Advances in Battery Manufacturing, Service, and Management Systems E-Book

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Serie: IEEE Series on Systems Science and Engineering
• Sprache: Englisch

Seitenzahl: 616

Veröffentlichungsjahr: 2016

Beschreibung

Addresses the methodology and theoretical foundation of battery manufacturing, service and management systems (BM²S²), and discusses the issues and challenges in these areas

This book brings together experts in the field to highlight the cutting edge research advances in BM²S² and to promote an innovative integrated research framework responding to the challenges. There are three major parts included in this book: manufacturing, service, and management. The first part focuses on battery manufacturing systems, including modeling, analysis, design and control, as well as economic and risk analyses.  The second part focuses on information technology’s impact on service systems, such as data-driven reliability modeling, failure prognosis, and service decision making methodologies for battery services. The third part addresses battery management systems (BMS) for control and optimization of battery cells, operations, and hybrid storage systems to ensure overall performance and safety, as well as EV management.  The contributors consist of experts from universities, industry research centers, and government agency. In addition, this book:

• Provides comprehensive overviews of lithium-ion battery and battery electrical vehicle manufacturing, as well as economic returns and government support
• Introduces integrated models for quality propagation and productivity improvement, as well as indicators for bottleneck identification and mitigation in battery manufacturing
• Covers models and diagnosis algorithms for battery SOC and SOH estimation, data-driven prognosis algorithms for predicting the remaining useful life (RUL) of battery SOC and SOH
• Presents mathematical models and novel structure of battery equalizers in battery management systems (BMS)
• Reviews the state of the art of battery, supercapacitor, and battery-supercapacitor hybrid energy storage systems (HESSs) for advanced electric vehicle applications

Advances in Battery Manufacturing, Services, and Management Systems is written for researchers and engineers working on battery manufacturing, service, operations, logistics, and management. It can also serve as a reference for senior undergraduate and graduate students interested in BM²S².

Leseprobe

CONTENTS

Cover

Series Page

Title Page

Copyright

Preface

Contributors

Part I: Battery Manufacturing Systems

Chapter 1: Lithium-Ion Battery Manufacturing for Electric Vehicles: A Contemporary Overview

1.1 Introduction

1.2 Li-Ion Battery Cells, Modules, and Packs

1.3 Joining Technologies for Batteries

1.4 Battery Manufacturing: The Industrial Landscape

1.5 Conclusions

References

Chapter 2: Improving Battery Manufacturing Through Quality and Productivity Bottleneck Indicators

2.1 Introduction

2.2 Literature Review

2.3 Problem Formulation

2.4 Integrated Quality and Productivity Performance Evaluation

2.5 Bottleneck Analysis

2.6 Conclusions

Acknowledgment

Appendix A: Operators Θ(⋅), Φ1(⋅) and Φ2(⋅)

References

Chapter 3: Event-Based Modeling for Battery Manufacturing Systems Using Sensor Data

3.1 Introduction

3.2 Sensor Networks for Battery Manufacturing System

3.3 Event-Based Modeling Approach

3.4 Event-Based Diagnosis For Market Demand–Driven Battery Manufacturing

3.5 Event-Based Costing for Market Demand–Driven Battery Manufacturing System

3.6 Conclusions

Acknowledgment

References

Chapter 4: A Review on End-of-Life Battery Management: Challenges, Modeling, and Solution Methods

4.1 Introduction

4.2 Research Issues of Battery Remanufacturing

4.3 Modeling and Analysis for Battery-Remanufacturing Systems

4.4 Summary

References

Chapter 5: An Analytics Approach for Incorporating Market Demand into Production Design and Operations Optimization

5.1 Introduction

5.2 Design and Operational Decision Support

5.3 Linkage to a Financial Transfer Function

5.4 A Quantification of Risk in Design and Operations

5.5 Exploration of Design and Operations Choices

5.6 Manufacturing Operations Transfer Function: Throughput, Inventory, Expense, and Fulfillment

5.7 Activity- Based Costing

5.8 Conclusion

References

Part II: Battery Service Systems

Chapter 6: Prognostic Classification Problem in Battery Health Management

6.1 Introduction

6.2 Failure Predictions by Logistic Regression and JPM

6.3 Numerical Study

6.4 Discussion of the Impact of Imbalanced Data

6.5 Conclusion

References

Chapter 7: A Bayesian Approach to Battery Prognostics and Health Management

7.1 Introduction

7.2 Background

7.3 Battery Model for a Bayesian Approach

7.4 Particle Filtering Framework for State Tracking and Prediction

7.5 Battery Model Considerations for PF Performance

7.6 Decision Making for Optimizing Battery Use

7.7 Summary

References

Chapter 8: Recent Research on Battery Diagnostics, Prognostics, and Uncertainty Management

8.1 Introduction

8.2 Battery Diagnostics

8.3 Battery Prognostics

8.4 Uncertainty Management

8.5 Summary

References

Chapter 9: Lithium-Ion Battery Remaining Useful Life Estimation Based on Ensemble Learning with LS-SVM Algorithm

9.1 Introduction

9.2 LS-SVM Algorithm

9.3 LS-SVM Ensemble Learning Algorithm

9.4 Experiment Verification and Analysis

9.5 Conclusion

References

Chapter 10: Data-Driven Prognostics for Batteries Subject to Hard Failure

10.1 Introduction

10.2 The Prognostic Model

10.3 Simulation Study

10.4 Summary

References

Part III: Battery Management Systems (BMS)

Chapter 11: Review of Battery Equalizers and Introduction to the Integrated Building Block Design of Distributed BMS

11.1 Concept of Battery Equalization

11.2 Equalization Methods

11.3 Introduction of Integrated Building Block Design of a Distributed BMS

11.4 The Proposed Integrated Building Block Design of BMS

11.5 System Implementation

11.6 Tested System Description

11.7 Functional Performance Evaluation

11.8 Conclusion

References

Chapter 12: Mathematical Modeling, Performance Analysis and Control of Battery Equalization Systems: Review and Recent Developments

12.1 Introduction

12.2 Modeling of Battery Equalization Systems

12.3 Performance Evaluation of Battery Equalization Systems

12.4 Control Strategies for Battery Equalization Systems

12.5 Summary

References

Chapter 13: Review of Structures and Control of Battery-Supercapacitor Hybrid Energy Storage System for Electric Vehicles

13.1 Introduction

13.2 Batteries for EVs

13.3 Supercapacitors for EVs

13.4 Battery-Supercapacitor Hybrid Energy Storage System

13.5 Control Strategy for HESS

13.6 Conclusions

References

Chapter 14: Power Management Control Strategy of Battery-Supercapacitor Hybrid Energy Storage System Used in Electric Vehicles

14.1 Introduction

14.2 Low-Level Hybrid Topologies

14.3 High-Level Supervisory Control

14.4 Conclusions

References

Chapter 15: Federal and State Incentives Heighten Consumer Interest in Electric Vehicles

15.1 Introduction

15.2 Electric Vehicles and the Federal Role

15.3 Public Interest in HEVs and Electric Vehicles

15.4 Federal Support for HEVs and Electric Vehicles

15.5 Support for EVs in the Obama Administration

15.6 Impact of GHG Regulations

15.7 Vehicle Environmental Life Cycle Comparisons

15.8 State Initiatives

15.9 Prospects for Growth

15.10 Conclusion

Acknowledgment

References

Index

IEEE Press Series on Systems Science and Engineering

End User License Agreement

List of Tables

Table 1.1

Table 1.2

Table 2.1

Table 2.2

Table 2.3

Table 2.4

Table 2.5

Table 4.1

Table 5.1

Table 6.1

Table 6.2

Table 6.3

Table 6.4

Table 6.5

Table 6.6

Table 6.7

Table 7.1

Table 8.1

Table 8.2

Table 9.1

Table 9.2

Table 9.3

Table 9.4

Table 9.5

Table 10.1

Table 10.2

Table 10.3

Table 10.4

Table 11.1

Table 11.2

Table 13.1

Table 13.2

Table 13.3

Table 13.4

Table 14.1

Table 14.2

Table 14.3

Table 15.1

Table 15.2

Table 15.3

Table 15.4

Table 15.5

Table 15.6

List of Illustrations

Figure 1.1

Figure 1.2

Figure 1.3

Figure 1.4

Figure 1.5

Figure 1.6

Figure 1.7

Figure 1.8

Figure 1.9

Figure 1.10

Figure 1.11

Figure 1.12

Figure 1.13

Figure 1.14

Figure 1.15

Figure 1.16

Figure 1.17

Figure 1.18

Figure 1.19

Figure 1.20

Figure 1.21

Figure 1.22

Figure 1.23

Figure 2.1

Figure 2.2

Figure 2.3

Figure 2.4

Figure 3.1

Figure 3.2

Figure 3.3

Figure 3.4

Figure 3.5

Figure 3.6

Figure 3.7

Figure 4.1

Figure 4.2

Figure 4.3

Figure 4.4

Figure 4.5

Figure 4.6

Figure 4.7

Figure 4.8

Figure 5.1

Figure 5.2

Figure 5.3

Figure 5.4

Figure 5.5

Figure 5.6

Figure 5.7

Figure 5.8

Figure 5.9

Figure 5.10

Figure 5.11

Figure 5.12

Figure 5.13

Figure 6.1

Figure 6.2

Figure 6.3

Figure 6.4

Figure 6.5

Figure 6.6

Figure 6.7

Figure 6.8

Figure 6.9

Figure 7.1

Figure 7.2

Figure 7.3

Figure 7.4

Figure 7.5

Figure 7.6

Figure 7.7

Figure 7.8

Figure 7.9

Figure 7.10

Figure 7.11

Figure 7.12

Figure 7.13

Figure 7.14

Figure 8.1

Figure 8.2

Figure 8.3

Figure 8.4

Figure 8.5

Figure 8.6

Figure 8.7

Figure 8.8

Figure 8.9

Figure 8.10

Figure 8.11

Figure 8.12

Figure 8.13

Figure 8.14

Figure 8.15

Figure 9.1

Figure 9.2

Figure 9.3

Figure 9.4

Figure 9.5

Figure 9.6

Figure 10.1

Figure 10.2

Figure 10.3

Figure 10.4

Figure 10.5

Figure 10.6

Figure 10.7

Figure 10.8

Figure 11.1

Figure 11.2

Figure 11.3

Figure 11.4

Figure 11.5

Figure 11.6

Figure 11.7

Figure 11.8

Figure 11.9

Figure 11.10

Figure 11.11

Figure 11.12

Figure 11.13

Figure 11.14

Figure 11.15

Figure 11.16

Figure 11.17

Figure 11.18

Figure 11.19

Figure 11.20

Figure 11.21

Figure 11.22

Figure 11.23

Figure 11.24

Figure 12.1

Figure 12.2

Figure 12.3

Figure 12.4

Figure 12.5

Figure 13.1

Figure 13.2

Figure 13.3

Figure 13.4

Figure 13.5

Figure 13.6

Figure 13.7

Figure 13.8

Figure 14.1

Figure 14.2

Figure 14.3

Figure 14.4

Figure 14.5

Figure 14.6

Figure 14.7

Figure 14.8

Figure 14.9

Figure 14.10

Figure 14.11

Figure 14.12

Figure 14.13

Figure 14.14

Figure 14.15

Figure 14.16

Figure 14.17

Figure 14.18

Figure 14.19

Figure 14.20

Figure 14.21

Figure 14.22

Figure 14.23

Figure 14.24

Figure 14.25

Figure 14.26

Figure 14.27

Figure 14.28

Figure 14.29

Figure 14.30

Figure 14.31

Figure 14.32

Figure 14.33

Figure 14.34

Figure 14.35

Figure 14.36

Figure 14.37

Figure 14.38

Figure 14.39

Figure 14.40

Figure 14.41

Figure 14.42

Figure 14.43

Figure 14.44

Figure 14.45

Figure 14.46

Figure 15.1

Figure 15.2

Guide

Cover

Table of Contents

Begin Reading

Part 1

Chapter 1

Pages

ii

iii

iv

xv

xvi

xvii

xviii

xix

xx

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

331

332

333

334

335

336

337

338

339

340

341

342

343

344

345

346

347

348

349

350

351

352

353

354

355

356

357

358

359

360

361

362

363

364

365

366

367

368

369

370

371

372

373

374

375

376

377

378

379

380

381

382

383

384

385

IEEE Press445 Hoes LanePiscataway, NJ 08854

IEEE Press Editorial BoardTariq Samad, Editor in Chief

George W. ArnoldXiaoou LiRay PerezGiancarlo FortinoVladimir LumelskyLinda ShaferDmitry GoldgofPui-In MakZidong WangEkram HossainJeffrey NanzerMengChu Zhou

Kenneth Moore, Director of IEEE Book and Information Services (BIS)

Advances in Battery Manufacturing, Service, and Management Systems

Edited by

Jingshan Li

Shiyu Zhou

Yehui Han

Copyright © 2017 by The Institute of Electrical and Electronics Engineers, Inc.

Published by John Wiley & Sons, Inc., Hoboken, New Jersey. All rights reserved

Published simultaneously in Canada

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, scanning, or otherwise, except as permitted under Section 107 or 108 of the 1976 United States Copyright Act, without either the prior written permission of the Publisher, or authorization through payment of the appropriate per-copy fee to the Copyright Clearance Center, Inc., 222 Rosewood Drive, Danvers, MA 01923, [phone], fax [phone], or on the web at www.copyright.com. Requests to the Publisher for permission should be addressed to the Permissions Department, John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, [phone], fax [phone], or online at http://www.wiley.com/go/permission.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives or written sales materials. The advice and strategies contained herein may not be suitable for your situation. You should consult with a professional where appropriate. Neither the publisher nor author shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

For general information on our other products and services or for technical support, please contact our Customer Care Department within the United States at [phone], outside the United States at [phone] or fax [phone].

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic formats. For more information about Wiley products, visit our web site at www.wiley.com.

Library of Congress Cataloging-in-Publication Data is available.

ISBN: 978-1-119-05649-2

Preface

Due to the fast development of mobile technology and renewable energy sources, battery, as a key energy storage device, has played an ever-growing important role in daily life and the world economy. Because of the unprecedent broad application of batteries, the commercial-scale manufacturing of batteries, as well as their service and management, are essential to ensure high quality, high reliability, and high performance of batteries. At present, major investment in battery-related research is on the new battery materials and design. However, the innovative system-level technologies on battery mass production, service, and management are also critical in order to materialize the impact of the emerging battery technology on the society and the economy at a large scale. Furthermore, the growing demands and rapid development in energy storages have introduced enormous challenges in battery manufacturing, service, and management. Therefore, there is a need to systematically address the methodology and theoretical foundation to study the issues and challenges in these areas.

This book volume is exclusively devoted to battery manufacturing, service, and management systems (BM2S2). It highlights the cutting edge research advances in BM2S2 and promotes an innovative integrated research framework responding to the challenges. There are three major parts included in this volume: manufacturing; service; and management.

The first part focuses on battery manufacturing systems, including modeling, analysis, design, and control, as well as economic and risk analyses.

Chapter 1 by Cai presents a comprehensive overview of lithium-ion battery and battery electric vehicle (BEV) manufacturing, with particular emphasis on the joining, assembly, and packaging of battery cells, modules, and packs. The reviews cover from different battery types, advantage and disadvantages of several battery-joining technologies, to battery manufacturing process, as well as applications from battery suppliers and BEV manufacturers.

Chapter 2 by Ju, Li, Xiao, Huang, Arinez, Biller and Deng introduces an integrated model of productivity and quality in serial production lines with repair for battery manufacturing. An analytical method to evaluate line performance is developed and identification methods for downtime and quality bottlenecks are introduced. Such a work can lead to providing a quantitative tool for production engineers to analyze and improve system performance in battery manufacturing.

Chapter 3 by Chang, Li, Biller, and Xiao presents an event-based modeling (EBM) approach for the large-format power battery manufacturing systems. Through quantifying the impacts of disruption events using sensor data, and modeling market demand as an end-of-line virtual station, the whole battery production line is analyzed, and bottleneck-based improvement strategies are proposed. Finally, real-time costing method is established based on EBM.

Chapter 4 by Jin discusses the economic and ecological benefits, principles, operational strategy and processes of battery remanufacturing. In addition, three major challenges associated with batteries remanufacturing, as well as the modeling methods and analytical solutions to address these challenges are discussed, including remaining useful life estimation of end of life (EOL) batteries; decision making for EOL batteries with uncertainty; and remanufacturing operations considering balancing and compatibility issues.

Chapter 5 by Johnson, Biller, Wang, and Biller discusses a set of analytical methods with the capability of raising the economic return while reducing the financial and operational risks in the design and operations of manufacturing ecosystem, built on battery production example at General Electric. The market demand is endogenously incorporated into production design and operations optimization, leading to higher economic returns, robust order fulfillment, and derisked management of capital-intensive projects.

The second part emphasizes on information technology's impact on service system, such as data-driven reliability modeling, failure prognosis, and decision-making methodologies for battery services.

Chapter 6 by Son, Kontar, and Zhou discusses prognosis problem in battery health management in the form of classification problem. It is shown that the joint prognostic model (JPM) outperforms the conventional logistic regression. In addition, a brief discussion on the imbalanced data issue is presented, and a possible resolution for overcoming the issue is provided by oversampling the minority class (failed batteries) or to undersampling the majority class (censored batteries).

Chapter 7 by Saha reviews the conventional approaches used in estimating battery state of charge (SOC) and state of health (SOH), as well as a more advanced algorithmic approach based on Bayesian inference. Both data-driven and model-based approaches are discussed with suggestions on how to leverage the best features of both.

Chapter 8 by Xi, Jing, Lee, and Hayrapetyan investigates recent research on battery diagnostics, prognostics, and uncertainty management especially for lithium-ion (Li-ion) batteries, such as models and diagnosis algorithms for battery SOC and SOH estimation, data-driven prognosis algorithms for predicting the remaining useful life (RUL) of battery SOC and SOH, and management of five important types of uncertainties, which play key roles for reliable battery diagnostics and prognostics.

Chapter 9 by Peng, Lu, Xie, Liu, and Liao compares several popular model aggregation techniques and presents a new alternative for lithium-ion battery prognostics. The method utilizes the mixture of probability distributions obtained from different RUL estimation models and updates the aggregation structure under a Bayesian framework. It is also extendable to more complex data-driven prognostic applications where heterogeneous models are developed.

Chapter 10 by Zhou, Man, and Son introduces a prognostic framework for estimating the RUL of batteries under hard failure. A joint modeling scheme is used to take into consideration both the degradation data and the time-to-failure data. The maximum power interval (MPI) is introduced to better assess the performance of the prognostic algorithm. Such an algorithm is suitable for applications where monitored degradation signal (e.g., internal resistance) does not have a clear preset failure threshold.

The third part addressing battery management system (BMS) intends to control and optimize battery cells, operations, and hybrid storage systems to ensure overall performance and safety, as well as EV management.

Chapter 11 by Li, Han, and Zhang reviews and compares the topologies, advantages, and disadvantages of different kinds of battery equalizers and introduces their broad applications. In addition, an integrated building block design of a distributed BMS is presented, which integrates the power electronics and the battery cell together in each building block to achieve easy reconfiguration and installation, high equalization efficiency and speed, and enhanced protection and reliability.

Since battery equalization is a critical part of the BMS, Chapter 12 by Han, Zhang, and Han presents an overview of the results to date on the issues of mathematical modeling, performance analysis, and control of battery equalization systems. In addition, the new developments in this area are discussed and the future topics are summarized.

As batteries have high energy density and relatively low cost, but low specific power and short cycle life, while supercapacitors preserve high peak power, long cycle life, but relatively low energy density and high cost, combining the two can potentially overcome the drawbacks of each single energy storage device. Chapter 13 by Ju, Zhang, Deng, and Li reviews the state of the art of battery, supercapacitor, and battery-supercapacitor hybrid energy storage system (HESS) for advanced electric vehicle applications, and discusses the optimal control methods for such HESS.

Following it, Chapter 14 by Zhang, Deng, Wu, Ju, and Li studies power management strategies for HESS in electric vehicles. The goal is to improve energy supply and power flow for better vehicle performance, energy efficiency, and extended battery life. The low-level hybrid topologies are reviewed, and high-level supervisory control methods are discussed. An integrated power management strategy to combine both time and frequency domain controls is presented.

Chapter 15 by Canis discusses the steps by which federal support for battery research has grown over the past 40 years and considers how successful the major initiatives have been in promoting development and use of electric vehicles. It also reviews some of the major battery technologies in use and on the drawing board and the framework of international competition that is shaping this infant industry.

The editors are grateful to Mr. Cong Zhao of University of Wisconsin-Madison for his substantial efforts on organizing, editing, and reviewing of the chapters, and the anonymous reviewers for their helpful comments to improve the book quality. The funding support from the Research Innovation Committee at College of Engineering in University of Wisconsin-Madison is invaluable to the success of this work. In addition, we express our deep gratitude to Mary Hatcher, Brady Chin, and Allison McGinniss of Wiley and Dr. Mengchu Zhou, Series Editor, who have provided incredible support to this book volume.

Jingshan Li

Shiyu Zhou

Yehui Han

Contributors

Jorge Arinez, Manufacturing Systems Research Lab, General Motors Research & Development Center, Warren, MI, USA

Bahar Biller, General Electric Global Research Center, Niskayuna, NY, USA

Stephan Biller, GE Global Research Center, General Electric, Niskayuna, NY, USA

Wayne Cai, Manufacturing Systems Research Laboratory, General Motors Global, R&D Center, Warren, MI, USA

William Canis, Congressional Research Service (CRS), The Library of Congress, Washington, DC, USA

Qing Chang, Department of Mechanical Engineering, Stony Brook University, Stony Brook, NY, USA

Weiwen Deng, State Key Laboratory of Automotive Simulation and Control, Jilin University, Changchun, China

Weiji Han, Department of Electrical and Computer Engineering, University of Connecticut, Storrs, CT, USA

Yehui Han, Department of Electrical and Computer Engineering, University of Wisconsin-Madison, Madison, WI, USA

Mushegh Hayrapetyan, University of Michigan—Dearborn, MI, USA

Ningjian Huang, Manufacturing Systems Research Lab, General Motors Research & Development Center, Warren, MI, USA

Xiaoning Jin, University of Northeastern, Boston, MA, USA

Rong Jing, University of Michigan—Dearborn, MI, USA

Chris Johnson, General Electric Global Research Center, Niskayuna, NY, USA

Feng Ju, Department of Industrial and Systems Engineering, University of Wisconsin, Madison, WI, USA; and State Key Laboratory of Automotive Simulation and Control, Jilin University, Changchun, China

Raed Kontar, Department of Industrial and Systems Engineering, University of Wisconsin-Madison, Madison, WI, USA

Cheol Lee, University of Michigan—Dearborn, Dearborn, MI, USA

Jingshan Li, Department of Industrial and Systems Engineering, University of Wisconsin, Madison, WI, USA; and State Key Laboratory of Automotive Simulation and Control, Jilin University, Changchun, China

Yang Li, School of Mechanical Engineering, Tongji University, Shanghai, China

Ye Li, Department of Electrical and Computer Engineering, University of Wisconsin-Madison, Madison, WI, USA

Haitao Liao, University of Arizona, Tucson, AZ, USA

Datong Liu, Harbin Institute of Technology, Harbin, P. R. China

Siyuan Lu, Harbin Institute of Technology, Harbin, 150080, P. R. China

Jianing Man, Department of Systems Engineering and Engineering Management, City University of Hong Kong, Kowloon, Hong Kong

Yu Peng, Harbin Institute of Technology, Harbin, P. R. China

Bhaskar Saha, Palo Alto Research Center, Palo Alto, CA, USA

Junbo Son, Alfred Lemer College of Business and Economics, University of Delaware, Newark, DE, USA

Shanshan Wang, General Electric Global Research Center, Niskayuna, NY, USA

Jian Wu, State Key Laboratory of Automotive Simulation and Control, Jilin University, Changchun, China

Zhimin Xi, University of Michigan, Dearborn, MI, USA

Wei Xie, University of Arizona, Tucson, AZ, USA

Guoxian Xiao, Manufacturing Systems Research Lab, General Motors Research & Development Center, Warren, USA and General Motors R&D, General Motors Corporation, Warren, MI, USA

Liang Zhang, Department of Electrical and Computer Engineering, University of Connecticut, Storrs, CT, USA

Qiao Zhang, State Key Laboratory of Automotive Simulation and Control, Jilin University, Changchun, China

Shiyu Zhou, Department of Industrial and Systems Engineering, University of Wisconsin-Madison, Madison, WI, USA

Qiang Zhou, Department of Systems Engineering and Engineering Management, City University of Hong Kong, Kowloon, Hong Kong

Part IBattery Manufacturing Systems

Chapter 1Lithium-Ion Battery Manufacturing for Electric Vehicles: A Contemporary Overview

Wayne Cai

Manufacturing Systems Research Laboratory, General Motors Global R&D Center, Warren, MI, USA

1.1 Introduction

During the last few decades, environmental concern about the petroleum-based transportation has led to renewed and stronger interest in electric vehicles (EV). In an EV, energy storage devices (such as batteries, supercapacitors) or conversion devices (such as fuel cells) are used to store or generate electricity to power the vehicle. The first highway-capable EV with mass production in the modern age was GM's EV1 [1], which used lead-acid-based batteries as onboard energy storage. With the advancement of newer generations of high-density energy storage batteries such as the metal-hydride batteries and most recently the lithium-ion (Li-ion) batteries, battery electric vehicles (BEVs) have seen tremendous growth in the past decade. Batteries used as the power and energy sources to drive BEVs are called traction batteries.

A BEV falls into one of the following four categories: hybrid electric vehicle (HEV), plug-in electric vehicle (PHEV), extended range electric vehicle (EREV), and pure BEV. An HEV is generally powered by an internal combustion engine and a battery pack. The internal combustion engine is the primary source of energy during medium or high-speed driving conditions with the batteries serving as the main power source in stop-and-go traffic as well as power assist in vehicle acceleration, where the batteries are also called power batteries. The battery pack is relatively small and recharged by the internal combustion engine and regenerative braking. An exemplary vehicle is Toyota's Prius (2015 model year), offering an EPA-estimated 50 mpg fuel economy using a small 4.3 kWh of Li-ion battery pack [2]. A PHEV operates under either the battery mode, the internal combustion engine mode, or a combination of the two modes. The battery pack, however, can be charged via an external electrical power grid. An exemplary vehicle is Toyota's Prius Plug-in [2]. Depending on the design intent and the size of the battery pack, the traction batteries in PHEV can be either power or energy batteries. An EREV differs from a PHEV in that the battery pack is relatively large and the vehicle operates primarily under the electric mode. The internal combustion engine in the vehicle is used exclusively or primarily to charge the traction batteries (although the internal combustion engine can also be used to assist the battery mode driving in special circumstances). An exemplary vehicle is GM's Chevrolet Volt [3]. A pure BEV is powered entirely electrically by an onboard battery pack through the traction motors. The battery pack is typically recharged via an external electrical power grid. Although many automakers are mass-producing BEVs in the marketplace, the most notable models are Tesla Model S [4], Nissan LEAF [5], and BMW i3 [6,7]. Figure 1.1 shows a complete landscape of major BEV manufacturers and their Li-ion battery cell suppliers. A comparison with reference [8] immediately finds significant industry evolution during the past 5 years. While every single global automotive manufacturer is now producing BEVs, a few BEV start-ups and many traction battery joint ventures have been reorganized or even gone out of business during the past few years. At the end of 2014, Panasonic, AESC, LG Chem, and BYD were the top four largest manufacturers of traction battery cell in the world, supplying batteries to Tesla Model S (pure BEV), Nissan LEAF (pure BEV), GM Chevrolet (EREV), and BYD (pure EV and PHEV), among others [9]. Table 1.1 lists some key technical data for several major BEVs in the marketplace.

Figure 1.1 Major BEV manufacturers and Li-ion battery suppliers (2015 landscape).

Table 1.1 Selected technical data for major BEVs

Toyota Prius Plug-in [2]

GM Chevy Volt [3]

Tesla Model S [4]

Nissan LEAF [5]

BMW i3 [6,7]

Model Year

2012–2015

2015

2012–2015

2013/2014

2014

Energy Storage (kWh)

4.4

16

85

24

18.8

Fuel Economy (MPGe)

58

62

89

115

124

Pure Electric Driving Range (miles)

11

39

265

75

81

Cell Manufacturer

Panasonic

LG Chem

Panasonic

AESC

Samsung SDI

# of Cells

56

288

7104

192

96

Cell Format

Prismatic

Pouch

Cylindrical

Pouch

Prismatic

Cell-to-Cell Joining

Bolting

Ultrasonic welding

Wire bonding

Ultrasonic welding

Laser welding

# of Modules

3

9

16

48

8

Module-to-Module Joining

Bolting

1.2 Li-Ion Battery Cells, Modules, and Packs

This section reviews different formats and structures of Li-ion battery cells, modules, and packs as seen in BEVs. The focus is on the characteristics relevant to the joining, assembly, and packaging rather than the battery chemistries, functions, and performances.

1.2.1 Formats of Li-Ion Battery Cells

A battery cell is the most basic and fully independent operating unit in a storage battery. It is primarily composed of positive and negative electrodes, separators, electrolytes, and a container. In the current marketplace, there exist primarily three different cell formats for a traction battery cell: cylindrical, prismatic, and pouch. Due to legacy reasons, the cylindrical format has been the mainstream ranging from alkaline (such as AA cells) to NiMH to Li-ion (such as 18650) cells. However, when rechargeable batteries such as NiMH or lithium-ion batteries have been considered for automotive battery applications, other formats of battery cells such as prismatic and pouch types have been developed to improve the volumetric efficiency [10], accommodate thermal management, and/or packaging requirement.

1.2.1.1 Cylindrical Cells

Figure 1.2a shows an 18650 cylindrical cell (i.e., 18 mm in diameter and 65 mm in height) as used in Tesla's EVs. Figure 1.2b is an anatomy of a representative cylindrical cell [11], although the exact structure varies for different manufacturers. The cylindrical cells are known to be less volumetric efficient than prismatic cells. However, the commercial production lines for many cylindrical cells allow for some advanced passive safety features such as positive temperature coefficient (PTC) and current interrupt device (CID) (Figure 1.2c and d) to be built in reference [12]. PTC is a type of material that demonstrates significantly high electrical resistivity at high temperatures so as to melt the PTC itself to break the circuit at higher electrical current [13]. CID is another passive device that breaks when the pressure inside a cell reaches high levels. Normally, when the cell is overheated, such as in a thermal runaway, the pressure increases to a level to break the CID and thereof the circuit [13]. Although manufacturers make cylindrical cells of many different dimensions, 18650 cells are the most produced cells due in part to Tesla's needs.

Figure 1.2 Cylindrical format Li-ion battery cells.

1.2.1.2 Prismatic Cells

For a prismatic Li-ion battery cell, the current collectors (after anode and cathode coatings) and separators are either wound, as shown in Figure 1.3 [14], or laminated (not shown), and then inserted into a prismatic shaped container and sealed all together after filling in the electrolyte. The container is normally made of steels or aluminum alloys (although can be plastics too) and offers rigidity for dimensioning, handling, and protecting the cell. No standard exists as to the size of prismatic cells.

Figure 1.3 An anatomy of a prismatic Li-ion battery cell. (Reproduced from Ref. [14] with permission from Cadex Electronics, Inc.)

1.2.1.3 Pouch Cells

A number of BEV manufactures use pouch cells for light-weighting, better volumetric energy density, and high spatial efficiency. Inside the cells (Figure 1.4) [15], multiple layers of precut positive/negative electrodes and separators are stacked with electrode leads (or tabs) and then welded. Then the edges of the aluminum-laminated films (i.e., the pouch materials) are heat sealed. Similar to prismatic cells, no standards exist as to the size of pouch cells.

Figure 1.4 Schematics of pouch-type cells. (Reproduced from Ref. [15] with permission from Automotive Energy Supply Corporation.)

1.2.2 Battery Modules and Pack

A module is a group of two or more battery cells joined together that can be replaced in maintenance and repair without impacting the rest of the battery pack. A module is also typically the minimum unit installed with safety components, power and heat management electronics. Modules can vary in their sizes, see Table 1.1. A pack is a collection of all battery modules in the BEVs. The enclosure of a battery pack is sealed and watertight; it can protect the modules inside in the event of vehicle impact or crash. Due to excessive flexibility and softness of the pouch cells, holding components are generally needed to prevent pouch cells from having dimension and alignment issues. Such holding components can include frames, rigid cases, and supporting trays.

1.3 Joining Technologies for Batteries

This section reviews a few selected joining technologies that are most pertinent to Li-ion battery cell and pack manufacturing, that is, ultrasonic welding, resistance welding, laser welding, wire bonding, and mechanical joining. The advantages and limitations are discussed. The applications in major BEVs will be discussed in Section 1.4.

1.3.1 Ultrasonic Metal Welding

1.3.1.1 Overview

Ultrasonic metal welding (USMW) is a process in which a high frequency, usually 20 kHz or above, of ultrasonic energy is used to produce relative lateral motions to create solid-state bonds between two or multiple metal sheets clamped under pressure. The high-frequency shear forces induce alternating metal surface friction and heat to produce a weld. A schematic of the USMW system is shown in Figure 1.5 [16]. It can be used to join a wide range of metal sheets or thin foils, see Figure 1.6 [17].

Figure 1.5 A schematic of USMW system. (Reproduced from Ref. [16] with permission from Cadex Electronics, Inc.)

Figure 1.6 (a) Aluminum wire welding onto copper. (b) Copper and aluminum welding. (c) Multilayered copper foil welding. (Reproduced from Ref. [17] with permission from Nippon Avionics Co., Ltd.)

USMW is considered a solid-state welding. In contrast to fusion welding processes, USMW has several inherent advantages. The main advantage of USMW lies in its excellent welding quality for thin, dissimilar, and multiple layers of highly conductive metals (such as Cu and Al), which is crucial in battery cell joining and for battery tab joining [18]. Another advantage is the low heat-affected zone. USMW also produces a very thin layer of bonding interfaces (typically a few microns) and therefore eliminates metallurgical defects that commonly exist in most fusion welds such as porosity, hot-cracking, and bulk intermetallic compounds. Therefore, it is often considered the best welding process for Li-ion battery applications.

1.3.1.2 Ultrasonic Welding Physics

The bonding mechanisms for USMW are not completely understood. A combination of the following four mechanisms may attribute to the bonding: (a) micromelting (e.g., a few microns of thin interface layer melting), (b) metal interlocking (due to plastic deformation, particularly the severe deformation caused by sonotrode knurls), (c) diffusion, and (d) chemical bonding (such as covalent and metallic bonding). To better understand different phases generated at the bonding interfaces, an Al-Cu phase diagram such as the one in reference [19] should be consulted.

Figure 1.7 [20] illustrates how the joints of multiple metal sheets are generated in ultrasonic welding. It is believed that the propagation of the welds is through the top layer (i.e., the layer in contact with the sonotrode) to the bottom layer (i.e., the layer in contact with the anvil) [20].

Figure 1.7 Weld propagation in USMW of multiple sheets.

There are three important physical attributes pertaining to the quality of an ultrasonic weld:

The temperatures at the bonding interfaces.

Recent researches [21,22] were able to measure in situ the welding temperatures using the self-developed thin-film thermocouples and thermopile sensors. Although it was found that the measured temperature is 660°C for Cu-Cu ultrasonic welding at 1 mm away for the weld spot, it was uncertain whether melting actually occurred at the weld spots. According to the Fick's laws of diffusion [23], temperature is the most critical factor in diffusion bonding to ensure proper rate of solid-state atomic diffusion between the interfacing metals. Therefore, from both melting and diffusion points of view, higher temperature will be beneficial to the welding quality. In this respect, research has been performed to predict the welding temperature [24]. Higher welding temperatures and more uniform welding temperature distribution can also be achieved via a number of innovative methods shown in Figure 1.8 [24]. According to reference [18], in USMW, if the welding parameters (e.g., vibration amplitude, welding pressure, and welding time) are set too low, low temperatures at the weld interfaces result in low bonding strength.

Fracture and perforation of the metals at the weld spots.

The second attribute critical to the weld quality is the fracture and perforation of the metals. Figure 1.9a is a sketch of a two-layered circular ultrasonic weld whose size is dictated by the sonotrode knurl area as shown in Figure 1.9b. According to reference [18], if the welding parameters (e.g., vibration amplitude, welding pressure, and welding time) are set too high, excessive plastic deformation and/or higher temperatures can result in metal fracture and perforation at the weld spots and consequently poor joint strength, although the interfacial bonding strength can be higher. Figure 1.10 shows micrographs of several ultrasonic welds including a Cu-Cu weld (Figure 1.10a), where the top Cu layer is fractured/perforated fairly severely.

Structural stress and failure induced by USMW.

Since the ultrasonic vibration is a mechanical wave that can propagate to cause stresses throughout the entire system, it is important to ensure that the structure (under specific boundary conditions) does not have a natural frequency at or near the ultrasonic frequency. As an example, paper [27] studied the distribution of stresses in the battery tab during ultrasonic welding using an analytical mechanistic model, as shown in Figure 1.11. The main focus of the study was to assess the effects of the elastic vibration of the battery tab on the stress development near the weld spot area during welding. It was found that the natural frequencies of the tab depend on the length between the weld spot and tab-end (interface between the battery tab and cell pouch), boundary conditions of the tab-end, the cross-sectional area, and the material of the tab. Therefore, it is important to design the weld position on the tab such that the tab's natural frequencies stay away from 20 kHz as much as possible to minimize tab stresses. Further, the stresses near the weld area could exceed the tab material's yield strength and cause fatigue fracture.

For larger and complex structures, modal analyses using finite-element analysis should be performed to extract the natural frequencies of a welding system under different design options in order to optimize the system to move away from resonance at the ultrasonic welding frequency. Further, steady-state dynamics analysis should also be performed to investigate the field outputs such as the stress/strain/displacement under the ultrasonic welding vibration input (such as +/–20 μm of sinusoidal input of 20 kHz) to assess the soundness of the design. As another example, Figure 1.12 depicts one welding configuration on a battery interconnect circuit board, consisting of a positive and a negative battery tab welded with a U-shaped interconnect busbar [28]. Welding of the tabs is performed on one side (i.e., the left-hand side Cu tab welding with the interconnect) followed by the subsequent welding on the other side of the interconnect. The joint made by the first welding is termed as “existing weld,” and the joint made by the subsequent welding action is called “active weld.” The ultrasonic vibration generated during the active weld welding may place enough stresses on the system and destroy the existing weld on the left-hand side [28]. Therefore, the system (including the choice of materials and boundary conditions) should be designed to avoid resonance under ultrasonic welding.

Figure 1.8 Temperature contours at the end of a 500 ms ultrasonic welding for (a) baseline model, (b) insulated anvil, (c) 100°C preheating, and (d) 0.6 mm thick busbar instead of 0.9 mm. (Reproduced from Ref. [24] with permission from ASME.)

Figure 1.9 (a) Two layers of metals with sonotrode knurl marks. (b) A sonotrode (with knurls on the tip).

Figure 1.10 Micrographs of ultrasonic welds.

Figure 1.11 A pouch battery cell assembly (with the pouch partially shown) under ultrasonic vibration. (Reproduced from Ref. [27] with permission from ASME.)

Figure 1.12 Modeling of battery welding system: (top) boundary conditions and (bottom) finite-element mesh.

1.3.1.3 Ultrasonic Welding Quality Evaluation

Standards and guidelines for destructive, postweld quality evaluation are well established [29] for many types of welds, including ultrasonic spot welds [30,31]. They generally prescribe the quality evaluation and testing procedures. As for nondestructive evaluation (NDE), a variety of methods are developed using ultrasonic probes, eddy current, X-ray/CT, electrical resistance, etc. Success of any of the methods largely depends on the nature of the weld and defect types, and significant challenges exist in interpreting the test data. Jia et al. [32] reported that stereography method has the potential for accurate NDE for ultrasonic welds. In terms of real-time, online welding process monitoring and NDE, no standard or guideline exists, although many sensors such as temperature sensors (including thermocouples, infrared (IR)), force/pressure sensors (such as load cells), displacement (such as linear variable differential transformer (LVDT), accelerometers, and acoustic sensors are reportedly used [33]. In particular, online monitoring and quality assurance methods were developed for GM's Chevy Volt [34] and Cadillac ELR [35].

1.3.2 Resistance Welding

Resistance welding relies on a higher contact resistance at the joint interface to induce a localized joule heating and fusion of materials when the electrical current is applied through two electrodes. Resistance welding process is fast and generally automated. It has wide applications in sheet metal industries, particularly for steels welding. Although resistance welding has also been used in the battery welding for decades, its usage was primarily limited to low current-carrying applications and faces challenges in high-power BEVs:

Li-ion battery metals use highly electrically and thermally conductive materials such as aluminum and copper. These metals are difficult to weld using the conventional resistance spot welding technology, particularly when the contact resistance(s) at the metal interface(s) becomes low. It hence requires very large electrical current density (i.e., current vs. weld size) to be applied in the welding circuit to generate enough joule heat at the intended weld interfaces. A steady stream of recent advances has given users much improved capabilities to control various aspects of the process. For example, projection resistance welding method can sometimes be used where a small metal projection is introduced at one of the metals to reduce the total contact area of the metals and hence increase the current density. Another solution is to increase the current density by using a special type of resistance welder called capacitive discharge welder [36] to provide very high welding current (such as 10–100 kA) in a very short period of time (such as 10 ms). Nevertheless, it is still very difficult to produce a large-sized weld nugget for battery metals because of the extremely high electrical current density required.

As is the case for all fusion welding technologies of dissimilar materials, welds are difficult to form due to different melting temperatures; in addition, a large amount of intermetallics is typically produced, making the weld brittle with very high electrical resistivity.

When welding multiple layers, it is very difficult to ensure homogenous melting at all the interfaces.

Figure 1.13 [37] and Figure 1.14 [38] shows the resistance welding/welds using single-side welding electrodes, that is, two electrodes are on the same side of the metals to form a closed current conducting circuit instead of the more conventional process of two-sided resistance welding (not shown) with the two electrodes on each side of the metals. As early as 2004, NASA [37] set process specifications for the resistance spot welding of battery and electronic assemblies, where battery assemblies are considered to be nonstructural without load-carrying requirement.

Figure 1.13 Resistance spot welding of battery and electronic assemblies. (Reproduced from Ref. [37]. Public domain.)

Figure 1.14 Battery cell resistance spot welding by (a) Amada Miyachi (reproduced from Ref. [36] with permission from Amada Miyachi) and (b) Sunstone Engineering (reproduced from Ref. [38] with permission from Sunstone).

1.3.3 Laser Beam Welding

Laser beam welding (LBW), or simply laser welding, is a welding technique to join workpieces through the use of the high power beam of laser. The process has been frequently used in high-volume applications, but recently it has also been used in electronics and battery industries. Figure 1.15 shows laser welding of busbars to cylindrical battery cans [39]. Figure 1.16a shows a laser seam welding of an aluminum can [39]. In battery tab welding, as described in Figure 1.16b, weld penetration must be controlled accurately so that the weld nugget does not penetrate into the can [39].
