethernet are defined by IEEE 802.3. Ethernet transmits data over both copper and fiber cables. Wireless LAN standards (e.g. those defined by IEEE 802.11) use radio waves, or others use infrared signals as a transmission medium. Power line communication uses a building's power cabling to transmit data.
Wired technologies
The orders of the following wired technologies are, roughly, from slowest to fastest transmission speed.
Coaxial cable is widely used for cable television systems, office buildings, and other work-sites for local area networks. The cables consist of copper or aluminum wire surrounded by an insulating layer (typically a flexible material with a high dielectric constant), which itself is surrounded by a conductive layer. The insulation helps minimize interference and distortion. Transmission speed ranges from 200 million bits per second to more than 500 million bits per second.ITU-TG.hn technology uses existing home wiring (coaxial cable, phone lines and power lines) to create a high-speed (up to 1 Gigabit/s) local area networkTwisted pair wire is the most widely used medium for all telecommunication. Twisted-pair cabling consist of copper wires that are twisted into pairs. Ordinary telephone wires consist of two insulated copper wires twisted into pairs. Computer network cabling (wired Ethernet as defined by IEEE 802.3) consists of 4 pairs of copper cabling that can be utilized for both voice and data transmission. The use of two wires twisted together helps to reduce crosstalk and electromagnetic induction. The transmission speed ranges from 2 million bits per second to 10 billion bits per second. Twisted pair cabling comes in two forms: unshielded twisted pair (UTP) and shielded twisted-pair (STP). Each form comes in several category ratings, designed for use in various scenarios.An optical fiber is a glass fiber. It carries pulses of light that represent data. Some advantages of optical fibers over metal wires are very low transmission loss and immunity from electrical interference. Optical fibers can simultaneously carry multiple wavelengths of light, which greatly increases the rate that data can be sent, and helps enable data rates of up to trillions of bits per second. Optic fibers can be used for long runs of cable carrying very high data rates, and are used for undersea cables to interconnect continents.Price is a main factor distinguishing wired- and wireless-technology options in a business. Wireless options command a price premium that can make purchasing wired computers, printers and other devices a financial benefit. Before making the decision to purchase hard-wired technology products, a review of the restrictions and limitations of the selections is necessary. Business and employee needs may override any cost considerations.[6]
Wireless technologies
Exotic technologies
There have been various attempts at transporting data over exotic media:
IP over Avian Carriers was a humorous April fool's Request for Comments, issued as RFC 1149. It was implemented in real life in 2001.[7]Extending the Internet to interplanetary dimensions via radio waves, the Interplanetary Internet.[8]Both cases have a large round-trip delay time, which gives slow two-way communication, but doesn't prevent sending large amounts of information.
Network nodes
Apart from any physical transmission medium there may be, networks comprise additional basic system building blocks, such as network interface controller (NICs), repeaters, hubs, bridges, switches, routers, modems, and firewalls.
Network interfaces
A network interface controller (NIC) is computer hardware that provides a computer with the ability to access the transmission media, and has the ability to process low-level network information. For example, the NIC may have a connector for accepting a cable, or an aerial for wireless transmission and reception, and the associated circuitry.
The NIC responds to traffic addressed to a network address for either the NIC or the computer as a whole.
In Ethernet networks, each network interface controller has a unique Media Access Control (MAC) address—usually stored in the controller's permanent memory. To avoid address conflicts between network devices, the Institute of Electrical and Electronics Engineers (IEEE) maintains and administers MAC address uniqueness. The size of an Ethernet MAC address is six octets. The three most significant octets are reserved to identify NIC manufacturers. These manufacturers, using only their assigned prefixes, uniquely assign the three least-significant octets of every Ethernet interface they produce.
Repeaters and hubs
A repeater is an electronic device that receives a network signal, cleans it of unnecessary noise and regenerates it. The signal is retransmitted at a higher power level, or to the other side of an obstruction, so that the signal can cover longer distances without degradation. In most twisted pair Ethernet configurations, repeaters are required for cable that runs longer than 100 meters. With fiber optics, repeaters can be tens or even hundreds of kilometers apart.
A repeater with multiple ports is known as a hub. Repeaters work on the physical layer of the OSI model. Repeaters require a small amount of time to regenerate the signal. This can cause a propagation delay that affects network performance. As a result, many network architectures limit the number of repeaters that can be used in a row, e.g., the Ethernet 5-4-3 rule.
Hubs have been mostly obsoleted by modern switches; but repeaters are used for long distance links, notably undersea cabling.
Bridges
A network bridge connects and filters traffic between two network segments at the data link layer (layer 2) of the OSI model to form a single network. This breaks the network's collision domain but maintains a unified broadcast domain. Network segmentation breaks down a large, congested network into an aggregation of smaller, more efficient networks.
Bridges come in three basic types:
Local bridges: Directly connect LANsRemote bridges: Can be used to create a wide area network (WAN) link between LANs. Remote bridges, where the connecting link is slower than the end networks, largely have been replaced with routers.Wireless bridges: Can be used to join LANs or connect remote devices to LANs.Switches
A network switch is a device that forwards and filters OSI layer 2datagrams ( frames) between ports based on the destination MAC address in each frame.[9] A switch is distinct from a hub in that it only forwards the frames to the physical ports involved in the communication rather than all ports connected. It can be thought of as a multi-port bridge.[10] It learns to associate physical ports to MAC addresses by examining the source addresses of received frames. If an unknown destination is targeted, the switch broadcasts to all ports but the source. Switches normally have numerous ports, facilitating a star topology for devices, and cascading additional switches.
Multi-layer switches are capable of routing based on layer 3 addressing or additional logical levels. The term switch is often used loosely to include devices such as routers and bridges, as well as devices that may distribute traffic based on load or based on application content (e.g., a Web URL identifier).
Routers
A router is an internetworking device that forwards packets between networks by processing the routing information included in the packet or datagram (Internet protocol information from layer 3). The routing information is often processed in conjunction with the routing table (or forwarding table). A router uses its routing table to determine where to forward packets. A destination in a routing table can include a "null" interface, also known as the "black hole" interface because data can go into it, however, no further processing is done for said data, i.e. the packets are dropped.
Modems
Modems (MOdulator-DEModulator) are used to connect network nodes via wire not originally designed for digital network traffic, or for wireless. To do this one or more carrier signals are modulated by the digital signal to produce an analog signal that can be tailored to give the required properties for transmission. Modems are commonly used for telephone lines, using a Digital Subscriber Line technology.
Firewalls
A firewall is a network device for controlling network security and access rules. Firewalls are typically configured to reject access requests from unrecognized sources while allowing actions from recognized ones. The vital role firewalls play in network security grows in parallel with the constant increase in cyber attacks.
Network structure
Network topology is the layout or organizational hierarchy of interconnected nodes of a computer network. Different network topologies can affect throughput, but reliability is often more critical. With many technologies, such as bus networks, a single failure can cause the network to fail entirely. In general the more interconnections there are, the more robust the network is; but the more expensive it is to install.
Common layouts
Common layouts are:
A bus network: all nodes are connected to a common medium along this medium. This was the layout used in the original Ethernet, called 10BASE5 and 10BASE2.A star network: all nodes are connected to a special central node. This is the typical layout found in a Wireless LAN, where each wireless client connects to the central Wireless access point.A ring network: each node is connected to its left and right neighbour node, such that all nodes are connected and that each node can reach each other node by traversing nodes left- or rightwards. The Fiber Distributed Data Interface (FDDI) made use of such a topology.A mesh network: each node is connected to an arbitrary number of neighbours in such a way that there is at least one traversal from any node to any other.A fully connected network: each node is connected to every other node in the network.A tree network: nodes are arranged hierarchically.Note that the physical layout of the nodes in a network may not necessarily reflect the network topology. As an example, with FDDI, the network topology is a ring (actually two counter-rotating rings), but the physical topology is often a star, because all neighboring connections can be routed via a central physical location.
Overlay network
An overlay network is a virtual computer network that is built on top of another network. Nodes in the overlay network are connected by virtual or logical links. Each link corresponds to a path, perhaps through many physical links, in the underlying network. The topology of the overlay network may (and often does) differ from that of the underlying one. For example, many peer-to-peer networks are overlay networks. They are organized as nodes of a virtual system of links that run on top of the Internet.[11]
Overlay networks have been around since the invention of networking when computer systems were connected over telephone lines using modems, before any data network existed.
The most striking example of an overlay network is the Internet itself. The Internet itself was initially built as an overlay on the telephone network.[11] Even today, each Internet node can communicate with virtually any other through an underlying mesh of sub-networks of wildly different topologies and technologies. Address resolution and routing are the means that allow mapping of a fully connected IP overlay network to its underlying network.
Another example of an overlay network is a distributed hash table, which maps keys to nodes in the network. In this case, the underlying network is an IP network, and the overlay network is a table (actually a map) indexed by keys.
Overlay networks have also been proposed as a way to improve Internet routing, such as through quality of service guarantees to achieve higher-quality streaming media. Previous proposals such as IntServ, DiffServ, and IP Multicast have not seen wide acceptance largely because they require modification of all routers in the network.[citation needed] On the other hand, an overlay network can be incrementally deployed on end-hosts running the overlay protocol software, without cooperation from Internet service providers. The overlay network has no control over how packets are routed in the underlying network between two overlay nodes, but it can control, for example, the sequence of overlay nodes that a message traverses before it reaches its destination.
For example, Akamai Technologies manages an overlay network that provides reliable, efficient content delivery (a kind of multicast). Academic research includes end system multicast,[12] resilient routing and quality of service studies, among others.
Communications protocols
A communications protocol is a set of rules for exchanging information over network links. In a protocol stack (also see the OSI model), each protocol leverages the services of the protocol below it. An important example of a protocol stack is HTTP (the World Wide Web protocol) running over TCP over IP (the Internet protocols) over IEEE 802.11 (the Wi-Fi protocol). This stack is used between the wireless router and the home user's personal computer when the user is surfing the web.
Whilst the use of protocol layering is today ubiquitous across the field of computer networking, it has been historically criticized by many researchers[13] for two principal reasons. Firstly, abstracting the protocol stack in this way may cause a higher layer to duplicate functionality of a lower layer, a prime example being error recovery on both a per-link basis and an end-to-end basis.[14] Secondly, it is common that a protocol implementation at one layer may require data, state or addressing information that is only present at another layer, thus defeating the point of separating the layers in the first place. For example, TCP uses the ECN field in the IPv4 header as an indication of congestion; IP is a network layer protocol whereas TCP is a transport layer protocol.
Communication protocols have various characteristics. They may be connection-oriented or connectionless, they may use circuit mode or packet switching, and they may use hierarchical addressing or flat addressing.
There are many communication protocols, a few of which are described below.
IEEE 802
IEEE 802 is a family of IEEE standards dealing with local area networks and metropolitan area networks. The complete IEEE 802 protocol suite provides a diverse set of networking capabilities. The protocols have a flat addressing scheme. They operate mostly at levels 1 and 2 of the OSI model.
For example, MACbridging (IEEE 802.1D) deals with the routing of Ethernet packets using a Spanning Tree Protocol. IEEE 802.1Q describes VLANs, and IEEE 802.1X defines a port-based Network Access Control protocol, which forms the basis for the authentication mechanisms used in VLANs (but it is also found in WLANs) – it is what the home user sees when the user has to enter a "wireless access key".
Ethernet
Ethernet, sometimes simply called LAN, is a family of protocols used in wired LANs, described by a set of standards together called IEEE 802.3 published by the Institute of Electrical and Electronics Engineers.
Wireless LAN
Wireless LAN, also widely known as WLAN or WiFi, is probably the most well-known member of the IEEE 802 protocol family for home users today. It is standarized by IEEE 802.11 and shares many properties with wired Ethernet.
Internet Protocol Suite
The Internet Protocol Suite, also called TCP/IP, is the foundation of all modern networking. It offers connection-less as well as connection-oriented services over an inherently unreliable network traversed by data-gram transmission at the Internet protocol (IP) level. At its core, the protocol suite defines the addressing, identification, and routing specifications for Internet Protocol Version 4 (IPv4) and for IPv6, the next generation of the protocol with a much enlarged addressing capability.
SONET/SDH
Synchronous optical networking (SONET) and Synchronous Digital Hierarchy (SDH) are standardized multiplexing protocols that transfer multiple digital bit streams over optical fiber using lasers. They were originally designed to transport circuit mode communications from a variety of different sources, primarily to support real-time, uncompressed, circuit-switched voice encoded in PCM (Pulse-Code Modulation) format. However, due to its protocol neutrality and transport-oriented features, SONET/SDH also was the obvious choice for transporting Asynchronous Transfer Mode (ATM) frames.
Asynchronous Transfer Mode
Asynchronous Transfer Mode (ATM) is a switching technique for telecommunication networks. It uses asynchronous time-division multiplexing and encodes data into small, fixed-sized cells. This differs from other protocols such as the Internet Protocol Suite or Ethernet that use variable sized packets or frames. ATM has similarity with both circuit and packet switched networking. This makes it a good choice for a network that must handle both traditional high-throughput data traffic, and real-time, low-latency content such as voice and video. ATM uses a connection-oriented model in which a virtual circuit must be established between two endpoints before the actual data exchange begins.
While the role of ATM is diminishing in favor of next-generation networks, it still plays a role in the last mile, which is the connection between an Internet service provider and the home user.[15]
Geographic scale
A network can be characterized by its physical capacity or its organizational purpose. Use of the network, including user authorization and access rights, differ accordingly.
Nanoscale networkA nanoscale communication network has key components implemented at the nanoscale including message carriers and leverages physical principles that differ from macroscale communication mechanisms. Nanoscale communication extends communication to very small sensors and actuators such as those found in biological systems and also tends to operate in environments that would be too harsh for classical communication.[16]
Personal area networkA personal area network (PAN) is a computer network used for communication among computer and different information technological devices close to one person. Some examples of devices that are used in a PAN are personal computers, printers, fax machines, telephones, PDAs, scanners, and even video game consoles. A PAN may include wired and wireless devices. The reach of a PAN typically extends to 10 meters.[17] A wired PAN is usually constructed with USB and FireWire connections while technologies such as Bluetooth and infrared communication typically form a wireless PAN.
Local area networkA local area network (LAN) is a network that connects computers and devices in a limited geographical area such as a home, school, office building, or closely positioned group of buildings. Each computer or device on the network is a node. Wired LANs are most likely based on Ethernet technology. Newer standards such as ITU-TG.hn also provide a way to create a wired LAN using existing wiring, such as coaxial cables, telephone lines, and power lines.[18]
The defining characteristics of a LAN, in contrast to a wide area network (WAN), include higher data transfer rates, limited geographic range, and lack of reliance on leased lines to provide connectivity. Current Ethernet or other IEEE 802.3 LAN technologies operate at data transfer rates up to 100 Gbit/s, standarized by IEEE in 2010.[19] Currently, 400 Gbit/s Ethernet is being developed.
A LAN can be connected to a WAN using a router.
Home area networkA home area network (HAN) is a residential LAN used for communication between digital devices typically deployed in the home, usually a small number of personal computers and accessories, such as printers and mobile computing devices. An important function is the sharing of Internet access, often a broadband service through a cable TV or digital subscriber line (DSL) provider.
Storage area networkA storage area network (SAN) is a dedicated network that provides access to consolidated, block level data storage. SANs are primarily used to make storage devices, such as disk arrays, tape libraries, and optical jukeboxes, accessible to servers so that the devices appear like locally attached devices to the operating system. A SAN typically has its own network of storage devices that are generally not accessible through the local area network by other devices. The cost and complexity of SANs dropped in the early 2000s to levels allowing wider adoption across both enterprise and small to medium-sized business environments.
Campus area networkA campus area network (CAN) is made up of an interconnection of LANs within a limited geographical area. The networking equipment (switches, routers) and transmission media (optical fiber, copper plant, Cat5 cabling, etc.) are almost entirely owned by the campus tenant / owner (an enterprise, university, government, etc.).
For example, a university campus network is likely to link a variety of campus buildings to connect academic colleges or departments, the library, and student residence halls.
Backbone networkA backbone network is part of a computer network infrastructure that provides a path for the exchange of information between different LANs or sub-networks. A backbone can tie together diverse networks within the same building, across different buildings, or over a wide area.
For example, a large company might implement a backbone network to connect departments that are located around the world. The equipment that ties together the departmental networks constitutes the network backbone. When designing a network backbone, network performance and network congestion are critical factors to take into account. Normally, the backbone network's capacity is greater than that of the individual networks connected to it.
Another example of a backbone network is the Internet backbone, which is the set of wide area networks (WANs) and core routers that tie together all networks connected to the Internet.
Metropolitan area networkA Metropolitan area network (MAN) is a large computer network that usually spans a city or a large campus.
Wide area networkA wide area network (WAN) is a computer network that covers a large geographic area such as a city, country, or spans even intercontinental distances. A WAN uses a communications channel that combines many types of media such as telephone lines, cables, and air waves. A WAN often makes use of transmission facilities provided by common carriers, such as telephone companies. WAN technologies generally function at the lower three layers of the OSI reference model: the physical layer, the data link layer, and the network layer.
Enterprise private networkAn enterprise private network is a network that a single organization builds to interconnect its office locations (e.g., production sites, head offices, remote offices, shops) so they can share computer resources.
Virtual private networkA virtual private network (VPN) is an overlay network in which some of the links between nodes are carried by open connections or virtual circuits in some larger network (e.g., the Internet) instead of by physical wires. The data link layer protocols of the virtual network are said to be tunneled through the larger network when this is the case. One common application is secure communications through the public Internet, but a VPN need not have explicit security features, such as authentication or content encryption. VPNs, for example, can be used to separate the traffic of different user communities over an underlying network with strong security features.
VPN may have best-effort performance, or may have a defined service level agreement (SLA) between the VPN customer and the VPN service provider. Generally, a VPN has a topology more complex than point-to-point.
Global area networkA global area network (GAN) is a network used for supporting mobile across an arbitrary number of wireless LANs, satellite coverage areas, etc. The key challenge in mobile communications is handing off user communications from one local coverage area to the next. In IEEE Project 802, this involves a succession of terrestrial wireless LANs.[20]
Organizational scope
Networks are typically managed by the organizations that own them. Private enterprise networks may use a combination of intranets and extranets. They may also provide network access to the Internet, which has no single owner and permits virtually unlimited global connectivity.
Intranet
An intranet is a set of networks that are under the control of a single administrative entity. The intranet uses the IP protocol and IP-based tools such as web browsers and file transfer applications. The administrative entity limits use of the intranet to its authorized users. Most commonly, an intranet is the internal LAN of an organization. A large intranet typically has at least one web server to provide users with organizational information. An intranet is also anything behind the router on a local area network.
Extranet
An extranet is a network that is also under the administrative control of a single organization, but supports a limited connection to a specific external network. For example, an organization may provide access to some aspects of its intranet to share data with its business partners or customers. These other entities are not necessarily trusted from a security standpoint. Network connection to an extranet is often, but not always, implemented via WAN technology.
Internetwork
An internetwork is the connection of multiple computer networks via a common routing technology using routers.
Internet
The Internet is the largest example of an internetwork. It is a global system of interconnected governmental, academic, corporate, public, and private computer networks. It is based on the networking technologies of the Internet Protocol Suite. It is the successor of the Advanced Research Projects Agency Network (ARPANET) developed by DARPA of the United States Department of Defense. The Internet is also the communications backbone underlying the World Wide Web (WWW).
Participants in the Internet use a diverse array of methods of several hundred documented, and often standardized, protocols compatible with the Internet Protocol Suite and an addressing system (IP addresses) administered by the Internet Assigned Numbers Authority and address registries. Service providers and large enterprises exchange information about the reachability of their address spaces through the Border Gateway Protocol (BGP), forming a redundant worldwide mesh of transmission paths.
Darknet
A darknet is an overlay network, typically running on the internet, that is only accessible through specialized software. A darknet is an anonymizing network where connections are made only between trusted peers — sometimes called "friends" ( F2F)[21] — using non-standard protocols and ports.
Darknets are distinct from other distributed peer-to-peer networks as sharing is anonymous (that is, IP addresses are not publicly shared), and therefore users can communicate with little fear of governmental or corporate interference.[22]
Routing
Routing is the process of selecting network paths to carry network traffic. Routing is performed for many kinds of networks, including circuit switching networks and packet switched networks.
In packet switched networks, routing directs packet forwarding (the transit of logically addressed network packets from their source toward their ultimate destination) through intermediate nodes. Intermediate nodes are typically network hardware devices such as routers, bridges, gateways, firewalls, or switches. General-purpose computers can also forward packets and perform routing, though they are not specialized hardware and may suffer from limited performance. The routing process usually directs forwarding on the basis of routing tables
