5G Radio Access Network Architecture E-Book

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Serie: Wiley - IEEE
• Sprache: Englisch

Seitenzahl: 830

Veröffentlichungsjahr: 2020

Beschreibung

Discover how the NG-RAN architecture is, and isn't, ready for the challenges introduced by 5G 5G Radio Access Network Architecture: The Dark Side of 5G explores foundational and advanced topics in Radio Access Network (RAN) architecture and why a re-thinking of that architecture is necessary to support new 5G requirements. The distinguished engineer and editor Sasha Sirotkin has included numerous works written by industry insiders with state of the art research at their disposal. The book explains the relevant standards and technologies from an academic perspective, but also explains why particular standards decisions were made and how a variety of NG-RAN architecture options could be deployed in real-life networks. All major standards and technologies associated with the NG-RAN architecture are discussed in this book, including 3GPP, O-RAN, Small Cell Forum, IEEE, and IETF. Readers will learn about how a re-design of the RAN architecture would ensure that 5G networks can deliver their promised throughput and low latency KPIs consistently and sustainably. The book is structured as follows: * An overview of the market drivers of the NG-RAN architecture, like spectrum models, 5G-relevant regulatory considerations, and 5G radio interface technical requirements * An overview of the 5G System, from the core network, to the RAN, to the radio interface protocols and physical layer, with emphasis on how these are different compared to 4G * Release-15 RAN architectures defined in 3GPP, O-RAN, and Small Cell Forum * RAN architecture evolution in Release-16 and Release-17 * Enabling technologies, like virtualization, open source technologies, multi-access edge (MEC) computing, and operations, administration, and management (OAM) * NG-RAN deployment considerations, objectives, and challenges, like costs, spectrum and radio propagation considerations, and coverage Perfect for network designers and operators who require a solid understanding of the NG-RAN architecture, 5G Radio Access Network Architecture also belongs on the bookshelves of network engineers who aim to increase their understanding of the standards and technologies relevant to the NG-RAN architecture.

Leseprobe

Table of Contents

Cover

Title Page

Copyright

Dedication

Preface

Acknowledgments

List of Contributors

Contributors

Acronyms and Abbreviations

1 Introduction

2 Market Drivers

2.1 Introduction

2.2 Key Ideas

2.3 Spectrum

2.4 New Spectrum Models

2.5 Regulations Facilitating 5G Applications

2.6 Network Deployment Models

2.7 Technical Requirements of 5G Radio Interfaces

2.8 Business Drivers

2.9 Role of Standards

2.10 Role of Open Source

2.11 Competition

2.12 Challenges

2.13 Summary

References

Notes

3 5G System Overview

3.1 Introduction

3.2 5G Core Network

References

3.3 NG Radio Access Network

References

3.4 NR Protocol Stack

References

3.5 NR Physical Layer

References

Notes

4 NG‐RAN Architecture

4.1 Introduction

References

4.2 High‐Level gNB‐CU/DU Split

References

4.3 Multi‐Radio Dual Connectivity

References

4.4 Control–User Plane Separation

References

4.5 Lower‐Layer Split

References

4.6 Small Cells

References

4.7 Summary

Notes

5 NG‐RAN Evolution

5.1 Introduction

5.2 Wireless Relaying in 5G

References

5.3 Non‐terrestrial Networks

References

Notes

6 Enabling Technologies

6.1 Introduction

6.2 Virtualization

References

6.3 Open Source

References

6.4 Multi‐Access Edge Computing

References

6.5 Operations, Administration, and Management

References

6.6 Transport Network

References

Notes

7 NG‐RAN Deployment Considerations

7.1 Introduction

7.2 Key Ideas

7.3 Deployment Objectives and Challenges

7.4 Deployment Considerations

7.5 Conclusions

References

Notes

Index

End User License Agreement

List of Tables

Chapter 2

Table 2.1 IMT‐2020 spectrum needs based on TPRs.

Table 2.2 LSA vs. CBRS.

Table 2.3 Summary of IMT‐2020 requirements.

Chapter 3

Table 3.4.1 Downlink channel mapping.

Table 3.5.1 Scalable numerology supported by NR.

Table 3.5.2 Supported bandwidth sizes in Release‐15 NR for different subcarri...

Table 3.5.3 Supported PRACH preambles.

Table 3.5.4 DCI formats supported in NR (Release‐15).

Table 3.5.5 Supported PUCCH formats in 5G NR.

Chapter 4

Table 4.1.1 Common Public Radio Interface (CPRI) Radio Equipment Control (REC...

Table 4.5.1 Front haul transport downlink bandwidth comparison.

Table 4.2.1 Uplink transmit and receive window.

Table 4.6.1 Pros and cons of disaggregation points.

Table 4.6.1 Typical cell dimensioning.

Chapter 5

Table 5.3.1 Typical performances of NTN for considered usage scenarios.

Table 5.3.2 NR impacts to support the NTN reference scenarios.

Table 5.3.3 Objectives of non‐terrestrial network (NTN) channel modeling.

Chapter 6

Table 6.4.1 MEC hosts divided into proximity zones according to a certain cri...

Table 6.5.1 Operations and notifications for the provisioning MnSs for the NS...

Table 6.5.2 IOCs for the RAN components.

Table 6.5.3 IOCs for the DU components.

Table 6.5.4 Endpoints IOCs.

Table 6.5.5 Example RRM policy configuration.

Table 6.5.6 Legacy SON functionality.

Table 6.6.1 Head‐of‐line blocking time versus line rate.

Chapter 7

Table 7.1 Typical bandwidths and coverage ranges for different 5G frequency r...

Table 7.2 Fronthaul bandwidth for low‐, mid‐, and high‐band scenarios.

Table 7.3 Latency requirements for various split options.
