This completely updated and revised second edition of Surface Analysis: The Principal Techniques, deals with the characterisation and understanding of the outer layers of substrates, how they react, look and function which are all of interest to surface scientists. Within this comprehensive text, experts in each analysis area introduce the theory and practice of the principal techniques that have shown themselves to be effective in both basic research and in applied surface analysis.

Examples of analysis are provided to facilitate the understanding of this topic and to show readers how they can overcome problems within this area of study.

Leseprobe

Contents

List of Contributors

Preface

1 INTRODUCTION

1.1 HOW DO WE DEFINE THE SURFACE?

1.2 HOW MANY ATOMS IN A SURFACE?

1.3 INFORMATION REQUIRED

1.4 SURFACE SENSITIVITY

1.5 RADIATION EFFECTS – SURFACE DAMAGE

1.6 COMPLEXITY OF THE DATA

2 AUGER ELECTRON SPECTROSCOPY

2.1 INTRODUCTION

2.2 PRINCIPLE OF THE AUGER PROCESS

2.3 INSTRUMENTATION

2.4 QUANTITATIVE ANALYSIS

2.5 DEPTH PROFILE ANALYSIS

2.6 SUMMARY

REFERENCES

PROBLEMS

3 ELECTRON SPECTROSCOPY FOR CHEMICAL ANALYSIS

3.1 OVERVIEW

3.2 X-RAY INTERACTION WITH MATTER, THE PHOTOELECTRON EFFECT AND PHOTOEMISSION FROM SOLIDS

3.3 BINDING ENERGY AND THE CHEMICAL SHIFT

3.4 INELASTIC MEAN FREE PATH AND SAMPLING DEPTH

3.5 QUANTIFICATION

3.6 SPECTRAL FEATURES

3.7 INSTRUMENTATION

3.8 SPECTRAL QUALITY

3.9 DEPTH PROFILING

3.10 X–Y MAPPING AND IMAGING

3.11 CHEMICAL DERIVATIZATION

3.12 VALENCE BAND

3.13 PERSPECTIVES

3.14 CONCLUSIONS

ACKNOWLEDGEMENTS

REFERENCES

PROBLEMS

4 MOLECULAR SURFACE MASS SPECTROMETRY BY SIMS

4.1 INTRODUCTION

4.2 BASIC CONCEPTS

4.3 EXPERIMENTAL REQUIREMENTS

4.4 SECONDARY ION FORMATION

4.5 MODES OF ANALYSIS

4.6 IONIZATION OF THE SPUTTERED NEUTRALS

4.7 AMBIENT METHODS OF DESORPTION MASS SPECTROMETRY

REFERENCES

PROBLEMS

5 DYNAMIC SIMS

5.1 FUNDAMENTALS AND ATTRIBUTES

5.2 AREAS AND METHODS OF APPLICATION

5.3 QUANTIFICATION OF DATA

5.4 NOVEL APPROACHE

5.5 INSTRUMENTATION

5.6 CONCLUSIONS

REFERENCES

PROBLEMS

6 LOW-ENERGY ION SCATTERING AND RUTHERFORD BACKSCATTERING

6.1 INTRODUCTION

6.2 PHYSICAL BASIS

6.3 RUTHERFORD BACKSCATTERING

6.4 LOW-ENERGY ION SCATTERING

ACKNOWLEDGEMENT

REFERENCES

PROBLEMS

KEY FACTS

7 VIBRATIONAL SPECTROSCOPY FROM SURFACES

7.1 INTRODUCTION

7.2 INFRARED SPECTROSCOPY FROM SURFACES

7.3 ELECTRON ENERGY LOSS SPECTROSCOPY (EELS)

7.4 THE GROUP THEORY OF SURFACE VIBRATIONS

7.5 LASER RAMAN SPECTROSCOPY FROM SURFACES

7.6 INELASTIC NEUTRON SCATTERING (INS)

7.7 SUM-FREQUENCY GENERATION METHODS

REFERENCES

PROBLEMS

8 SURFACE STRUCTURE DETERMINATION BY INTERFERENCE TECHNIQUES

8.1 INTRODUCTION

8.2 ELECTRON DIFFRACTION TECHNIQUES

8.3 X-RAY TECHNIQUES

8.4 PHOTOELECTRON DIFFRACTION

REFERENCES

9 SCANNING PROBE MICROSCOPY

9.1 INTRODUCTION

9.2 SCANNING TUNNELLING MICROSCOPY

9.3 ATOMIC FORCE MICROSCOPY

9.4 SCANNING NEAR-FIELD OPTICAL MICROSCOPY

9.5 OTHER SCANNING PROBE MICROSCOPY TECHNIQUES

9.6 LITHOGRAPHY USING PROBE MICROSCOPY METHODS

9.7 CONCLUSIONS

REFERENCES

PROBLEMS

10 THE APPLICATION OF MULTIVARIATE DATA ANALYSIS TECHNIQUES IN SURFACE ANALYSIS

10.1 INTRODUCTION

10.2 BASIC CONCEPTS

10.3 FACTOR ANALYSIS FOR IDENTIFICATION

10.4 REGRESSION METHODS FOR QUANTIFICATION

10.5 METHODS FOR CLASSIFICATIO

10.6 SUMMARY AND CONCLUSION

ACKNOWLEDGEMENTS

REFERENCES

PROBLEMS

APPENDIX 1 VACUUM TECHNOLOGY FOR APPLIED SURFACE SCIENCE

A1.1 INTRODUCTION: GASES AND VAPOURS

A1.2 THE PRESSURE REGIONS OF VACUUM TECHNOLOGY AND THEIR CHARACTERISTICS

A1.3 PRODUCTION OF A VACUUM

A1.4 MEASUREMENT OF LOW PRESSURES

ACKNOWLEDGEMENT

REFERENCES

APPENDIX 2 UNITS, FUNDAMENTAL PHYSICAL CONSTANTS AND CONVERSIONS

A2.1 BASE UNITS OF THE SI

A2.2 FUNDAMENTAL PHYSICAL CONSTANTS

A2.3 OTHER UNITS AND CONVERSIONS TO SI

REFERENCES

Index

This edition first published 2009 ©2009 John Wiley & Sons Ltd

Registered officeJohn Wiley & Sons Ltd, The Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, United Kingdom

For details of our global editorial offices, for customer services and for information about how to apply for permission to reuse the copyright material in this book please see our website at www.wiley.com.

The right of the author to be identified as the author of this work has been asserted in accordance with the Copyright, Designs and Patents Act 1988.

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, except as permitted by the UK Copyright, Designs and Patents Act 1988, without the prior permission of the publisher.

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic books.

Designations used by companies to distinguish their products are often claimed as trademarks. All brand names and product names used in this book are trade names, service marks, trademarks or registered trademarks of their respective owners. The publisher is not associated with any product or vendor mentioned in this book. This publication is designed to provide accurate and authoritative information in regard to the subject matter covered. It is sold on the understanding that the publisher is not engaged in rendering professional services. If professional advice or other expert assistance is required, the services of a competent professional should be sought.

The publisher and the author make no representations or warranties with respect to the accuracy or completeness of the contents of this work and specifically disclaim all warranties, including without limitation any implied warranties of fitness for a particular purpose. This work is sold with the understanding that the publisher is not engaged in rendering professional services. The advice and strategies contained herein may not be suitable for every situation. In view of ongoing research, equipment modifications, changes in governmental regulations, and the constant flow of information relating to the use of experimental reagents, equipment, and devices, the reader is urged to review and evaluate the information provided in the package insert or instructions for each chemical, piece of equipment, reagent, or device for, among other things, any changes in the instructions or indication of usage and for added warnings and precautions. The fact that an organization or Website is referred to in this work as a citation and/or a potential source of further information does not mean that the author or the publisher endorses the information the organization or Website may provide or recommendations it may make. Further, readers should be aware that Internet Websites listed in this work may have changed or disappeared between when this work was written and when it is read. No warranty may be created or extended by any promotional statements for this work. Neither the publisher nor the author shall be liable for any damages arising herefrom.

Library of Congress Cataloging-in-Publication Dat

Surface analysis: the principal techniques /c [edited by] John Vickerman, Ian Gilmore. –2nd ed. p. cm.Includes bibliographical references and index.ISBN 978-0-470-01763-01. Surfaces (Technology)–Analysis. 2. Spectrum analysis. I. Vickerman, J. C. II. Gilmore, Ian. TA418.7.S726 2009620′.44–dc222008040278

Contributors

David G. CastnerNational ESCA & Surface Analysis Center for Biomedical Problems, Departments of Chemical Engineering and Bioengineering, University of Washington, Seattle, WA 98195-1750, USA

Mark DowsettDepartment of Physics, University of Warwick, Coventry, CV4 7AL, UK

Peter GardnerManchester Interdisciplinary Biocentre, School of Chemical Engineering and Analytical Science, The University of Manchester, Manchester, M1 7DN, UK

Ian S. GilmoreSurface and Nanoanalysis, Quality of Life Division, National Physical Laboratory, Teddington, Middlesex, TW11 0LW, UK

Joanna L. S. LeeSurface and Nanoanalysis, Quality of Life Division, National Physical Laboratory, Teddington, Middlesex, TW11 0LW, UK

Graham J. LeggettDepartment of Chemistry, University of Sheffield, Brook Hill, Sheffield S3 7HF, UK

Christopher A. LucasDepartment of Physics, University of Liverpool, Liverpool, L69 3BX, UK

Hans Jörg MathieuEPFL, Départment des Matériaux, CH-1015, Lausanne, Switzerland

David McPhailDepartment of Materials, Imperial College, Prince Consort Road, London, SW7 2AZ

Martyn E. PembleTyndall National Institute, ‘Lee Maltings’, Prospect Row, Cork, Ireland

Buddy D. RatnerDepartment of Bioengineering, University of Washington, Seattle, WA 98195-1720, USA

Edmund TaglauerMax-Planck-Institut für Plasmaphysik, EURATOM Association, D-8046, Garching bei München, Germany

John C. VickermanSurface Analysis Research Centre, Manchester Interdisciplinary Biocentre, School of Chemical Engineering and Analytical Science, The University of Manchester, Manchester, M1 7DN, UK

Preface

In today’s world there are vast areas of high innovation technologies which benefit strongly from the application of surface analysis techniques in research, manufacture and quality control. Examples cover the gamut of industry sectors with strong growth in the use of surface analysis for nano-technologies, biotechnologies, nanoparticle characterization, lightweight materials, energy efficient systems and energy storage. Over the years an enormous number of techniques have been developed to probe different aspects of the physics, chemistry and biology of surfaces. Some of these techniques have found wide application in basic surface science and applied surface analysis and have become very powerful and popular techniques. This book seeks to introduce the reader to the principal techniques used in these fields together with the computational methods used to interpret the increasingly complex data generated by them. Each chapter has been written by experts in the field. The coverage includes the basic theory and practice of each technique together with practical examples of its use and application and most chapters are followed by some review questions to enable the reader to develop and test their understanding. The aim has been to give a thorough grounding without being too detailed.

Chapter 1 introduces the concept of ‘the surface’ and the challenges implicit in distinguishing the composition of the surface of materials from the rest of the material. In Chapter 2 Professor Hans Jörg Mathieu from Ecole Polytechnique, Lausanne, introduces perhaps the oldest widely used technique of surface analysis – Auger Electron Spectroscopy (AES). This technique has been exploited extensively and extremely effectively in Lausanne for metal and alloy analysis.

Electron Spectroscopy for Surface Analysis (ESCA) or X-ray Photoelectron Spectroscopy (XPS) is probably the most widely used surface analysis technique. It has been extremely effective for the solution of an enormous number of problems in both basic surface science and in applied analysis. Professors Buddy Ratner and Dave Castner from Washington State University have exploited the technique very successfully for polymer and biomaterials analysis and they introduce this technique in Chapter 3.

Secondary ion mass spectrometry (SIMS), introduced in Chapter 4 by Professor John Vickerman, is a very powerful technique because of the mass spectral nature of the data. The group in Manchester have contributed particularly to the development of SIMS for molecular surface analysis and in addition to its application to inorganic materials analysis they have shown that it can be exploited very effectively to investigate the complexities of biological systems.

SIMS has also been very effectively and widely used in its so-called dynamic form to characterize the elemental composition of electronic materials. Professor Mark Dowsett from the University of Warwick and Dr David McPhail of Imperial College, London, provide an insight into the challenges and capabilities of the technique in Chapter 5.

Low energy ion scattering (LEIS) and Rutherford backscattering (RBS) are powerful for probing the elemental composition and structure of surfaces. Professor Edmund Taglauer from the Max Planck Institute in Garching is a widely recognized authority on these elegant techniques which are introduced in Chapter 6.

Vibrational spectroscopy is very widely used in chemistry for compound identification and analysis. There are now many variants which can be applied to the study of surfaces and particularly of molecules on surfaces. Professor Martyn Pemble of the Tyndall National Institute, Cork and Dr Peter Gardner of The University of Manchester, have been involved in the development of several of the techniques and they exploit them in research associated with the growth of electronic materials and in understanding biological processes. They discuss a number of these variants in Chapter 7.

In Chapter 8 Dr Chris Lucas of the Department of Physics, The University of Liverpool, introduces techniques which use diffraction and other interference based methods for the analysis of surface structure. Low energy electron diffraction (LEED) has been an important technique in basic surface science for many years; however, more recently extended X-ray absorption fine structure (EXAFS) and the related techniques which probe local short range surface structure have become extremely valuable and are used extensively in many areas of materials characterization.

Surface studies have been significantly advanced by the scanning probe techniques – scanning tunnelling microscopy (STM) and atomic force microscopy (AFM). The impressive images with atomic resolution of metal surfaces have excited many surface analysts. The extension of the capabilities to bio-organic materials has resulted in considerable insights into the surface behaviour of these materials. Professor Graham Leggett, who is exploiting these techniques to study bio-organic surfaces at the University of Sheffield describes the theory and practice of these techniques in Chapter 9.

As the capabilities of the analytical techniques have advanced and the materials to be characterized have become ever more complex the need for computational methods to help interpret the multivariate character of the data has become a vital component of the analytical process for many of the techniques. In Chapter 10 Joanna Lee and Dr Ian Gilmore of the National Physical Laboratory, introduce the main methods of multivariate data analysis as applied to surface analysis.

Two appendices have been provided. Since most, though not all, surface analysis techniques are carried out in vacuum based equipment, Appendix 1 provided by Dr Rod Wilson, briefly describes the main features of the vacuum technology used in surface analysis. Appendix 2 provides a listing of the main units, constants and conversions that require to be used in surface analysis.

Most surface problems, be they in basic surface science or applied surface analysis, require careful selection of the most appropriate technique to answer the questions posed. Frequently more than one technique will be required. It is anticipated that readers of this book will be equipped to make the judgements required. Thus the book should be of value to those who need to have a wide overview of the techniques in education or in industrial quality control or R&D laboratories. For those who wish to further develop their knowledge and practice of particular techniques, it should also give a good basic understanding from which to build.

John C. VickermanManchester, UK

Ian S. GilmoreTeddington, UK

1

INTRODUCTION

JOHN C. VICKERMAN

Manchester Interdisciplinary Biocentre, School of Chemical Engineering and Analytical Science, The University of Manchester, Manchester, UK

The surface behaviour of materials is crucial to our lives. The obvious problems of corrosion are overcome by special surface treatments. The optical behaviour of glass can be modified by surface coatings or by changing the surface composition. The surface chemistry of polymers can be tuned so that they cling for packaging, are non-stick for cooking or can be implanted into our bodies to feed in drugs or replace body components. The auto-exhaust catalyst which removes some of the worst output of the combustion engine is a masterpiece of surface chemistry as are the industrial catalysts which are vital for about 90% of the output of the chemical industry. Thus whether one considers a car body shell, a biological cell, tissue or implant, a catalyst, a solid state electronic device or a moving component in an engine, it is the surface which interfaces with its environment. The surface reactivity will determine how well the material behaves in its intended function. It is therefore vital that the surface properties and behaviour of materials used in our modern world are thoroughly understood. Techniques are required which enable us to analyse the surface chemical and physical state and clearly distinguish it from that of the underlying solid.

1.1 How do we Define the Surface?

It is obvious that the surface properties of solids are influenced to a large extent by the solid state properties of the material. The question arises as to how we define the surface. Since the top layer of surface atoms are those that are the immediate interface with the other phases (gas, liquid or solid) impinging on it, this could be regarded as the surface. However, the structure and chemistry of that top layer of atoms or molecules will be significantly determined by the atoms or molecules immediately below. In a very real sense therefore, the surface could be said to be the top 2–10 atomic or molecular layers (say, 0.5–3 nm). However, many technologies apply surface films to devices and components, to protect, lubricate, change the surface optical properties, etc. These films are in the range 10–100 nm or sometimes even thicker, but the surface may be thought of in this depth range. However, beyond 100 nm it is more appropriate to begin to describe such a layer in terms of its bulk solid state properties. Thus we can consider the surface in terms of three regimes: the top surface monolayer, the first ten or so layers and the surface film, no greater than 100 nm. To understand fully the surface of a solid material, we need techniques that not only distinguish the surface from the bulk of the solid, but also ones that distinguish the properties of these three regimes.

1.2 How Many Atoms in a Surface?

It will be appreciated that it is not straightforward to probe a surface layer of atoms or molecules analytically and distinguish their structure and properties from that of the rest of the solid. One has only to consider the relatively small number of atoms involved in the surface layer(s) of an atomic solid to see that high sensitivity is required. How many atoms are we dealing with at the surface and in the bulk of a solid? We can consider a 1 cm cube of metal. One of the 1 cm2 surfaces has roughly 1015 atoms in the surface layer. Thus the total number of atoms in the cube will be ≈1023. Therefore the percentage of surface to bulk atoms will be:

Typically, a surface analysis technique may be able to probe in the region of 1mm2. Thus in the top monolayer there will be about 1013 atoms. In the top ten layers there will be 1014 atoms or 10−10 mol. Clearly in comparison with conventional chemical analysis we are considering very low concentrations. Things become more demanding when we remember that frequently the chemical species which play an important role in influencing surface reactivity may be present in very low concentration, so the requirement will be to analyse an additive or contaminant at the 10−3 or even 10−6 (ppm) atomic level, i.e. 1010 or 107 atoms or 10−14 or 10−17 mole levels respectively, perhaps even less.

Similar demands arise if the analysis has to be carried out with high spatial resolution. The requirement to map variations in chemistry across a surface can arise in a wide variety of technologies. There may be a need to monitor the homogeneity of an optical or a protective coating or the distribution of catalyst components across a support, a contaminant on an electronic device or a drug in a cell or tissue, etc. It is not unusual for 1 μm spatial resolution to be demanded, frequently even less would be beneficial. If we continue the discussion above in an area of 1 μm2 (10−12 m2 or 10−8 cm2) there are only ≈107 atoms, so if we want to analyse to the 10−3 atom fraction level, there are only 104 atoms. The nano particles that are part of many technologies these days present far fewer atoms for analysis, making the surface analysis task even more demanding.

Thus surface analysis is demanding in terms of its surface resolution and sensitivity requirements. However, there are in fact many surface analysis techniques, all characterized by distinguishing acronyms – LEED, XPS, AES, SIMS, STM, etc. Most were developed in the course of fundamental studies of surface phenomena on single crystal surface planes. Such studies which comprise the research field known as surface science seek to provide an understanding of surface processes at the atomic and molecular level. Thus for example, in the area of catalysis, there has been an enormous research effort directed towards understanding the role of surface atomic structure, composition, electronic state, etc. on the adsorption and surface reactivity of reactant molecules at the surface of the catalyst. To simplify and systematically control the variables involved, much of the research has focused on single crystal surfaces of catalytically important metals and more recently inorganic oxides. The surface analysis techniques developed in the course of these and related research are, in the main, based on bombarding the surface to be studied with electrons, photons or ions and detecting the emitted electrons, photons or ions.

1.3 Information Required

To understand the properties and reactivity of a surface, the following information is required: the physical topography, the chemical composition, the chemical structure, the atomic structure, the electronic state and a detailed description of bonding of molecules at the surface. No one technique can provide all these different pieces of information. A full investigation of a surface phenomenon will always require several techniques. To solve particular problems it is seldom necessary to have all these different aspects covered; however, it is almost always true that understanding is greatly advanced by applying more than one technique to a surface study. This book does not attempt to cover all the techniques in existence. A recent count identified over 50! The techniques introduced here are those (excluding electron microscopy which is not covered but for which there are numerous introductions) that have made the most significant impact in both fundamental and applied surface analysis. They are tabulated (via their acronyms) in Table 1.1 according to the principal information they provide and the probe/detection system they use. The number after each technique indicates the chapter in which it is described.

Table 1.1 Surface analysis techniques and the information they can provide

ESCA/XPS – Electron analysis for chemical analysis/X-ray photoelectron spectroscopy. X-ray photons of precisely defined energy bombard the surface, electrons are emitted from the orbitals of the component atoms, electron kinetic energies are measured and their electron binding energies can be determined enabling the component atoms to be determined.

AES – Auger electron spectroscopy. Basically very similar to the above except that a keV electron beam may be used to bombard the surface.

SIMS – Secondary ion mass spectrometry. There are two forms, i.e. dynamic and molecular SIMS. In both a beam of high energy (keV) primary ions bombard the surface while secondary atomic and cluster ions are emitted and analysed with a mass spectrometer.

ISS – Ion scattering spectrometry. An ion beam bombards the surface and is scattered from the atoms in the surface. The scattering angles and energies are measured and used to compute the composition and surface structure of the sample target.

IR – Infrared (spectroscopy). Various variants on the classical methods – irradiate with infrared photons which excite vibrational frequencies in the surface layers; photon energy losses are detected to generate spectra.

EELS – Electron energy loss spectroscopy. Low energy (few eV) electrons bombard the surface and excite vibrations – the resultant energy loss is detected and related to the vibrations excited.

INS – Inelastic neutron scattering. Bombard a surface with neutrons – energy loss occurs due to the excitation of vibrations. It is most efficient in bonds containing hydrogen.

SFG – Sum frequency generation. Two photons irradiate and interact with an interface (solid/gas or solid liquid) such that a single photon merges resulting in electronic or vibrational information about the interface region.

LEED – Low energy electron diffraction. A beam of low energy (tens of eV) electrons bombard a surface; the electrons are diffracted by the surface structure enabling the structure to be deduced.

RHEED – Reflection high energy electron diffraction. A high energy beam (keV) of electrons is directed at a surface at glancing incidence. The angles of electron scattering can be related to the surface atomic structure.

EXAFS – Extended X-ray absorption fine structure. The fine structure of the absorption spectrum resulting from X-ray irradiation of the sample is analysed to obtain information on local chemical and electronic structure.

STM – Scanning tunnelling microscopy. A sharp tip is scanned over a conducting surface at a very small distance above the surface. The electron current flowing between the surface and the tip is monitored; physical and electron density maps of the surface can be generated with high spatial resolution.

AFM – Atomic force microscopy (not included in table). Similar to STM but applicable to non-conducting surfaces. The forces developed between the surface and the tip are monitored. A topographical map of the surface is generated.

It is a characteristic of most techniques of surface analysis that they are carried out in vacuum. This is because electrons and ions are scattered by molecules in the gas phase. While photon based techniques can in principle operate in the ambient, sometimes gas phase absorption of photons can occur and as a consequence these may also require vacuum operation. This imposes a restriction on some of the surface processes that can be studied. For example, to study the surface gas or liquid interface it will usually be necessary to use a photon based technique, or one of the scanning probe techniques. Developments since the turn of the century are enabling the analysis of surfaces under ambient atmospheres using mass spectral methods analogous to SIMS (Chapter 4).

However, the vacuum based methods allow one to control the influence of the ambient on the surface under study. To analyse a surface uncontaminated by any adsorbate it is necessary to operate in ultra-high vacuum (<10−9 mmHg) since at 10−6 mmHg a surface can be covered by one mono-layer of adsorbed species within 1 s if the sticking coefficient (probability for adsorption) is 1. Controlled exposure of the surface to adsorbates or other surface treatments can then be carried out to monitor effects in a controlled manner. Appendix 1 on ‘Vacuum Technology’ will enable the reader to become familiar with the concepts and equipment requirements in the generation of vacua.

1.4 Surface Sensitivity

To generate the information, we require that a surface analysis technique should derive its data as near exclusively as possible from within the depth range discussed in Section 1.2. The extent to which a technique does this is a measure of its surface sensitivity. Ion scattering spectrometry (ISS) derives almost all its information from the top monolayer. It is very surface sensitive. Electron Spectroscopy for Chemical Analysis (ESCA) or X-ray Photoelectron Spectroscopy (XPS) samples the top ten or so layers of the surface, while infrared (IR) spectroscopy is not very surface sensitive and will sample deep into the solid, unless it is used as a reflection mode.

In general the surface sensitivity of an analytical method is dependent on the radiation detected. As already indicated, most of the methods of surface analysis involve bombarding the surface with a form of radiation – electrons, photons, ions, neutrons – and then collecting the resulting emitted radiation – electrons, photons, ions, neutrons. The scanning probe methods are a little different, although one could say that scanning tunnelling microscopy (STM) detects electrons. (Atomic force microscopy monitors the forces between the surface and a sharp tip, see Chapter 9.) The surface sensitivity depends on the depth of origin of the detected species. Thus in XPS while the X-ray photons which bombard the surface can penetrate deep into the solid, the resultant emitted electrons which can be detected without loss of energy can only arise from within 1–4 or 8 nm of the surface. Electrons generated deeper in the solid may escape, but on the way out they will have collided with other atoms and lost energy. They are no use for analysis. Thus the surface sensitivity of ESCA is a consequence of the short distance electrons can travel in solids without being scattered (known as the inelastic mean free path). Similarly, in secondary ion mass spectrometry (SIMS) the surface is bombarded by high energy ions. They deposit their energy down to 30 or 40 nm. However, 95% of the secondary ions that are knocked out (sputtered) of the solid arise from the top two layers.

There are techniques like infrared (IR) spectroscopy which, although they are not intrinsically very surface sensitive, can be made so by the methods used to apply them. Thus with IR a reflection approach can be used in which the incoming radiation is brought in at a glancing incidence. This enables vibrational spectra to be generated from adsorbates on single crystal surfaces. The technique is very surface sensitive. Surface sensitivity can be significantly increased even in surface sensitive methods like ESCA by irradiating the surface at glancing incidence – see Chapter 3.

Various terms are used to define surface sensitivity. With all the techniques described in this book the total signal detected will originate over a range of depths from the surface. An information depth may be specified which is usually defined as the average distance (in nm) normal to the surface from which a specified percentage (frequently 90, 95 or 99%) of the detected signal originates. Sometimes, as in ESCA, a sampling depth, is defined. This is three times the inelastic mean free path, and turns out to be the information depth where the percentage is 95%. Obviously a very small proportion of the detected signal does arise from deeper in the solid, but the vast majority of the useful analytical information arises from within the sampling depth region.

In molecular SIMS the information depth is the depth from which 95% of the secondary ions originate. For most materials this is believed to be about two atomic layers, about 0.6 nm. However, it is sometimes difficult to be sure what a layer is. For example, there are surface layers used to generate new optical properties that are composed of long organic chains bonded to metal or oxide surfaces. The organic layer is much less dense than the substrate underneath. SIMS studies of these materials suggest that the analytical process may remove the whole molecular chain which can easily be >20 nm long. Surface sensitivity in this case is a very different concept from that which would apply to the surface of a metal or inorganic compound.

1.5 Radiation Effects – Surface Damage

To obtain the surface information required entails ‘interfering’ with the surface state in some way! Most of the techniques require the surface to be bombarded with photons, electrons or ions. They will affect the chemical and physical state of the surface being analysed. Thus in the course of analysing the surface, the surface may be changed. It is important to understand the extent to which this may happen, otherwise the information being generated from the surface may not be characteristic of the surface before analysis; rather it may reflect a surface damaged by the incident radiation.

Table 1.2 shows the penetration depth and influence of the 1000 eV particles. It can be seen that most of the energy is deposited in the near surface under ion and electron bombardment, so in general terms it would be expected that the extent of surface damage would vary as photons < electrons < ions. Consequently, it is sometimes carelessly suggested that ESCA/XPS is a low damage technique. However, the power input to the surface in the course of an experiment is considerably less in the ion bombardment method of SIMS compared to photon bombardment in ESCA (Table 1.3). SIMS is very obviously a phenomenon that depends on damage – ions bombard to knock out other ions! Without damage there is no information, but as will be seen in Chapter 4 it can be operated in a low damage mode to generate significant surface information. The X-ray photons which bombard the surface in XPS penetrate deep into the solid. However, if the material is delicate, e.g. a polymer, and if the power input is too high or the time under the beam too long, the sample can be literally ‘fried’. The same effect is even more obvious for the methods involving electron irradiation. It is consequently very difficult to analyse the surfaces of organic materials using any technique which relies on electron bombardment.

Table 1.2 Penetration depths of particles

ParticleEnergy (eV)Depths (Å)Photon100010 000Electron100020Ions100010

Table 1.3 Comparison of typical primary particle flux densities and energies and the resulting power dissipated in SSIMS, LEED and X-ray photoelectron experiments

1.6 Complexity of the Data

The advance in the capability of surface analysis techniques has been enormous since the publication of the first edition of this book. The information content of many of them has escalated. The complexity of materials that they are now expected to characterize has also increased. As a consequence it is sometimes difficult to understand the data using the simple analysis routines employed when the techniques were in their infancy. SIMS is a good case in point. The spectra in molecular SIMS can be so complex that it is impossible to discern by a ‘stare and compare’ approach the important chemical differences between, say, what is supposed to be a ‘good’ sample and a ‘bad’ sample. This type of problem has become particularly acute as surface analysis techniques have begun to be applied to biological systems. Multiple factors may influence the spectral differences. To deal with this type of problem many analysts and researchers have turned to computational methods of multivariate analysis (MVA) that seek to isolate the crucial differences between the spectra of differing materials or treatments. MVA methods are introduced and discussed in a new Chapter 10.

Surface analysis techniques have been enormously successful in developing our understanding of surface phenomena. There are vast numbers of areas of technology which would benefit from the application of surface analysis techniques in both research and development and in quality control. Frequently these techniques are not being applied because of a lack of knowledge and understanding of how they can help. Hopefully, this book will help to develop increased awareness such that surface analysis will be increasingly applied to further our understanding of the surface states at both the fundamental and applied levels.

None of the techniques are analytical ‘black boxes’ delivering answers to problems at the push of a button. Two general rules should be remembered in surface analysis: (a) in every case it is important to understand the capabilities and limitations of the technique being used with regard to the material being studied and the information required; (b) no one technique gives the whole story.
