Broadband Optical Access Networks E-Book

Leonid G. Kazovsky

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Sprache: Englisch

Seitenzahl: 477

Veröffentlichungsjahr: 2011

Beschreibung

Broadband optical access network is an ideal solution to alleviate the first/last mile bottleneck of current Internet infrastructures. Richly illustrated throughout to help clarify important topics, Broadband Optical Access Networks covers the architectures, protocols enabling technologies of broadband optical access networks, and all current and future competing technologies for access networks. This comprehensive work presents the evolution of optical access networks, including reach extension, bandwidth enhancement, and discusses the convergence of optical and wireless technologies for broadband access, making it an invaluable reference for researchers, electrical engineers, and graduate students.

Leseprobe

CONTENTS

Cover

Half Title page

Title page

Copyright page

Foreword

Preface

Acknowledgments

Chapter 1: Broadband Access Technologies: An Overview

1.1 Communication Networks

1.2 Access Technologies

1.3 Digital Subscriber Line

1.4 Hybrid Fiber Coax

1.5 Optical Access Networks

1.6 Broadband over Power Lines

1.7 Wireless Access Technologies

1.8 Broadband Services and Emerging Technologies

1.9 Summary

References

Chapter 2: Optical Communications: Components and Systems

2.1 Optical Fibers

2.2 Optical Transmitters

2.3 Optical Receivers

2.4 Optical Amplifiers

2.5 Passive Optical Components

2.6 System Design and Analysis

2.7 Optical Transceiver Design for TDM PONS

2.8 Summary

References

Chapter 3: Passive Optical Networks: Architectures and Protocols

3.1 PON Architectures

3.2 PON Standards History and Deployment

3.3 Broadband PON

3.4 Gigabit-Capable PON

3.5 Ethernet PON

3.6 IEEE 802.av-2009 10GEPON Standard

3.7 Next-Generation Optical Access System Development in the Standards

3.8 Summary

References

Chapter 4: Next-Generation Broadband Optical Access Networks

4.1 TDM-PON Evolution

4.2 WDM-PON Components And Network Architectures

4.3 Hybrid TDM/WDM-PON

4.4 WDM-PON Protocols And Scheduling Algorithms

4.5 Summary

References

Chapter 5: Hybrid Optical Wireless Access Networks

5.1 Wireless Access Technologies

5.2 Hybrid Optical–Wireless Access Network Architecture

5.3 Integrated Routing Algorithm for Hybrid Access Networks

5.4 Summary

References

Index

Broadband Optical Access Networks

Copyright © 2011 by John Wiley & Sons, Inc. All rights reserved.

Published by John Wiley & Sons, Inc., Hoboken, New Jersey.Published simultaneously in Canada.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, scanning, or otherwise, except as permitted under Sections 107 or 108 of the 1976 United States Copyright Act, without either the prior written permission of the Publisher, or authorization through payment of the appropriate per-copy fee to the Copyright Clearance Center, Inc., 222 Rosewood Drive, Danvers, MA 01923, [phone], fax [phone], or on the web at www.copyright.com. Requests to the Publisher for permission should be addressed to the Permissions Department, John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, [phone], fax [phone], or online at http://www.wiley.com/go/permission.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives or written sales materials. The advice and strategies contained herein may not be suitable for your situation. You should consult with a professional where appropriate. Neither the publisher nor author shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

For general information on our other products and services or for technical support, please contact our Customer Care Department within the United States at [phone], outside the United States at [phone] or fax [phone].

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic format. For more information about Wiley products, visit our web site at www.wiley.com

Library of Congress Cataloging-in-Publication Data Is Available

Kazovsky, Leonid G.

Broadband optical access networks / Leonid G. Kazovsky, Ning Cheng, Wei-Tao Shaw, David Gutierrez, Shing-Wa Wong.

Includes index.

ISBN 978-0-470-18235-2

oBook ISBN: 978 0470 910931 ePDF ISBN: 978 0470 910924 ePub ISBN: 978 0470 922675

FOREWORD

Broadband optical access networks are crucial to the future development of the Internet. The continuing evolution of high-capacity, low-latency optical access networks will provide users with real-time high-bandwidth access to the Web essential for such emerging trends as immersive video communications and ubiquitous cloud computing. These ultrahigh-speed access networks must be built under challenging economic and environmental imperatives to be “faster, cheaper, and greener.” This book presents in a clear and illustrative format the technical and scientific concepts that are needed to accomplish the design of new broadband access networks upon which users will surf the wave of the twenty-first-century Internet.

The book is coauthored by Professor Leonid Kazovsky and his graduate students. Professor Kazovsky is a recognized leader and authority in the field and has a long and distinguished track record for making highly timely and significant research contributions within the general area of optical communication systems and optical networks. He has contributed over the last 40 years in the areas of wavelength-division-multiplexed (WDM) and coherent transmission systems for the core network as well as transmission systems and network architectures and technologies at the metro and access levels. This book builds on Professor Kazovsky’s research conducted at Bellcore (where he worked in the 1980s), at Stanford University (where he has worked since 1990), and at numerous European research organizations during sabbaticals in the UK, the Netherlands, Italy, Denmark, and (most recently) Sweden. This rich set of influences gives the book and its readers the benefits of broad exposure to diverse research ideas and approaches.

Professor Kazovsky heads the Photonics and Networking Research Laboratory at Stanford University. He and his team of researchers are focusing on broadband optical access networks. They bring their ongoing research results to this unique book, bridging fundamentals of optical communication and networking system design with technology issues and current standards. Once that foundation is laid, the book delves into current high-capacity research issues, including evolution to WDM optical access, converged hybrid optical/wireless access networks, and implementation issues of broadband optical access. Research ideas generated by Professor Kazovsky’s research group have been widely adopted worldwide, including in framework projects of the European Union.

We strongly recommend this book, as it offers timely, accurate, authoritative, and innovative information regarding broadband optical access network design and implementation. We’re confident that you will enjoy reading the book and learn much while doing so.

DANIEL KILPER and PETER VETTERAlcatel-Lucent Bell Labs, Murray Hill, New Jersey

JAMES F. KELLYGoogle, Mountain View, California

ALAN WILLNERUSC Viterbi School of Engineering, Los Angeles, California

BISWANATH MUKHERJEEUniversity of California Davis, Davis, California

ANDERS BERNTSON, GUNNAR JACOBSEN, and MIKHAIL POPOVAcreo, Stockholm, Sweden

PREFACE

The roots of this book were planted about a decade ago. At that time, I became increasingly convinced that wide-area and metropolitan-area networks, where much of my group’s research has been centered at that time, were in good shape. Although research in these fields was (and still is) needed, that’s not where the networking bottleneck seemed to be. Rather, the bottleneck was (and still is in many places) in the access networks, which choked users’ access to information and services. It was clear to me that the long-term solution to that problem has to involve optical fiber access networks.

That conviction led me to switch the focus of my group’s research to optical access networks. In turn, that decision led to a decade of exciting exceptionally interesting research into the many challenges facing modern access networks. These challenges include rapidly increasing demands for larger bandwidth and better quality of service, graceful evolution to more powerful solutions without complete rebuilding of existing infrastructure, enhancing network range and number of users, improving access networks’ resilience, simplifying network architecture, finding better control strategies, and solving the problem of fiber/wireless integration. All these problems would have to be solved while maintaining the economic viability of access networks so that operators would be prepared to make the necessary (and huge) investment in fiber and other infrastructure.

Finding solutions for the foregoing problems occupied most of my research group’s time and attention for much of the past decade. In the beginning of that decade (and for a long time after that), my group, the Photonics and Networking Research Laboratory (PNRL) at Stanford University, was one of very few (or perhaps even the only) university research group working on fiber access, as many other optical researchers tended to discount optical access issues as trivial. Although that made funding for our research difficult to find, that position allowed us to make many pioneering contributions widely used and cited today. Later, many other university and industrial research groups entered the field, and several large-scale research efforts were organized, most notably in Europe, where serious research into both passive optical networks (PONs) and active optical networks (AONs) has been conducted over the last several years. Notable European efforts in broadband fiber access include ICT ALPHA (architectures for flexible photonic home and access networks, focused on AON, PON, and technoeconomics), ICT OASE (optical access seamless evolution, focused on PON, technoeconomics, and business models) and ICT SARDANA (focused on PON and optical metropolitan networks). These efforts resulted in extremely fast progress in the field. It was gratifying to see many PNRL research results adopted, used, and developed further by these (and other) efforts, especially in SARDANA.

Many of my colleagues working on optical access research encouraged me over the past few years to integrate results of the PNRL research on optical access networks into a single volume and publish it to ensure the broadest possible dissemination of our results. They feel that our results, when published in a single volume rather than the current combination of conference and journal articles, will further stimulate new research, plant new ideas, and lead to exciting new developments.

For a long while, I was reluctant to do so. The field of broadband fiber access networks is exceptionally broad; in addition, it is still very young and is developing and changing very fast. Thus, writing a comprehensive book on this subject is (nearly) impossible. Eventually, though, a stream of inquiries for additional information about our research convinced me to change my mind, and my research students and myself began the time-consuming process of writing our book.

Our goal was fairly modest: to summarize in one place the research results produced by the PNRL over the past decade or so. The reader should keep this goal in mind. We make no attempt to cover the entire field, just to provide a summary of our research. Even that goal proved to be difficult to achieve, as we are continuing our research as new technologies emerge, so our understanding of the field continues to evolve with time. However, we trust that the reader will consider this book a useful addition to his or her knowledge base of optical access networks.

SHAPE LEONID KAZOVSKY

Stanford University Stanford, California

ACKNOWLEDGMENTS

This book is based on research results obtained by our research group, the Photonics and Networking Research Laboratory at Stanford University. Our research on broadband fiber access networks, conducted over a decade or so, required a consistent effort by a large group of exceptionally talented graduate students, postdocs, and visitors. Some of these contributors are co-authors of the book, while others are working in other organizations and on other projects and so were too busy to help with the book-writing process. We are thankful to all of them, however.

Our research on broadband fiber access networks required a sizable team and a substantial amount of experimental, theoretical, and simulation efforts. This would be impossible without the generous and long-term support of our sponsors. We are grateful to our sponsors, who trusted us with the necessary resources. Our main sponsors in that area were, or are, the National Science Foundation under grants 0520291 and 0627085, KDDI Laboratories, Motorola, the Stanford Networking Research Center (no longer in existence), ST Microelectronics, ANDevices, Huawei, Deutsche Telecom, and Alcatel-Lucent Bell Laboratories.

We also thank the many research visitors to our group (mainly postdocs or visiting professors), who helped in a variety of ways, ranging from making research contributions to our book, to providing suggestions and comments on its contents, to taking part in one or more of our broadband access research projects. In particular, we are grateful to Dr. Kyeong Soo (Joseph) Kim of Swansea University; Professor Chunming Qiao of SUNY Buffalo; Dr. Luca Valcarenghi of Scuola Superiore Sant’Anna, Italy; Professor David Larrabeiti of Universidad Carlos III de Madrid, Madrid, Spain; and Dr. Divanilson Campelo of University of Brasilia, Brazil. Many others helped as well; unfortunately, a comprehensive list would be too long to include here.

We are grateful to the challenging, exciting research environment at Stanford University, where the lead author of this book has had the pleasure of working for the past two decades. Without that environment, this book would never have materialized.

Last but not least, we would like to thank our many colleagues all over the world for stimulating discussions, for their friendship, and for their help. We are particularly grateful to Prof. Vincent Chan, MIT; Prof. Alan Willner, USC; Drs. James Kelly and Cedric Lam of Google, Inc.; Prof. Andrea Fumagali, University of Texas; Profs. Ben Yoo and Biswanath Mukherjee, University of California, Davis; Profs. Djan Khoe and Dr. Harm of the Technical University of Eindoven, the Netherlands; Prof. Giancarlo Prati of the Scuola Superiore St. Anna, Pisa, Italy; Prof. Palle Jeppesen of the Danish Technical University, Copenhagen, Denmark; Drs. Gunnar Jacobsen, Mikhail Popov, and Claus Larsen of Acreo, Stockholm, Sweden; Dr. Shu Yamamoto of KDDI, Japan; and Dr. Frank Effenburger of Huawei.

Stanford University Stanford, California

SHAPE LEONID KAZOVSKY SHAPE NING CHENG SHAPE WEI-TAO SHAW SHAPE DAVID GUTIERREZ SHAPE SHING-WA WONG

CHAPTER 1

BROADBAND ACCESS TECHNOLOGIES: AN OVERVIEW

In past decades we witnessed the rapid development of global communication infrastructure and the explosive growth of the Internet, accompanied by ever-increasing user bandwidth demands and emerging multimedia applications. These dramatic changes in technologies and market demands, combined with government deregulation and fierce competition among data, telcom, and CATV operators, have scrambled the conventional communication services and created new social and economic challenges and opportunities in the new millennium. To meet those challenges and competitions, current service providers are striving to build new multimedia networks. The most challenging part of current Internet development is the access network. As an integrated part of global communication infrastructure, broadband access networks connect millions of users to the Internet, providing various services, including integrated voice, data, and video. As bandwidth demands for multimedia applications increase continuously, users require broadband and flexible access with higher bandwidth and lower cost. A variety of broadband access technologies are emerging to meet those challenging demands. While broadband communication over power lines and satellites is being developed to catch the market share, DSL (digital subscriber line) and cable modem continue to evolve, allowing telecom and CATV companies to provide high-speed access over copper wires. In the meantime, FTTx and wireless networks have become a very promising access technologies. The convergence of optical and wireless technologies could be the best solution for broadband and mobile access service in the future. As new technology continues to be developed, the future access technology will be more flexible, faster, and cheaper. In this chapter we discuss current access network scenarios and review current and emerging broad access technologies, including DSL, cable modem, optical, and wireless solutions.

1.1 COMMUNICATION NETWORKS

Since the development of telegraph and telephone networks in the nineteenth century, communication networks have come a long way and evolved into a global infrastructure. More than ever before, communications and information technologies pervade every aspect of our lives: our homes, our workplaces, our schools, and even our bodies. As part of the fundamental infrastructure of our global village, communication networks has enabled many other developments—social, economic, cultural, and political—and has changed significantly how people live, work, and interact.

Today’s global communication network is an extremely complicated system and covers a very large geographic area, all over the world and even in outer space. Such a complicated system is built and managed within a hierarchical structure, consisting of local area, access area, metropolitan area, and wide area networks (as shown in Figure 1.1. All the network layers cooperate to achieve the ultimate task: anyone, anywhere, anytime, and any media communications.

FIGURE 1.1 Hierarchical architecture of global communication infrastructure.

Local Area Networks Local area networks (LANs) mainly connect computers and other electronic devices (servers, printers, etc.) within an office, a single building, or a few adjacent buildings. Therefore, the geographical coverage of LANs is very small, spanning from a few meters to a few hundred meters. LANs are generally not a part of public networks but are owned and operated by private organizations. Common topologies for LANs are bus, ring, star, or tree. The most popular LANs are parts of the Ethernet, supporting a few hundred users with typical bit rates of 10 or 100 Mb/s.

Access Networks The computers and other communication equipment of a private organization are usually connected to a public telecommunication networks through access networks. Access networks bridge end users to service providers through twist pairs (phone line), coaxial cables, or other leased lines (such as OC3 through optical fiber). The typical distance covered by an access network is a few kilometers up to 20 km. For personal users, access networks use DSL or cable modem technology with a transmission rate of a few megabits per second; for business users, networks employ point-to-point fiber links with hundreds of megabits or gigabits per second.

Metropolitan Area Networks Metropolitan area networks (MANs) aggregate the traffic from access networks and transport the data at a higher speed. A typical area covered by a MAN spans a metropolitan area or a small region in the countryside. Its topology is usually a fiber ring connecting multiple central offices, where the transmission data rate is typically 2.5 or 10 Gb/s.

Wide Area Networks Wide area networks (WANs) carry a large amount of traffic among cities, countries, and continents. MAN multiplexes traffic from LANs and transports the aggregated traffic at a much higher data rate, typically tens of gigabits per second or higher using wavelength-division multiplexing (WDM) technology over optical fibers. Whereas a WAN covers the area of a nation or, in some cases, multiple nations, a link or path through a MAN could be as long as a few thousand kilometers. Beyond MANs, submarine links connect continents. Generally, the submarine systems are point-to-point links with a large capacity and an extremely long path, from a few thousand up to 10,000 km. Because these links are designed for ultralong distances and operate under the sea, the design requirements are much more stringent than those of their terrestrial counterparts. Presently, submarine links are deployed across the Pacific and Atlantic oceans. Some shorter submarine links are also widely used in the Mediterranean, Asian Pacific, and African areas.

Service Convergence Historically, communication networks provide mainly three types of service: voice, data, and video (triple play). Voice conversation using plain old telephony is a continuous 3.4-kHz analog signal carried by two-way, point-to-point circuits with a very stringent delay requirement. The standard TV signal is a continuous 6-MHz analog signal usually distributed with point-to-multipoint broadcasting. Data transmission is typically bursty with varying bandwidth and delay requirements. Because the traffic characteristics of voice, data, and video and their corresponding requirements as to quality of service (QoS) are fundamentally different, three major types of networks were developed specifically to render these services in a cost-effective manner: PSTN (public-switched telephone networks) for voice conversation, HFC (hybrid fiber coax) networks for video distribution, and the Internet for data transfer. Although HFC networks are optimized for video broadcasting, the inherent one-way communication is not suitable for bidirectional data or voice. PSTN adopts circuit switching technology to carry information with specific bandwidth or data rates, such as voice signals. However, circuit-switched networks are not very efficient for carrying bursty data traffic. With packet switching, the Internet can support bursty data transmission, but it is very difficult to meet stringent delay requirements for certain applications. Therefore, no single network can satisfy all the service requirements.

Emerging multimedia applications such as video on demand, e-learning, and interactive gaming require simultaneous transmission of voice, data, and video. Driven by user demands and stiff competition, service providers are moving toward a converged network for multimedia applications, which will utilize Internet protocol (IP) technologies to provide triple-play services. As VoIP (voice over IP) has been developed in the past few years and more recently IP TV has become a mature technology, all network services will converge into an IP-based service platform. Furthermore, the integration of optical and wireless technologies will make quadruple play (voice, data, video, and mobility) a reality in the near future.

1.2 ACCESS TECHNOLOGIES

Emerging multimedia applications continuously fuel the explosive growth of the Internet and gradually pervade every area of our lives, from home to workplace. To provide multimedia service to every home and every user, access networks are built to connect end users to service providers. The link between service providers and end users is often called the last mile by service providers, or from an end user’s perspective, the first mile. Ideally, access networks should be a converged platform capable of supporting a variety of applications and services. Through broadband access networks, integrated voice, data, and video service are provided to end users. However, the reality is that access networks are the weakest links in the current Internet infrastructure. While national information highways (WANs and MANs) have been developed in most parts of the globe, ramps and access routes to these information highways (i.e., the first/last mile) are mostly bike lanes or at best, unpaved roads, causing traffic congestion. Hence, pervasive broadband access should be a national imperative for future Internet development. In this section we review current access scenarios and discuss the last-mile bottleneck and its possible solutions.

1.2.1 Last-Mile Bottleneck

Due to advances in photonic technologies and worldwide deployment of optical fibers, during the last decade the telecommunication industry has experienced an extraordinary increase in transmission capacity in core transport networks. Commercial systems with 1-Tb/s transmission can easily be implemented in the field, and the state-of-the-art fiber optical transmission technology has reached 10 Tb/s in a single fiber. In the meanwhile, at the user end, the drastic improvement in the performance of personal computers and consumer electronic devices has made possible expanding demands of multimedia services, such as video on demand, video conferencing, e-learning, interactive games, VoIP, and others. Table 1.1 lists common end-user applications and their bandwidth requirements. As a result of the constantly increasing bandwidth demand, users may require more than 50 Mb/s in the near future. However, the current copper wire technologies bridging users and core networks have reached their fundamental bandwidth limits and become the first-last-mile bottleneck. Delays in Web page browsing, data access, and audio/video clip downloading have earned the Internet the nickname “World Wide Wait.” How to alleviate this bottleneck has been a very challenging task for service providers.

TABLE 1.1 Multimedia Applications and Their Bandwidth Requirements

1.2.2 Access Technologies Compared

For broadband access services, there is strong competition among several technologies: digital subscriber line, hybrid fiber coax, wireless, and FTTx (fiber to the x, x standing for home, curb, neighborhood, office, business, premise, user, etc.). For comparison, Table 1.2 lists the bandwidths (per user) and reaches of these competing technologies. Currently, dominant broadband access technologies are digital subscriber loop and coaxial cable. For conventional ADSL (asymmetric DSL) technology, the bandwidth available is a few Mb/s within the 5.5-km range. Newer VDSL (very high-speed DSL) can provide 50 Mb/s, but the maximum reach is limited to 1.5 km. On the other hand, coaxial cable has a much larger bandwidth than twist pairs, which can be as high as 1 Gb/s. However, due to the broadcast nature of CATV system, current cable modems can provide each user with an average bandwidth of a few Mb/s. While DSL and cable provide wired solutions for broadband access, Wi-Fi (wireless fidelity), and WiMAX (worldwide interoperability for microwave access) provide mobile access in a LAN or MAN network. Even though a nominal bandwidth of Wi-Fi and WiMAX can be relatively higher (54 Mb/s in 100 m for Wi-Fi and 28 Mb/s in 15 km for WiMAX), the reach of such wireless access is very limited and the actual bandwidth provided to users can be much lower, due to the interference in wireless channels. As a LAN technology, the primary use of Wi-Fi is in home and office networking. To reach the central office or service provider, multiple-hop wireless links with WiMAX have to be adopted. An alternative technology that is also under development is MBWA (mobile broadband wireless access, IEEE 802.20), which is very similar to WiMAX (IEEE 802.16e). Compared to the fixed access solutions, the advantages of the wireless technologies are easy deployment and ubiquitous or mobile access, and the disadvantages are unreliable bandwidth provisioning and/or limited access range.

TABLE 1.2 Comparison of Bandwidth and Reach for Popular Access Technologies

The bandwidth and/or reach of the copper wire and wireless access technology is very limited due to the physical media constraints. To satisfy the future use demand (>30 Mb/s), there is a strategic urgency for service providers to deploy FTTx networks. Currently, for cost and deployment reasons, FTTx is competing with other access technologies. Long term, however, only optical fiber can provide the unlimited capacity and performance that will be required by future broadband services. FTTx has long been dubbed as a future-proof technology for the access networks. A number of optical access network architectures have been standardized (APON, BPON, EPON, and GPON), and cost-effective components and devices for FTTx have matured. We are currently witnessing a worldwide deployment of optical access networks and a steady increase in FTTx users.

1.3 DIGITAL SUBSCRIBER LINE

Digital subscriber line (also called digital subscriber loop) is a family of access technologies that utilize the telephone line (twisted pair) to provide broadband access service. While the audio signal (voice) carried by a telephony system is limited from 300 to 3400 Hz, the twisted pair connecting the users to the central office is capable of carrying frequencies well beyond the 3.4-kHz upper limit of the telephony system. Depending on the length and the quality of the twisted pair, the upper limit can extend to tens of megahertz. DSL takes advantage of this unused bandwidth and transmits data using multiple-frequency channels. Thus, some types of DSL allow simultaneous use of the telephone and broadband access on the same twisted pair. Figure 1.2 shows the typical setup of a DSL configuration. At the central office, a DSLAM (DSL access multiplexer) sends the data to users via downstream channels. At the user side, a DSL modem functions as a modulator/demodulator (i.e., receives data from DSLAM and modulates user data for upstream transmission).

FIGURE 1.2 DSL access networks.

1.3.1 DSL Standards

DSL comes in different flavors, supporting various downstream/upstream bit rates and access distances. DSL standards are defined in ANSI T1, and ITU-T Recommendation G.992/993. Table 1.2 lists various DSL standards and their performance. Collectively, these DSL technologies are referred to as xDSL. Two commonly deployed DSL standards are ADSL and VDSL.

As its name suggests, ADSL supports asymmetrical transmission. Since the typical ratio of traffic asymmetry is about 2:1 to 3:1, ADSL becomes a popular choice for broadband access. In addition, there is more crosstalk from other circuits at the DSLAM end. As the upload signal is weak at the noisy DSLAM end, it makes sense technically to have upstream transmission at a lower bit rate. Depending on the length and quality (such as the signal-to-noise ratio) of the twisted pair, the downstream bit rate can be as high as 10 times the upstream transmission. The maximum reach of ADSL is 5500 m. While ADSL1 can support a downstream bit rate up to 8 Mb/s and an upstream data rate up to 896 kb/s, ADSL2 supports up to 15 Mb/s downstream and 3.8 Mb/s upstream.

To support higher bit rates, the VDSL standard was developed after ADSL. Trading transmission distance for data rate, VDSL can support a much higher data rate but with very limited reach. VDSL1 standards specify data rates of 50 Mb/s for downstream and 30 Mb/s for upstream transmission. The maximum reach of VDSL1 is limited to 1500 m. The newer version of VDSL standards, VDSL2, is an enhancement of VDSL1, supporting a data rate up to 100 Mb/s (with a transmission distance of 500 m). At 1 km, the bit rate will drop to 50 Mb/s. For reaches longer than 1.6 km, the VDSL2 performance is close to ADSL. Because of its higher data rates and ADSL-like long reach performance, VDSL2 is considered to be a very promising solution for upgrading existing ADSL infrastructure.

ADSL and VDSL are designed for residential subscribers with asymmetric bandwidth demands. For business users, symmetrical connections are generally required. Two symmetrical DSL standards, HDSL and SHDSL, are developed for business customers. While HDSL supports a T1 line data rate at 1.552 Mb/s (including 8 kb/s of overhead) with a reach of about 4000 m, SHDSL can provide a 6.696-Mb/s data rate with a maximum reach of 5500 m. However, HDSL and SHDSL do not support simultaneous telephone service, as most business customers do not have a requirement for a simultaneous voice circuit.

1.3.2 Modulation Methods

DSL uses a DMT (discrete multitone) modulation method. In DMT modulation, complex-to-real inverse discrete Fourier transform is used to partition the available bandwidth of the twisted pair into 256 orthogonal subchannels. DMT is adaptive to the quality of the twisted pair, so all the available bandwidth is fully utilized. The signal-to-noise ratio of each subchannel is monitored continuously. Based on the noise margin and bit error rate, a set of subchannels are selected, and a block of data bits are mapped into subchannels. In each subchannel, QAM (quadrature amplitude modulation) with a 4-kHz symbol rate is used to modulate the bit stream onto a subcarrier, leading to 60 kb/s per channel. Typically, the frequency range between 25 and 160 kHz is used for upstream transmission, and 140 kHz to 1.1 MHz is used for downstream transmission.

1.3.3 Voice over DSL

DSL was designed originally to carry data over phone lines, and DSL signal is separated from voice signal. Recently, new protocols have been proposed to merge voice and data at the circuit level. With advanced coding technologies, a 64-kb/s digitized voice signal can be compressed to 8 kb/s or less, thus allowing more voice channels to be carried over the same phone line. A voice over a DSL (VoDSL) gateway converts and compresses the analog voice signal to digital bit streams, so that calls made over VoDSL are indistinguishable from conventional calls. Usually, 12 to 20 voice channels can be carried over a single DSL line, depending on the transmission distance and the signal quality. A VoDSL system can be integrated into higher-layer protocols such as IP and ATM. Early DSL networks used ATM to ensure QoS, where ATM virtual circuits were used for the voice traffic. ADSL and VDSL networks migrate to packet-based transport, and they use packet-switched based virtual circuits instead of ATM ones.

1.4 HYBRID FIBER COAX

Cable networks were originally developed for a very simple reason: TV signal distribution. Therefore, cable networks are optimized for one-way, point-to-multipoint broadcasting of analog TV signals. As optical communication systems were developed, most cable TV systems have gradually been upgraded to hybrid fiber coax (HFC) networks, eliminating numerous electronic amplifiers along the trunk line. However, before cable access technology can be deployed, a return pass must be implemented for upstream traffic. To support two-way communication, bidirectional amplifiers have to be used in HFC systems, where filters are deployed to split the upstream (forward) and downstream (reverse) signals for separate amplification.

Figure 1.3 presents the network architecture of a typical HFC network. In HFC networks, analog TV signals are carried from the cable headend to distribution nodes using optical fibers, and from the distribution node, coaxial cable drops are deployed to serve 500 to 2000 subscribers. As shown in the figure, an HFC network is a shared medium system with a tree topology. In such a topology, multiple users share the same HFC infrastructure, so medium access control is required in upstream transmission while downstream transmission uses a broadcast scheme. A cable modem deployed at the subscriber end provides data connection to the cable network, while at the headend, the cable modem termination system connects to a variety of data servers and provides service to subscribers.

FIGURE 1.3 HFC access networks.

Compared with the twisted pairs in a telephone system, coaxial cables have a much higher bandwidth (1000 MHz), thus can support a much higher data rate. Depending on the signal-to-noise ratio on the coaxial cable, 40 Mb/s can be delivered to the end users with QAM modulation. For upstream transmission, QPSK can deliver up to a 10-Mb/s data rate. However, as cable systems are shared-medium networks, the bandwidth is thus shared by all the cable modems connected to the network. By contrast, DSL uses dedicated twist pairs for each user, thus no bandwidth sharing for different users. Furthermore, as the transmission bandwidth must be shared by multiple users, medium access control protocol must be deployed to govern upstream transmission. If congestion occurs in a specific channel, the headend must be able to instruct cable modems to tune its receiver to a different channel.

1.4.1 Cable Modem

Cable modems were developed to transport high-speed data to and from end users in an HFC network. Traditional TV broadcasting occupies frequencies up to 1 GHz, with each TV channel occupying 6 MHz of bandwidth (Part 76 in the FCC rules). A cable modem uses two of those 6-MHz channels for data transmission. For upstream transmission, a cable modem sends user data to the headend using a 6-MHz band between 5 and 42 MHz. At the same time, the cable modem must tune its receiver to a 6-MHz band within a 450- to 750-MHz band to receive downstream data. While a QAM modulation scheme is used for downstream data, a QPSK modulation scheme is usually selected for upstream transmission, as it is more immune to the interference resulting from radio broadcasting.

1.4.2 DOCSIS

DOCSIS (Data Over Cable Service Interface Specifications), developed by CableLabs, a consortium of equipment manufactuers, is the current standard for cable access technology. DOCSIS defines the functionalities and properties of cable modems at a subscriber’s premises and cable modem termination systems at the headend. As its name suggests, DOCSIS specifies the physical layer characteristics, such as transmission frequency, bit rate, modulation format, and power levels, of cable modem and cable modem termination systems, but also the data link layer protocol, such as frame structure, medium access control, and link security. Three different versions of DOCSIS (1.0/2.0/3.0) was developed during the past decade and were later ratified as ITU-T Recommendation J.112, J.122, and J.222. Although some compromise is needed as cable networks are a shared medium, DOCSIS offers various classes of service with medium access control. Such QoS features in DOCSIS can support applications (such as VoIP) that have stringent delay or bandwidth requirements.

Physical Layer The upstream PMD layer supports two modulation formats: QPSK and 16-QAM, and the downstream PMD layers uses 64-QAM and 256-QAM. The nominal symbol rate is 0.16, 0.32, 0.64, 1.28, 2.56, or 5.12 Mbaud. Therefore, the maximum downstream data rate is about 40 Mb/s and the upstream data rate is about 20 Mb/s. To mitigate the effect of noise and other detrimental channel effects, Reed–Solomon encoding, transmitter equalizer, and variable interleaving schemes are commonly used.

Data Link Layer The DOCSIS data link layer specifies frame structure, MAC, and link security. The frame structure used in HFC networks is very similar to the Ethernet in both the upstream and downstream directions. For the downstream direction, data frames are embedded in 188-byte MPEG-2 (ITU-T H.222.0) packets with a 4-byte header followed by 184 bytes of payload. Downstream uses TDM transmission schemes, synchronous to all modems. In the upstream direction, TDMA or S-CDMA are defined for medium access control. An upstream packet includes physical layer overhead, a unique word, MAC overhead, packet payload, and FEC bytes. MAC layer specifications also include modem registration, ranging, bandwidth allocation, collision detection and contention resolution, error detection, and data recovery. An access security mechanism in DOCSIS defines a baseline privacy interface, security system interface, and removable security module interface, to ensure information security in HFC networks.

1.5 OPTICAL ACCESS NETWORKS

Due to their ultrahigh bandwidth and low attenuation, optical fibers have been widely deployed for wide area networks and metro area networks. To some extent, multimode fibers were also deployed in office buildings for local area networks. Even though optical fibers are ideal media for high-speed communication systems and networks, the deployment cost was considered prohibitive in the access area, and copper wires still dominate in the current marketplace. However, as discussed in Section 1.2, emerging multimedia applications have created such large bandwidth demands that copper wire technologies have reached their bandwidth limits. Meanwhile, low-cost photonic components and passive optical network architecture have made fiber a very attractive solution. In the past few years, various PON architecture and technologies have been studied by the telecom industry, and a few PON standards have been approved by ITU-T and IEEE. FTTx becomes a mature technology in direct competition with copper wires. In fact, large-scale deployment has started in Asia, North America, and Europe, and millions of subscribers are enjoying the benefit of PON technologies.

1.5.1 Passive Optical Networks

Figure 1.4 illustrates the architecture of a passive optical network. As the name implies, there is no active component between the central office and the user premises. Active devices exist only in the central office and at user premises. From the central office, a standard single-mode optical fiber (feeder fiber) runs to a 1:N passive optical power splitter near the user premises. The output ports of the passive splitter connects to the subscribers through individual single-mode fibers (distribution fibers). The transmission distance in a passive optical networks is limited to 20 km, as specified in current standards. The fibers and passive components between the central office and users premises are commonly called an optical distribution network. The number of users supported by a PON can be anywhere from 2 to 128, depending on the the power budget, but typically, 16, 32, or 64. At the central office, an optical line terminal (OLT) transmits downstream data using 1490-nm wavelength, and the broadcasting video is sent through 1550-nm wavelength. Downstream uses a broadcast and select scheme; that is, the downstream data and video are broadcast to each user with MAC addresses, and the user selects the data packet–based MAC addresses. At the user end, an optical network unit (ONU), also called an optical network terminal (ONT), transmits upstream data at 1310-nm wavelength. To avoid collision, upstream transmission uses a multiple access protocol (i.e., time-division multiple access) to assign time slots to each user. This type of passive optical network is called TDM PON. The ONU could be located in a home, office, a curbside cabinet, or elsewhere. Thus comes the so-called fiber-to-the-home/office/business/neighborhood/curb/user/premises/node, all of which are commonly referred to as fiber to thex. In the case of fiber-to-the-neighborhood/curb/node, twisted pairs are typically deployed to connect end users to the ONUs, thus providing a hybrid fiber/DSL access solution.

FIGURE 1.4 Passive optical networks.

1.5.2 PON Standard Development

Early work of passive optical networks started in 1990s, when telecom service providers and system equipment vendors formed the FSAN (full service access networks) working group. The common goal of the FSAN group is to develop truly broadband fiber access networks. Because of the traffic management capabilities and robust QoS support of ATM (asynchronous transfer mode), the first PON standard, APON, is based on ATM and hence referred to as ATM PON. APON supports 622.08 Mb/s for downstream transmission and 155.52 Mb/s for upstream traffic. Downstream voice and data traffic is transmitted using 1490-nm wavelength, and downstream video is transmitted with 1550-nm wavelength. For upstream, user data are transmitted with 1310-nm wavelength. All the user traffic is encapsulated in standard ATM cells, which consists of 5-byte control header and 48-byte user data. APON standard was ratified by ITU-T in 1998 in Recommendation G.983.1. In the early days, APON was most deployed for business applications (e.g., fiber-to-the-office). However, APON networks are largely substituted with higher-bit-rate BPONs and GPONs.

Based on APON, ITU-T further developed BPON standard as specified in a series of recommendations in G.983. BPON is an enhancement of APON, where a higher data rate and detailed control protocols are specified. BPON supports a maximum downstream data rate at 1.2 Gb/s and a maximum upstream data rate at 622 Mb/s. ITU-T G.983 also specifies dynamic bandwidth allocation (DBA), management and control interfaces, and network protection. There has been large-scale deployment of BPON in support of fiber-to-the-premises applications.

The growing demand for higher bandwidth in the access networks stimulated further development of PON standards with higher capacity beyond those of APON and BPON. Starting in 2001, the FSAN group developed a new standard called gigabit PON, which becomes the ITU-T G.984 standard. The GPON physical media–dependent layer supports a maximum downstream/upstream data rate at 2.488 Gb/s, and the transmission convergence layer specifies a GPON frame format, media access control, operation and maintenance procedures, and an encryption method. Based on the ITU-T G.7041 generic framing procedure, GPON adopts GEM (a GPON encapsulation method) to support different layer 2 protocols, such as ATM and Ethernet. The novel GEM encapsulation method is backwardly compatible with APON and BPON and provides better efficiency than do Ethernet frames. Deployment of GPON had taken off in North America and largely replaced older BPONs and more.

While ITU-T rolled out BPON and GPON standards, IEEE Ethernet-in-the-first-mile working group developed a PON standard based on Ethernet. The EPON physical media–dependent layer can support maximum 1.25-Gb/s (effective data rate 1.0 Gb/s) downstream/upstream traffic. EPON encapsulate and transport user data in Ethernet frames. Thus, EPON is a natural extension of the local area networks in the user premises, and connects LANs to the Ethernet-based MAN/WAN infrastructure. Since there is no data fragment or assembly in EPON and its requirement on physical media–dependent layer is more relaxed, EPON equipment is less expensive than GPON. As Ethernet has been used widely in local area networks, EPON becomes a very attractive access technology. Currently, EPON networks have been deployed on a large scale in Japan, serving millions of users.

1.5.3 WDM PONs

As the user bandwidth demands keep increasing, current GPON or EPON will eventually no longer be able to satisfy the bandwidth requirement. There are a few possible solutions. One possibility is to split a single PON into multiple PONs so that each PON supports fewer users and each user gets more bandwidth. Another alternative is to use a higher bit rate, such as 10 Gb/s. In fact, an IEEE 802.3av study group is creating a draft standard on 10-Gb/s EPON. However, both solutions for higher bandwidth (i.e., higher bit rate or fewer users per PON) are not very cost-effective and do not scale very well as the bandwidth demands increase further. In addition, the power distribution of the passive splitter is fixed; that will lead to an uneven power budget for users and limit the transmission distance. Ultimately, WDM PON is the only future proof of technology that can satisfy any bandwidth demands.

Figure 1.5 shows the network architecture of WDM PONs. Transmitters with varying wavelengths will be deployed at the OLT and ONU sides, and a passive wavelength-division multiplexer will be inserted at the distribution node to separate and combine multiple wavelengths. Thus, the fiber distribution network will be kept passive. If the user bandwidth demands are not very large, or in the other words, a small number of users can still share a single wavelength, a passive power splitter following the WDM is used to broadcast the downstream traffic and combine the upstream traffic. In this case, multiple wavelengths separate a single PON into multiple logical TDM PONs. Each PON runs on a different wavelength, and fewer users share the bandwidth of a TDM PON. In addition, since the optical power is split for a smaller number of users, WDM PONs is less subject to optical power budget constraints, leading to long-reach access networks. If a user requires a large amount of bandwidth (e.g., a few gigabits per second), a single wavelength can be provided for this specific user; or in an extreme case, multiple wavelengths, hence a large bandwidth, can be provided to a single user if needed.

FIGURE 1.5 WDM passive optical networks.

In WDM PONs, the equipment and resources at OLT are shared by fewer users, leading to higher cost per user. Hence, WDM PONs are considered much more expensive than TDM PONs. However, to support high-bandwidth applications, there will be a need in the near future to move from TDM access networks to WDM access networks. Currently, the way to migrate from current TDM access networks to WDM access networks in a cost-effective, flexible, and scalable manner is not at all clear. A method to upgrade the access service smoothly and cost-effectively from a current TDM FTTx network to a future WDM FTTx network with a minimum influence on legacy users is the object of intense research. Various approaches to implementing WDM have been and are being explored, and field deployment has begun in Asia (South Korea, to be exact). A number of schemes to incorporate WDM technology into access networks have been studied and tested in experiments, and the WDM FTTx network architecture exhibits certain exceptional features in the WDM implementation in either downstream, upstream, or both directions. As optical technology becomes cheaper and easier to deploy and end users demand ever-increasing bandwidth, WDM PONs will eventually make the first/last-mile bottleneck history.

1.5.4 Other Types of Optical Access Networks

In addition to the passive optical networks, TDM and WDM PONs, that we have discussed, other types of optical access networks have been developed over the years, including Ethernet over fiber, DOCSIS PON, RF PON, and free-space optical networks. Ethernet over fiber is essentially point-to-point Ethernet built on fiber links. DOCSIS and RF PON is two flavors of PON developed for cable companies. Free-space optical networks is a wireless access solution utilizing optical communication technologies.

Ethernet over Fiber Ethernet over fiber is deployed primarily in point-to-point topology. Typically, dedicated fiber connects a subscriber to the central office, and each subscriber requires two dedicated transceivers (one at the user premises and the other at the central office). This approach requires a large number of fibers and optical transceivers and thus incurs a large cost associated with fiber and equipment. Since each fiber link can run on its full capacity, Ethernet over fiber, which requires gigabit bandwidth, is used primarily for business subscribers. Figure 1.6 shows an alternative architecture for Ethernet over fiber. A local Ethernet switch is deployed to the user sites. Individual fiber can then run from the switch to each user, and only a single fiber (bidirectional) or two fibers (unidirectional) connect the Ethernet switch to the central office. This approach reduces the number of fibers run from the central office but requires an active Ethernet switch in the field and requires at least two more transceivers than is the case on the left in the figure.

FIGURE 1.6 Point-to-point Ethernet optical access networks.

DOCSIS PON While telecom companies are deploying PONs worldwide on a large scale, MSOs (multisystem operators) need to upgrade their fiber coax systems to compete in FTTx markets. DOCSIS PON, or DPON, is developed to provide a DOCSIS service layer interface on top of PON architecture. DPON implements DOCSIS functionalities, including OAMP (operation, administration, maintenance, and provisioning) on existing PON systems, and thus allow MSOs to use set-top and DOCSIS equipment located in homes and headends over PONs. However, fundamentally, DPON service is based on current EPON or GPON MAC and physical layer standards. Therefore, DPON is just an application running on top of PON systems.

RF PON Radio-frequency PON (RF PON) is another flavor of passive optical networks developed for MSOs. RF PONs support RF video broadcasting signals over optical fibers. As MSOs expand the network footprint and launch new products using additional RF bandwidth, more active RF components are deployed and higher frequencies sometimes require RF electronics change-outs and respacing. As a consequence, HFC networks experience reduced signal quality, lower reliability, and higher operating and maintenance cost. RF PONs are a natural evolution of current HFC networks, as they offer backward compatibility with current RF video broadcasting technologies and provides significant cost reduction in network operation and maintenance.

OCDM PON Optical code-division multiplexing (OCDM) has been demonstrated recently as an alternative multiplexing technique for PONs. Similar to electronic CDMA technology, users in OCDM PONs are assigned orthogonal codes with which each user’s data are encoded or decoded into or from optical pulse sequence. OCDM PONs can thus provide asynchronous communications and security against unauthorized users. However, the optical encoders and decoders for OCDM are expensive, and the number of users is limited by interference and noise.

Free-Space Optical Networks Unlike fiber optic communications, free-space optical communication (also called optical wireless communication) uses atmosphere as the communication medium. This is probably one of the old long-distance communication methods (e.g., smoke signals) used a few thousands years ago. During the past decades, there has been revived interest in free-space communication for satellite and urban environment. Particularly in the access networks, it can used to connect a subscriber directly to a central office. Figure 1.7 shows a typical setup for urban free-space optical communication networks. Due to the line-of-sight requirement for free-space optical communications, optical transceivers are usually mounted on the tops of buildings, and telescopes are typically used in the transmitter to improve the alignment of optical links. Multiple point-to-point links can form a mesh network, improving its scalability and reliability. As a wireless technology, the cost of free-space optical communication is very low, about 10% of fiber optic communications, and the high-speed link can be set up and torn down in a couple hours. Compared to other wireless access technologies, it provides a higher data rate, longer reach, and better signal quality. So far, thousands of free-space optical links have been deployed. However, atmosphere is not an ideal transmission medium, due to attenuation and scattering at optical frequency. Turbulence, rain, and dense fog could be very challenging for free-space optical communication. For long-reach links, alignment of optical transmitters and receivers is also difficult, and an adaptive ray-tracking system might be needed for rapid pointing and accurate alignment. Potentially, survivable network topology, transmitter and receiver arrays, and adaptive and equalization technologies could help mitigate the atmospheric effect and alignment problem. Integration with wire line networks such as PONs can greatly improve the reliability and survivability of free-space optical access networks. In the future, we may witness more and more free-space optical networks in urban settings.

FIGURE 1.7 Free-space optical communications and networks. Point-to-point optical wireless links on the roofs of buildings form a mesh network for broadband access.

1.6 BROADBAND OVER POWER LINES

Ac power lines have long been considered a workable communication medium. For decades, utility companies have used power lines for signaling and control, but they are used primarily for internal management of power grids, household intercoms, and lighting controls. As deregulation of both the telecom and electricity industries was unfolding in the 1990s, broadband access over power lines became a possibility. As power lines reach more residences than does any other medium, significant efforts have been made to develop high-speed access over power lines. A number of solutions have been proposed and tested in the field. Even though DSL or cable currently dominates the broadband access services, and PONs are very promising for the near future, broadband over power lines (BPL) can still claim its part in the current market. For example, in some rural areas, building infrastructure to provide DSL or cable could be very expensive, while power-line communications could easily provide broadband services. Anywhere there is electricity there could be broadband over power lines. In addition, there is a great potential to network all the appliances in a household through the power line, thus providing a smart home solution. However, at present power-line communication technology and its market potential remain to be developed further.

1.6.1 Power-Line Communications

Figure 1.8 shows the topology of the electrical power distribution grid. The three-phase power generated at a power plant enters a transmission substation, where the three-phase power generated by the power generators is converted to extremely high voltages (155 to 765 kV) for long-distance transmission over the grid. Within the transmission grid, many power substations convert the extremely high transmission voltage down to distribution voltages (less than 10 kV), and this medium-voltage electricity is sent through a bus that can split the power in multiple directions. Along the distribution bus, there are regulator banks that regulate the voltage on the line to avoid overshoot or undershoot, and taps that send electricity down the street. At each building or house, there is a transformer drum attached to the electricity pole, reducing the medium voltage (typically, 7.2 kV) to household voltage (110 or 240 V).

FIGURE 1.8 Electrical power transmission and distribution.

Broadband over power lines utilizes the medium-voltage power lines to transmit data to and from each house, as shown in Figure 1.9. Typically, repeaters are installed along the power lines for long-distance data transmission, and some bypass devices allow RF signals to bypass transformers. In the last step of data transmission, the signals can be carried to each house by the power line or, alternatively, using Wi-Fi or other wireless technology for last-mile connection.

FIGURE 1.9 Broadband power-line communications.

1.6.2 BPL Modem

A BPL modem plugs into a common power socket on the wall, sending and receiving data through a power line. On the other end, the BPL modem connects to computers or other network devices by means of Ethernet cables. In some cases, a wireless router can be integrated with a BPL modem. BPL modems transmit at medium to high frequencies, from a few megahertz to tens of megahertz. Typical data rates supported by a BPL modem range from hundreds of kilobits per second to a few megabits per second. Various modulation schemes can be used for power-line communications, including the older ASK (amplitude shift keying), FSK (frequency shift keying) modulation and newer DMT, DSSS (direct sequence spread spectrum) and OFDM (orthogonal frequency-division multiplexing) technologies. DMT, DSSS, or OFDM modulation is perferred in modern BPL modems, as it is more robust in handling interference and noise. Recent research has demonstrated a gigabit data rate over power lines using microwave frequencies via surface wave propagation. This technology can avoid the interference problems very common in power lines.

1.6.3 Challenges in BPL

BPL is a promising technology, but its development is relatively slow compared with DSL and cable. There are a number of technical challenges that must be overcome. A power line is not a very good medium for data transmission: Various transformers used in the electric grid do not pass RF signals, the numerous sources of signal reflections (impedance mismatches and lack of proper impedance termination) on power lines hinder data transmission, and noise from numerous sources (such as power motors) contaminates the transmission spectrum. Since power lines consist of untwisted and unshielded wire, their long length makes them large antennas emitting RF signals and interfering with other radio communications. Furthermore, a power line is a shared medium limiting the bandwidth delivered to each user and raising security concerns for private communications. All these issues have to be fully addressed before large-scale deployment can be implemented. Fortunately, much progress has been made through intensive research during recent decades. BPL is poised to be a promising technology for entry into the current highly competitive market.

1.7 WIRELESS ACCESS TECHNOLOGIES

Starting with RF communication and broadcasting, wireless communication technologies have had an incredibly powerful effect on the entire world since the beginning of the twentieth century. Nowadays, AM/FM radio and TV broadcasting blanket every continent except Antarctica; wireless cellular networks provide voice communication to hundreds of millions of users; satellites provide video broadcasting and communication links worldwide; and Bluetooth and wireless LANs support mobile services to individuals. Wireless networks are everywhere. The popularity of wireless technologies is due primarily to their mobility, scalability, low cost, and ease of deployment. Wireless technologies will continue to play an important part in our daily lives, and fourth-generation wireless networks will be able to provide quadruple play through seamless integration of a variety of wireless networks, including wireless personal networks, wireless LANs, wireless access networks, cellular wide area networks, and satellite networks. In recent years, a number of wireless technologies have been developed as alternatives to traditional wired access service (DSL, cable, and PONs). Except for free-space optical communications (Section 1.5), most wireless access networks use RF signals to establish communication links between a central office and subscribers. In this section we discuss various broadband radio access technologies and their characteristics. The choice of radio access technologies depends largely on the applications, required data rate, available frequency spectrum, and transmission distance. Even though wireless access networks cannot compete with wired access technologies in terms of data rate and reliability, they offer flexibility and mobility that no other technologies can provide. Therefore, wireless access networks complement current wired access technologies and will continue to grow in the future.

1.7.1 Wi-Fi Mesh Networks

The Wi-Fi network based on IEEE 802.11 standards was developed in the 1990s for wireless local area networks, where a set of wireless access points function as communication hubs for mobile clients. Because of its flexibility and low deployment cost, Wi-Fi has become an efficient and economical networking option that is widespread in both households and the industrial world, and is a standard feature of laptops, PDAs, and other mobile devices. Now Wi-Fi is available in thousands of public hot spots, millions of campus and corporate facilities, and hundreds of millions of homes. Even though current Wi-Fi networks are limited primarily to point-to-multipoint communications between access points and mobile clients, multiple access points can be interconnected to form a wireless mesh network, as shown in Figure 1.7. The wireless access points establish wireless links among themselves to enable automatic topology discovery and dynamic routing configuration. The wireless links among access points form a wireless backbone referred to as mesh backhaul. Multihop wireless communications in mesh backhaul are employed to forward traffic to and from a wired Internet entry point, and each access point may provide point-to-multipoint access to users known as mesh access. Therefore, a Wi-Fi mesh network can provide broadband access services in a self-organized, self-configured, and self-healing way, enabling quick deployment and easy maintenance.

Over the years, a set of standards has been specified by the IEEE 802.11 working group, including the most popular 802.11b/g standards. Table 1.3
