Numerical Methods for Strong Nonlinearities in Mechanics E-Book
142,99 €
Mehr erfahren.
- Herausgeber: John Wiley & Sons
- Kategorie: Wissenschaft und neue Technologien
- Serie: ISTE Consignment
- Sprache: Englisch
Numerical Methods for Strong Nonlinearities in Mechanics deals with recent advances in the numerical treatment of contact/friction and damage phenomena. Although physically distinct, these phenomena both lead to a strong nonlinearity in the mechanical problem, therefore limiting the regularity of the problem, which is now non-differentiable.
This has two direct consequences: on the one hand, the mathematical characteristics of the problem deviate from wellestablished forms, requiring innovative discretization schemes; on the other hand, the low regularity makes it particularly difficult to solve the corresponding large-scale algebraic systems robustly and efficiently. In addition, neither the uniqueness, nor the existence of solutions, remain assured, resulting in bifurcation points, limit loads and structural instabilities, which are always tricky to overcome numerically.
