Corrosion and Materials Selection - Alireza Bahadori - E-Book

Corrosion and Materials Selection E-Book

Alireza Bahadori

0,0
153,99 €

Beschreibung

The petroleum and chemical industries contain a wide variety ofcorrosive environments, many of which are unique to these industries. Oil and gas production operationsconsume a tremendous amount of iron and steel pipe, tubing, pumps, valves, and sucker rods. Metalliccorrosion is costly. However, the cost of corrosion is not just financial. Beyond the huge direct outlay offunds to repair or replace corroded structures are the indirectcosts - natural resources, potential hazards, and lostopportunity. Wasting natural resources is a direct contradiction tothe growing need for sustainable development. By selecting the correct material and applying proper corrosionprotection methods, these costs can be reduced, or even eliminated. This book provides a minimum designrequirement for consideration when designing systems in order to prevent or control corrosion damagesafely and economically, and addresses: * Corrosion problems in petroleum and chemicalindustries * Requirements for corrosion control * Chemical control of corrosive environments * Corrosion inhibitors in refineries and petrochemicalplants * Materials selection and service life ofmaterials * Surface preparation, protection andmaintainability * Corrosion monitoring - plant inspection techniques andlaboratory corrosion testing techniques Intended for engineers and industry personnel working in thepetroleum and chemical industries, this book is also a valuableresource for research and development teams, safety engineers,corrosion specialists and researchers in chemical engineering,engineering and materials science.

Sie lesen das E-Book in den Legimi-Apps auf:

Android
iOS
von Legimi
zertifizierten E-Readern

Seitenzahl: 1104

Bewertungen
0,0
0
0
0
0
0



Table of Contents

Cover

Title Page

Copyright

Dedication

About the Author

Preface

Acknowledgements

Chapter 1: Fundamentals of Corrosion in the Oil, Gas, and Chemical Industries

1.1 Uniform Corrosion

1.2 Localized Corrosion

1.3 Low-Temperature Corrosion

1.4 High-Temperature Corrosion

Chapter 2: Corrosion Problems in the Petroleum and Chemical Industries

2.1 Stress Corrosion Cracking and Embrittlement

2.2 Hydrogen Attack

2.3 Corrosion Fatigue

2.4 Liquid-Metal Embrittlement

2.5 Basic Definition of Erosion-Corrosion

2.6 Mixed-Phase Flow

2.7 Entrained Catalyst Particles

2.8 Systematic Analysis of Project

2.9 Forms of Corrosion and Preventive Measures

2.10 Selective Leaching or De-Alloying Corrosion

2.11 Erosion-Corrosion

2.12 Stress Corrosion Cracking

2.13 Types of Hydrogen Damage

2.14 Concentration Cell Corrosion

2.15 Filiform Corrosion

2.16 Types of Intergranular Corrosion

2.17 Microbiologically Influenced Corrosion

2.18 Corrosion in Concrete

Chapter 3: Corrosion Considerations in Material Selection

3.1 Corrosion in Oil and Gas Products

3.2 Corrosives and Corrosion Problems in Refineries and Petrochemical Plants

Chapter 4: Engineering Materials

4.1 The Range of Materials

4.2 Properties of Engineering Materials

4.3 Corrosion Prevention Measures

4.4 Material Selection Procedure

4.5 Guidelines on Material Selection

4.6 Procedure for Material Selection

4.7 Process Parameters

4.8 Corrosion Rate and Corrosion Allowances

4.9 Corrosion Allowance

4.10 Selection of Corrosion-Resistance Alloys

4.11 Economics in Material Selection

4.12 Materials Appreciation and Optimization

4.13 Corrosion in Oil and Gas Products

4.14 Engineering Materials

4.15 Cast Iron

4.16 Non-Ferrous Metals

4.17 Polymers

4.18 Ceramics and Glasses

4.19 Composite Materials

Chapter 5: Chemical Control of Corrosive Environments

5.1 General Requirements and Rules for Corrosion Control

5.2 Basic Types of Inhibitors and How They Work

5.3 Corrosive Environments

5.4 Techniques for the Application of Inhibitors

5.5 Inhibitor Mechanisms

5.6 Criteria for Corrosion Control by Inhibitors

5.7 System Condition

5.8 Selection of Inhibitors

5.9 Economics of Inhibition

5.10 Environmental Factors for Corrosion Inhibitor Applications

Chapter 6: Requirements for Corrosion Control in the Petroleum and Petrochemical Industries

6.1 Exploration

6.2 Production

6.3 System Requirements for Corrosion Control of Oil Fields by Inhibitors

6.4 Types of Inhibitor

6.5 Selection of Inhibitor

6.6 Measurement

6.7 Factors Governing Oil Well Corrosion

6.8 Application of Inhibitor

6.9 Water Flooding and Water Disposal

6.10 Transportation and Storage

6.11 Biological Control in Oil and Gas Systems

6.12 Scale Control in Oil Systems

Chapter 7: Corrosion Inhibitors in Refineries and Petrochemical Plants

7.1 Nature of Corrosive Fluids

7.2 Corrosion of Steel

7.3 Corrosion of Copper Alloys

7.4 Neutralizing Corrosion Inhibitors

7.5 Filming Inhibitors

7.6 Special Concepts in the Use of Corrosion Inhibitors in Refineries

7.7 Economic Aspects of Chemical Inhibition and Other Measures for Corrosion Prevention

7.8 Special Refinery Processes Amenable to Corrosion Inhibitors

7.9 Corrosion in Gas Processing Units

7.10 Miscellaneous Refinery Corrosion Problems

7.11 Selection of Inhibitor

7.12 Control of Fouling

7.13 Utility (Cooling Water and Boiler Systems)

7.14 Boiler Corrosion Problems

7.15 Treatment of Acid Systems

7.16 Chemical Cleaning of Process Equipment

7.17 Critical Equipment Areas

7.18 Identification of Deposits

7.19 Chemical Cleaning

Chapter 8: Corrosion Inhibitor Evaluations

8.1 On-Line Monitoring of Corrosion

8.2 Corrosion Monitoring Techniques

8.3 Selecting a Technique for Corrosion Monitoring

8.4 Corrosion Monitoring Strategy

8.5 Measurement of Dissolved Solids

8.6 Measurement of Suspended Solids

8.7 Corrosion Product Analysis

8.8 Design Requirements

8.9 Automated Systems

8.10 Evaluation of Corrosion Inhibitors

8.11 Detection of Corrosion

8.12 Miscellaneous Corrosion Tests

8.13 Results of the Test Method

8.14 Field Testing of Inhibitors

8.15 Inhibitor Properties Other Than Effectiveness in Mitigating Corrosion

8.16 Monitoring of Corrosion Inhibitors

8.17 Corrosion Behavior of High-Alloy Tubular Materials in Inhibited Acidizing Conditions

Chapter 9: Compatibility in Material Selection

9.1 Requirements for Compatibility

9.2 Structures and Equipment

9.3 Piping Systems

9.4 Fasteners

9.5 Encapsulation, Sealing, and Enveloping

9.6 Electrical and Electronic Equipment

9.7 Coatings, Films, and Treatments

9.8 Chemical Compatibility

9.9 Environment

9.10 Stray Currents

9.11 Beneficial Results

9.12 Shape or Geometry

9.13 Structures

9.14 Mechanics

Chapter 10: Surface Preparation, Protection and Maintenance

10.1 Surface

10.2 Protection

10.3 Maintenance

10.4 Economics

Chapter 11: Fabrication and Choice of Material to Minimize Corrosion Damage

11.1 Design

11.2 Materials

11.3 Fabrication

11.4 Welding Procedure

11.5 Welding and Joining

11.6 Soldered Joints

Chapter 12: Heat Treatment

12.1 General Heat Treatment Requirements

12.2 Heat Treatment Process

12.3 Preheating of Metals

12.4 Surface Treatment of Stainless Steel

12.5 Handling, Transport, Storage, and Erection of Coated Metalwork

12.6 Inspection

12.7 Corrosion of Carbon Steel Weldments

12.8 Discussion

12.9 Conclusions

12.10 Corrosion of Austenitic Stainless Steel Weldments

12.11 Corrosion of Ferritic Stainless Steel Weldments

12.12 Corrosion of Duplex Stainless Steel Weldments

12.13 Stress-Corrosion Cracking

12.14 Use of High-Alloy Filler Metals

12.15 Corrosion of Nickel-Bases Alloys

Glossary of Terms

Bibliography

Index

End User License Agreement

Pages

xxi

xxiii

xxiv

xxv

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

85

86

84

87

88

89

90

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

199

198

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

295

296

297

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

298

325

326

327

328

329

330

331

332

333

334

335

337

338

340

341

339

342

345

343

344

346

347

348

349

350

351

352

353

354

355

356

357

358

359

360

361

362

363

364

365

367

366

368

369

370

371

372

373

374

375

376

377

378

379

380

381

382

383

385

386

387

388

389

390

391

392

393

394

395

396

397

398

399

400

401

402

403

404

405

406

407

408

409

410

411

412

413

414

415

416

417

418

419

420

421

423

424

425

426

427

428

429

430

431

432

433

434

435

436

437

438

439

440

441

442

443

444

445

446

447

448

449

450

451

452

453

454

455

456

457

458

459

461

462

463

464

465

466

467

468

469

470

471

472

473

474

475

476

477

478

479

480

481

482

483

484

485

486

487

488

489

490

491

492

493

494

495

496

497

498

499

500

501

502

503

504

505

506

507

508

509

510

511

512

513

514

515

516

517

518

519

520

521

523

524

525

526

527

528

529

530

531

532

533

535

536

537

538

539

540

541

542

543

544

545

Guide

Cover

Table of Contents

Preface

Chapter 1: Fundamentals of Corrosion in the Oil, Gas, and Chemical Industries

List of Illustrations

Figure 1.1

Figure 1.2

Figure 1.3

Figure 1.4

Figure 1.5

Figure 2.1

Figure 2.2

Figure 2.3

Figure 2.4

Figure 2.5

Figure 2.6

Figure 2.7

Figure 2.8

Figure 2.9

Figure 2.10

Figure 2.11

Figure 2.12

Figure 2.13

Figure 2.14

Figure 2.15

Figure 2.16

Figure 2.17

Figure 2.18

Figure 2.19

Figure 2.20

Figure 2.21

Figure 2.22

Figure 2.23

Figure 2.24

Figure 3.1

Figure 3.2

Figure 3.3

Figure 3.4

Figure 3.5

Figure 3.6

Figure 3.7

Figure 3.8

Figure 3.9

Figure 3.10

Figure 4.1

Figure 4.2

Figure 4.3

Figure 5.1

Figure 5.2

Figure 5.3

Figure 5.4

Figure 6.1

Figure 6.2

Figure 6.3

Figure 8.1

Figure 8.2

Figure 8.3

Figure 8.4

Figure 8.5

Figure 9.1

Figure 9.2

Figure 9.3

Figure 9.4

Figure 9.5

Figure 9.6

Figure 9.7

Figure 9.8

Figure 9.9

Figure 9.10

Figure 9.11

Figure 9.12

Figure 9.13

Figure 9.14

Figure 9.15

Figure 9.16

Figure 9.17

Figure 9.18

Figure 9.19

Figure 9.20

Figure 9.21

Figure 9.22

Figure 9.23

Figure 9.24

Figure 9.25

Figure 9.26

Figure 9.27

Figure 9.28

Figure 9.29

Figure 9.30

Figure 9.31

Figure 9.32

Figure 9.33

Figure 9.34

Figure 9.35

Figure 9.36

Figure 9.37

Figure 9.38

Figure 9.39

Figure 9.40

Figure 9.41

Figure 9.42

Figure 9.43

Figure 9.44

Figure 9.45

Figure 9.46

Figure 9.47

Figure 9.48

Figure 9.49

Figure 9.50

Figure 9.51

Figure 9.52

Figure 9.53

Figure 10.1

Figure 10.2

Figure 10.3

Figure 10.4

Figure 10.5

Figure 10.6

Figure 10.7

Figure 10.8

Figure 10.9

Figure 10.10

Figure 10.11

Figure 10.12

Figure 10.13

Figure 10.14

Figure 10.15

Figure 10.16

Figure 10.17

Figure 10.18

Figure 10.19

Figure 10.20

Figure 10.21

Figure 10.22

Figure 10.23

Figure 11.1

Figure 11.2

Figure 11.3

Figure 11.4

Figure 11.5

Figure 11.6

Figure 11.7

Figure 11.8

Figure 11.9

Figure 11.10

Figure 11.11

Figure 12.1

Figure 12.2

Figure 12.3

Figure 12.4

Figure 12.5

Figure 12.6

Figure 12.7

Figure 12.8

Figure 12.9

Figure 12.10

Figure 12.11

Figure 12.12

Figure 12.13

Figure 12.14

Figure 12.15

List of Tables

Table 2.1

Table 2.2

Table 3.1

Table 4.1

Table 4.2

Table 4.3

Table 4.4

Table 4.5

Table 4.6

Table 4.7

Table 4.8

Table 4.9

Table 4.10

Table 4.11

Table 4.12

Table 4.13

Table 4.14

Table 4.15

Table 4.16

Table 5.1

Table 5.2

Table 5.3

Table 5.4

Table 5.5

Table 6.1

Table 6.2

Table 6.3

Table 6.5

Table 6.6

Table 6.4

Table 6.7

Table 6.8

Table 6.9

Table 7.1

Table 7.2

Table 7.3

Table 7.4

Table 7.5

Table 7.6

Table 7.7

Table 7.8

Table 8.1

Table 8.2

Table 8.3

Table 8.4

Table 8.5

Table 8.6

Table 8.7

Table 8.8

Table 8.9

Table 8.10

Table 8.11

Table 8.12

Table 9.1

Table 9.2

Table 10.1

Table 10.2

Table 10.3

Table 10.4

Table 10.5

Table 11.1

Table 11.2

Table 11.3

Table 11.4

Table 11.5

Table 11.6

Table 11.7

Table 11.8

Table 11.9

Table 11.10

Table 11.11

Table 11.12

Table 11.13

Table 12.1

Table 12.2

Table 12.3

Table 12.4

Table 12.5

Table 12.6

Table 12.7

Table 12.8

Table 12.9

Corrosion and Materials Selection

A Guide for the Chemical and Petroleum Industries

Alireza Bahadori

School of Environment, Science and Engineering, Southern Cross University, Australia

This edition first published 2014

© 2014 John Wiley & Sons, Ltd

Registered office

John Wiley & Sons Ltd, The Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, United Kingdom

For details of our global editorial offices, for customer services and for information about how to apply for permission to reuse the copyright material in this book please see our website at www.wiley.com.

The right of the author to be identified as the author of this work has been asserted in accordance with the Copyright, Designs and Patents Act 1988.

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, except as permitted by the UK Copyright, Designs and Patents Act 1988, without the prior permission of the publisher.

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic books.

Designations used by companies to distinguish their products are often claimed as trademarks. All brand names and product names used in this book are trade names, service marks, trademarks or registered trademarks of their respective owners. The publisher is not associated with any product or vendor mentioned in this book.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. It is sold on the understanding that the publisher is not engaged in rendering professional services and neither the publisher nor the author shall be liable for damages arising herefrom. If professional advice or other expert assistance is required, the services of a competent professional should be sought

The advice and strategies contained herein may not be suitable for every situation. In view of ongoing research, equipment modifications, changes in governmental regulations, and the constant flow of information relating to the use of experimental reagents, equipment, and devices, the reader is urged to review and evaluate the information provided in the package insert or instructions for each chemical, piece of equipment, reagent, or device for, among other things, any changes in the instructions or indication of usage and for added warnings and precautions. The fact that an organization or Website is referred to in this work as a citation and/or a potential source of further information does not mean that the author or the publisher endorses the information the organization or Website may provide or recommendations it may make. Further, readers should be aware that Internet Websites listed in this work may have changed or disappeared between when this work was written and when it is read. No warranty may be created or extended by any promotional statements for this work. Neither the publisher nor the author shall be liable for any damages arising herefrom.

Library of Congress Cataloging-in-Publication Data

Bahadori, Alireza.

Corrosion and materials selection : a guide for the chemical and petroleum industries / Alireza Bahadori.

pages cm

Includes bibliographical references and index.

ISBN 978-1-118-86922-2 (cloth)

1. Petroleum refineries— Materials— Corrosion. 2. Petroleum pipelines— Corrosion. 3. Corrosion and anti-corrosives. I. Title.

TP690.8.B24 2014

660′.28304— dc23

2014004163

ISBN: 9781118869222

1 2014











Dedicated to the loving memory of my parents, grandparents, and to all who contributed so much to my work over the years

About the Author

Alireza Bahadori, PhD, is a research staff member in the School of Environment, Science and Engineering at Southern Cross University, Lismore, NSW, Australia. He received his PhD from Curtin University, Perth, Western Australia.

During the past 20 years, Dr Bahadori has held various process and petroleum engineering positions and has been involved in many large-scale projects at the National Iranian Oil Co. (NIOC), Petroleum Development Oman (PDO), and Clough AMEC PTY LTD. He is the author of around 250 articles and 12 books, published by prestigious publishers such as John Wiley & Sons, Elsevier, Springer, and Taylor & Francis.

Dr Bahadori is the recipient of the highly competitive and prestigious Australian Government's Endeavour International Postgraduate Research Award as part of his research in the oil and gas area. He also received a top-up award from the State Government of Western Australia through Western Australia Energy Research Alliance (WA:ERA) in 2009. Dr Bahadori serves as a member of the editorial board and a reviewer for a large number of journals. He was honoured by Elsevier as the outstanding author of Journal of Natural Gas Science and Engineering in 2009.

Preface

Metallic corrosion is costly. Several billion dollars annually in the USA, and about one-third of that is noted as avoidable corrosion, a cost that could be eliminated if proper corrosion protection methods were in place.

Today, there are a great deal of construction materials available, varying from metallic to non-metallic. There are also a large number of factors to be taken into consideration when selecting a material for a given application.

Factors that influence corrosion consideration in material selection are distinct from those that interact in a more complex fashion. For example, “application” influences selection because the type of process, and the variables during operation etc., will define whether a material can be used for the intended purpose or not. On the other hand mechanical and metallurgical properties are not uniquely defined for all environments. For example, if the material is to be used at low temperature then embrittlement can be a serious problem.

These considerations have a direct influence on corrosion consideration in material selection. However, when there is discrepancy amongst sections of this book, or between this and other disciplines regarding selection of materials, other priorities, such as client preference, in-house experience, and specific industry standards, should also be observed.

This book covers corrosion considerations in the selection of materials specifically used in the oil, gas, chemical and petrochemical industries. It provides the necessary tools for the design stage of a system, in order to avoid or minimize corrosion hazards technically, economically and safely during the designed life of such a system. Proper corrosion control of structures and units is most effectively and economically begun during the design stage.

Various forms of corrosion and prevention methods are discussed in this book.

It also deals with the control of corrosive environments by inhibitors, general requirements for the petroleum and chemical industries, and utility systems such as cooling water, boiler water systems etc.

Finally it deals with monitoring internal corrosion. It provides guidance for on-line monitoring of internal corrosion in plants associated with the oil, gas and chemical industries, and guidance on laboratory monitoring and evaluation of corrosion inhibitors. The book also covers experiments on the corrosion behaviour of high-alloy tubular materials in inhibited acidizing conditions.

Metallic corrosion is costly. However, the cost of corrosion is not just financial. Beyond the huge direct outlay of funds to repair and/or replace corroded and/or decaying structures are the indirect costs (natural resources, potential hazards, and lost opportunities). When a project is constructed with a material not able to survive its environment for the length of the designed life, natural resources are needlessly consumed to continually repair and maintain the structure. Wasting natural resources is a direct contradiction of the growing need for sustainable development to benefit future generations.

In addition to the waste of natural resources, facilities that cannot sustain their environment can lead to hazardous situations. Accidents caused by corroded structures can lead to huge safety concerns, loss of life and resources, and more. One failed pipeline, bridge collapse, or other catastrophe is one too many, and leads to huge indirect costs (more traffic delays, loss of business, etc.) and public outcry. Depending on which market sector (industrial, infrastructure, commercial, etc.) is being considered, these indirect costs may be as high as five to ten times the direct cost.

Acknowledgements

I would like to thank the editorial and production team, Rebecca Stubbs, Emma Strickland, and Sarah Keegan of John Wiley & Sons for their editorial assistance.

Chapter 1Fundamentals of Corrosion in the Oil, Gas, and Chemical Industries

The petroleum and chemical industries contain a wide variety of corrosive environments; many are unique to these industries. Thus it is convenient to group all these environments together. Corrosion problems occur in at least three general areas: (1) production, (2) transportation and storage, and (3) operations.

Oil and gas production operations consume a tremendous amount of iron and steel pipe, tubing, pumps, valves, and sucker rods. Leaks cause loss of oil and gas, and also permit infiltration of water and silt, thus increasing corrosion damage. Saline water and sulfides are often present in oil and gas wells and corrosion occurs both inside and outside the casing. Surface equipment is subject to atmospheric corrosion.

What follows is a simple explanation of how corrosion occurs, the different types, and how problems can be solved.

We have all seen corrosion and know that the process produces a new and less desirable material from the original metal and can result in a loss of function of the component or system. The corrosion product we see most commonly is the rust which forms on the surface of steel.

1.1

For this to happen the major component of steel, iron (Fe) at the surface of a component undergoes a number of simple changes. Firstly, the iron atom can lose some electrons and become a positively charged ion.

1.2

This allows it to bond to other groups of atoms that are negatively charged. We know that wet steel rusts to give a variant of iron oxide, so the other half of the reaction must involve water and oxygen , something like this:

1.3

This makes sense as we have a negatively charged material that can combine with the iron and electrons produced in the first reaction. We can, for clarity, ignore the electrons and write

1.4

Oxygen dissolves quite readily in water and because there is usually an excess of it, reacts with the iron hydroxide.

1.5

This series of steps tells us a lot about the corrosion process:

Ions are involved and need a medium to move in (usually water).

Oxygen is involved and needs to be supplied.

The metal has to be willing to give up electrons to start the process.

A new material is formed and this may react again or could protect the original metal.

A series of simple steps are involved and a driving force is needed to achieve them.

The most important fact is that interfering with the steps allows the corrosion reaction to be stopped or slowed to a manageable rate.

1.1 Uniform Corrosion

Uniform corrosion, as the name suggests, occurs over the majority of the surface of a metal at a steady and often predictable rate. Although it is unsightly, its predictability facilitates easy control, the most basic method being to make the material thick enough to function for the lifetime of the component. Uniform corrosion can be slowed or stopped in five basic ways:

Slow down or stop the movement of electrons:

Coat the surface with a non-conducting medium such as paint, lacquer or oil

Reduce the conductivity of the solution in contact with the metal, an extreme case being to keep it dry

Wash away conductive pollutants regularly

Apply a current to the material (see cathodic protection).

Slow down or stop oxygen from reaching the surface. This is difficult to do completely, but coatings can help.

Prevent the metal from giving up electrons:

Use a more corrosion-resistant metal higher in the electrochemical series,

Use a sacrificial coating that gives up its electrons more easily than the metal being protected

Apply cathodic protection

Use inhibitors.

Select a metal that forms an oxide that is protective and stops the reaction.

Control and consideration of environmental and thermal factors is also essential.

1.2 Localized Corrosion

The consequences of localized corrosion can be a great deal more severe than uniform corrosion, generally because the failure occurs without warning and after a surprisingly short period of use or exposure. Application of the five basic principles needs greater thought and insight.

1.2.1 Galvanic Corrosion

This can occur when two different metals are placed in contact with each other and is caused by the greater willingness of one to give up electrons than the other. Three special features of this mechanism need to operate for corrosion to occur:

The metals need to be in contact electrically.

One metal needs to be significantly better at giving up electrons than the other

An additional path for ion and electron movement is necessary.

Prevention of this problem is based on ensuring that one or more of the three features do not exist:

Break the electrical contact using plastic insulators or coatings between the metals.

Select metals close together in the galvanic series.

Prevent ion movement by coating the junction with an impermeable material, or ensure the environment is dry and that liquids cannot be trapped.

1.2.2 Pitting Corrosion

Pitting corrosion occurs in materials that have a protective film, such as a corrosion product or a coating. When this breaks down, the exposed metal gives up electrons easily and the reaction initiates tiny pits with localized chemistry supporting rapid attack. Control can be ensured by:

selecting a resistant material,

ensuring a high enough flow velocity of fluids in contact with the material or

frequent washing,

control of the chemistry of fluids and use of inhibitors,

use of a protective coating,

maintaining the material's own protective film.

Note: Pits can be crack initiators in stressed components or those with residual stresses resulting from forming operations. This can lead to stress corrosion cracking.

1.2.3 Selective Attack

This occurs in alloys such as brass, when one component or phase is more susceptible to attack than another and corrodes preferentially, leaving a porous material that crumbles. It is best avoided by selection of a resistant material, but other means can be effective such as:

Coating the material

Reducing the aggressiveness of the environment

Use of cathodic protection.

1.2.4 Stray Current Corrosion

When a direct current flows through an unintended path, the flow of electrons supports corrosion. This can occur in soils, and flowing or stationary fluids. The most effective remedies involve controlling the current by:

insulating the structure to be protected or the source of current,

earthing sources and/or the structure to be protected,

applying cathodic protection,

using sacrificial targets.

1.2.5 Microbial Corrosion

This general class covers the degradation of materials by bacteria, molds, and fungi, or their by-products. It can occur by a range of actions, such as:

Attack on the metal or protective coating by acid by-products, sulfur, hydrogen, sulfide or ammonia

Direct interaction between the microbes and metal under attack.

Prevention can be achieved by:

selection of resistant materials,

frequent cleaning,

control of the chemistry of the surrounding medium and removal of nutrients,

use of biocides,

cathodic protection.

1.2.6 Intergranular Corrosion

This is preferential attack on the grain boundaries of the crystals that form the metal. It is caused by the physical and chemical differences between the centers and the edges of the grain.

It can be avoided by:

selection of stabilized materials,

control of heat treatments and processing to avoid susceptible temperature range.

1.2.7 Concentration Cell Corrosion (Crevice)

If two areas of a component in close proximity differ in the amount of reactive constituent available, the reaction in one of the areas is speeded up. An example of this is crevice corrosion, which occurs when oxygen cannot penetrate a crevice and a differential aeration cell is set up. Corrosion occurs rapidly in the area with less oxygen. The potential for crevice corrosion can be reduced by:

avoiding sharp corners and designing out stagnant areas,

use of sealants,

use of welds instead of bolts or rivets,

selection of resistant materials.

1.2.8 Thermogalvanic Corrosion

Temperature changes can alter the corrosion rate of a material and a good rule of thumb is that a 10 °C rise doubles the corrosion rate. If one part of component is hotter than another, the difference in the corrosion rate is accentuated by the thermal gradient and local attack occurs in a zone between the maximum and minimum temperatures. The best method of prevention is to design out the thermal gradient or to supply a coolant to even out the difference.

1.2.9 Corrosion Caused By Combined Action

This is corrosion accelerated by the action of fluid flow, sometimes with the added pressure of abrasive particles in the stream. The protective layers and corrosion products of the metal are continually removed, exposing fresh metal to corrosion. Prevention can be achieved by:

reducing the flow rate and turbulence,

use of replaceable or robust linings in susceptible areas,

avoiding sudden changes of direction,

streamlining or avoiding obstructions to the flow.

1.2.10 Corrosion Fatigue

The combined action of cyclic stresses and a corrosive environment reduce the life of components below that expected by the action of fatigue alone. This can be reduced or prevented by:

coating the material,

good design that reduces stress concentration,

avoiding sudden changes of section,

removing or isolating sources of cyclic stress.

1.2.11 Fretting Corrosion

This is caused by relative motion between two surfaces in contact by a stick–slip action resulting in breakdown of protective films or welding at the contact areas, allowing other corrosion mechanisms to operate. Prevention is possible by:

designing out vibrations,

lubrication of metal surfaces,

increasing the load between the surfaces to stop the motion,

surface treatments to reduce wear and increase the friction coefficient.

1.2.12 Stress Corrosion Cracking

The combined action of a static tensile stress and corrosion forms cracks and eventually leads to catastrophic failure of the component. This is specific to a metal material paired with a specific environment. Prevention can be achieved by:

reducing the overall stress level and designing out stress concentrations,

selection of a suitable material not susceptible to the environment,

designing to minimize thermal and residual stresses,

developing compressive stresses in the surface the material,

use of a suitable protective coating.

1.2.13 Hydrogen Damage

A surprising fact is that hydrogen atoms are very small and hydrogen ions even smaller and can penetrate most metals. Hydrogen, by various mechanisms, embrittles a metal, especially in areas of high hardness causing blistering or cracking particularly in the presence of tensile stresses. This problem can be prevented by:

using a resistant or hydrogen-free material,

avoiding sources of hydrogen, such as cathodic protection, pickling processes, and certain welding processes,

removal of hydrogen within the metal by baking.

Corrosion control measures should be implemented during the design stage of petroleum and chemical plants and include:

Proper design

Proper material selection

Proper process that involves reduced temperature, low concentration of critical corrosive species, reduced flow velocity, oxygen elimination, etc.

Proper protective coatings and linings, especially for refractories.

For practical purposes, corrosion in oil, gas, petrochemical, and chemical plants can be classified into low-temperature corrosion and high temperature corrosion. Low temperature corrosion occurs below 260 °C in the presence of water. High temperature corrosion takes place above 260 °C. The presence of water is not necessary in this case because corrosion occurs by direct reaction between the metal and the environment.

1.3 Low-Temperature Corrosion

Most corrosion problems are not caused by hydrocarbons, but by various inorganic compounds such as water, hydrogen sulfide, hydrochloric acid, hydrofluoric acid, sulfuric acid, and caustic. There are two principal sources of these compounds, feed-stock contaminants and process chemicals.

1.3.1 Low-Temperature Corrosion by Feed-Stock Contaminants

In this case, the cause of refinery corrosion is the presence of contaminants in the crude oil as it is processed. Corrosive hydrogen chloride evolves in crude preheat furnaces from relatively harmless magnesium and calcium chlorides entrained in crude oil. In petrochemical plants, certain corrosives may have been introduced from upstream refinery and other process operations. Other corrosives can form from corrosion products after exposure to air during shut-down; polythionic acids fall into this category. Corrosive contaminants are as follows:

Air

Water

Hydrogen sulfide

Hydrogen chloride

Nitrogen compounds

Sour water

Polythionic acids.

1.3.1.1 Air

During shut-down most plant equipment is exposed to air. Air also can enter the suction side of pumps if seals are not tight. In general, the air contamination of hydrocarbon streams is more detrimental with regard to fouling than corrosion. However, air contaminant has been cited as a cause of accelerated corrosion in vacuum towers and vacuum transfer lines, and accelerated overhead corrosion of crude distillation towers.

1.3.1.2 Water

The water content of crude oils and water originating from stripping steam in fractionation towers hydrolyzes certain inorganic chlorides to hydrogen chloride, and is responsible for various forms of corrosion in fractionation tower overhead systems. It is good practice to keep equipment dry in order to minimize corrosion.

A combination of moisture and air enters into storage tanks during normal breathing as a result of pumping and changes in temperature. Corrosion of tank bottoms occurs mostly with crude oil tanks, and is caused by water and salt entrained in the crude oil. A layer of water usually settles out and can become highly corrosive.

1.3.1.3 Hydrogen Sulfide

Hydrogen sulfide is the main constituent of refinery sour water and can cause severe corrosion problems in the overhead systems of certain fractionation towers, in hydrocracker and hydrotreater effluent streams from vapor recovery of fluid catalytic cracking (FCC) units, in sour water stripping units and in sulfur recovery units. Carbon steel has fairly good resistance to aqueous sulfide corrosion because a protective film of FeS is formed to avoid hydrogen stress cracking (sulfide cracking); hard welds (above 200 HB) must be avoided, through suitable post-weld heat treatment, if necessary.

Excessive localized corrosion in vessels can be resolved by selective lining with alloy 400 (N04400), but this can be less resistant than carbon steel to aqueous sulfide corrosion at temperatures above 150 °C. If significant amounts of chlorides are not present, lining vessels with Type 405 (S40500) or Type 304 (S30400) stainless steel can be considered.

Recently titanium Grade 2 (R50400) tubes have been used as replacements for carbon steel tubes to control aqueous sulfide corrosion in heat exchangers. Hydrogen sulfide is present in some feed stocks handled by petrochemical plants. During processing at elevated temperatures, hydrogen sulfide is also formed by the decomposition of organic sulfur compounds that are present.

1.3.1.4 Hydrogen Chloride

In refineries, corrosion by hydrogen chloride is primarily a problem in crude distillation units, and to lesser degree in reforming and hydrotreating units. In petrochemical plants, HCl contamination can be present in certain feed stocks or can be formed by the hydrolysis of aluminium chloride catalyst.

To minimize aqueous chloride corrosion in the overhead system of crude towers, it is best to keep the salt content of the crude oil charge as low as possible, about 4 ppm. Another way to reduce overhead corrosion would be to inject sodium hydroxide into the crude oil, downstream of the desalter. Up to 10 ppm caustic soda can usually be tolerated.

In most production wells, chloride salts are found either dissolved in water that is emulsified in crude oil or as suspended solids. Salts also originate from brines injected for secondary recovery or from seawater ballast in marine tankers. Typically, the salts in crude oils consist of 75% sodium chloride, 15% magnesium chloride, and 10% calcium chloride. When crude oils are charged to crude distillation units and heated to temperatures above approximately 120 °C, hydrogen chloride is evolved from magnesium and calcium chloride, while sodium chloride is essentially stable up to roughly 750 °C.

Neutralizers are injected into the overhead vapor line of the crude tower to maintain the pH value of the stripping steam condensate between 5 and 6. A pH value above 7 can increase corrosion with sour crudes, as well as fouling and underdeposit corrosion by chloride salt neutralizers.

1.3.1.5 Nitrogen Compounds

Organic nitrogen compounds, such as indole, carbuzole, pyridine, or quinoline, are present in many crude oils, but do not contribute to corrosion problems unless converted to ammonia or hydrogen cyanide. This occurs in catalytic cracking, hydrotreating, and hydrocracking operations, where , in combination with and other constituents, becomes the major constituent of sour water, which can be highly corrosive to carbon steel.

Ammonia is also produced in ammonia plants as a raw material for the manufacture of urea and other nitrogen-based fertilizers. Ammonia in synthesis gas at temperatures between 450 and 500 °C causes nitridation of steel components. When synthesis gas is compressed to up to 34.5 MPa (5000 psig) prior to conversion, corrosive ammonium carbonate is formed, requiring various stainless steels for critical components. Condensed ammonia is also corrosive and can cause stress corrosion cracking (SCC) of stressed carbon steel and low-alloy steel components.

1.3.1.6 Sour Water

The term sour water denotes various types of process water containing and small amounts of phenols, mercaptanes, chlorides, and fluorides. High concentrations of ammonia can saturate process water with ammonium bisulfide and causes serious corrosion of carbon steel components. Ammonium bisulfide will also rapidly attack admiralty metal (C44300) tubes. Only titanium Grade 2 (R50400) tubes have sufficient resistance to be used in this case.

1.3.1.7 Polythionic Acids

Combustion of in refinery flares can produce polythionic acids of the type (including sulfurous acid) and can cause severe intergranular corrosion of flare tips made of stainless steels and high-nickel alloys. Corrosion can be minimized by using lower-nickel alloys such as alloy 825 (N08825) or alloy 625 (N06625). Polythionic acids also cause SCC during shut-down.

1.3.2 Low-Temperature Corrosion by Process Chemicals

Severe corrosion problems can be caused by process chemicals, such as various alkylation catalysts and by-products, organic acid solvents used in certain petrochemical processes, hydrogen chloride stripped off reformer catalysts, and caustic and other neutralizers that ironically, are added to control acid corrosion. A filming-amine corrosion inhibitor can be quite corrosive if injected undiluted (neat) into a hot vapor stream. Another group of process chemicals that are corrosive, or become corrosive, is solvents used in treating and gas-scrubbing operations. These chemicals are as follows:

Acetic acid

Aluminum chloride

Organic chloride

Hydrogen fluoride

Sulfuric acid

Caustic

Amine

Phenol.

1.3.2.1 Acetic Acid

Corrosion by acetic acid can be a problem in petrochemical process units for the manufacture of certain organic intermediates such as terephthalic acid. Various types of austenitic stainless steels are used, as well as alloy C-4 (N06455), alloy C-276 (N10276) and titanium, to control corrosion by acetic acid in the presence of small amount of hydrogen bromide or hydrogen chloride.

A small amount of water in the acetic acid can have a significant influence on corrosion. Type 304 (S30400) stainless steel has sufficient resistance to lower concentrations of acetic acid up to the boiling point. Higher concentrations can be handled by type 304 stainless steel if the temperature is below 90 °C.

Corrosion by acetic acid increases with temperature. Bromide and chloride contamination causes pitting and SCC, while addition of oxidizing agents, including air, can reduce corrosion rates by several orders of magnitude. Figure 1.1 shows fracture morphologies (side view) of the 3.5NiCrMoV steels tested at various acetic acid concentrations (pH 3.21–4.95) with a strain rate of at 150 °C.

Figure 1.1Fracture morphologies (side view) of the 3.5NiCrMoV steels tested at various acetic acid concentrations (pH 3.21–4.95) with a strain rate of at 150 °C.

(Reprinted from W.Y. Maeng, D.D. Macdonald, 2008, with permission from Elsevier.)

1.3.2.2 Aluminium Chloride

Certain refining and petrochemical processes, such as butane isomerization, ethylbenzene production and polybutene production, use aluminium chloride as a catalyst. It is not corrosive if it is kept absolutely dry, otherwise it hydrolyzes to hydrochloric acid.

During shut-down, equipment should be opened for the shortest possible time. Upon closing, the system should be dried with hot air, followed by inert gas blanketing. Equipment that is exposed to hydrochloric acid may require extensive lining with nickel alloys, such as alloys 400 (N04400), B-2 (N10665), G4 (N06455), or C-276 (N10276).

1.3.2.3 Organic Chloride

Organic chloride in crude oils will form various amounts of hydrogen chloride at the elevated temperatures of crude preheat furnaces. Many crude oils contain small amounts of organic chlorides (5 to 50 ppm), but the major problem is contamination with chlorinated organic solvents during production.

If contaminated crude oil must be run off for distillation, the usual approach is to blend it slowly into uncontaminated crude oil.

1.3.2.4 Hydrogen Fluoride

Some alkylation processes use concentrated HF instead of as the catalyst. In general, HF is less corrosive than HCl because it passivates most metals by the formation of protective fluoride films. If these films are destroyed by dilute acid, severe corrosion occurs. Therefore, as long as feedstocks are dry, carbon steel—with various corrosion allowances—can be used for the vessels, piping, and valve bodies of hydrofluoric acid alkylation units. All carbon steel welds that will contact HF, should be post-weld heat treated.

Fractionation towers should have Type 410 (S41000) stainless steel tray valves and bolting, and for desiobutanizer tower tray valves and bolting, alloy 400 (N04400) is recommended. Corrosion problems in HF alkylation units occur after shut-down because pockets of water have been left in the equipment. It is very important that equipment be thoroughly dried by draining all low spots and by circulating hydrocarbon before the introduction of HF catalyst at start-up.

1.3.2.5 Sulfuric Acid

Certain alkylation units use essentially concentrated sulfuric acid as the catalyst; some of this acid is entrained in reactor effluent and must be removed by neutralization with caustic and scrubbing with water. Acid removal may not be complete, however, and traces of acid—at various concentrations (in terms of water)—remain in the stream.

Dilute sulfuric acid can be highly corrosive to carbon steel, which is the principal material of construction for sulfuric acid alkylation units. Because the boiling point of sulfuric acid ranges from 165 to 315 °C, depending on concentration, entrained acid usually ends up in the bottom of the first fractionation tower and reboiler following the reactor; this is where the entrained acid becomes concentrated.

Acid concentrations above 85% by weight are not corrosive to carbon steel if temperatures are below 40 °C. Cold-worked metal (usually used for bends) should be stress relieved. Under ideal operating conditions, few, if any, corrosion and fouling problems occur.

Carbon steel depends on a film of iron sulfate for corrosion resistance, and if this film is destroyed by high velocities and flow turbulence, corrosion can be quite severe.

Figure 1.2 shows corrosion rate as a function of concentration for carbon steel with different amounts of carbon. Test temperature: . Figure 1.3 illustrates a carbon steel ring in 96% reagent-grade under static conditions at 25 °C.

Figure 1.2Corrosion rate as a function of concentration for carbon steel with different amounts of carbon. Test temperature: . Test duration: 24 h (except for tests in which the corrosion rate was so high that the steel specimen would have completely corroded).

(Reprinted from Z. Panossian et al., 2012, with permission from Elsevier.)

Figure 1.3A carbon steel ring in 96% reagent-grade under static conditions at 25 °C

(Reprinted from Z. Panossian et al., 2012, with permission from Elsevier.)

1.3.2.6 Caustic

Sodium hydroxide is widely used in refinery and petrochemical plant operations to neutralize acid constituents. At ambient temperature and under dry conditions, NaOH can be handled in carbon steel equipment. Carbon steel is also satisfactory for aqueous caustic solutions below 50–80 °C, depending on concentration. For caustic service above these temperatures, but below 95 °C, carbon steel can also be used if it has been post-weld heat treated to avoid SCC at welds. Austenitic stainless steels, such as Type 304 (S 30400), can be used up to approximately 120 °C, while nickel alloys are required at higher temperatures.

Injecting 3%, instead of 40% NaOH solution minimizes the problem of soda corrosion of the crude transfer line. If caustic is injected too close to an elbow of the transfer line, impingement by droplets of caustic can cause severe attack and a hole-through at the elbow.

1.3.2.7 Amines

Corrosion of carbon steel by amines in gas treating and sulfur recovery units can usually be traced to faulty plant design, poor operating practices, and solution contamination. In general, corrosion is most severe in systems removing only and is least severe in systems removing only .

Systems handling mixtures of the two fall between these two extremes if the gases contain at least 1 vol.% . Corrosion in amine plants using monoethanolamine is more severe than in those using diethanolamine, because the former is more prone to degradation. Corrosion is not caused by the amine itself, but is caused by dissolved hydrogen sulfide or carbon dioxide and by amine degradation products.

1.3.2.8 Phenol

Phenol (carbolic acid) is used in refineries to convert heavy, waxy distillates obtained from crude oil distillation into lubricating oils. As a rule, all components in the treating and raffinate recovery sections, except tubes in water-cooled heat exchangers, are made from carbon steel. If water is not present, few significant corrosion problems can be expected to occur in these sections.

In the extract recovery section severe corrosion can occur, especially where high flow turbulence is encountered. As a result, certain components require selective alloying with Type 316 (S31600) stainless steel. Typically, stainless steel liners are required for the top of the dryer tower, the entire phenol flash tower, and various condenser shells and separator drums that handle phenolic water.

Tubes and headers in the extract furnace should also be made of Type 316 (S31600) stainless steel with U-bends sleeved in alloy C-4 (N06455) on the outlet side to minimize velocity accelerated corrosion.

1.4 High-Temperature Corrosion

Equipment failures can have serious consequences because processes at high temperatures usually involve high pressures as well. With hydrocarbon streams, there is always the danger of fire when ruptures occur.

High-temperature refinery corrosion is caused by various sulfur compounds originating from crude oil. Sulfidic corrosion rate correlations are available and therefore equipment life can be predicted with some degree of reliability. Different types of high-temperature corrosion are named as follows:

Sulfidic corrosion

Sulfidic corrosion without hydrogen present

Sulfudic corrosion with hydrogen present

Naphthenic acids

Fuel ash

Oxidation.

1.4.1 Sulfidic Corrosion

Corrosion by various sulfur compounds at temperatures between 260 and 540 °C is a common problem in many petroleum-refining processes, and occasionally in petrochemical processes. Sulfur compounds originate from crude oils and include polysulfides, hydrogen sulfide, mercaptans, aliphatic sulfides, disulfides, and thiophenes.

With the exception of thiophenes, sulfur compounds react with metal surfaces at elevated temperatures, forming metal sulfide, certain organic molecules, and hydrogen sulfide. Corrosion is in the form of uniform thining, localized attack, or erosion corrosion.

Nickel and nickel-rich alloys are rapidly attacked by sulfur compounds at elevated temperatures, while chromium-containing steels provide excellent corrosion resistance (as does aluminium). Combinations of hydrogen sulfide and hydrogen can be particularly corrosive, and as a rule, austenitic stainless steels are required for effective corrosion control.

1.4.2 Sulfidic Corrosion without Hydrogen Present

This type of corrosion occurs in various components of crude distillation, catalytic cracking, hydrotreating, and hydrocracking units upstream of the hydrogen injection line.

Preheat-exchanger tubes, furnace tubes, and transfer lines are generally made from carbon steel, as is the corresponding equipment in the vacuum distillation section. The lower shell of distillation towers, where temperatures are above 230 °C is usually lined with stainless steel containing 12% Cr, such as Type 405. Trays are made of stainless steel containing 12% Cr. Even with the low corrosion rates of carbon steel, certain tray compounds, such as tray valves, may fail in a short time because attack occurs from both sides of a relatively thin piece of metal.

Metal skin temperature, rather than flow stream temperatures, should be used to predict corrosion rates when significant differences between the two arise. For example, metal temperatures of furnace tubes are typically 85 to 110 °C higher than the temperature of the hydrocarbon stream passing through the tubes. Furnace tubes normally corrode at a higher rate on the hot side (fire side) than on the cool side (wall side).

1.4.3 Sulfidic Corrosion with Hydrogen Present

The presence of hydrogen in, for example, hydrotreating and hydrocracking operations, increases the severity of high-temperature sulfidic corrosion. Hydrogen coverts organic sulfur compounds in feed stocks to hydrogen sulfide; corrosion becomes a function of H2S concentration.

Downstream of the hydrogen injection line, low-alloy steel piping usually requires aluminizing in order to minimize sulfidic corrosion. Alternatively Type 321 (S32100) stainless steel can be used. Tubes in the preheat furnace are aluminized low-alloy steel, or aluminized 12% Cr stainless steel. Reactors are usually made of 2.25 Cr-1 Mo steel, either with a Type 347 (S34700) stainless steel weld overlay or an internal factory lining. Reactor internals are often Type 321 stainless steel.

When selecting materials for this service, the recommendations of API 941-2004 should be followed to avoid problems with high-temperature hydrogen attack.

The most practical corrosion rate correlations seem to be the so-called Cooper–Gorman curves based on a survey conducted by the NACE Committee T-8 on Refining Industry Corrosion. A modified Cooper–Gorman curve is shown in Figure 1.4. To facilitate use of these curves the original segments of the curves have been extended (dashed lines).

Figure 1.4Effect of temperature and hydrogen sulfide content on high-temperature corrosion of 5 Cr-0.5 Mo steel (naphtha desulfurizers) .

(Reproduced with permission from Wesfarmers Chemicals, Energy & Fertilisers. www.wescef.com.au)

Stainless steels containing at least 18% Cr are often required for complete immunity to corrosion because Cooper–Gorman curves are primarily based on corrosion rate data for an all-vapor system; partial condensation can be expected to increase corrosion rates because of droplet impingement.

1.4.4 Naphthenic Acids

These organic acids are present in many crude oils. The general formula may be written as , where R is usually a cyclopentane ring. The higher molecular weight acids can be bicyclic , tricyclic , and even polycyclic. Naphthenic acid content is generally expressed in terms of the neutralization number (total acid number), which should be evaluated by ASTM D 664 as mg KOH/grams of sample.

This acid is corrosive only at temperatures above 230 °C in the neutralization number range of 1 to 6 encountered with crude oil and various side-cuts. At any given temperature, the corrosion rate is proportional to the neutralization number, and triples with each 55 °C increase in temperature.

In contrast to high-temperature sulfidic corrosion, no protective scale is formed, and low-alloy and stainless steels containing up to 12% Cr provide no benefits whatsoever over carbon steel. The presence of naphthenic acids may accelerate high-temperature sulfidic corrosion that occurs at furnace headers, elbows, and tees of crude distillation units because of unfavorable flow conditions.

Severe naphthenic acid corrosion (in the form of pitting) has been experienced in the vacuum towers of crude distillation units in the temperature zone of 290 to 345 °C and sometimes as low as 230 °C. Attack is often limited to the inside and the very top of the outside surfaces of bubble caps. Figure 1.5 shows different kinds of corrosion morphologies associated with naphthenic acid attack. Region 1 is the IMPT random packing, region 2 is the tray and bubble caps, region 3 is the column wall flash zone, region 4 is the support grid, and region 5 is the transfer line.

Figure 1.5Different kinds of corrosion morphologies associated with naphthenic acid attack. Region 1 is the IMPT random packing, region 2 is the tray and bubble caps, region 3 is the column wall flash zone, region 4 is the support grid, and region 5 is the transfer line.

(Reprinted from P.P. Alvisi, V.F.C. Lins, 2011, with permission from Elsevier.)

Attacks on bubble caps are due to impinging droplets of condensing acids. Naphthenic acid corrosion is most easily controlled by blending crude oils having high neutralization numbers with other crude oils, in order to keep this neutralization number between 0.5 and 1.0. However, this does not prevent corrosion of vacuum tower internals operating in the 290 to 345 °C range. These should be made from Type 316 (S31600) or, preferably, Type 317 (S31700) stainless steel containing at least 3.5% Mo. The vacuum tower lining in this temperature range should also be Type 317 (S31700) stainless steel. Aluminum has excellent resistance to naphthenic acid corrosion in vacuum towers and can be used if its strength limitations and low resistance to velocity effects are kept in mind. Alloy 20 (N08020) and titanium Grade 2 (R50400) are also resistant to naphthenic acid corrosion. In contrast, aluminized carbon steel tray components, such as bubble caps, have performed poorly.

1.4.5 Fuel Ash

Corrosion by fuel ash deposits can be one of the most serious operating problems with boiler and preheat furnaces. All fuels except natural gas contain certain inorganic contaminants that leave the furnace with products of combustion. These will deposit on heat-receiving surfaces, such as superheater tubes, and after melting can cause severe liquid-phase corrosion.

Contaminants of this type include various combinations of vanadium, sulfur, and sodium compounds. Fuel ash corrosion is most likely to occur when residual fuel oil (Bunker C fuel) is burned. In particular, vanadium pentoxide vapor reacts with sodium sulfate to form sodium vanadate . The latter compound reacts with steel, forming a molten slag that runs off and exposes fresh metal to attack. Corrosion increases sharply with increasing temperature and the vanadium content of the fuel oil. If the vanadium content exceeds 150 ppm, the maximum tube wall temperature should be limited to 650 °C. Between 20 and 150 ppm V, the maximum tube wall temperature can be between 650 and 845 °C, depending on the sulfur content and the sodium–vanadium ratio of the fuel oil. With 5 to 20 ppm V, the maximum tube wall temperature can exceed 845 °C.

In general, most alloys are likely to suffer from fuel ash corrosion. However, alloys with high chromium and nickel contents provide the best resistance to this type of attack. Sodium vanadate corrosion can be reduced by firing boilers with low excess air . This minimizes the formation of sulfur trioxide in the firebox and produces high-melting slags containing vanadium tetroxide and trioxide rather than pentoxide. In the temperature range 400 to 480 °C, boiler tubes are corroded by alkali pyrosulfates such as sodium pyrosulfate and potassium pyrosulfate, when appreciable concentrations of sulfur trioxide are present.

Additives can be helpful in controlling corrosion, particularly in conjunction with firing in low excess air. The effectiveness of the additives varies. The most useful additives are based on organic magnesium compounds.
