An important factor in the design of new structures and repairs to existing structures is the expected service life.
In France, for major civil engineering works such as bridges, this duration is around 100 years (the British even go as far as 120 years).
For more modest structures such as water treatment plants, storage silos, etc., this duration was tacitly defined as around 50 years.
There are many factors that can influence this:
– the nature of the materials used in the construction (masonry, steel, concrete, wood, etc.);
– the quality of these materials (high-performance concrete, stainless steel, etc.);
– the constructive arrangements used (accumulation of water on metal structures, lack of encapsulation of steel in a reinforced concrete structure, etc.);
– quality of the execution (quality of the welding, implementation of concrete, etc.);
– monitoring and maintenance.
Within the context of the European Regulation for Calculation and Implementation, all these criteria have been taken into account when determining the duration of use of a structure.
This means that the design of the structures is obsolete if the maintenance conditions are not respected.
Let us recall section 2.4 of EN 1990:
“2.4 Durability
(1) The structure shall be designed such that deterioration over its design working life does not impair the performance of the structure below that intended, having due regard to its environment and the anticipated level of maintenance.
(2) In order to achieve an adequately durable structure, the following should be taken into account:
– the intended or foreseeable use of the structure;
– the required design criteria;
– the expected environmental conditions;
– the composition, properties and performance of the materials and products;
– the properties of the soil;
– the choice of the structural system;
– the shape of members and the structural detailing;
– the quality of workmanship, and the level of control;
– the particular protective measures;
–
the intended maintenance during the design working life
”.
The question also arises for repairs carried out on a structure: what life expectancy should they be given?
With regard to new structures, EN 1990 indicates the following durations in Table I.1.
Table I.1.Indicative design working life
Design working life category
Indicative design working-life (years)
Examples
1
10
Temporary structures
a
2
10–25
Replaceable structural elements, for example rolling beams, supporting devices
3
15–30
Agricultural structures and the like
4
50
Buildings and other structures
5
100
Monumental structures of buildings, bridges and other civil engineering structures
aStructures or parts of structures that can be disassembled for reuse should not be considered as temporary.
In the section “Execution of concrete structures”, section 4.1 of EN 13670 also specifies the need for an inspection program:
“(5) This standard assumes that the structure after completion is used as intended in the design and submitted to planned inspection and maintenance necessary to achieve the intended design working life and to detect weaknesses or any unexpected behavior”.
This requirement implies providing access to the main structural elements at the design level.
Examples include:
– suspended bridges where replacement of the suspension has not been studied at design stage;
– water treatment plants for which it was not possible to empty the tanks (nonbypassable treatment line).
It also implies the need for a “state 0” during the reception for new constructions as well as a structure maintenance plan.
From this state, the sequence of tasks that is required to guarantee the duration of use of the structures is presented in the figure below:
Figure I.1.Sequence of tasks required to guarantee the duration
The purpose of this book is to create an inventory of the methodologies used for inspections of civil engineering structures and to present the elements that can serve as a basis for the diagnosis and maintenance program of concrete structures.
We present the main topics that the reader can deepen their knowledge of by reading the standards cited.
How to use this guide
For a better understanding of the methodology used, in the last part of each inspection methodology listed in Chapter 1 is a paragraph about “points of to look out for”, which refers to Chapter 3 for probable causes of the pathology and to Chapter 4 for the means of reinforcement that can be considered.
Chapter 2 gives the basic notions of resistance of the materials that are required for proper comprehension of the behavior of concrete and the interpretation of the observed disorders.
The examples in the Appendix are informative; they aim to show a type of connection in adequation with the inspected structure. They are purely formal.
Inspection and diagnosis of structures are the most important phases of a maintenance operation and, eventually, of renovation. They require asking oneself a few questions before discussing the planning and recovery solution.
The questions are generally the following:
– what is the typology of the damage?
– what could be their cause?
– what is their scope?
– what is their probable evolution?
– what are the consequences for the structure?
– can the damage be repaired (technically and financially)?
To answer this question, the following methodology is usually applied:
– the first step involves a detailed visual assessment. This should be carried out by an expert civil engineer. It is similar to a health check without thorough analysis;
– the second step consists of a diagnosis by auscultation of the structure. This is managed by a civil engineer who relies on a specialized (and possibly multidisciplinary) laboratory.
For bridges, the Centre of Research and Expertise for Risks, Environment and Transport (CEREMA) formalized this principle and set up a methodology for monitoring and diagnosing this type of structure, which is summarized hereafter.
The management of structures is based on:
–
Recording of bridges:
this is a preliminary phase that consists of recognizing and recording the various heritage structures. The necessary data are: the type of structure, its
exact location
, its
main dimensional characteristics
and its
use
. The information should be verified in the field in order to take information into account that may not be included in the files;
–
The project file:
this is a document that gathers all the features of the structure along with its history. The contents of the file are defined in the Technical Instructions (ITSEOA);
–
Monitoring of structures:
this is of siginificant importance for maintaining the heritage and safety of users. It consists of following the evolution of various structures from a reference state (initial detailed inspection (IDI)), which is defined at the end of the construction or in the management takeover. The reference state can be modified by carrying out significant works such as expansion and extension. This monitoring is carried out over two levels:
-
periodic inspections
;
-
periodic detailed inspections
.
NOTE.– There is also a detailed end-of-warranty inspection to ensure the condition of a structure under contractual guarantee or 10-year liability.
Table 1.1.Periodic inspections table
Aim
Frequency
Requirements
Achievement
It applies to all structures if they are not carried out in the same year as another inspection (periodic or exceptional detailed inspection).
From 1 year (annual check) to 3 years (assessment visit) maximum.
– Detect any change in the pathologies that had already been noticed.
– Take note of serious damages that pose a threat to users.
– Identify the nature of routine or specialized maintenance.
Visual inspection without special access by trained agents.
Table 1.2.Periodic detailed inspections table
Aim
Frequency
Requirements
Achievement
Establish a health check of the structure and define the actions related to routine or specialized maintenance.
