Basic Geological Mapping E-Book

Richard J. Lisle

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Serie: The Geological Field Guide Series
• Sprache: Englisch

Seitenzahl: 349

Veröffentlichungsjahr: 2011

Beschreibung

Part of The Geological Field Guide Series, Basic Geological Mapping, 5th Edition is an essential basic guide to field techniques in mapping geology. Now completely revised and updated the book retains the concise clarity which has made it an indispensable instant reference in its previous editions. It provides the reader with all the necessary practical information and techniques that they will need while carrying out work in the field, covering a wide spectrum of different conditions, needs and types of countries. This edition covers new developments in technology including Google Earth and the use of GPS. This is an ideal field guide to geological mapping for 2nd/3rd year undergraduates of Geology, Hydrogeology and Geological Engineering.

Leseprobe

Table of Contents

Title Page

Copyright

The Geological Field Guide Series

Preface to The Fourth Edition

Preface to The Fifth Edition`

Chapter 1: Introduction

1.1 Outline and Approach

1.2 Safety

1.3 Field Behaviour

1.4 A Few Words of Comfort

Chapter 2: Field Equipment

2.1 Hammers and Chisels

2.2 Compasses and Clinometers

2.3 Hand Lenses

2.4 Tapes

2.5 Map Cases

2.6 Field Notebooks

2.7 Scales

2.8 Protractors

2.9 Pencils, Erasers and Mapping Pens

2.10 Acid Bottles

2.11 Global Positioning System (GPS) and Mobile Phones

2.12 Other Instruments

2.13 Field Clothing

Chapter 3: Topographic Base Maps

3.1 Types of Geological Map

3.2 Topographic Base Maps

3.3 Geographic Coordinates and Metric Grids

3.4 Grid Magnetic Angle

3.5 Position Finding on Maps

3.6 Use of Air Photography as a Mapping Tool

3.7 Suitability of Images for Geological Mapping

Chapter 4: Methods of Geological Mapping

4.1 Strategy for the Mapping Programme

4.2 Mapping by Following Contacts

4.3 Traversing

4.4 Exposure Mapping

4.5 Mapping in Poorly Exposed Regions

4.6 Superficial Deposits

4.7 Drilling

4.8 Geophysical Aids to Mapping

4.9 Large-Scale Maps of Limited Areas

4.10 Underground Mapping

4.11 Photogeology

Chapter 5: Technological Aids to Mapping

5.1 Digital Terrain Models

5.2 Topographic Surveying Techniques

Chapter 6: Field Measurements and Techniques

6.1 Measuring Strike and Dip of Planar Structures

6.2 Plotting Strike and Dip

6.3 Recording Strike and Dip

6.4 Measuring Linear Features

6.5 Folds

6.6 Faults

6.7 Thrusts

6.8 Joints

6.9 Unconformities

6.10 Map Symbols

6.11 Specimen Collecting

6.12 Field Photography

6.13 Panning

Chapter 7: Mappable Rock Units and Lithology

7.1 Lithostratigraphy and Sedimentary Rocks

7.2 Sedimentary Formations

7.3 Rock Descriptions

7.4 Identifying and Naming Rocks in the Field

7.5 Fossils

7.6 Phaneritic Igneous Rocks

7.7 Aphanitic Igneous Rocks

7.8 Veins and Pegmatites

7.9 Igneous Rocks in General

7.10 Pyroclastic Rocks

7.11 Metamorphic Rocks

7.12 Economic Geology

Chapter 8: Field Maps and Field Notebooks

8.1 Field Maps

8.2 Field Notebooks

Chapter 9: Fair Copy Maps and Other Illustrations

9.1 Fair Copy Maps

9.2 Transferring Topography

9.3 Transferring Geology

9.4 Lettering and Symbols

9.5 Formation Letters

9.6 Layout

9.7 Colouring

9.8 Stratigraphic Column

9.9 Overlays

9.10 Computer Drafting of the Fair Copy Map

Chapter 10: Cross-Sections and 3D Illustrations

10.1 Cross-Sections

10.2 Method of Apparent Dips

10.3 Down-Plunge Projection Method

10.4 Balanced Cross-Sections

10.5 Columnar Sections

10.6 Block Diagrams

10.7 Models

Chapter 11: Geological Reports

11.1 Preparation

11.2 Revising and Editing

11.3 Layout

11.4 The ‘Introduction’

11.5 Main Body of the Report

11.6 The ‘Conclusions’ Section

11.7 Text Illustrations

11.8 References

11.9 Appendices

11.10 Some Final Thoughts

Appendix A: Adjustment of a Closed Compass Traverse

Appendix B: Field Equipment Checklist

Appendix C: Indicators of Stratigraphical Way-Up

Appendix D: Useful Chart and Tables

References

Selected Map Symbols

Colour Plates

Index

This edition first published 2011 © 2011 by John Wiley & Sons, Ltd.

Wiley-Blackwell is an imprint of John Wiley & Sons, formed by the merger of Wiley's global Scientific, Technical and Medical business with Blackwell Publishing.

Registered office: John Wiley & Sons, Ltd, The Atrium, Southern Gate, Chichester, West Sussex,

Editorial Offices: 9600 Garsington Road, Oxford, OX4 2DQ, UK

The Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, UK

111 River Street, Hoboken, NJ 07030-5774, USA

For details of our global editorial offices, for customer services and for information about how to apply for permission to reuse the copyright material in this book please see our website at www.wiley.com/wiley-blackwell.

The right of the author to be identified as the author of this work has been asserted in accordance with the UK Copyright, Designs and Patents Act 1988.

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, except as permitted by the UK Copyright, Designs and Patents Act 1988, without the prior permission of the publisher.

Designations used by companies to distinguish their products are often claimed as trademarks. All brand names and product names used in this book are trade names, service marks, trademarks or registered trademarks of their respective owners. The publisher is not associated with any product or vendor mentioned in this book. This publication is designed to provide accurate and authoritative information in regard to the subject matter covered. It is sold on the understanding that the publisher is not engaged in rendering professional services. If professional advice or other expert assistance is required, the services of a competent professional should be sought.

Library of Congress Cataloging-in-Publication Data

Lisle, Rixhard J.

Basic geological mapping.– 5th ed. / Richard J. Lisle, Peter J. Brabham, and John W. Barnes.

p. cm.

Rev. ed. of: Basic geological mapping / John W. Barnes, with Richard J. Lisle. 4th ed. Includes index.

ISBN 978-0-470-68634-8 (pbk.)

1. Geological mapping. I. Brabham, Peter. II. Barnes, J. W. (John Wykeham), 1921- III. Barnes, J. W. (John Wykeham), 1921- Basic geological mapping. IV. Title.

QE36.B33 2011

550.22'3–dc23

2011022844

ISBN: 978-0-470-68634-8

A catalogue record for this book is available from the British Library.

This book is published in the following electronic format: ePDF 978-1-119-97402-4;ePub 978-1-119-97751-3; MOBI 978-1-119-97752-0

The Geological Field Guide Series

The Field Description of Metamorphic Rocks, Norman Fry

The Mapping of Geological Structures, Ken McClay

Field Geophysics, Fourth edition John Milsom

The Field Description of Igneous Rocks, Second edition Dougal Jerram and Nick Petford

Sedimentary Rocks in the Field, Fourth edition Maurice Tucker

Preface to The Fourth Edition

This book is a basic guide to field techniques used in geological mapping. It is meant to be kept in camp with you and even carried in your rucksack in the field. In addition, because no piece of geological mapping can be considered complete until the geology has been interpreted and explained, chapters are provided on drawing cross-sections, on preparing and presenting ‘fair copy’ maps, and on presenting geological diagrams from your fieldwork suitable for inclusion in your report. A report explaining the geology is an essential part of any field project, and a brief chapter on the essentials for writing and illustrating it concludes this book. Some emphasis, too, is given to field sketch-mapping because many reports lack those large-scale detailed maps of small areas that can often explain complex aspects of the geology that cannot be shown on the scale of the field map being used, and that are difficult to describe in words. Attention is also given to field notebooks, which are, in many cases, deplorable.

It is assumed that readers of this book have already had at least one year of university or equivalent geology, and have already been told what to look for in the field. Geological mapping cannot, however, be taught in lectures and the laboratory: it must be learnt in the field. Unfortunately, only too often, trainee geologists are left largely to their own devices, to sink or swim, and to learn to map for themselves with a minimum of supervision on ‘independent’ mapping projects. It is hoped that this book will help in that task.

John W. Barnes and Richard J. Lisle

2003

Preface to The Fifth Edition

This fifth edition of Basic Geological Mapping was revised without the help of John Wakeham Barnes who sadly passed away in 2007. On the suggestion of referees we have updated the text by including mention of modern technological aids and data that are used in modern geological mapping, such as applied geophysics, digital terrain models, and optical and GPS-based surveying. There has also been more emphasis given to structural geology and cross-section construction. Whilst making these additions we have been conscious of the need to maintain John's successful formula; to offer a practical guide for the student undertaking a mapping project with a minimum of resources and academic supervision.

We are grateful for the advice of Jim Hendry and Rob Strachan (University of Portsmouth), Chris Berry and Alun Rodgers (Cardiff University) and the book's reviewers.

Richard J. Lisle and Peter J. Brabham

January 2011

Chapter 1

Introduction

Most geological maps record the regional distribution of rocks belonging to different formations. However, such maps reveal far more than where we could find rocks belonging to a given formation. The geometrical shape of the different formations on the geological map can also be interpreted in terms of the geological structure and geological history of the region concerned. As an earth scientist you must remember that accurate geological maps form the basis of most geological work, even laboratory work. They are used to solve problems in earth resource exploration (minerals and hydrocarbons), civil engineering (roads, dams, tunnels, etc.), environmental geoscience (pollution, landfill) and hazards (landslides, earthquakes, etc.). Making a geological map is therefore a fundamental skill for any professional geologist. As Wallace (1975) states, ‘There is no substitute for the geological map and section—absolutely none. There never was and there never will be. The basic geology still must come first—and if it is wrong, everything that follows will probably be wrong.’

There are many kinds of geological map, from small-scale reconnaissance surveys to large-scale detailed underground maps and engineering site plans, and each is made using different techniques. In this textbook, however, we are concerned only with the rudiments of geological mapping. The intention is to provide basic methods and good field practice on which you can further build, and adapt, to deal with a wide range of types of geological mapping.

1.1 Outline and Approach

This book is arranged in what is hoped is a logical order for those about to go into the field on their first independent mapping project. This first chapter includes the important issue of fieldwork safety and appropriate conduct during fieldwork, which should always be considered before anything else. The equipment you will need for mapping is described in Chapter 2, which is followed by a chapter devoted to the many types of geological map you may have to deal with some time during your professional career. A description follows of the different kinds of topographic base maps that may be available on which to plot your geological observations in the field. Methods to locate yourself on a map are also described, and advice is given on what to do if no topopgraphic base maps at all are available.

The following four chapters describe the methods, techniques and strategies used in geological mapping, including a brief description of photogeology—that is, the use of aerial photographs in interpreting geology on the ground. A further chapter is devoted to the use of field maps and those most neglected items, field notebooks.

The last three chapters concern ‘office work’, some of which may have to be done whilst still at your field camp. They cover methods of drawing cross-sections and the preparation of other diagrams to help your geological interpretation. Advice is also given on preparing a ‘fair copy’ geological map that shows your interpretation of the data from your field map. However, a geological map is not, as is sometimes supposed, an end in itself. The whole purpose is to explain the geology of the area and your map is only a part of that process: a report is also needed to explain the geological phenomena found in the area and the sequence of geological events. Chapter 11 is a guide on how to present this important part of the geological mapping project.

The approach here is practical: it is basically a ‘how to do it’ book. It avoids theoretical considerations. It is a guide to what to do in the field to collect the evidence from which conclusions can be drawn. What those conclusions are is up to you, but bear in mind what the eminent geologist Lord Oxburgh has said about mapping—that making a geological map is one of the most intellectually challenging tasks in academia (Dixon, 1999).

1.2 Safety

DO NOT PROCEED UNTIL YOU HAVE READ THIS SECTION!

Geological fieldwork is not without its hazards. In Britain, field safety is covered by the Health and Safety at Work Act 1974, and its subsequent amendments. Both employers and workers have obligations under the Act and they extend equally to teachers and students.

The safety risks depend on the nature of the fieldwork as well as on the remoteness, weather conditions and topography of the area being mapped. Before starting the mapping project, a formal risk assessment should be carried out. This will determine the safety precautions and the equipment to be carried whilst in the field. Table 1.1 lists some common risks, but your risk assessment must also consider the specific dangers associated with the area to be mapped. This will involve doing your homework before leaving for the mapping, for example consulting topographic maps, finding the address of nearest medical services, looking at tide tables, and so on.

Table 1.1 Common safety hazards associated with geological mapping

RiskPrecautionsFall from steep slopesStay away from cliffs, steep slopes, quarry edges, overgrown boulder fields, and so on. Do not rely on Global Positioning System (GPS) but examine a topographic map to identify steep slopes and plan your route. Avoid climbing; leave dangerous exposures unmapped rather than take risks. Do not run down slopes. In mountains but not on a path, stay put in dense mist, fog and darknessStruck by falling rock and splinters from hammeringAvoid rock overhangs; wear a helmet if near cliffs, quarry faces. Do not enter mines or caves. When hammering always use safety goggles and take care with bystanders and passers-byDrowning after being swept away by waves, tides and floodsAvoid the water's edge at sea, lakes and rivers. Consult tide tables. Do not enter caves, mines, potholes. Do not attempt to cross fast-flowing riversCannot be reached by emergency servicesWork in pairs, or in close association; leave details of the day's route in camp before leaving for the field; wear bright clothing, carry a mobile phone, whistle, torch, flashing LED beacon or a mirror to attract the attention of passers-by or mountain rescue teamsExposure, an extreme chilling arising from sudden drop in temperatureThe symptoms range from uncontrolled shivering, low body temperature, exhaustion and confusion. Carry warm clothing and waterproofs, thermal safety blanket, matches, emergency rations (e.g. glucose tablets, water)Motoring accidentDrive carefully on narrow mountain roads; at roadside exposures take care with passing traffic and wear high-visibility jackets. Never drive whilst under the influence of alcohol or drugs.

A geologist should be able to swim, even if fully clothed. If you swim you are less likely to panic when you slip off an outcrop into a river; or from weed-covered rocks into the sea or a rock pool, or even if you just fall flat on your face when crossing a seemingly shallow stream. Such accidents happen to most of us sometime. If you are faced by something risky, play it safe, especially if you are on your own. A simple stumble and a broken ankle in a remote area can suddenly become very serious if nobody knows where you are and you are out of mobile phone coverage.

In some northern latitudes (e.g. northern Canada, Svalbard) geologists have to carry guns and flares to ward off the unwanted attentions of polar bears. So if you are planning work abroad, do your homework on special dangers before you go.

1.3 Field Behaviour

Geologists spend much of their time in the open air and, more often than not, their work takes them to the less inhabited parts of a country. If they did not like being in open country, presumably they would not have become geologists in the first place: consequently, it is taken for granted that geologists are conservation-minded and have a sympathetic regard for the countryside and those who live in it. Therefore, remember the following:

1. Do not leave gates open, climb wire fences or drystone walls or trample crops, and do not leave litter or disturb communities of plants and animals.

2. Do not hammer for the sake of it. Greenly and Williams (1930, p. 289) observe that ‘indiscriminate hammering is the mark of a beginner’ (several key localities once showing beautiful structures have been defaced by geological hammering, drilling and graffiti). When you are collecting specimens do not strip out or spoil sites where type fossils or rare minerals occur. Take only what you need for your further research.

3. Before you embark on any field programme you should have studied your public access rights on footpaths using maps or web-based enquiry. In the UK, you do not have the right to walk wherever you want, but open access to many remote areas is now covered by the Countryside and Rights of Way Act 2000. These are typically areas of mountain, moor, heathland, downland and registered common land; further details can be found on the Ramblers website. When in the field always ask permission to enter any private land when not on a public footpath. Most owners are willing to cooperate with geology students if they are asked politely first; landowners are usually very interested in what lies beneath their land, but understandably get very annoyed to find strangers sampling their rocks uninvited.

If working in a foreign country, carry a simple A5 size laminated card explaining in the local language who you are and what you are doing; this often diffuses any conflict and confusion with landowners due to your poor communication skills. Bear in mind that irate farmers can inhibit/restrict geological activities in an area for years to come, and this has already happened in parts of Britain. Many other countries are less populated and have open space, and the situation may be easier, but every country has some land where owners expect you to consult them before working there. If in doubt, ask! (See also the Geological Fieldwork Code published by the Geologists' Association, 2000.)

1.4 A Few Words of Comfort

Finally, some cheering words for those about to start their first piece of independent mapping. The first week or so of nearly every geological mapping project can be depressing, especially when you are on your own in a remote area. No matter how many hours are spent in the field each day, little seems to show on the map except unconnected fragments of information that have no semblance to an embryonic geological map. Do not lose heart: this is quite normal. Like solving a jigsaw, the first stages are always slow until a pattern starts to emerge; then the rate of progress increases as the separate pieces of information start fitting together.

The last few days of fieldwork are often frustrating for, no matter what you do, there always seems to be something left to be filled in. When this happens, check that you do have all the essential information and then work to a specific finishing date. Otherwise you will never finish your map.

Detailed fieldwork preplanning, executing a daily field plan and good time management are often the keys to success.
