Nanoelectromechanical Systems E-Book

Laurent Duraffourg

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Sprache: Englisch

Seitenzahl: 298

Veröffentlichungsjahr: 2015

Beschreibung

This book will present the theoretical and technological elements of nanosystems. Among the different topics discussed, the authors include the electromechanical properties of NEMS, the scaling effects that give these their interesting properties for different applications and the current manufacturing processes. The authors aim to provide useful tools for future readers and will provide an accurate picture of current and future research in the field.
