In-situ Characterization of Heterogeneous Catalysts E-Book

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Sprache: Englisch

Seitenzahl: 890

Veröffentlichungsjahr: 2013

Beschreibung

HELPS RESEARCHERS DEVELOP NEW CATALYSTS FOR SUSTAINABLE FUEL AND CHEMICAL PRODUCTION Reviewing the latest developments in the field, this book explores the in-situ characterization of heterogeneous catalysts, enabling readers to take full advantage of the sophisticated techniques used to study heterogeneous catalysts and reaction mechanisms. In using these techniques, readers can learn to improve the selectivity and the performance of catalysts and how to prepare catalysts as efficiently as possible, with minimum waste. In-situ Characterization of Heterogeneous Catalysts features contributions from leading experts in the field of catalysis. It begins with an introduction to the fundamentals and then covers: * Characterization of electronic and structural properties of catalysts using X-ray absorption fine structure spectroscopy * Techniques for structural characterization based on X-ray diffraction, neutron scattering, and pair distribution function analysis * Microscopy and morphological studies * Techniques for studying the interaction of adsorbates with catalyst surfaces, including infrared spectroscopy, Raman spectroscopy, EPR, and moderate pressure XPS * Integration of techniques that provide information on the structural properties of catalysts with techniques that facilitate the study of surface reactions Throughout the book, detailed examples illustrate how techniques for studying catalysts and reaction mechanisms can be applied to solve a broad range of problems in heterogeneous catalysis. Detailed figures help readers better understand how and why the techniques discussed in the book work. At the end of each chapter, an extensive set of references leads to the primary literature in the field. By explaining step by step modern techniques for the in-situ characterization of heterogeneous catalysts, this book enables chemical scientists and engineers to better understand catalyst behavior and design new catalysts for green, sustainable fuel and chemical production.

Leseprobe

Table of Contents

Title page

Copyright page

Contributors

Introduction: Goals and Challenges for the In-situ Characterization of Heterogeneous Catalysts

Catalysis and the Need to Characterize Active Sites in Different Types of Materials and Chemical Environments

Catalyst Composition and Active Phase Identification

Structural Features and Spatial Array of the Active Phase in the Catalyst

The Surface Morphology of the Catalyst Active Phase

Electronic Properties and Chemical State of the Active Phase in the Catalyst

Properties of Adsorbates, Surface Chemistry, and Reaction Mechanism

Acknowledgment

References

1: QEXAFS in Catalysis Research: Principles, Data Analysis, and Applications

1.1 Introduction

1.2 Implementation

1.3 Data Analysis Methods

1.4 Examples of QEXAFS in Catalysis Research

1.5 Summary and Outlook

Acknowledgments

References

2: Spatially Resolved X-ray Absorption Spectroscopy

2.1 Introduction

2.2 X-ray Absorption Spectroscopy

2.3 Full-Field Microscopy and Tomography

2.4 Scanning Microscopy and Tomography

2.5 Outlook

References

3: Energy-Dispersive EXAFS: Principles and Application in Heterogeneous Catalysis

3.1 Introduction

3.2 The Dispersive Concept and Its Ramifications for the Study of Heterogeneous Materials

3.3 Examples of Applications of Dispersive EXAFS to Problems in Catalysis

3.4 Future Perspectives and Possibilities

3.5 Conclusions

Acknowledgments

References

4: In-situ Powder X-ray Diffraction in Heterogeneous Catalysis

4.1 Introduction

4.2 Crystal Structure and Powder Diffraction

4.3 Tools for In-situ Measurements

4.4 Applications of XRD to the In-situ Characterization of Catalysts

4.5 Simple Reduction and Activation of Oxides

4.6 Sintering of Nanocatalysts

4.7 In-situ Determination of Active Phase in Metal/Oxide Catalyst

4.8 Conclusions

Acknowledgment

References

5: Pair Distribution Function Analysis of High-Energy X-ray Scattering Data

5.1 Introduction

5.2 Structural Insights from the PDF Data

5.3 Measuring a PDF

5.4 In-situ Studies

5.5 Applications of In-situ PDF Methods to Problems in Catalysis

5.6 Outlook

Acknowledgment

References

6: Neutron Scattering for In-situ Characterization of Heterogeneous Catalysis

6.1 Introduction

6.2 Neutron Sources

6.3 Sample Environment

6.4 Neutron Scattering Techniques for Catalysis

6.5 Examples of Extracting Structural Characteristics from Small-Angle Scattering of Catalysts

6.6 Conclusion

Acknowledgments

References

7: Visualization of Surface Structures of Heterogeneous Catalysts under Reaction Conditions or during Catalysis with High-Pressure Scanning Tunneling Microscopy

7.1 Surface Structures of Heterogeneous Catalysts in Ultrahigh Vacuum

7.2 Surface Structures of Heterogeneous Catalysts under Reaction Conditions

7.3 Techniques for Studies of Surface Structure of Catalysts under Reaction Conditions or during Catalysis

7.4 Surface Restructuring in the Surface Layer of a Catalyst

7.5 Pressure-Dependent Surface Coverage of Adsorbates and Structural Evolution from Low to High Pressure

7.6 Temperature-Driven Surface Restructuring at a Relatively High Pressure of Reactants and the Challenge in Obtaining Atomically Resolved Images at High Temperature and High Pressure

7.7 Summary

Acknowledgment

References

8: In-situ Infrared Spectroscopy on Model Catalysts

8.1 Introduction

8.2 IRRAS Applications on Crystalline Planar Samples under UHV Conditions

8.3 In-situ IRRAS Studies on Model Systems at Elevated Pressures

8.4 PM-IRRAS

8.5 Conclusions

References

9: Infrared Spectroscopy on Powder Catalysts

9.1 Introduction

9.2 Experimental Approaches

9.3 Molecular Probe Acid/Base Properties of Molecular Sieves

9.4 Water–Gas Shift Reaction

9.5 Carbon Monoxide Oxidation

9.6 Methanol-to-Hydrocarbon Conversion

9.7 NOx Storage and Reduction

9.8 Hydrodesulfurization Catalysts

9.9 Selective Oxidation of Alcohols and Hydrocarbons

9.10 Probing the Solid–Liquid Interface with ATR Spectroscopy

9.11 Ultra-fast Time-Resolved Studies

9.12 IR Microspectroscopy

9.13 Concluding Remarks

References

10: Structural Characterization of Catalysts by Operando Raman Spectroscopy

10.1 Introduction

10.2 Equipment for Operando Raman Spectroscopy

10.3 Effect of Water on Catalyst Reconstruction

10.4 Peroxide Species

10.5 Catalysis by Oxides

10.6 Space-Resolved Operando Raman

10.7 Conclusions

Acknowledgments

References

11: In-situ Electron Paramagnetic Resonance of Powder Catalysts

11.1 Introduction

11.2 Basic Principle and Instrumentation of EPR

11.3 Selected Application Examples

11.4 Conclusions and Outlook

References

12: Application of Ambient-Pressure X-ray Photoelectron Spectroscopy for the In-situ Investigation of Heterogeneous Catalytic Reactions

12.1 Introduction

12.2 Historical Perspective and Technical Advances

12.3 Using AP-XPS to Study Molecular Adsorption on Single Crystal Substrates

12.4 Using AP-XPS to Study Adsorption onto Well-Defined Nanoparticles

12.5 Using AP-XPS to Study Metal-Catalyzed Nanotube Growth

12.6 AP-XPS Applied to Electrochemistry

12.7 AP-XPS Investigations of Operating Technical Catalysts

12.8 Conclusion

Acknowledgments

References

13: Combined X-ray Diffraction and Absorption Spectroscopy in Catalysis Research: Techniques and Applications

13.1 Introduction

13.2 Instrumentation

13.3 Examples

13.4 Summary and Outlook

Acknowledgments

References

14: Combining Infrared Spectroscopy with X-ray Techniques for Interrogating Heterogeneous Catalysts

14.1 Introduction

14.2 Braiding Infrared Spectroscopies with X-ray Techniques: An Overview

14.3 Currently Demonstrated Couples of IR and X-ray Methods and Their Utilization

14.4 Coupling Transmission IR to Small-Angle X-ray Scattering (SAXS)

14.5 Coupling Transmission IR and Transmission EXAFS

14.6 Possibilities for Future Developments

14.7 Conclusions

Acknowledgments

References

15: XRD–Raman and Modulation Excitation Spectroscopy

15.1 Introduction

15.2 Instrumentation

15.3 XRD–Raman Applications

15.4 Modulation Excitation Spectroscopy

References

16: Catalyst Imaging Using Synchrotron-Based Multitechnique Approaches

16.1 Introduction

16.2 Imaging Catalytic Solids with Synchrotron Radiation

16.3 Current and Future Developments in the Field and the Possibilities for Catalyst Imaging

Acknowledgments

References

Index

Copyright © 2013 by John Wiley & Sons, Inc. All rights reserved

Published by John Wiley & Sons, Inc., Hoboken, New Jersey

Published simultaneously in Canada

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, scanning, or otherwise, except as permitted under Section 107 or 108 of the 1976 United States Copyright Act, without either the prior written permission of the Publisher, or authorization through payment of the appropriate per-copy fee to the Copyright Clearance Center, Inc., 222 Rosewood Drive, Danvers, MA 01923, [phone], fax [phone], or on the web at www.copyright.com. Requests to the Publisher for permission should be addressed to the Permissions Department, John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, [phone], fax [phone], or online at http://www.wiley.com/go/permissions.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives or written sales materials. The advice and strategies contained herein may not be suitable for your situation. You should consult with a professional where appropriate. Neither the publisher nor author shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

For general information on our other products and services or for technical support, please contact our Customer Care Department within the United States at [phone], outside the United States at [phone] or fax [phone].

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic formats. For more information about Wiley products, visit our web site at www.wiley.com.

Library of Congress Cataloging-in-Publication Data:

In-situ characterization of heterogeneous catalysts / edited by José A. Rodriguez, Brookhaven National Laboratory, Upton, New York, USA, Jonathan C. Hanson, Brookhaven National Laboratory, Upton, New York, USA, Peter J. Chupas, Argonne National Laboratory, Lemont, Illinois, USA.

pages cm

Includes bibliographical references and index.

ISBN 978-1-118-00016-8 (hardback)

1. Heterogeneous catalysis. I. Rodriguez, José A., editor of compilation. II. Hanson, Jonathan C., editor of compilation. III. Chupas, Peter J., editor of compilation.

QD505.I49 2013

541'.395–dc23

2012045180

Contributors

Miguel A. Bañares, Catalytic Spectroscopy Laboratory, CSIC—Instituto de Catalisis y Petroleoquímica, Madrid, Spain

Andrew M. Beale, Department of Inorganic Chemistry and Catalysis, Debye Institute for NanoMaterials Science, Utrecht University, Utrecht, The Netherlands

Hendrik Bluhm, Chemical Sciences Division, Lawrence Berkeley National Laboratory, Berkeley, CA

Angelika Brückner, Leibniz-Institut für Katalyse e. V. an der Universität Rostock, Rostock, Germany

Karena W. Chapman, X-ray Science Division, Advanced Photon Source Argonne National Laboratory, Argonne, IL

Wei-Ren Chen, Chemical and Engineering Materials Division, Spallation Neutron Source, Oak Ridge, TN

Fang Cheng, Department of Chemistry and Biochemistry, University of Notre Dame, Notre Dame, IN

Peter J. Chupas, X-ray Science Division, Advanced Photon Source, Argonne National Laboratory, Argonne, IL

Andrew J. Dent, SERC Daresbury Laboratory, Warrington, UK

Marcos Fernández-García, CSIC—Instituto de Catalisis y Petroleoquímica, Madrid, Spain

Anatoly I. Frenkel, Physics Department, Yeshiva University, New York, NY

Jan-Dierk Grunwaldt, Karlsruher Institut für Technologie (KIT), Institute of Technical Chemistry and Polymer, Chemistry (ITCP), Campus South and Institute of Catalysis Research and Technology (IKFT), Campus North, Karlsruhe, Germany

Jonathan C. Hanson, Chemistry Department, Brookhaven National Laboratory, Upton, NY

Michael Hävecker, Division Solar Energy Research, Elektronenspeicherring BESSY II, Berlin, Germany

Ashfia Huq, Chemical and Engineering Materials Division, Spallation Neutron Source, Oak Ridge, TN

Syed Khalid, National Synchrotron Light Source, Brookhaven National Laboratory, Upton, NY

Axel Knop-Gericke, Department of Inorganic Chemistry, Fritz-Haber-Institut der Max-Planck-Gesellschaft, Berlin, Germany

Zhi Liu, Advanced Light Source, Lawrence Berkeley National Laboratory, Berkeley, CA

Gerhard Mestl, SÜD-CHEMIE AG, Bruckmühl, Germany

Marco Milanesio, Dipartimento di Scienze e Tecnologie Avanzate and Nano-SiSTeMI Interdisciplinary Centre, Università del Piemonte Orientale “A. Avogadro,” Alessandria, Italy

Kumudu Mudiyanselage, Chemistry Department, Brookhaven National Laboratory, Upton, NY

Maarten Nachtegaal, Paul Scherrer Institute, Viiligen, Switzerland

Mark A. Newton, European Synchrotron Radiation Facility, Grenoble, France

Luan Nguyen, Department of Chemistry and Biochemistry, University of Notre Dame, Notre Dame, IN

Poul Norby, Technical University of Denmark, Department of Energy Conversion and Storage, Roskilde, Denmark

José A. Rodriguez, Chemistry Department, Brookhaven National Laboratory, Upton, NY

Javier Ruiz-Martinez, Department of Inorganic Chemistry and Catalysis, Debye Institute for NanoMaterials Science, Utrecht University, Utrecht, The Netherlands

Christian G. Schroer, Technische Universität Dresden, Institute for Structural Physics, Dresden, Germany

Darío J. Stacchiola, Chemistry Department, Brookhaven National Laboratory, Upton, NY

David E. Starr, Center for Functional Nanomaterials, Brookhaven National Laboratory, Upton, NY

Eli Stavitski, National Synchrotron Light Source, Brookhaven National Laboratory, Upton, NY

Franklin (Feng) Tao, Department of Chemistry and Biochemistry, University of Notre Dame, Notre Dame, IN

Atsushi Urakawa, Institute of Chemical Research of Catalonia, Tarragona, Spain

Wouter van Beek, Swiss-Norwegian Beamlines at ESRF, Grenoble Cedex, France

Lei Wang, Department of Chemistry and Biochemistry, University of Notre Dame, Notre Dame, IN

Bert M. Weckhuysen, Department of Inorganic Chemistry and Catalysis, Debye Institute for NanoMaterials Science, Utrecht University, Utrecht, The Netherlands

Yingchun Ye, Department of Chemistry and Biochemistry, University of Notre Dame, Notre Dame, IN

Shiran Zhang, Department of Chemistry and Biochemistry, University of Notre Dame, Notre Dame, IN

Yuan Zhu, Department of Chemistry and Biochemistry, University of Notre Dame, Notre Dame, IN

Introduction: Goals and Challenges for the In-situ Characterization of Heterogeneous Catalysts

José A. Rodriguez, Jonathan C. Hanson, and Peter J. Chupas

Catalysis and the Need to Characterize Active Sites in Different Types of Materials and Chemical Environments

Catalysis is central to the production of fuels and chemicals, including more than 70% of today’s chemical products. About 20% of the value of all commercial products manufactured in the United States is derived from processes involving catalysis [1–3]. Thus, the understanding and optimization of heterogeneous catalysts is a critical need within the chemical industry [2, 3]. The most important considerations when designing a new catalyst or when optimizing the performance of an existing one are activity, selectivity, and durability [3]. The catalyst must be able to perform a reaction of interest at an acceptable rate under a practical set of temperatures and pressures. There is a commercial incentive to tune catalysts to operate at low temperatures and pressures [2, 3]. It is concurrently important that the rate of side reactions be minimal, and the catalyst must be able to sustain the desired reaction over long periods of time [3]. When designing or optimizing a catalyst, one must know the nature of its active sites and how they interact with the reactants, intermediates, and products of a catalytic process. The structural and electronic properties of the active sites are usually affected by the chemical environment in which they operate. This book describes experimental techniques that have been developed to characterize catalysts and study reaction mechanisms in situ under academic and technical or industrial conditions.

Heterogeneous catalysts can be metals, oxides, carbides, sulfides, nitrides, practically any type of material [1–3]. In the nineteenth century it was already known that all the regions or atoms in the surface of a heterogeneous catalyst are not involved in the real catalytic process. The concept of the “active site” in catalysis has been used since its introduction in the 1920s by Taylor and Langmuir [4, 5]. However, despite considerable scientific effort over many years, our knowledge of what exactly the active sites are and how they really work is in most cases very primitive [6]. First, it is necessary to identify the active site and fully characterize its electronic and structural properties under reaction conditions. Since industrial catalysts and catalytic processes are extremely complex [2, 3], the development of techniques for the characterization of catalytic systems in situ as they evolve in time with a changing chemical environment is a very challenging task. Figure I.1 shows four different types of systems which are frequently used in catalytic studies. Figure I.1A displays an image of high-resolution transmission electron microscopy (HR-TEM) for a high surface area Pt-Ru/CeO2 catalyst [7]. One sees particles of a Pt–Ru alloy (1.5–3 nm in size) on top of a ceria support that mainly exhibits the (111) face of the oxide. In the case of Figure I.1B, the HR-TEM image corresponds to a Pt/CeOx/TiO2 catalyst [8]. The loading of Pt is very low (0.5 wt%) and the small particles of the metal (0.4–0.5 nm) are difficult to detect with HR-TEM. The TiO2 support nanoparticles are monocrystalline and present an average size of 10–15 nm. The bright spots as indicated by the arrows represent CeO2 nanoparticles with an average diameter of about 4–5 nm. In the Pt/CeOx/TiO2 catalyst, the very low content of Pt points to the need for characterization techniques with a high sensitivity. Many catalytic processes are carried out on the type of metal/oxide powder catalyst shown in Figure I.1A,B, with the surface exhibiting a high degree of structural heterogeneity [1–3]. In contrast, when studying correlations between surface “structure” and reactivity, it may be advantageous to do experiments on well-defined single-crystal surfaces such as those displayed in Figure I.1C,D [9, 10]. Furthermore, the system in Figure I.1A has the typical metal/oxide configuration seen in many industrial catalysts [1–3]. However, to enhance the participation of ceria in catalytic reactions, one may adopt an inverse configuration in which nanoparticles of this oxide are deposited on top of the surface of a metal or another oxide [11]. Thus, the inverse CeO2/CuO and CeO2/CuOx/Cu(111) catalysts shown in Figure I.2 exhibit a very high activity for the low-temperature oxidation of CO and the CO preferential oxidation (PROX) reactions [12, 13]. In practical terms, one needs to develop techniques for the in-situ characterization of all the systems shown in Figure I.1 and Figure I.2, and even much more complex materials in which there are multiple phases coexisting in a three-dimensional space [14]. When focusing on spatial resolution, characteristic length scales relevant for catalytic materials range from a few millimeters (usual sample size) to nanometers (typical size of catalytic nanoparticles). If one is interested in the geometrical structure of molecules adsorbed on the surface of the catalyst as reactants or intermediates, then the significant length scale is in the order of angstroms or picometers.

Figure I.1. Different types of systems investigated in studies in the area of catalysis. (A) Image of HR-TEM for a Pt–Ru/CeO2 catalyst. Reprinted with permission from Reference 7. Copyright (2012) Elsevier. (B) Image of HR-TEM for a Pt/CeOx/TiO2 catalyst. Reprinted with permission from Reference 8. Copyright (2012) American Chemical Society. (C) Top view of a Sn–Pt(111) model catalyst. (D) Side view of a TiO2(110) surface.

Figure I.2. Inverse ceria/copper oxide catalysts. (A) Image of HR-TEM for a CeO2/CuO powder catalyst. Reprinted with permission from Reference 12. Copyright (2010) American Chemical Society. (B) Image of STM for a CeO2/CuOx/Cu(111) model catalyst. Reprinted with permission from Reference 13. Copyright (2011) American Chemical Society.

Time is a very important parameter when studying a catalytic process. A phenomenological rate law gives the disappearance of reactants or appearance of products as a function of time for a particular set of reaction conditions (pressure, temperature, and chemical concentrations) [6]. At a microscopic level, molecules are transformed and the chemical environment around the active sites of a catalyst changes as a function of time [6, 10]. In order to obtain a full understanding of the key transformations associated with a catalytic process, one must be able to track the time evolution of the structural and electronic properties of the active site. The activation and breaking of a chemical bond inside a molecule occurs in the picosecond regime but the completion of a full reaction cycle on the surface of a catalyst usually takes longer times. Based on turnover rates for typical reactions (10−2–103 molecules/site•second) [9, 10], one can estimate that the timescale for a catalytic transformation on the surface of a catalyst is usually in the range of minutes to milliseconds under typical reaction conditions. Ideally, one must be able to track transformations of the catalytic material in this time range. Very valuable information about catalytic processes can be obtained under steady-state conditions (i.e., no variations in temperature, pressure, and reaction rate), but to obtain a detailed understanding of reaction mechanism one frequently has to do experiments in a non-steady-state or transient mode in which the properties of the catalytic system are perturbed by changing the temperature (see Fig. I.3), or by pulses (fluctuations) in the pressures of the reactants [5, 6, 15]. In principle, the perturbations in the reaction conditions can affect the structural properties of the catalyst (Fig. I.3 and Fig. I.4) and the lifetime of surface intermediates that are produced during the reaction.

Figure I.3. Three-dimensional plot of in-situ XRD patterns collected during the reduction/activation of a powder CuO/ZnO catalyst in a mixture of 0.25% CO, 0.25% CO2, and 4% H2 in argon. The XRD patterns were collected at temperatures between 375 and 493 K. A CuO → Cu structural transformation was seen around 400 K. Reprinted with permission from Reference 5. Copyright (1991) Elsevier.

Figure I.4. Variation of the lattice constant of ceria after exposing a powder Au–CeO2 catalyst to CO, the reaction mixture for the water–gas shift reaction (CO/H2O), CO, and O2. The reported values were obtained after analyzing results of time-resolved XRD by Rietveld refinement. Reprinted with permission from Reference 15. Copyright (2006) American Chemical Society.

On the basis of the considerations discussed in the previous paragraphs, one finds that the ideal tool for a detailed study of typical catalytic processes should have high sensitivity and allow us the fast acquisition of data in a milliseconds timescale with a spatial resolution in the range of nanometers or smaller, monitoring simultaneously the properties of the catalyst active sites and the adsorbed reaction intermediates. This is a highly demanding set of requirements. At the present time, no single technique can accomplish all of these tasks. For a complete characterization of a catalytic process, one must combine different techniques. Many of the existing techniques focus only on examining the properties of the catalyst, while others are better suited for studying the surface chemistry associated with the reaction process. In practical terms, it is necessary to find a reasonable balance between temporal and spatial resolutions. Techniques which can provide morphological information at the nanometer or subnanometer range do not have the time resolution required for most transient or kinetic studies. Most characterization techniques give average properties for relative large areas (from micrometers to millimeters) of the catalyst sample, making emphasis on obtaining high sensitivity for dealing with low concentrations of elements and for allowing the fast data acquisition necessary for transient experiments.

Nowadays surface science offers a quite impressive array of experimental techniques to investigate the properties of surfaces [6, 10]. Many of these techniques are based on some type of excitation (photons, electrons, neutrons, ions, electromagnetic field, heat, etc.) to which the catalyst responds. A similar type of excitation can be associated with different types of phenomena yielding information about different properties. For example, X-ray diffraction (XRD), X-ray absorption spectroscopy (XAS), and X-ray photoelectron spectroscopy (XPS) all use photons for probing the sample and are among the most frequently employed techniques for catalyst characterization [5, 6]. XRD occurs in the elastic scattering of X-ray photons by atoms in a periodic lattice and can be used to obtain structural information. In contrast, irradiating a catalyst with X-ray photons can induce excitation of electrons from occupied core levels to empty valence levels (XAS) or generate photoelectrons (XPS), yielding information about the composition of the sample and the electronic properties of the elements present.

Many surface science techniques operate under vacuum or high-vacuum conditions [6, 10] and cannot be applied in the characterization of catalysts under normal reaction conditions. In order to overcome this problem, several laboratories have developed experimental systems which combine a high-pressure system with an ultra-high-vacuum (UHV) analysis chamber [9, 10, 16]. The high-pressure reactor allows the kinetics of catalytic reactions to be measured on a given surface (see Fig. I.5), while analysis of the structure and composition of the surface both before and after reaction can be accomplished in the UHV chamber. This approach has provided valuable insights into many catalytic processes [9, 10, 16], but it is now clear that the combination of prenatal and postmortem analysis can miss important changes that occur to the surface of a catalyst under reaction conditions [17–19]. Since surfaces are flexible entities which can reconstruct after interacting with adsorbed molecules (see Fig. I.6 and References [17–19]), one must perform an in-situ characterization of the catalyst. In recent years, notable advances in design and instrumentation have added moderate-pressure XPS (Fig. I.7) and high-pressure scanning tunneling microscopy (HP-STM) [17, 20, 21] to the arsenal of techniques that is available for the in-situ characterization of catalysts. Furthermore, there has been an extraordinary effort to develop or improve characterization techniques which take advantage of synchrotrons or neutron facilities. It is in these facilities where major advances have been made in the development of techniques which allow us the structural characterization of crystalline or amorphous materials [22–26], dealing with diluted samples [26, 27], the fast acquisition of data [27–29], and catalyst imaging [24, 26, 30]. There has also been substantial progress in the integration of techniques for the simultaneous study of the catalyst properties and reaction mechanism [25, 30–34].

Figure I.5. Arrhenius plots for the 2CO + O2 → 2CO2 reaction on Cu(111) and on a surface in which ceria nanoparticles covered ∼18% of the copper substrate. PCO = 20 Torr, PO2 = 10 Torr. Reprinted with permission from Reference 13. Copyright (2011) American Chemical Society.

Figure I.6. Images of in-situ low-energy electron microscopy obtained before and during the exposure of a CeOx/CuOx/Cu(111) model catalyst to CO [19]. In the final step, the system consisted of ceria nanoparticles dispersed on a reconstructed Cu(111) surface. Reprinted with permission from Reference 19. Copyright (2012) American Chemical Society.

Figure I.7. Carbon and oxygen 1s XPS spectra of (A) pure Cu and (B) Zn/Cu (0.1 mL Zn) in the presence of 0.1 Torr of CO2 and 0.1 Torr of H2O at room temperature. Two carbonaceous species, formate and methoxy, are shown to form on both surfaces. Activated CO2 and carbonate species present in pure CO2 remain visible on each surface. In addition, molecularly adsorbed H2O is also observed in both spectra. The presence of Zn makes carbonate the majority species on the surface. Reprinted with permission from Reference 20. Copyright (2009) Elsevier.

This book is divided in 16 chapters which cover recent advances in an array of techniques which can be used to study in-situ catalytic processes taking place on high-surface area powders or on well-defined model catalysts. Using these techniques, one can perform fundamental studies of the physical and chemical properties of a catalyst obtaining information about composition, structural features, surface morphology, electronic states, and chemical reactivity. Figure I.8 shows a typical approach followed nowadays in the study of catalytic processes. First, one must identify and characterize the active phase of the catalyst. This is usually followed by studies of surface chemistry aimed at obtaining the details of the reaction mechanism. Theoretical studies can provide a conceptual frame for understanding the properties of the catalyst or the steps in the reaction mechanism [35, 36]. The integral approach shown in Figure I.8 eventually can yield a fundamental understanding of the behavior of active sites which can be used for the rational design of better catalysts. This approach usually takes advantage of the in-situ techniques described in this book.

Figure I.8. Different areas of research during the study of catalytic processes. A fundamental understanding is obtained by combining in-situ characterization of the active phase in the catalyst with experimental and theoretical studies of the surface chemistry associated with the catalytic process. NS, neutron scattering; TEM, transmission electron microscopy; EPR, electron paramagnetic resonance; UV-Vis, ultraviolet–visible spectroscopy; IR, infrared; DFT, density functional theory; MD; molecular dynamics; MC, Monte Carlo.

Catalyst Composition and Active Phase Identification

The fist step in any catalytic study is to identify the composition and active phase of the catalyst under reaction conditions. XAS is perhaps the technique most frequently used for this task. The first three chapters in the book show different versions of XAS, making emphasis in time and spatial resolution. XAS is one of the most powerful techniques available to follow the composition of catalysts as a function of time in kinetic or transient studies [27–29]. It also can be used to study spatial gradients of composition in chemical reactors [24, 26, 30].

XPS is among the most used techniques to measure the composition and chemical state of catalysts ex situ under high-vacuum conditions [6]. Chapter 12 describes recent developments in instrumentation [17, 20, 21] which now make possible the use of XPS to determine the composition of catalysts under moderate pressure conditions. XRD is also one of the most frequently applied techniques in catalyst characterization [37]. If the sample has long-range order, then time-resolved XRD is an extremely powerful tool to identify the active phase of a catalyst (see Fig. I.3 [5] and Fig. I.9 [38]) and to follow its behavior as a function of time with changing temperature or pressure (Chapter 4). Depending on the nature of the sample, neutron scattering (Chapter 6), infrared spectroscopy (Chapter 8 and Chapter 9), Raman spectroscopy (Chapter 10, Chapter 15, and Chapter 16), and electron paramagnetic resonance spectroscopy (Chapter 11) also can provide information about the nature of the active phase in a catalyst, although some of these techniques are better suited for studying adsorption and surface reactions.

Figure I.9. Temperature-programmed reduction of CuO. (Temperature increase rate = 350°C/h or 5.8°C/min; 5% CO/95% He; gas flow rate ∼15–20 mL/min). (A) Time-resolved X-ray diffraction (TR-XRD) patterns. (B) Intensities for the Cu(111) diffraction line in XRD and the CO2 signal (mass-to-charge ratio, m/z) 44 in quadrupole mass spectrometry (QMS) at the exit of the reactor. Reprinted with permission from Reference 38. Copyright (2004) American Chemical Society.

Structural Features and Spatial Array of the Active Phase in the Catalyst

The actual structure of the active phase of a catalyst can range all the way from crystalline to amorphous [1–3]. Furthermore, a part of the catalyst can be crystalline and another amorphous. This is a frequent situation seen in metal/oxide catalysts where the oxide support is mainly crystalline and small metal particles are amorphous (Fig. I.1B). In a common terminology used in the area of crystallography [37], the structure of a catalyst can have local, medium-, or long-range order. This book describes four techniques that can be used to obtain detailed information about the structure of catalysts: extended X-ray absorption fine structure (EXAFS; Chapter 1, Chapter 2, and Chapter 3), X-ray powder diffraction (Chapter 4), pair distribution function (PDF) analysis (Chapter 5), and neutron diffraction (Chapter 6). These techniques respond to different ranges of crystallinity or order in the sample.

X-ray powder diffraction and neutron diffraction require long-range crystalline order. XRD is one of the oldest and most frequently applied techniques for the structural characterization of catalysts [6, 37]. It is frequently used to identify crystalline phases inside catalysts, by means of diffraction lines and the corresponding lattice structural parameters, and to obtain an indication of particle size [6, 37]. Furthermore, time-resolved XRD (Chapter 4) provides a convenient way to study lattice variations in the catalyst structure as a function of temperature and pressure of the reactants (Fig. I.4). A large penetration depth and a high sensitivity to lighter elements, especially mobile species such as hydrogen and oxygen, make neutron diffraction an excellent tool to probe heterogeneous catalysts in operational conditions (Chapter 6). Traditionally the use of neutron diffraction in the field of catalysis has been quite limited. However, recent advances in data acquisition and processing together with the availability of higher flux neutron instruments at various facilities now make the study of the structure and dynamics of heterogeneous catalysts using neutrons a realistic goal (Chapter 6).

Traditionally, EXAFS has been the technique of choice for obtaining structural information for samples with a low degree of order (Chapter 1, Chapter 2, and Chapter 3), but in recent years PDF analysis has emerged as a complimentary technique (Chapter 5). The structural insights within the PDF extend from the local coordination environment, usually measured by EXAFS, up to several nanometers approaching the length scale of particles relevant to most catalytic processes. Since the early 2000s, advances in experimental approach, instrumentation, and detector technologies have increased access to PDF data, providing improved data quality in substantially reduced measurement times (Chapter 5). Nowadays, EXAFS and PDF structural studies can be performed to follow the behavior of catalysts in a wide range of pressures and temperatures (see Fig. I.10) [39]. To measure at the same time the structural parameters of crystalline and amorphous regions of a catalyst sample, one can combine XRD with PDF (Chapter 5) or XRD and EXAFS (Chapter 13). The power of combining XRD and EXAFS is illustrated by a recent study of the reduction of a water–gas shift CuFe2O4 catalyst in CO [32]. For CuFe2O4 under reducing conditions, the combined use of the two techniques allowed the acquisition of accurate data for the kinetics of nucleation and growth of metallic Cu (Fig. I.11), the active phase in the catalytic process.

Figure I.10. Time-resolved PDF analysis of an inverse CeO2/CuO catalyst under water–gas shift reaction conditions [39]. The CuO initially present in the catalyst is reduced to metallic Cu, whereas the ceria transforms into CeO2-x. Reprinted with permission from Reference 39. Copyright (2010) American Chemical Society.

Figure I.11. Comparison of the Cu0 fractions determined by X-ray diffraction (XRD) and X-ray absorption fine structure (XAFS) for the reduction of a water–gas shift CuFe2O4 catalysts in CO. Reprinted with permission from Reference 32. Copyright (2011) American Chemical Society.

The Surface Morphology of the Catalyst Active Phase

On the basis of studies using well-defined single-crystal surfaces, it is possible to classify catalytic processes into structure-sensitive and structure-insensitive reactions [9, 10]. If the reaction needs a specific array of sites to turn over, the number of sites may be varied by exposing different crystallographic orientations [6, 9, 10]. In catalysis, a main goal is to induce changes in surface morphology to enhance catalytic activity [10, 18, 36]. This is a very difficult task due to a general lack of knowledge of the behavior of catalytic surfaces under reaction conditions.

Environmental transmission electron microscopy (E-TEM) and HP-STM are two important techniques for studying the surface morphology of powder and model catalysts under reacting gases. Transmission electron microscopy is one the techniques most often used for the ex-situ characterization of catalysts [6, 40]. Using this technique the determination of particle size distribution and dispersion is a routine matter. The detection of supported particles is possible if there is sufficient contrast between particles and support (Fig. I.1A). The major limitation of conventional transmission electron microscopy is that it is not an in-situ technique [6, 40]. Recent technical developments have made it possible to study the behavior of catalysts under low pressures of a gas [25, 41–43], as shown in Figure I.12. Using aberration-corrected E-TEM, it has been shown that the morphology of an oxide substrate or supported metal particles can depend dramatically on the gaseous environment [25, 42, 43]. Since the 1980s, scanning tunneling microscopy (STM) has been a dominant tool for imaging the surface of single-crystal surfaces (Chapter 7). Studies with STM are usually performed under UHV conditions [10] but, in principle, this technique can be applied in a pressure range from UHV to atmospheric or high pressures since the tunneling process between the sample and tip only occurs in a very close range of 3–5 Å. In recent years, remarkable progress has been made in the instrumentation for HP-STM [17, 44]. HP-STM has the unique capability of examining the structure of adsorbates and surface sites of a catalyst atom by atom to address several crucial issues of heterogeneous catalysis such as the restructuring of the catalyst surface, the ensemble on surfaces of alloy catalysts, binding site, and even configuration of adsorbates under reaction conditions (Chapter 7).

Figure I.12. Instantaneous view of a gold nanoparticle on TiO2 under reaction conditions (in 1 vol% CO in air [0.75 Torr] at room temperature). The structural model was derived using results of E-TEM. A gold nanoparticle, bounded by {111} and {100} facets, has a polygonal interface with the TiO2 support. The edges of the polygonal, or perimeter interface, are parallel to the <110> directions. Reprinted with permission from Reference 43. Copyright (2012) John Wiley & Sons.

Electronic Properties and Chemical State of the Active Phase in the Catalyst

The reactivity of an atom in a molecule, nanoparticle, or solid is strongly linked to its electronic properties [36, 45]. The identification of the active phase of a catalyst usually involves a determination of the chemical state and electronic properties of the elements present in the system. Over the years several techniques have been developed to probe the core and valence states of solids [6, 46, 47]. XAS (Chapter 1, Chapter 2, and Chapter 3), XPS (Chapter 12), ultraviolet–visible–near infrared spectroscopy (Chapter 16), and electron paramagnetic resonance spectroscopy (Chapter 11) are used widely for probing the electronic properties of atoms in solid catalysts. When acquiring data of XAS and XPS, the high intensity that a synchrotron source provides together with highly efficient detection devices leads to a high-energy resolution that improves our ability to separate different chemical states of an element in a catalyst (see Fig. I.13) [48]. The high intensity of the synchrotron radiation also makes it possible to track fast changes in the electronic properties during transient experiments (Chapter 1, Chapter 3, and Chapter 16) and sample mapping showing spatial gradients of concentration as a function of chemical state (Chapter 2 and Chapter 16). It is known that variations in the geometrical structure of a material usually produce changes in its electronic properties that modify the way in which the material responds to the presence of adsorbates [36]. The integration of instrumentation for XRD and XAS in the same experimental setup (Chapter 13) allows the direct study of possible correlations among the structural, electronic, and catalytic properties of a material.

Figure I.13. Evolution of the Cu K-edge XANES of CuO/ZnO at 523 K during oxygen addition to a methanol steam reforming feed (c(MeOH) ∼6 vol%, c(H2O) ∼1.5 vol% in 25 mL/min He). Different Cu phases are indicated. Reprinted with permission from Reference 48. Copyright (2001) Elsevier.

Properties of Adsorbates, Surface Chemistry, and Reaction Mechanism

In the scheme of Figure I.8, the determination of the active phase of the catalyst is followed by experimental and theoretical studies on the surface chemistry and reaction mechanism associated with the catalytic process. The beauty of knowing a reaction mechanism is that it gives us a rational way to improve catalytic activity and selectivity [49]. Figure I.14 shows the calculated energy profile for a possible mechanism of the water–gas shift reaction (CO + H2O → H2 + CO2) on a Cu29 nanoparticle [50]. The Cu29 particle was present in Cu/CeO2(111) catalysts [51] and the calculations were performed using density functional theory [50]. The interaction of the reactants with Cu29 produces significant perturbations in the geometrical structure of the nanocatalyst. Chemical bonds are broken (O–H) and new ones are formed (O–C; H–H). The theoretical study predicts reaction intermediates (OH, H, HOCO) that must be validated by experimental measurements. Ideally, one should be able to monitor simultaneously the changes that occur in the structure of the metal particle and the chemical species that are being transformed on the catalyst surface. Proof of a mechanism for a catalyzed reaction lies in directly observing the chemical species involved in the elementary steps and the kinetics for their transformations [49].

Figure I.14. Calculated energy profile and structures for the water–gas shift reaction (CO + H2O → H2 + CO2) on a Cu29 nanoparticle [50]. The label “TS” is used to denote a transition state. Reprinted with permission from Reference 50. Copyright (2007) American Institute of Physics.

Techniques such as XAS (Chapter 1, Chapter 2, Chapter 3, and Chapter 16), neutron scattering (Chapter 6), infrared spectroscopy (Chapter 8, Chapter 9, and Chapter 16), Raman spectroscopy (Chapter 10 and Chapter 16), electron paramagnetic resonance spectroscopy (Chapter 11), and ambient-pressure XPS (Chapter 12) can be used to study the adsorption and transformation of chemical species on the surface of a catalyst under reaction conditions. Infrared spectroscopy is perhaps the most commonly used technique in catalysis to identify adsorbed species and to study the way in which these species are chemisorbed in the surface of the catalyst [6]. It is a frequently used technique in mechanistic studies [7, 15, 52–55], having one the longest histories among the methods for in-situ characterization [6]. When combined with probe molecules (CO, NO, etc.), infrared spectroscopy can yield valuable information about the adsorption sites in the catalyst [7, 52, 56–58]. Raman spectroscopy has also become popular for in-situ studies because it also can give information about the active sites and adsorbed species [52, 59]. Since the selection rules for vibrational transitions in infrared and Raman spectroscopies are different [60], the information obtained from a Raman spectrum often complements that obtained from an infrared study and thus provides valuable structural information (Chapter 10, Chapter 15, and Chapter 16). Inelastic neutron spectroscopy has been used in catalysis research principally due to its high sensitivity to the vibrations of hydrogen atoms (Chapter 6). Hydrogen due to its large incoherent scattering cross section is far more visible by interacting with neutrons than other elements [61], whereas Raman and infrared spectroscopies are more sensitive to the motion of heavier atoms.

Over the years, XPS has proven to be a very useful technique for studying the transformation of molecules on surfaces [10, 46]. The kinetic energy of the photoemitted electron is not only element specific but also contains chemical information because the energy levels of core electrons depend on the chemical state of the atom [46]. With the development of ambient-pressure XPS, it is now possible to study intermediates in common catalytic (Fig. I.7) and electrocatalytic processes (Chapter 12). In many cases, intermediates that are difficult to identify with infrared spectroscopy can be easily identified using XPS and vice versa. Electron paramagnetic resonance spectroscopy is not frequently used in mechanistic studies because it requires paramagnetic species containing unpaired electrons to be present in the system under study [60]. However, when this condition is satisfied, the technique can provide rich information on the local environment of paramagnetic species and how this local environment changes as a reaction progresses (Chapter 11).

The techniques mentioned in the previous two paragraphs, in addition to probe adsorbed species on the surface of a catalyst, can also yield simultaneous information about some properties of the catalytic material during reaction. The last three chapters in the book (Chapter 14, Chapter 15, and Chapter 16) aim at the integration of techniques that provide information on the structural properties of the catalysts, XRD, and X-ray absorption fine structure, with techniques that allow the study of surface reactions: infrared and Raman spectroscopy. A typical example of this type of studies is presented in Figure I.15 [62]. Such integration, a very challenging task, is a significant step forward toward the grand goal of being able to obtain a full picture of all the components in a catalytic process [24, 31, 34, 54, 62].

Figure I.15. Multitechnique approach to illuminate CO dissociation and transient carbon storage by Pd/Al2O3 during CO/NO cycling. Each of the X-ray techniques may be used in simultaneous time-resolved conjunction with DRIFTS and mass spectrometry (MS). The data from each technique pertain to the structure reactivity behavior of a 2 wt% Pd/Al2O3 catalyst during a single switch from 5% CO/He to 5% NO/He at 673 K. Reprinted with permission from Reference 62. Copyright (2010) American Chemical Society.

Acknowledgment

The authors are grateful for the financial support of the U.S. Department of Energy, Office of Basic Energy Sciences.

References

[1] Heinemann, H. (1997) Development of industrial catalysis, in Ertl G., Knözinger H., Weitkamp J. (eds.), Handbook of Heterogeneous Catalysis, Wiley-VCH, Weinheim, Germany.

[2] Bartholomew, C. H., Farrauto, R. J. (2005) Fundamentals of Industrial Catalytic Processes, 2nd ed., Wiley-Aiche, New York.

[3] Hagen, J. (2006) Industrial Catalysis: A Practical Approach, Wiley-VCH, Weinheim, Germany.

[4] Boudart, M. (1997) Principles of heterogeneous catalysis, in Ertl G., Knözinger H., Weitkamp J. (eds.), Handbook of Heterogeneous Catalysis, Wiley-VCH, Weinheim, Germany.

[5] Clausen, B. S., et al. (1991) In situ cell for combined XRD and on-line catalysis tests: studies of Cu-based water gas shift and methanol catalysts, J. Catal., 132, 524–535.

[6] Chorkendorff, I., Niemantsverdriet, J. W. (2007) Concepts of Modern Catalysis and Kinetics, 2nd ed., Wiley-VCH, Weinheim, Germany.

[7] Xu, W., et al. (2012) In-situ studies of CeO2-supported Pt, Ru and Pt-Ru alloy catalysts for the water-gas shift reaction: active phases and reaction intermediates, J. Catal., 291, 117–126.

[8] Kundu, et al. (2012) Exploring the structural and electronic properties of Pt/ceria- modified TiO2 and its photo-catalytic activity for water splitting under visible light, J. Phys. Chem. C, 116, 14062–14070.

[9] Rodriguez, J. A., Goodman, D. W. (1991) High-pressure catalytic reactions over single-crystal metal surfaces, Surf. Sci. Rep., 14, 1–108.

[10] Somorjai, G. A., Li, Y. (2010) Introduction to Surface Chemistry and Catalysis, 2nd ed., John Wiley & Sons, New York.

[11] Rodriguez, J. A., Hrbek, J. (2010) Inverse oxide/metal catalysts: a versatile approach for activity tests and mechanistic studies, Surf. Sci., 604, 241–244.

[12] Hornés, A., et al. (2010) Inverse CeO2/CuO catalyst as an alternative to classical direct configurations for preferential oxidation of CO in hydrogen-rich stream, J. Am. Chem. Soc., 132, 34–35.

[13] Yang, F., et al. (2011) CO oxidation on inverse CeOx/Cu(111) catalysts: high catalytic activity and ceria-promoted dissociation of O2, J. Am. Chem. Soc., 133, 3444–3451.

[14] Schlögl, R. (1997) Bulk catalysts and supports, in Ertl G., Knözinger H., Weitkamp J. (eds.), Handbook of Heterogeneous Catalysis, Wiley-VCH, Weinheim, Germany.

[15] Wang, X., et al. (2006) In-situ studies of the active sites for the water gas shift reaction over Cu-CeO2 catalysts: complex interaction between metallic copper and oxygen vacancies of ceria, J. Phys. Chem. B, 110, 428–434.

[16] Campbell, C. T. (1989) Studies of model catalysts with well-defined surfaces combining ultrahigh vacuum surface characterization with medium- and high-pressure kinetics, Adv. Catal., 36, 1–54.

[17] Tao, F., Salmeron, M. (2011) In-situ studies of chemistry and structure of materials in reactive environments, Science, 331, 171–174.

[18] Somorjai, G. A. (1991) The flexible surface—correlation between reactivity and restructuring ability, Langmuir, 7, 3176–3182.

[19] Senanayake, S. D., et al. (2012) Nanopattering in CeOx/Cu(111): a new type of surface reconstruction and enhancement of catalytic activity, J. Phys. Chem. Lett., 3, 839–843.

[20] Ogletree, D. F., et al. (2009) Photoelectron spectroscopy under ambient and temperature conditions, Nucl. Instrum. Methods Phys. Res. A, 601, 151–160.

[21] Salmeron, M., Schlögl, R. (2008) Ambient pressure photoelectron spectroscopy: a new tool for surface science and nanotechnology, Surf. Sci. Rep., 63, 169–199.

[22] Chupas, P. J., et al. (2003) Rapid-acquisition pair distribution function (RA-PDF) analysis, J. Appl. Crystallogr., 36, 1342–1347.

[23] Chupas, P. J., et al. (2007) Applications of an amorphous silicon-based area detector for high-resolution, high-sensitivity and fast time-resolved pair distribution function measurements, J. Appl. Crystallogr., 40, 463–470.

[24] Schroer, C. G., et al. (2003) Mapping the chemical states of an element inside a sample using tomographic X-ray absorption spectroscopy, Appl. Phys. Lett., 82, 3360–3362.

[25] Ciston, J., et al. (2011) Morphological and structural changes during the reduction and reoxidation of CuO/CeO2 and Ce1-xCuxO2 nanocatalysts: in-situ studies with enviromnental TEM, XRD and XAS, J. Phys. Chem. C, 115, 13851–13859.

[26] Schroer, C. G., et al. (2010) Hard X-ray microscopy with elemental, chemical, and structural contrast, Acta Phys. Pol. A, 117, 357–368.

[27] Newton, M. A., et al. (2002) Bringing time resolution to EXAFS: recent developments and application to chemical systems, Chem. Soc. Rev., 31, 83–95.

[28] Ferri, D., et al. (2010) First steps in combining concentration modulation techniques with synchronous dispersive EXAFS/DRIFTS/mass spectrometry for in situ time resolved study of heterogeneous catalysts, Phys. Chem. Chem. Phys., 12, 5634–5646.

[29] Ressler, T. (2009) Solid state kinetics and catalytic behaviour of selective oxidation catalysts from time-resolved EXAFS investigations, Catal. Today, 145, 258–266.

[30] Kox, M. H. F., et al. (2009) Label-free chemical imaging of catalytic solids by coherent anti-Stokes Raman scattering and synchrotron-based infrared microscopy, Angew. Chem. Intl. Ed., 48, 8990–8993.

[31] Beale, A. M., et al. (2005) Adding a third dimension to operand spectroscopy: a combined UV-Vis, Raman, and XAFS setup to study heterogeneous catalysts under working conditions, Chem. Commun. (Camb.), 3015–3016.

[32] Frenkel, A., et al. (2011) Combining X-ray absorption and X-ray diffraction techniques for in situ studies of chemical transformations in heterogeneous catalysis: advantages and limitations, J. Phys. Chem. C, 115, 17884–17890.

[33] Boccaleri, E., et al. (2007) In situ simultaneous Raman/high-resolution X-ray powder diffraction study of transformations occurring in materials at non-ambient conditions, J. Appl. Crystallogr., 40, 684–693.

[34] Newton, M. A., van Beek, W. (2010) Combining synchrotron-based X-ray techniques with vibrational spectroscopies for the in situ study of heterogeneous catalysts: a view from a bridge, Chem. Soc. Rev., 39, 4845–4863.

[35] van Santen, R. A., Neurock, M. (2006) Molecular Heterogeneous Catalysis: A Conceptual and Computational Approach, Wiley-VCH, Weinheim, Germany.

[36] Nørskov, J. K., et al. (2008) The nature of the active site in heterogeneous metal catalysis, Chem. Soc. Rev., 37, 2163–2171.

[37] Bergeret, G. (1997) Structure and morphology. X-ray powder diffraction, in Ertl G., Knözinger H., Weitkamp J. (eds.), Handbook of Heterogeneous Catalysis, Wiley-VCH, Weinheim, Germany.

[38] Wang, X., et al. (2004) Time-resolved studies for the mechanism of reduction of copper oxides with carbon monoxide: complex behavior of lattice oxygen and the formation of suboxides, J. Phys. Chem. B, 108, 13667–13673.

[39] Barrio, L., et al. (2010) Unraveling the active site in copper-ceria systems for the water-gas shift reaction: in-situ characterization of an inverse powder CeO2-x/CuO-Cu catalyst, J. Phys. Chem. C, 114, 3580–3587.

[40] Datye, A. K. (1997) Electron microscopy and diffraction, in Ertl G., Knözinger H., Weitkamp J. (eds.), Handbook of Heterogeneous Catalysis, Wiley-VCH, Weinheim, Germany.

[41] Hansen, P. L., et al. (2002) Atom-resolved imaging of dynamic shape changes in supported copper nanocrystals, Science, 295, 2053–2055.

[42] Yoshida, H., et al. (2012) Visualizing gas molecules interacting with supported nanoparticulate catalysts at reaction conditions, Science, 335, 317–319.

[43] Kuwauchi, Y., et al. (2012) Intrinsic catalytic structure of gold nanoparticles supported on TiO2, Angew. Chem. Intl. Ed., 51, 7729–7733.

[44] Rasmussen, P. B., et al. (1998) The reactor STM: a scanning tunneling microscope for investigation of catalytic surfaces at semi-industrial reaction conditions, Rev. Sci. Instrum., 69, 3879–3884.

[45] Sholl, D., Steckel, J. A. (2009) Density Functional Theory: A Practical Introduction, Wiley-Interscience, New York.

[46] Woodruff, D. P., Delchar, T. A. (1994) Modern Techniques of Surface Science, 2nd ed., Cambridge University Press, Cambridge, UK.

[47] Che, M., Bozon-Verduraz, F. (1997) UV-Vis-NIR and EPR spectroscopies, in Ertl G., Knözinger H., Weitkamp J. (eds.), Handbook of Heterogeneous Catalysis, Wiley-VCH, Weinheim, Germany.

[48] Günter, M. M., et al. (2001) Redox behavior of copper oxide/zinc oxide catalysts in the steam reforming of methanol studied by in situ X-ray diffraction and absorption spectroscopy, J. Catal., 203, 133–149.

[49] Campbell, C. T. (1994) Micro- and macro-kinetics: their relationship in heterogeneous catalysis, Top. Catal., 1, 353–366.

[50] Liu, P., Rodriguez, J. A. (2007) Water-gas shift reaction on Metal nanoparticles and surfaces, J. Chem. Phys., 126, 164705.

[51] Rodriguez, J. A., et al. (2007) Water-gas shift reaction on Cu and Au nanoparticles supported on CeO2(111) and ZnO(000ī): intrinsic activity and importance of support interactions, Angew. Chem. Intl. Ed., 46, 1329–1332.

[52] Stavitski, E., Weckhuysen, B. M. (2010) Infrared and Raman imaging of heterogeneous catalysts, Chem. Soc. Rev., 39, 4615–4625.

[53] Chuang, S. C., Guzman, F. (2009) Mechanistic investigation of heterogeneous catalysis by transient infrared methods, Top. Catal., 52, 1448–1458.

[54] Frenkel, A., et al. (2012) Synchrotron techniques for in situ catalytic studies: capabilities, challenges and opportunities, ACS Catal., 2, 2269–2280.

[55] Burch, R., et al. (2011) A critical analysis of the experimental evidence for and against a formate mechanism for high activity water-gas shift catalysts, Appl. Catal. A: Gen., 409–410, 3–12.

[56] Rodriguez, J. A., et al. (1992) Infrared vibrational studies of CO adsorption on Cu/Pt(111) and CuPt(111) surfaces, J. Chem. Phys., 96, 7814–7825.

[57] Xu, M., et al. (2010) Monitoring electronic structure changes of TiO2(110) via sign reversal of adsorbate vibrational bands, Phys. Chem. Chem. Phys., 12, 3649–3652.

[58] Baron, M., et al. (2009) Resolving the atomic structure of vanadia monolayer catalysts: monomers, trimers, and oligomers on ceria, Angew. Chem. Intl. Ed., 48, 8006–8009.

[59] Bañares, M. A., Mestl, G. (2009) Structural characterization of operating catalysts by Raman spectroscopy, Adv. Catal., 52, 43–128.

[60] Drago, R. S. (1992) Physical Methods for Chemist, 2nd ed., Saunders, New York.

[61] Mitchell, P. C. H., et al. (2005) Vibrational Spectroscopy with Neutrons, with Applications in Chemistry, Biology, Materials Science and Catalysis, World Scientific Press, New York.

[62] Newton, M. A., et al. (2010) Combining time-resolved hard X-ray diffraction and diffuse reflectance infrared spectroscopy to illuminate CO dissociation and transient carbon storage by supported Pd nanoparticles during CO/NO cycling, J. Am. Chem. Soc., 132, 4540–4541.

1

QEXAFS in Catalysis Research: Principles, Data Analysis, and Applications

Anatoly I. Frenkel, Syed Khalid, Jonathan C. Hanson, and Maarten Nachtegaal

1.1 Introduction

Mechanisms of catalytic reactions are often very complex and elusive, due, in part, to the multiple length and timescales that characterize chemical transformations [1]. Characteristic length scales relevant for catalysis range from several millimeters (typical sample sizes) to micrometers (the size of the support) to nanometers (the typical size of catalytic nanoparticles) to picometers (the root mean square bond length disorder). The timescales range from minutes (e.g., reduction–oxidation [redox] reactions) to milliseconds (typical turnover rates) to pico- and femtoseconds (photoexcitation processes). Furthermore, the only possibility to have a glimpse at the activity of a catalyst is to follow the chemical reaction in real time, as opposed to prenatal and postmortem investigations [2]. In that sense, catalytic investigations in chemical and energy sciences are akin to biological catalysis studies that have similar challenges due to the large range of typical length and timescales, and similar solutions, for example, the use of in-situ spectroscopic and scattering methods. Mechanistic investigations of enzymatic catalysis have a unique advantage over nanoparticle catalysis due to the well-defined positions, and a small number, of active sites (metal ions) in the enzymes as opposed to a much larger number of active surface sites in the nanoparticles. Therefore, the modeling of many enzymatic processes, including the mapping of their energy landscapes, characterizing transition states, and studying reaction kinetics, can be successfully handled by first-principle calculations [3].

Among the indirect methods capable of resolving structural environment and electronic properties of active sites in catalytic materials, synchrotron-based X-ray absorption spectroscopy (XAS) has become one of the methods of choice, due to its excellent spatial, temporal, and energy resolutions [4]. The extended X-ray absorption fine structure (EXAFS) region refers to the oscillations observed in the X-ray absorption coefficient measured within 1000–1500 eV of the X-ray absorption edge energy, that is, the excitation energy of the core-level electron. In the EXAFS region, information about the local structural environment of the X-ray absorbing atom is extracted from the fine structure oscillations of the absorption coefficient. This fine structure signal is adequately described by the photoelectron scatterings from the neighboring atoms. The EXAFS measurement is, therefore, capable of probing atomic structure within the distance range of approximately 6–8 Å from the resonant (X-ray absorbing) atom [5]. Being a local structural probe, XAS does not require a long-range order. In addition, it is element specific (every element has its own core-level excitation energies) and can be used to study elements at low concentrations (such as promoters or noble metals) and low metal loading. The X-ray absorption near-edge structure (XANES) portion of the XAS signal is assigned to the energies between the first symmetry-allowed unoccupied state and the continuum states, that is, approximately, from 30 eV below to 40 eV past the absorption edge (e.g., Fig. 1.2a). XANES contains information about the electronic structure, density of unoccupied states, and bonding geometry around the absorbing atom.

XAS experiments have extremely short (10−16–10−15 s) characteristic time (which is the duration of the interference between the outgoing and the incoming photoelectron waves, limited by the core hole lifetime and other losses) and thus can be used to probe catalytic processes in the course of the reaction. Due to the relatively large penetration depth of hard X-rays, this technique can also be applied in situ, under reaction conditions (e.g., controlled gas atmosphere or pressure, or sample temperature) [6–8].

Crystallographic techniques are superior in quantitative and direct determination of the sample structure in comparison with XAS. However, the applications of these techniques are limited to ordered phases. These techniques would therefore be useless when reaction intermediates are dilute, strongly disordered, or dispersed [9]. However, these are the most common conditions that occur in chemical or enzymatic catalysis. XAS applications are particularly powerful in these rapidly emerging areas of science, since they are capable to determine the transient states, and their evolution, in the process of catalytic reaction.

Timescales in homo- and heterogeneous catalysis range from milliseconds (nucleation and growth, sintering, particle morphology changes) to seconds (reaction turnover times) to minutes (reduction and oxidation reactions) to hours to days (catalyst degradation and aging). Time-resolved X-ray absorption spectroscopy (TR-XAS) is particularly useful in these studies since it contains relevant information about real-time catalyst structure in the course of reaction. The in-situ TR-XAS technique is among the most commonly used structural methods to date for probing intermediate states during real-time transformations in a large variety of systems of interest in structural biology [9, 10] and materials science [11–15]. In structural biology studies, TR-XAS is often carried out by the freeze–quench method [16], which enables access to similar reaction rates (from milliseconds to seconds) but better data quality compared to the capabilities of the alternative, energy-scanning, or dispersive XAS modes. In the case of inorganic catalysts used in the industry and in model studies, the main effort in the TR-XAS methodology has been the push for fast data collection methods due to the need for in-situ or operando investigations [1].

To study the structural changes in the reactions that take place in the subsecond regime, TR-XAS was developed in energy-dispersive EXAFS (EDE) and energy-scanning, or quick EXAFS (QEXAFS) modes. In EDE, described in greater detail in Chapter 3 of this book, the sample is illuminated by the polychromatic beam and thus one can take repeated snapshots of the entire EXAFS spectrum at a timescale limited by the detector readout time and the photon flux, a few milliseconds [17–22]. EDE can be efficiently used in transmission mode only, and is thus limited to samples that have a relatively large concentration of absorbing atoms (in the percentage range) and are uniform in thickness. Detector normalization problems, temporal changes in beam flux, and spatial beam stability can decrease data quality. QEXAFS was developed by Frahm and coworkers [23] and applied to solving structures of materials over the past couple of decades by many groups [1, 23–31]. The newest version of eccentric cam-driven monochromators allow for much larger spectral ranges than previously used piezo-driven ones [32] and can collect EXAFS data with a time resolution as fast as a few tens of milliseconds per spectrum [33]. Ultrafast spectroscopic methods (in the femto- and picosecond ranges) by means of pump–probe schemes have also been recently developed [34–36], but are not yet applied to in-situ studies of catalytic systems and thus fall outside the scope of this chapter.

In Section 1.2, we will give an overview of the existing implementations of the QEXAFS technology. Section 1.3 will highlight the most commonly used methods in processing and analyzing TR-XAS data. In Section 1.4, we will survey the different applications of QEXAFS to the problems of heterogeneous catalysis that will demonstrate the advantage of in-situ and operando investigations by combined techniques versus static (e.g., only prenatal and postmortem) measurements. Finally, Section 1.5 will present the summary and future directions.

1.2 Implementation

In its simplest form, conventional QEXAFS or, alternatively, “on-the-fly XAS,” can be performed on all XAS beamlines when moving the double-crystal monochromator or a channel-cut monochromator (semi-)continuously through the energy range (Bragg angle) of interest, while the encoder readout of the Bragg angle and the detectors are sampled simultaneously. This mode of QEXAFS has been introduced by Frahm [23] at Hasylab in Germany and is now implemented at many beamlines, for example, at the DUBBLE beamline of the European Synchrotron Radiation Facility (ESRF) [37] in France, at BL18 [38] at Diamond in the United Kingdom, or at BL01 at the SPring-8 [39] in Japan, to name a few. With conventional QEXAFS, one typically obtains a time resolution in the range of a few seconds for the XANES region and up to a few minutes for the EXAFS region. In this chapter we will discuss only the implementation and technical details of dedicated QEXAFS systems that reach a subsecond resolution for a full EXAFS scan.
