Beyond-CMOS
State of the Art and Trends
Coordinated by
Alessandro Cresti
First published 2023 in Great Britain and the United States by ISTE Ltd and John Wiley & Sons, Inc.
Apart from any fair dealing for the purposes of research or private study, or criticism or review, as permitted under the Copyright, Designs and Patents Act 1988, this publication may only be reproduced, stored or transmitted, in any form or by any means, with the prior permission in writing of the publishers, or in the case of reprographic reproduction in accordance with the terms and licenses issued by the CLA. Enquiries concerning reproduction outside these terms should be sent to the publishers at the undermentioned address:
ISTE Ltd27-37 St George’s RoadLondon SW19 4EUUKwww.iste.co.uk
John Wiley & Sons, Inc.111 River StreetHoboken, NJ 07030USAwww.wiley.com
© ISTE Ltd 2023
The rights of Alessandro Cresti to be identified as the author of this work have been asserted by him in accordance with the Copyright, Designs and Patents Act 1988.
Any opinions, findings, and conclusions or recommendations expressed in this material are those of the author(s), contributor(s) or editor(s) and do not necessarily reflect the views of ISTE Group.
Library of Congress Control Number: 2022947446
British Library Cataloguing-in-Publication Data
A CIP record for this book is available from the British Library
ISBN 978-1-78945-127-6
ERC code:
PE7 Systems and Communication Engineering
PE7_5 (Micro- and nano-) electronic, optoelectronic and photonic components
PE3 Condensed Matter Physics
PE3_4 Electronic properties of materials, surfaces, interfaces, nanostructures, etc.
PE3_5 Physical properties of semiconductors and insulators
Preface
Alessandro CRESTI
CNRS, Grenoble INP, IMEP-LAHC, Université Grenoble Alpes, Université Savoie Mont Blanc, Grenoble, France
Going Beyond CMOS means going beyond Moore’s law (Moore 1965), which is basically an economic law from previous years (Englebart 1960) and described in more detail by Dennard et al. (1974) in terms of scaling of size and power at each new generation of transistors. Industry has followed this paradigm for many decades, beyond physical limits such as heating and short-channel effects. In this context, this research has enabled the development of this line using the so-called More Moore approach, which was recently described in the International Technology Roadmap for Semiconductors (ITRS, see: http://www.itrs2.net), which lasted until 2016.
These limits, on the contrary, have allowed the development of alternative research guides known as More-than-Moore (Arden et al. 2010) and Beyond CMOS (Nikonov and Young 2013). The first is a shift of the paradigm to different devices, which goes beyond transistors, and includes, for example, the development of sensors and energy harvesters. Beyond CMOS, on the contrary, is still mainly focused on logic devices, but includes different types of transistors complementary to metal–oxide–semiconductors. It consists of new technologies (such as tunnel FETs, spintronics, memristors or optical devices) and materials (such as III–V or 2D materials) that can be used as an alternative to silicon. Such an interesting development has also generated new scientific and economic advancements. Since 2016, the International Roadmap for Devices and Systems (IRDS, see: https://irds.ieee.org) has focused on these new technologies. Moreover, many important books (Balestra 2014a, 2014b; Brozek 2014; Chen et al. 2015; King Liu and Kuhn 2015; Topaloglu and Wong 2019; Dragoman and Dragoman 2021) have been published on the subject, whose contents are of primary interest.
This book focuses on some specific arguments detailed by leading and pioneering researchers in this field. All of the chapters contain a short introduction accessible to not-too-specialized readers and a discussion about the recent progresses and trends.
The first four chapters are devoted to steep-slope devices and low-power applications, which are one of the most important domains of Beyond CMOS electronics. The other chapters present more unconventional emerging technologies.
More specifically, Chapter 1, written by Marco Pala (CN2, Paris, France), presents the possible use of III–V semiconductors in tunnel field-effect transistors for steep-slope applications, in particular regarding their limits and advantages by numerical simulations of these devices.
Chapter 2, written by Mathieu Luisier (ETH, Zurich, Switzerland) and co-workers, illustrates the possible use of 2D materials for field-effect transistors, not restricted to transition metal dichalcogenides. 2D materials have the advantage of being extremely thin (few atomic layers), thus allowing a good electrostatic control and flexible applications.
In Chapter 3, Kaustav Banerjee (UC Santa Barbara, USA) illustrate the working mechanism and the implementation of steep-slope devices based on the negative capacitance properties of the gate obtained using ferroelectric materials. The author has a particularly critical view on the subject, which will be helpful to present the practical applications of this technology to the reader.
In Chapter 4, Joris Lacord (CEA-Leti, Grenoble, France) presents the exotic zero subthreshold swing and zero impact ionization field-effect transistor (Z2-FET) based on the silicon-on-insulator technology. This kind of steep-slope device is particularly promising, among other things, for applications in memories.
In Chapter 5, the field of 2D spintronics is deeply analyzed by Matthieu Jamet (Spintec, Grenoble, France), Diogo C. Vaz (CIC nanoGUNE BRTA, Donostia-San Sebastian, Spain), Juan F. Sierra, Josef Světlík and Sergio O. Valenzuela (ICN2, CSIC and BIST, Barcelona, Spain), Bruno Dlubak and Pierre Seneor (Thales, Palaiseau, France), Frédéric Bonell (Spintec, Grenoble, France), Thomas Guillet (ICN2, CSIC and BIST, Barcelona, Spain) and their collaborators, especially from the experimental point of view. In this chapter, the term “2D” refers to both 2D materials, 2D electron gases and 3D topological insulators, with applications ranging from memories to spin transport logic.
A more exotic subject is presented in Chapter 6, written by Steven A. Vitale (MIT, Lexington, Massachusetts, U.S.A.), which illustrates the possible use of the valley degree of freedom and valley excitons in electronics. This innovative technology, based on the fact that an electron can occupy different valleys in the band structure, is still premature, but has important perspectives for logic operations and beyond, up to quantum computing.
Electronics can also be implemented through molecular systems. Chapter 7, written by Dominique Vuillaume (IEMN, Lille, France), is devoted to this emerging technology, which is very promising for the ultimate miniaturization of electronics. The strength of such a technology is incredibly large and varies from the implementation of standard logic devices to plasmonics and thermal transport.
Another innovative field is superconducting quantum electronics, presented in Chapter 8, written by Pascal Febvre (IMEP-LaHC, Le Bourget du Lac, France) and Sasan Razmkhah (TOBB university of Economy and Technology, Ankara, Turkey). Several very promising applications of superconductivity in the field of beyond CMOS electronics, including the realization of logic devices, neuromorphic computing and superconducting qubits, are presented.
Finally, a completely alternative technology, which consists of using light instead of electrons for the logic operations, is described in Chapter 9, written by Wolfram Pernice (Universität Münster, Germany) and co-workers. Being able to integrate these operations in a single chip is a major advance towards applications, including massively parallel computing and efficient neural networks.
The aim of this book is to provide the reader with a fresh overview of the major research advances in this field, especially in Beyond CMOS logic devices, and a detailed physical insight into new trends that are inspirational for future devices.
