Fault-Tolerance Techniques for Spacecraft Control Computers E-Book

Mengfei Yang

0,0

128,99 €

Sammeln Sie Punkte in unserem Gutscheinprogramm und kaufen Sie E-Books und Hörbücher mit bis zu 100% Rabatt.

Mehr erfahren.

Herausgeber: John Wiley & Sons
Kategorie: Wissenschaft und neue Technologien
Sprache: Englisch

Beschreibung

Comprehensive coverage of all aspects of space application oriented fault tolerance techniques * Experienced expert author working on fault tolerance for Chinese space program for almost three decades * Initiatively provides a systematic texts for the cutting-edge fault tolerance techniques in spacecraft control computer, with emphasis on practical engineering knowledge * Presents fundamental and advanced theories and technologies in a logical and easy-to-understand manner * Beneficial to readers inside and outside the area of space applications
