Correlative Imaging E-Book
106,99 €
Mehr erfahren.
- Herausgeber: John Wiley & Sons
- Kategorie: Wissenschaft und neue Technologien
- Serie: RMS - Royal Microscopical Society
- Sprache: Englisch
Brings a fresh point of view to the current state of correlative imaging and the future of the field
This book provides contributions from international experts on correlative imaging, describing their vision of future developments in the field based on where it is today. Starting with a brief historical overview of how the field evolved, it presents the latest developments in microscopy that facilitate the correlative workflow. It also discusses the need for an ideal correlative probe, applications in proteomic and elemental analysis, interpretation methods, and how correlative imaging can incorporate force microscopy, soft x-ray tomography, and volume electron microscopy techniques. Work on placing individual molecules within cells is also featured.
Correlative Imaging: Focusing on the Future offers in-depth chapters on: correlative imaging from an LM perspective; the importance of sample processing for correlative imaging; correlative light and volume EM; correlation with scanning probe microscopies; and integrated microscopy. It looks at: cryo-correlative microscopy; correlative cryo soft X-ray imaging; and array tomography. Hydrated-state correlative imaging in vacuo, correlating data from different imaging modalities, and big data in correlative imaging are also considered.
- Brings a fresh view to one of the hottest topics within the imaging community: the correlative imaging field
- Discusses current research and offers expert thoughts on the field’s future developments
- Presented by internationally-recognized editors and contributors with extensive experience in research and applications
- Of interest to scientists working in the fields of imaging, structural biology, cell biology, developmental biology, neurobiology, cancer biology, infection and immunity, biomaterials and biomedicine
- Part of the Wiley–Royal Microscopical Society series
Correlative Imaging: Focusing on the Future will appeal to those working in the expanding field of the biosciences, correlative microscopy and related microscopic areas. It will also benefit graduate students working in microscopy, as well as anyone working in the microscopy imaging field in biomedical research.
Sie lesen das E-Book in den Legimi-Apps auf:
Seitenzahl: 552
Veröffentlichungsjahr: 2019
Ähnliche
Table of Contents
Cover
List of Contributors
Preface
1 It’s a Small, Small World: A Brief History of Biological Correlative Microscopy
1.1 It All Began with Photons
1.2 The Electron Takes Its Place
1.3 Putting It Together, 1960s to 1980s
1.4 CLEM Matures as a Scientific Tool 1990 to 2017
Acknowledgments
References
2 Challenges for CLEM from a Light Microscopy Perspective
2.1 Introduction
2.2 Microscopy Multiculturalism
2.3 Bridging the Gap between Light and Electron Microscopy
2.4 Future CLEM Applications and Modifications
References
3 The Importance of Sample Processing for Correlative Imaging (or, Rubbish In, Rubbish Out)
3.1 Introduction
3.2 Searching for Correlative Electron Microscopy Utopia
3.3 Sample Processing for Correlative Imaging: A Primer for the First Steps
3.4 Making It Go Faster (We Want More Speed, More Speed…)
3.5 Embedding Resins
3.6 Keeping the Region of Interest in Sight
3.7 Correlation and Relocation with Dual Modality Probes
3.8 Integration of Imaging Modalities, and In‐Resin Fluorescence
3.9 Streamlining the Correlative Approaches of the Future: SmartCLEM
3.10 How Deep Does the Rabbit Hole Go?
3.11 Hold That Thought, Though − Is This All Completely Necessary?
3.12 Improving Accessibility to Correlative Workflows
3.13 Coming to the End
References
4 3D CLEM: Correlating Volume Light and Electron Microscopy
4.1 Introduction
4.2 Imaging in 3D
4.3 Comparative and Correlative LM and EM Imaging
4.4 CLEM Is More than LM + EM
4.5 3D CLEM
4.6 Two Workflows for 3D CLEM
4.7 Where Is CLEM Going in the Future?
Acknowledgments
References
5 Can Correlative Microscopy Ever Be Easy? An Array Tomography Viewpoint
5.1 Introduction
5.2 Why Array Tomography?
5.3 Array Tomography of Abundant Subcellular Structures: Synapses
5.4 Array Tomography of Sparsely Distributed Structures: Cisternal Organelle
5.5 Array Tomography of Small Model Organisms: C. elegans
5.6 To Summarize: Finding the Right AT Approach
5.7 Areas of Improvement
Acknowledgments
References
6 Correlative Microscopy Using Scanning Probe Microscopes
6.1 Introduction
6.2 Principles of AFM
6.3 AFM and Optical Microscopy Correlative Approaches
6.4 Correlation with CLSM
6.5 Correlation with Cell Mechanics
6.6 AFM and Correlation with Electron Microscopy
6.7 Future Developments Involving Correlation Microscopy Using HS‐AFM
6.8 Concluding Remarks
Acknowledgments
References
7 Integrated Light and Electron Microscopy
7.1 Introduction
7.2 Large‐Scale and High‐Throughput (Volume) Microscopy
7.3 Super‐Resolution Fluorescence Microscopy
7.4 Cryo‐Electron Microscopy
7.5 Outlook
Acknowledgments
References
8 Cryo‐Correlative Light and Electron Microscopy: Toward
in situ
Structural Biology
8.1 Introduction
8.2 Cryo‐CLEM to Support Single Particle Analysis of Purified Macromolecules
8.3 Capturing Structural Dynamics of
in vitro
Reconstituted Systems
8.4 Identifying Macromolecules in Plunge‐Frozen Whole Cells
8.5 Macromolecular Structures in Thinned Samples from Thick Cell Areas
8.6 Enabling Structural Biology in Multicellular Organisms and Tissues by Cryo‐CLEM
8.7 Conclusions
Acknowledgments
References
9 Correlative Cryo Soft X‐ray Imaging
9.1 Introduction to Cryo Soft X‐ray Microscopy
9.2 Cryo‐SXT Correlation with Visible Light Microscopy
9.3 Cryo‐SXT Correlation with Cryo X‐ray Fluorescence
9.4 Cryo‐SXT Correlation with TEM
9.5 Multiple Correlation and Integration of Methods
Acknowledgments
References
10 Correlative Light‐ and Liquid‐Phase Scanning Transmission Electron Microscopy for Studies of Protein Function in Whole Cells
10.1 Introduction
10.2 Limitations of State‐of‐the‐Art Methods
10.3 Principle of Liquid STEM
10.4 Advantages of Liquid STEM
10.5 Future Prospects
Acknowledgments
References
11 Correlating Data from Imaging Modalities
11.1 Introduction
11.2 Registration during CLEM Stages
11.3 Registration Paradigm
11.4 Envisioned Future Developments
11.5 Visualization of Correlation
11.6 Conclusion
Acknowledgments
References
12 Big Data in Correlative Imaging
12.1 Introduction
12.2 The Protein Data Bank
12.3 Resources for Cryo‐EM
12.4 Light Microscopy Data Resources
12.5 EMPIAR
12.6 IDR: A Prototype Image Data Resource
12.7 Public Resources for Correlative Imaging
12.8 Future Directions
Acknowledgments
References
13 The Future of CLEM: Summary
Index
End User License Agreement
List of Tables
Chapter 10
Table 10.1 Important analytical techniques used to study the functional state of...
List of Illustrations
Chapter 1
Figure 1.1 The first micrograph to compare a sample imaged with a light micros...
Figure 1.2 Quite possibly the first truly correlative micrograph, i.e, of the ...
Figure 1.3 The laboratory of Professor H.D. Geissigner pioneered the developme...
Figure 1.4 Correlation approaches between cryo‐LM and FIB‐SEM is very promisin...
Figure 1.5 Correlative single molecule localization microscopy and EM of resin...
Figure 1.6 Correlation of live‐cell imaging to 3D‐EM integrates multiple dynam...
Figure 1.7 Citation report generated from Web of Science Core Collection betwe...
Chapter 2
Figure 2.1 Golgi apparatus in Hela Cells; (a) Transmission electron micrograph...
Figure 2.2 High resolution imaging of the Golgi apparatus in Hela Cells; (a) L...
Figure 2.3 Photooxidation of GFP polymerizes DAB to an electron‐dense precipit...
Figure 2.4 Proposed scheme for adaptation of FRET biosensors for use in electr...
Chapter 4
Figure 4.1 Schematic representation of a 3D CLEM project. Workflow starts with...
Figure 4.2 Schematic representation of a 3D CLEM workflow for adherent cells.
Figure 4.3 Schematic representation of a 3D CLEM workflow for tissue samples, ...
Chapter 5
Figure 5.1 Conjugate AT of synapses in mouse neocortex. a. An overlay of the f...
Figure 5.2 Cisternal organelles in mouse neocortex. a. Reconstructed volume fr...
Figure 5.3 Leaping strategy. a. A tightly trimmed sample with a
C. elegans
lar...
Figure 5.4 AT localization and 3D CLEM of
C. elegans
gonad distal tip cell. a.
Chapter 6
Figure 6.1 AFM principle. a: laser deflection reflected on the cantilever is d...
Figure 6.2 AFM imaging. a: Peak force error scan of eukaryotic HeLa cells (lef...
Figure 6.3 AFM parameters. Left: fluorescence grayscale of HeLa cells overexpr...
Figure 6.4 AFM correlation with SRLM. a: Left: SIM image of a PtK2 cell infect...
Figure 6.5 AFM stiffness maps on cells plated on micropatterns (a) and micropi...
Figure 6.6 a: CLAFEM description of the possible correlated modes of acquisiti...
Figure 6.7
In situ
correlated SEM/AFM imaging of a collagen lined lacunae in b...
Chapter 7
Figure 7.1 Conceptual overview of a workflow for integrated Correlative Array ...
Chapter 8
Figure 8.1 (a) Cryo‐EM image of purified Ebola virus (EBOV) nucleoprotein and ...
Chapter 9
Figure 9.1 (a) attenuation length showing the water window energy range (284 e...
Figure 9.2 3D reconstructions of whole control and HCV replicon‐bearing cells ...
Figure 9.3 Reconstructed slices of MCF‐7 cell incubated with superparamagnetic...
Figure 9.4 Comparison of reconstructed slices of a simulated 9 μm thick pseudo...
Figure 9.5 Correlative workflow for visible light fluorescence and cryo SXT. U...
Figure 9.6 Correlative workflow of STORM and cryo SXT. Step 1: Cells were grow...
Figure 9.7 Maps of the trophozoite stage of the malaria parasite. (a) cryo‐SXT...
Figure 9.8 Cryo‐SXM‐TEM correlation. (a) Overlay between visible l...
Chapter 10
Figure 10.1 Principles of liquid‐phase scanning transmission electron microsco...
Figure 10.2 Labeling of an ORAI1 dimer (pink) with two quantum dot (QD) probes...
Figure 10.3 Correlative light‐ and electron microscopy overview images of QD‐l...
Figure 10.4 ESEM‐STEM images of two Jurkat T cells with single QD‐labeled ORAI...
Figure 10.5 Statistical analysis of the label positions. (a) Pair‐correlation ...
Figure 10.6 Model of the biotinylated anti‐HER2 affibody (blue) binding to a s...
Figure 10.7 Correlative light and electron microscopy overview images of QD la...
Figure 10.8 Statistical analysis of the spatial distribution of labeled HER2 p...
Chapter 11
Figure 11.1 Diversity of features and difficulties of multiscale features: E...
Figure 11.2 Number of publications per year presenting methods of general im...
Figure 11.3 Schematic depiction of the possible registration steps during CL...
Figure 11.4 Choice of transformation: (a) Transformation basis families; (b‐...
Figure 11.5 Inspiring neurosurgery guiding through augmented reality and aug...
Guide
Cover
Table of Contents
Begin Reading
Pages
ii
iii
iv
xi
xii
xiii
xiv
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
23
24
25
26
27
28
29
30
31
32
33
34
35
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
Current and future titles in the Royal Microscopical Society – John Wiley Series
PublishedPrinciples and Practice of Variable Pressure/Environmental Scanning Electron Microscopy (VP‐ESEM)Debbie Stokes
Aberration‐Corrected Analytical Electron MicroscopyEdited by Rik Brydson
Diagnostic Electron Microscopy – A Practical Guide to Interpretation and TechniqueEdited by John W. Stirling, Alan Curry, and Brian Eyden
Low Voltage Electron Microscopy – Principles and ApplicationsEdited by David C. Bell and Natasha Erdman
Standard and Super‐Resolution Bioimaging Data Analysis: A PrimerEdited by Ann Wheeler and Ricardo Henriques
Electron Beam‐Specimen Interactions and Applications in MicroscopyBudhika Mendis
Biological Field Emission Scanning Electron Microscopy 2V SetEdited by Roland Fleck and Bruno Humbel
Understanding Light MicroscopyJeremy Sanderson
Correlative Microscopy in the Biomedical SciencesEdited by Paul Verkade and Lucy Collinson
ForthcomingThe Preparation of Geomaterials for Microscopical Study: A Laboratory ManualOwen Green and Jonathan Wells
Electron Energy Loss SpectroscopyEdited by Rik Brydson and Ian MacLaren
Correlative Imaging
Focusing on the Future
Edited by
Paul Verkade
University of BristolBristolUnited Kingdom
Lucy Collinson
The Francis Crick InstituteLondonUnited Kingdom
This edition first published 2020© 2020 John Wiley & Sons Ltd
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, except as permitted by law. Advice on how to obtain permission to reuse material from this title is available at http://www.wiley.com/go/permissions.
The right of Paul Verkade and Lucy Collinson to be identified as the authors of the editorial material in this work has been asserted in accordance with law.
Registered OfficesJohn Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, USAJohn Wiley & Sons Ltd, The Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, UK
Editorial OfficeThe Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, UK
For details of our global editorial offices, customer services, and more information about Wiley products visit us at www.wiley.com.
Wiley also publishes its books in a variety of electronic formats and by print‐on‐demand. Some content that appears in standard print versions of this book may not be available in other formats.
Limit of Liability/Disclaimer of WarrantyMATLAB® is a trademark of The MathWorks, Inc. and is used with permission. The MathWorks does not warrant the accuracy of the text or exercises in this book. This work’s use or discussion of MATLAB® software or related products does not constitute endorsement or sponsorship by The MathWorks of a particular pedagogical approach or particular use of the MATLAB® software.
In view of ongoing research, equipment modifications, changes in governmental regulations, and the constant flow of information relating to the use of experimental reagents, equipment, and devices, the reader is urged to review and evaluate the information provided in the package insert or instructions for each chemical, piece of equipment, reagent, or device for, among other things, any changes in the instructions or indication of usage and for added warnings and precautions. While the publisher and authors have used their best efforts in preparing this work, they make no representations or warranties with respect to the accuracy or completeness of the contents of this work and specifically disclaim all warranties, including without limitation any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives, written sales materials or promotional statements for this work. The fact that an organization, website, or product is referred to in this work as a citation and/or potential source of further information does not mean that the publisher and authors endorse the information or services the organization, website, or product may provide or recommendations it may make. This work is sold with the understanding that the publisher is not engaged in rendering professional services. The advice and strategies contained herein may not be suitable for your situation. You should consult with a specialist where appropriate. Further, readers should be aware that websites listed in this work may have changed or disappeared between when this work was written and when it is read. Neither the publisher nor authors shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.
Library of Congress Cataloging‐in‐Publication data applied for
ISBN: 9781119086451
Cover Design: WileyCover Images: Courtesy of Lucy Collinson, Chris Peddie, and Martin Jones, © Christos Georghiou/Shutterstock, © Andrii Vodolazhskyi/Shutterstock, © Choksawatdikorn/Shutterstock, © Sergey Nivens/Shutterstock
List of Contributors
Kurt AndersonThe Francis Crick Institute, London, United Kingdom
Tanmay A.M. BharatSir William Dunn School of Pathology, University of Oxford, United Kingdom
Jose L. CarrascosaDepartment of Macromolecular Structures, Centro Nacional de Biotecnologia (CNB‐CSIC), Madrid, Spain
Francisco Javier ChichónDepartment of Macromolecular Structures, Centro Nacional de Biotecnologia (CNB‐CSIC), Madrid, Spain
Georg FantnerLaboratory for Bio‐ and Nano‐instrumentation, School of Engineering, Interfaculty Institute of Bioengineering, Lausanne, Switzerland
Julia Fernandez‐RodriguezCentre for Cellular Imaging at Sahlgrenska Academy, University of Gothenburg, Sweden
Christopher J. GuérinVIB Bioimaging Core, Ghent, VIB Inflammation Research Center, Ghent and Department of Molecular Biomedical Research, University of Ghent, Belgium
J. P. HoogenboomImaging Physics, Delft University of Technology, The Netherlands
Eija JokitaloHelsinki Institute of Life Science, Institute of Biotechnology, University of Helsinki, Finland
Niels de JongeINM – Leibniz Institute for New Materials and Department of Physics, Saarland University, Saarbrücken, Germany
Judith KlumpermanSection Cell Biology, Center for Molecular Medicine, University Medical Center Utrecht, The Netherlands
Irina KolotuevUniversity of Lausanne, EM Facility, Switzerland
R. I. KoningCell and Chemical Biology, Leiden University Medical Center, The Netherlands
A. J. KosterCell and Chemical Biology, Leiden University Medical Center, The Netherlands
Wanda KukulskiCell Biology Division, MRC Laboratory of Molecular Biology, Francis Crick Avenue, Cambridge, United Kingdom
Frank LafontCellular Microbiology and Physics of Infection GroupCenter for Infection and Immunity of Lille, CNRS UMR8204 – Inserm U1019 – Lille Regional University Hospital Center – Institut Pasteur de Lille – Univ. Lille, France
R. I. LaneImaging Physics, Delft University of Technology, The Netherlands
Saskia LippensBioImaging Core, VIB, Ghent, Belgium
Nalan LivSection Cell Biology, Center for Molecular Medicine, University Medical Center Utrecht, The Netherlands
Kristina D. MichevaStanford University School of Medicine, California, United States
Tommy NilssonThe Research Institute of the McGill University Health Centre and McGill University, Montreal, Canada
Ardan PatwardhanEuropean Molecular Biology Laboratory, European Bioinformatics Institute (EMBL‐EBI), Wellcome Genome Campus, Hinxton, United Kingdom
Perrine Paul‐GilloteauxStructure Fédérative de Recherche François Bonamy, CNRS, INSERM, Université de Nantes, France
Christopher J. PeddieElectron Microscopy Science Technology Platform, The Francis Crick Institute, London, United Kingdom
Eva PereiroMistral beamline, ALBA Light Source, Cerdanyola del Vallès, Barcelona, Spain
A. Srinivasa RajaImaging Physics, Delft University of Technology, The Netherlands
Nicole L. SchieberCell Biology and Biophysics Unit, European Molecular Biology Laboratory, Heidelberg, Germany
Martin SchorbEuropean Molecular Biology Lab (EMBL), Heidelberg, Germany
Jason R. SwedlowCentre for Gene Regulation and Expression, University of Dundee, United Kingdom
1It’s a Small, Small World: A Brief History of Biological Correlative Microscopy
Christopher J. Guérin1, Nalan Liv2, and Judith Klumperman2
1 VIB Bioimaging Core, Ghent, VIB Inflammation Research Center, Ghent and Department of Molecular Biomedical Research, University of Ghent, Belgium
2 Section Cell Biology, Center for Molecular Medicine, University Medical Center Utrecht, The Netherlands
1.1 It All Began with Photons
Light microscopy (LM) is arguably the oldest technology still used in scientific research today. Until the mid‐1600s, the world of structures smaller than about 400 microns was unseen and unknown. While the principles of using lenses to magnify were known as far back as Euclid (c. 300 BCE) [1], microscopy had to await technical developments in the manufacture of lenses and the casings to hold and position them, before they could be used to extend the power of human visual resolution. The earliest published description of a biological sample viewed using a simple one lens microscope was probably in 1658’s Scrutinium pestis physico‐medicum [2] written by a German friar Athanasius Kircher. In this manuscript he describes the presence of “little worms” in blood that he associates with disease; thus anticipating the germ theory by almost 100 years.
Around the same period, Dutchman Antonie van Leeuwenhoek used his single‐lens microscope to examine samples of mold, bees, and lice, and reported these and other observations to the Royal Society in a series of letters beginning in 1673. It was when he went on to look at samples of blood, tooth plaque, and sperm that he observed that individual small structures that moved of their own volition! When he reported his observations in a letter to the Royal Society in London in 1676, they were met with great skepticism. In 1677, a delegation was sent to determine if he was brilliant or demented. Having vindicated his observations, he was elected to the Royal Society in 1680. However, while the best of van Leeuwenhoek’s microscopes had an impressive maximum magnification of 260 times, their resolving power was limited to about 1.4 μm [3].
Although simple one‐lens microscopes like Van Leeuwenhoek’s were impressive, a Dutch inventor by the name of Cornelius Jacobszoon Drebbel brought a new device to London [4] even earlier (1619), a two‐lens microscope that possessed higher magnification capacity than the Van Leeuwenhoek instrument since it was based on the principle that in a two‐lens microscope the total magnification of the lenses was multiplicative [5]; although the resolution was limited by optical aberrations.
Using a microscope very much like Drebbel’s, but with an improved source of illumination, the Englishman Robert Hooke was able to see details in pieces of plants, animals, and insects that had previously been unknown. For example, he observed that a piece of cork bark was composed of many small rectangular compartments. They reminded him of the small rooms that monks slept in. He called them cells, a name we still use today; had he called them chambers we might be studying chamber biology instead. He published these observations as well as the first recorded attempt to make measurements using a microscope in his 1665 book Micrographia[6]. These early studies of the invisible world of cells represent the birth of modern microscopy.
In the eighteenth and nineteenth centuries, microscopes became progressively more powerful, lens design was improved to remove aberrations, and innovations such as the use of polarized illumination were introduced. In the 1880s the German scientists Ernst Abbe and August Valentin Köhler working with Carl Zeiss brought together a sophisticated lens design [7] and improved illumination methods [8, 9] to create microscopes that could resolve subcellular structures. Abbe was the first to mathematically calculate the limits of microscope resolution using photons [10]. His calculations showed that the wavelength of visible light and the angle from which the diffracted light is collected defined the limits for microscopic resolution. Thus, the Abbe diffraction barrier of 188 nm was elucidated, and this would remain the limit of light microscopy until the advent of super‐resolution techniques some 125 years later.
1.2 The Electron Takes Its Place
In the 1920s, while light microscopy still had to fully exploit its resolution possibilities, a young French physics student was pondering the theories of Einstein, in particular the nature of electrons, and wondering if they had a wavelength. His name was Louis de Broglie and the equation describing the wave nature of electrons was at the heart of his PhD thesis [11]. In a triumph of early career achievement his thesis secured him the 1929 Nobel prize in physics! Being a theoretician, he had no practical use for his work and went on to the next equation. Fortunately, there were more practically minded physicists who did see the use of the wave nature of electrons. Ladislaus Marton in Brussels, and Ernst Ruska, Max Knoll, and Ernst Brüche in Berlin developed simultaneous prototype transmission electron microscopes, which proved that not only did electrons have a wavelength but also that they could be focused by electromagnetic lenses and used in the same manner as light was used in optical microscopy [12]. Ruska theorized that under the right conditions these microscopes could achieve a resolution of 2Ä, which was proved correct almost 40 years later [13].
Biologists rejoiced at the news that smaller subcellular structures could finally be resolved; however, it came at a price. Specimens had to be imaged in high vacuum and radiation damage from the strong electron beam was intense. Despite that, Marton published the first biological electron micrograph of a sample of Drosera intermedia, sundew, in the journal Nature in 1934 [14]. While this was a breakthrough, the actual resolution of electron micrographs would be insufficient to produce useful scientific data for another 20 years. So until almost the 1960s, electron microscopes were like the optical microscopes of the seventeenth century, largely curiosities.
1.3 Putting It Together, 1960s to 1980s
Although both light and electron microscopy continued to improve, it wasn’t until the 1960s that researchers tried to combine the two imaging techniques. When searching the early literature for correlative microscopy publications, it becomes obvious that the term as we now use it, to indicate light and electron microscopic studies on the same area of the same sample, has evolved over time. The earliest references are frequently studies of the same tissue or sample type but not necessarily on the same specimen; thus, they are more comparative than truly correlative. The earliest paper that we have found that imaged a sample in a light microscope with a similarly prepared sample in an electron microscope is from the pioneering work of Keith Porter, where chick embryonic fibroblasts were cultured on a formvar substrate, fixed and imaged (Figure 1.1) [15]. This was only done as a proof of principle for developing EM techniques, though, and no attempt was made to draw conclusions from any correlation. A correlative study from 1960 by Goodman and Morgan was performed on separate cell cultures and published as two papers, one for light [16] and one for transmission electron microscopy (TEM)[17].
Figure 1.1 The first micrograph to compare a sample imaged with a light microscope; 1) and an electron microscope; 2), was published by Keith Porter in 194515. While not truly correlative, e.g. of the same specimen, this did demonstrate that samples prepared with the same procedures could be imaged using multiple methods.
Reproduced with permission of ROCKEFELLER UNIVERSITY PRESS via Copyright Clearance Center ©1945.
Other correlative studies from 1969 [18] and 1970 [19, 20] used biopsy samples that had been divided and processed for either light or electron microscopy, and then extrapolated between the morphological findings in each. Additional studies of correlative microscopy went a step further and used the same sample but adjacent sections. In 1970, Watari and coworkers published a study of the islets of Langerhans using adjacent resin‐embedded sections [21], and in 1979, Hyde et al. used the same block to first cut thick sections and inspect them by LM, then selected areas were cut out from these samples, and thin sectioned for TEM [22]. A very early attempt to combine immunohistochemistry with TEM was published in 1974 by Bordi and Bussolati [23].
In 1980, Gonda and Hsu combined LM, scanning electron microscopy (SEM) and TEM to study developing mouse blastocysts [24]. These early studies, although not meeting the criteria for correlative microscopy that we use today, were examples of researchers trying to use multiple microscopy methods to bridge the resolution gap between photons and electrons.
It was probably the 1967 article by McDonald, Pease, and Hayes [25] that examined sectioned rabbit tissues by LM and SEM, that marks the first use of correlative microscopy with the specific purpose of adding the extra resolution available in the EM to the LM data (Figure 1.2). A 1969 paper by McDonald and Hayes used fixed, dried blood cells and clots and correlated images of the same cells using their morphology and proximity to neighboring cells to identify them [26]. In 1971, a short technical note was published by Ayres, Allen, and Williams using specimens from a cervical biopsy that were inspected by SEM, then reprocessed for LM imaging [27]. At the same time, a group led by H.D. Geissinger at the University of Guelph was working intensely on correlative microscopy and matching the same area in cell preparations and tissue slices using SEM and LM [28]. In a 1973 paper, Geissinger, Basrur, and Yamashiro constructed a custom‐built holder with a measuring caliper that could transfer between the LM stage and SEM specimen chamber [29,30], and by use of a method of correlated integers [31] they were able to reacquire the same coordinates and image the same area. Geissinger, Abandowitz, and Josefowicz used the same technique to examine hair shafts in transmitted and reflected light and SEM [32].
Figure 1.2 Quite possibly the first truly correlative micrograph, i.e, of the same sample imaged in both the LM (a) and EM (b), published by McDonald, Pierce and Hayes in 1967 [25]. An “area of delayed radiation lesion of rabbit sensory cortex” in a 4 μm section of paraffin embedded tissue. The authors used the correlation to point out features in the EM that were not obvious in the LM.
Reprinted by permission of the publisher, Springer Nature, from laboratory Investigation © 1967.
Geissenger and coworkers continued to explore the possibilities of correlative microscopy, combining many imaging modalities: SEM‐interferometry [33], and LM polarization‐SEM‐TEM (Figure 1.3) [34]. This approach of combining multiple LM and EM techniques was also adopted by other investigators. A paper from 1989 used a combination of live cell video microscopy, low‐voltage SEM, and high‐voltage TEM to study membrane associated glycoproteins in human platelet cells [35], and that same year a paper used intravital video microscopy, LM and TEM to study capillary growth [36].
Figure 1.3 The laboratory of Professor H.D. Geissigner pioneered the development of different correlative microscopy workflows using multiple imaging modalities. This elegant example from a 1980 paper demonstrates the extra information to be gained through the correlation of LM (inset a × 400), SEM (a × 1500) and TEM (b × 5400) examining a sample of human muscle in a patient with muscular distrophy.
Reprinted by permission of the publisher from Ultrastructural Pathology © 1980 (Taylor & Francis Ltd, http://www.tandfonline.com).
These early efforts to bridge the resolution scale were pioneering and led to a greater interest in using combined microscopic techniques to increase the data content of bioimaging experiments. This interest was further demonstrated in 1987 with the publication of the first book describing CLEM instrumentation and methods [37].
1.4 CLEM Matures as a Scientific Tool 1990 to 2017
In the next 25 years, the technique would continue to progress, not only with specific CLEM developments aimed at more precise and faster correlation but also by constantly implementing improvements made in the LM and EM fields. For example, in the early 1980s LM in the life sciences was reinvigorated by the development and commercialization of confocal laser scanning microscopy [38, 39]. This was quickly supplemented by the discovery of green fluorescent protein (GFP) [40, 41] and other fluorophores, allowing functional imaging in live cells [42, 43]. In the 1990s, subdiffraction‐limited or super‐resolution LM techniques with resolutions below the limit set by Abbe’s law started to appear. First was stimulated emission depletion (STED) microscopy [44], followed by structured illumination microscopy (SIM) [45], stochastic optical reconstruction microscopy (STORM) [46], and photoactivated localization microscopy (PALM) [47] More recent developments such as light sheet microscopy [48], tissue clearing, expansion microscopy [49], and adaptive optics [50] continue to extend the capabilities of LM and in due course will find their way into CLEM.
On the EM side, electron tomography (ET), which offers 3D visualization of a selected part of a specimen at very high resolution, has been continuously improved since 1968 and with the growing computational power is still increasingly applied and optimized. One of the most recent developments is ET done under cryo‐conditions [51, 52], providing exciting new applications in the field of structural biology. It is also of great importance for CLEM that the resolution of SEMs has been steadily improved, now almost approaching the TEM level [53]. Moreover, SEMs gained extended automated capabilities for 3D imaging [54, 55, 56], which greatly facilitates CLEM in the z‐axis. Further improvements in LM and EM have made them more complementary in terms of resolution, contrast generation, and image dimensions. The promising power of combining these complementary modalities in integrated or modular microscopy settings has boosted the development and applications of CLEM in the last decade.
One of the main challenges in CLEM studies is to use LM to determine where you are in the landscape of the nanoworld of EM. Sadly for microscopists, a cellular version of GPS does not yet exist. To correlate a region of interest (ROI) in a light micrograph to the corresponding area in an electron micrograph is no easy task. Ideally, what is needed is a probe that can be easily visualized in both microscopes. An early but noncorrelative immunohistochemical study did develop such a probe using horseradish peroxidase (HRP)‐antiperoxidase‐diaminobenzidine (DAB), but only inspected it in the TEM [57].
To the best of our knowledge, the first demonstration of a directly correlative tracer, visible in both LM and EM, was in 1980 when Roth synthesized a FITC‐protein A‐colloidal gold complex to label antibodies to amylase in sections of pancreas [58]. In 1982, Maranto used photoconversion of the fluorescent dye Lucifer yellow in the presence of DAB to create an osmiophilic polymer [59], and this was followed by other studies using photooxidized fluorophores [60, 61]. In 1987, Quattrochi and colleagues synthesized fluorescent nanospheres linked by IgG to protein A‐colloidal gold, and used them for retrograde neuronal labeling [62]. Polishchuk in 2000 used live‐cell confocal microscopy to localize GFP to the Golgi complex and subsequent HRP‐DAB reaction to relocate the ROI by serial section TEM to create 3D reconstructions [63]. In 2001, Adams reported the engineering of ReAsh‐EDT2[64] a biarsenical ligand that could photooxidize tetracystine tagged GFP for use in CLEM studies [65]. In 2005, Grabenbauer demonstrated a new method that proved it was possible to use GFP to directly photooxidize DAB, thus allowing for the correlative visualization of endogenously expressed proteins [66]. This was followed in 2011 by the engineering of Mini‐SOG, a fluorescent flavoprotein that was both fluorescent and a high‐efficiency photooxidizer developed specifically by Roger Tsien for CLEM [67]. All these attempts were hampered by the diffusible, nonquantitative HRP DAB reaction product that decreased the precision of the correlation.
In 2012, Martell and co‐workers developed APEX, a small (28‐kDa) genetically engineered peroxidase that can be coupled to fluoroproteins, remains active following fixation, creates a more precise localized reaction and does not require light to reduce DAB [68]. APEX is now also available in a modular form incorporating a GFP binding protein [69]. In 2015, the laboratory of Ben Giepmans developed a probe called FLIPPER, expressly for CLEM studies containing a fluoroprotein and a peroxidase that could be genetically expressed [70]. Most recently Arnold et al. developed a cryo‐LM stage that, combined with fiducial markers and a computational algorithm, is able to allow for precise correlation between cryo‐LM and FIB‐SEM [71] (Figure 1.4). This development is very exciting, as CLEM can now be used to precisely guide the FIB milling process of vitrified cellular samples and capture specific structures in their native orientation.
Figure 1.4 Correlation approaches between cryo‐LM and FIB‐SEM is very promising to precisely guide the FIB milling process of vitrified biological samples, and paves the way for visualization of single molecules in their native in‐situ states. Arnold et al. developed a cryo stage for spinning‐disk microscopy at cryogenic temperatures, and employed this approach to guide the FIB milling process to capture fluorescently labeled lipid droplets, in 300 nm lamellas.
Reprinted by permission from: Arnold, Jan, et al. “Site‐specific cryo‐focused ion beam sample preparation guided by 3D correlative microscopy.” Biophysical Journal 110.4; 2016): 860–869.
Since the interest in CLEM continues to increase, other types of probes are becoming rapidly available. In parallel and addition to the DAB‐dependent probes already described, others tried to preserve fluorescent signals in resin‐embedded tissues to make the CLEM workflow more flexible. In 2014, Peddie et al. succeeded in retaining fluoroprotein signals in resin embedded heavy metal stained tissues [72], and in the same year, Perkovic and co‐authors published a similar method for organic fluorophores [73]. Super‐resolution probes for CLEM have also been developed. In 2015, Paez Sengla and colleagues developed fixation‐resistant photoactivatable fluoroproteins for CLEM [74]. Recently, scientists working in Jena, Germany, synthesized polylactide nanoparticles incorporating iridium (III) complexes [75], Müller et al. reported the use of self‐labeling protein tags for time resolved CLEM experiments [76] and the laboratory of Roger Tsien described the use of Click‐EM for imaging metabolically tagged non‐protein biomolecules [77]. Nonfluorescent detection techniques to relocate ROIs have also been investigated. Physical marking of tissues using an infrared laser can help to reacquire an ROI at the EM level [78]. In 2012, Glenn and co‐authors developed probes that are cathodoluminescent, raising the possibility of discriminating between multiple probes at the EM level [79]. In 2015, Nagayama et al. demonstrated eGFP cathodoluminescence [80], and Furukawa and co‐workers developed rare‐earth nanophosphors for cathodoluminescent imaging in scanning‐transmission EM [81]. In 2016, Fukushima and co‐workers reported the development of yttrium oxide nanophosphors, which are both fluorescent and cathodoluminescent as well as electron dense [82] and Hemelaar et al. reported the use of fluorescent/cathodoluminescent nanodiamonds for correlative studies [83].
Although we still lack a cellular equivalent of GPS, a 2017 publication, integrating several of the developments mentioned above, has demonstrated a correlation technique using cathodoluminescence with a precision of <5 nm between LM and EM images [84]. While the development of probes is invaluable for the progress of CLEM, their applications are maximized thanks to the many computer vision and bioinformatics specialists who have made strides in the “back end” of the process; that of data analysis and eventual overlaying of the LM and EM digital data [85, 86, 87, 88]. With the development of specifically engineered probes and software, the CLEM workflow has become easier and more accessible to nonspecialist labs.
A way to minimize the effort to find back ROIs by LM and EM is to combine LM and EM in one microscope. The first attempt at such an integrated device was in 1978, when Hartmann and co‐workers published a note describing an attachment to a commercial SEM that incorporated light microscope optics [89]. Further adaptations were made, and in 1981 JS Ploem presented a prototype Leitz instrument at the VIII Conference on Analytical Cytology and Cytometry [90]. In 1982, Wouters and Koerten also published an integrated instrument for LM and SEM [91]. Then, for over 20 years there was little progress on the instrumentation front, until in 2008 three groups from Utrecht University and Leiden University Medical Center collaborated on the design of an adaptation to a TEM that incorporated a tilting sample holder and an aspherical (NA 0.55) objective lens mounted inside a TEM column perpendicular to the electron beam and connected externally to a scanning confocal microscope [92]. This integrated light and TEM was commercialized by FEI (now Thermo Fischer) under the name iCorr.
Although this approach worked successfully, it required special specimen preparation that had to compromise between preserving the fluorescent signal and maintaining ultrastructural integrity and contrast, which for room‐temperature CLEM still is a challenge. An improvement on this design introducing cryo‐EM to observe fluorochromes in their hydrated state was published in 2012 [93].
The following year a collaborative effort between groups from both academia and industry published the design for an integrated room‐temperature fluorescence‐SEM. This system employed a reflective mirror and a 45X NA 0.41 objective lens placed in an SEM column in which holes were bored to allow passage of the electron beam [94]. This design also required special specimen preparation with fixation in low‐concentration gluteraldehyde and dehydration insensitive fluorochromes. As far as can be determined, this design was never commercialized.
In 2010, Nishiyama and co‐workers published the design for a combined instrument in which a fluorescence microscope was mounted over an inverted SEM with the sample in a chamber constructed of a silicon nitride film [95]. This was later marketed by JEOL as the ClairScope. Because of its limited magnification and resolution capacity, it was never widely adopted but proved the impetus for other designs of integrated instruments.
In 2011, Albert Polman in AMOLF, Amsterdam developed the SPARC, a custom‐built stage that could be installed in an SEM containing a swinging parabolic mirror connected to an external CCD camera recording cathodoluminescence [96]. This design was used primarily for materials science and nanophotonics applications, although recent breakthroughs in biological applications could change that [97]. In 2013, the Charged Particle Optics group of Delft University of Technology developed SECOM, which included a high NA optical lens inside the vacuum chamber directly below the SEM pole piece [98, 99]. Both SPARC and SECOM are marketed by a spinoff company, DELMIC BV. In 2013, DELMIC joined with Phenom‐World BV to develop the Delphi that used a similar design to SECOM but as a standalone instrument; it was unveiled in 2014 at the IMC in Prague. A SECOM variant including super‐resolution capability was released in 2016. Using this SECOM platform, Peddie et al. recently presented strong stable blinking properties of GFP and YFP in‐vacuo, and used this to achieve super resolution CLEM of resin‐embedded cells [100] (Figure 1.5). Additional developmental work is underway on integrated instrumentation such as the inclusion of a miniature fluorescence microscope into a serial blockface sectioning SEM system for 3D CLEM studies [101]; and with the growing interest in correlative microscopy we can expect to see new instruments with additional capabilities that could bring CLEM into more widespread use.
Figure 1.5 Correlative single molecule localization microscopy and EM of resin embedded cells in an integrated super‐resolution LM in SEM. This approach successfully localizes the lipid DAG to subdomains of Golgi membranes, endoplasmic reticulum, cristae and outer mitochondrial membrane (c and d).
Reprinted from Peddie, Christopher J, et al. “Correlative super‐resolution fluorescence and electron microscopy using conventional fluorescent proteins in vacuo.” Journal of Structural Biology 199.2: 120–131; 2017) under creative commons license 4.0.
The early trend to combine multiple modes of light and electron microscopy continued into the 1990s with various permutations of light, fluorescence, video, SEM, and TEM being employed [102], and increasing numbers of studies that went beyond mere proof of principle to address significant scientific questions [103, 104, 105]. Newly developing microscopic techniques were integrated into CLEM studies including: intravital two‐photon [106], florescence recovery after photobleaching (FRAP) [107], cryo‐LM, and cryo‐EM [108], live‐cell imaging and immunogold labeling [109], fluorescence in situ hybridization (FISH) [110], cryo‐scanning transmission electron microscopy (cryo‐STEM) [111], and most recently super‐resolution microscopy [112, 113, 114, 115, 116, 117, 118]. For a long time, CLEM had remained a 2D technique, at least at the EM end. With the advent of TEM tomography, this changed, and many correlative LM‐TEM tomographic studies have opened up the third dimension at the nanoscale [119, 120, 121, 122, 123, 124, 125, 126]. More recently, other 3D EM techniques have been used for CLEM, such as: serial section TEM (ssTEM) [127, 128], array tomography [129, 130], focused ion beam SEM (FIB‐SEM) [131, 132, 133, 134], and serial blockface imaging (SBFI) [135]. Fermie et al. demonstrated correlation of live‐cell imaging to 3D EM, and linked dynamic characteristics of single organelles to their 3D ultrastructure [136](Figure 1.6). Other imaging techniques have also been used to enhance LM and EM studies, most often the use of CT or soft X‐rays produced by either synchrotron beamlines or standalone instrumentation [137, 138, 139, 140].
Figure 1.6 Correlation of live‐cell imaging to 3D‐EM integrates multiple dynamic and ultrastructural parameters at the cellular and subcellular level. The Klumperman laboratory recently published the first example of CLEM from live cells to 3D EM at the level of a single organelle. The 3D EM data (e–g) are obtained by FIB.SEM of the ROI identified in live cells (a–c) and fluorescence microscopy (D).
Reprinted by permission from: Fermie, et al. “Single organelle dynamics linked to 3D structure by correlative live‐cell imaging and 3D electron microscopy.” Traffic 19.5; 2018): 354–369.
CLEM came about because scientists needed more information than either LM or EM could offer on its own. The technique began slowly and it was some time before the hardware and software available could fully support its development. What began as a few papers showcasing the significant efforts of some intrepid microscopists has now become a rapidly growing body of literature (Figure 1.7). It took many years for photons and electrons to learn to work together, now that they have, the future for correlative microscopy looks bright indeed.
Figure 1.7 Citation report generated from Web of Science Core Collection between years 1900–2017 for 4,139 publications, which have the words correlative, light, electron, and microscopy either in their title or topic.
