Discontinuities in the Electromagnetic Field E-Book

M. Mithat Idemen

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Serie: IEEE/OUP Series on Electromagnetic Wave Theory (formerly IEEE only), Series Editor: Donald G. Dudley.
• Sprache: Englisch

Seitenzahl: 240

Veröffentlichungsjahr: 2011

Beschreibung

A multifaceted approach to understanding, calculating, and managing electromagnetic discontinuities

Presenting new, innovative approaches alongside basic results, this text helps readers better understand, calculate, and manage the discontinuities that occur within the electromagnetic field. Among the electromagnetic discontinuities explored in this volume are:

• Bounded jump discontinuities at the interfaces between two media or on the material sheets that model very thin layers

• Unbounded values at the edges of wedge-type structures

• Unbounded values at the tips of conical structures

The text examines all the key issues related to the bodies that carry the interfaces, edges, or tips, whether these bodies are at rest or in motion with respect to an observer. In addition to its clear explanations, the text offers plenty of step-by-step examples to clarify complex theory and calculations. Moreover, readers are encouraged to fine-tune their skills and knowledge by solving the text's problem sets.

Three fundamental, classical theories serve as the foundation for this text: distributions, confluence, and the special theory of relativity. The text sets forth the fundamentals of all three of these theories for readers who are not fully familiar with them. Moreover, the author demonstrates how to solve electromagnetic discontinuity problems by seamlessly combining all three theories into a single approach.

With this text as their guide, readers can apply a unique philosophy and approach to the investigation and development of structures that have the potential to enhance the capabilities of electronics, antennas, microwaves, acoustics, medicine, and many more application areas.

Leseprobe

Table of Contents

Series Page

Title Page

Copyright

Preface

Chapter 1: Introduction

Chapter 2: Distributions and Derivatives in the Sense of Distribution

2.1 Functions and Distributions

2.2 Test Functions. The Space C

2.3 Convergence in D

2.4 Distribution

2.5 Some Simple Operations in D′

2.6 Order of a Distribution

2.7 The Support of a Distribution

2.8 Some Generalizations

Chapter 3: Maxwell Equations in the Sense of Distribution

3.1 Maxwell Equations Reduced into the Vacuum

3.2 Universal Boundary Conditions and Compatibility Relations

3.3 The Concept of Material Sheet

3.4 The Case of Monochromatic Fields

Chapter 4: Boundary Conditions on Material Sheets at Rest

4.1 Universal Boundary Conditions and Compatibility Relations for a Fixed Material Sheet

4.2 Some General Results [19]

4.3 Some Particular Cases

Chapter 5: Discontinuities on a Moving Sheet

5.1 Special Theory of Relativity

5.2 Discontinuities on a Uniformly Moving Surface [75]

5.3 Discontinuities on a Nonuniformly Moving Sheet

Chapter 6: Edge Singularities on Material Wedges Bounded by Plane Boundaries

6.1 Introduction

6.2 Singularities at the Edges of Material Wedges

6.3 The Wedge with Penetrable Boundaries

6.4 The Wedge with Impenetrable Boundaries

6.5 Examples. Application to Half-Planes

6.6 Edge Conditions for the Induced Surface Currents

Chapter 7: Tip Singularities at the Apex of a Material Cone

7.1 Introduction

7.2 Algebraic Singularities of an H-Type Field

7.3 Algebraic Singularities of an E-Type Field

7.4 The Case of Impenetrable Cones

7.5 Confluence and Logarithmic Singularities

7.6 Application to some Widely used Actual Boundary Conditions

7.7 Numerical Solutions of the Transcendental Equations Satisfied by the Minimal Index

Chapter 8: Temporal Discontinuities

8.1 Universal Initial Conditions

8.2 Linear Mediums in the Generalized Sense

8.3 An Illustrative Example

References

Index

Wiley Page

Copyright © 2011 by the Institute of Electrical and Electronics Engineers, Inc.

Published by John Wiley & Sons, Inc., Hoboken, New Jersey. All rights reserved.

Published simultaneously in Canada.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, scanning, or otherwise, except as permitted under Section 107 or 108 of the 1976 United States Copyright Act, without either the prior written permission of the Publisher, or authorization through payment of the appropriate per-copy fee to the Copyright Clearance Center, Inc., 222 Rosewood Drive, Danvers, MA 01923, [phone], fax [phone]. Requests to the Publisher for permission should be addressed to the Permissions Department, John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, [phone], fax [phone], or online at http://www.wiley.com/go/permission.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives or written sales materials. The advice and strategies contained herein may not be suitable for your situation. You should consult with a professional where appropriate. Neither the publisher nor author shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

For general information on our other products and services or for technical support, please contact our Customer Care Department within the United States at [phone], outside the United States at [phone] or fax [phone].

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic formats. For more information about Wiley products, visit our web site at www.wiley.com.

Library of Congress Cataloging-in-Publication Data:

Idemen, M. Mithat.

Discontinuities in the electromagnetic field/M. Mithat Idemen.

p. cm.––(IEEE Press series on electromagnetic wave theory; 40)

ISBN 978-1-118-03415-6 (hardback)

1. Electromagnetic fields––Mathematics. 2. Maxwell equations. 3. Electromagnetic waves. I. Title.

QC665.E4I295 2011

530.14'1–dc22

2011002185

Preface

Without any hesitation we can claim that our civilization is largely based on the capacity and effectiveness of our knowledge pertaining to the natural phenomena collected under the name of electromagnetism. Our effective knowledge on these phenomena, with which we are familiar in fragments for nearly 2000 years, since the era of Thales, goes back only one and a quarter centuries ago. The years of 1873 and 1887 in the nineteenth century were two very important milestones in the intellectual evolution, as well as in the technological achievements of mankind. Indeed, the first one was the year in which the electricity, magnetism, and optics, which had been considered to be different natural phenomena until then, were unified under a common framework called the electromagnetism. To this end, Maxwell wrote a system of partial differential equations in England and claimed that those phenomena are all some particular aspects of a unique phenomenon which satisfies his equations. The equations introduced by Maxwell were not only what are reduced to the already known equations written 40 years ago by Faraday in England and 50 years ago by Ampère in France, but also claimed that the phenomenon in question consisted of a wave, which propagates with a finite velocity. What is very interesting is that physicists and engineers of those days were not familiar with such a kind of wave. To believe in the existence of the wave in question, one had to wait 14 years to witness the modest experiment carried out by Hertz in 1887 in Germany. That experiment, which revealed the so-called electromagnetic wave, showed also that energy transmission is possible through this wave. That was the indicator of a new direction for the civilization and thusly intensified the interest in the electromagnetic wave in both theoretical and experimental domains. Within the three years just after the Hertz experiment, the first radio receiver was realized by Branly in Germany in 1890, and soon after this, many crucial applications in communication, control, remote sensing, medicine, radio-astronomy, space communication, heating, and so on, began to flow. Among them we can mention, for example, the radio communication between two sides of the Atlantic Ocean (in 1901), radar (in 1940), laser (in 1957), tomography (in 1984), etc.

By considering new products of the actual technology, which permit us to use extremely short waves whose frequencies increase day by day, we can hope that electromagnetic waves will continue to be the basis of new, even unexpected, applications. These applications will require solutions of the Maxwell equations under new supplementary relations (boundary conditions, edge conditions, tip conditions, etc). Therefore, a thorough investigation of these supplementary relations is very important from both theoretical and practical points of view. The aim of this short monograph is to fulfill this job. I think (and hope) that readers who are fond of the theory will find several enjoyable points in the book. However, the meticulous colleagues will certainly find many points to criticize. As a scientist who imagines science as a continuously evolving struggle, I look forward with deep gratitude to all constructive comments and critiques.

What seems also important to me is that by claiming the existence of the electromagnetic wave before its experimental observation, the theory of Maxwell epitomizes an example for the “theory before experiment.” The electromagnetic wave is not the unique example presented by the Maxwell equations in this sense. Indeed, by claiming a nonuniversal time concept, they became also the main instigator for the Special Theory of Relativity established by Einstein nearly 30 years later than the Maxwell's Theory. The equations proposed by Maxwell conceal inside themselves too many secrets of the nature: reflected waves, refracted waves, creeping modes, whispering gallery modes, edge-excited waves, tip-excited waves, shadow boundaries, reflection boundaries, refraction boundaries, caustics, traveling waves, standing waves, Cherenkov waves, trapped waves, boundary conditions, edge conditions, tip conditions, space-time transformation under uniform motions, Doppler effect, aberration, and so on. They permit us to discover all these secretes as well as the interrelations among them if we interrogate with appropriate mathematical tools. I believe that the most effective tool for the investigation of the discontinuities in natural phenomena of any kind is the concept of distribution. This concept, which was introduced by Schwartz in 1950 (three quarters of a century later than the Maxwell equations) in France to the contemporary mathematics, extended the meaning of the Maxwell equations. If one assumes that the differential operations taking place in the Maxwell equations are all in the sense of distributions, then the discontinuities can be discussed pretty easily and rigorously. This monograph adopts this approach. When the surfaces which carry the discontinuities are in uniform motion, formulas of the Special Theory of Relativity help to reveal behaviors of the discontinuities by transforming the expressions pertinent to the surfaces at rest.

With their elegances and powers, the above-mentioned two theories (i.e., the Theory of Electromagnetism—including the special theory of relativity—and the Theory of Distributions) excite feelings of admiration. For me, they are not a heap of spiritless mathematical symbols but rather the self-consistent intellectual and fine-artistic productions of human mind. Since the Theory of Distributions as well as that of the Special Theory of Relativity are not thoroughly included into the undergraduate curriculum, in order to offer a self-contained book, the necessary (and sufficient) material which helps to clarify the essentials of these theories, are also be included into the book.

It is a great pleasure for me to confess that the publication of this monograph could not have been realized if sincere encouragements and supports by certain colleagues had not existed. Among them I mention especially Professor Tayfun Akgül (Istanbul Technical University, Turkey), Professor Ross Stone (IEEE Antennas and Propagation Society Publishing Board member), Professor Robert Mailloux (IEEE Antennas and Propagation Society Press Liason Committee Chair) and Professor Andreas C. Cangellaris (editor of the IEEE Press Series on Electromagnetic Wave Theory). I am indebted to all of them for their invaluable interests and supports.

I have also to thank Professor Alinur Büyükaksoy and Professor Ali Alkumru (both from the Gebze Institute of Technology, Turkey) for their several comments which helped me to improve the manuscript.

I express also my thanks to Taisuke Soda from the John Wiley and Sons, Inc. for his warm interest and meticulous work which produced a flawless publication, Lisa M. Van Horn of Wiley Production and Rajalakshmi Gnanakumar of Laserwords, for their superior support throughout the production process.

Lastly, I would like to extend my thanks and everlasting gratitude to TUBA (the Turkish Academy of Sciences) and Yeditepe University, Istanbul for partial support of my works.

M. Mithat Idemen

Heybeliada, Istanbul

March 2011

Chapter 1

Introduction

A man may imagine things that are false, but he can only understand things that are true.

Isaac Newton

Almost all mathematical problems connected with the electromagnetic phenomena require solutions of the Maxwell differential equations

1.1a,b

1.1c,d

under certain supplementary restrictions stipulated on certain surfaces. In (1.1a–d) E, D, H, and B stand for the electric field, electric displacement, magnetic field, and magnetic induction, respectively, while ρ and J are the volume densities of the charges and currents. As to the parameter t that appears in (1.1a,b), it is, as usual, the time. The surfaces that bear the above-mentioned supplementary restrictions are either the interfaces between bodies of different constitutive parameters or surfaces that support surface charges and currents† or material sheets that model very thin layers. The supplementary restrictions in question are the relations that state the physically admissible discontinuities that may occur on these surfaces. They consist, in general, of the so-called boundary conditions that give the jump discontinuities on the surfaces in questions. If the discontinuity surfaces also involve sharp edges and/or sharp tips, then some components of the field become infinitely large at some points. In this case, in addition to the boundary conditions, one also has to know the physically admissible asymptotic behaviors of the field near those points because, as was shown more than 60 years ago by Bouwkamp [1], one can construct many solutions to the Maxwell equations under the given boundary conditions. Of course some of these solutions are not acceptable from physics point of view. Depending on the nature of the singular point, the relations that state the asymptotic behaviors in question are called the edge conditions or the tip conditions.

It is worthwhile to remark here that any relation written on a surface cannot be treated as a boundary condition for the electromagnetic field. In order to be so, it must also be compatible with the Maxwell equations. The spectrum of the electromagnetic waves used in the telecommunication is enlarging every day more and more toward very short waves. Hence many types of roughness, which had been assumed to be negligible in earlier investigations in order to reduce mathematical difficulties, became today unavoidable. In studies to be made in forthcoming days, one will have to consider the effects of these types of roughness on the propagation of waves. Therefore rigorous and detailed investigations of the boundary, edge, and tip conditions for various geometrical and physical structures are of crucial importance from both pure scientific and technological applications points of view. The aim of the present monograph is to study the discontinuities (i.e., singularities) in questions in their most general framework and discuss the validity of some particular relations that are in use in current literature. Our fundamental basis will be the so-called distributions (or generalized functions). In order to clarify the crucial role of this concept in the present study, it will be useful to reexamine the derivation of the classical boundary conditions in almost all textbooks.

On those days when the Electromagnetic Theory had been established, one had a huge heap of scientific knowledge in theoretical physics, especially in fluid mechanics. With this potential, the scientists of that time (i.e., mathematicians, physicists, and engineers) had formulated and solved many mathematical problems that could have interesting and important interpretations in terms of the electromagnetic notions. First problems were those that needed to find the explicit expressions of the fields created by various sources distributed in the vacuum. They were very easy. Soon later, one had considered the problems connected with bodies having simple geometrical shapes such as infinite planes, infinitely long cylinders, whole spheres, whole ellipsoids, and so on. They were also rather easy and tractable with known techniques provided that the boundary conditions to be satisfied on the surfaces of the bodies were known beforehand. It was at this stage that the struggles to reveal the discontinuities of the electromagnetic field were started. The methods that seemed most propitious were what are based on the applications of the Gauss–Ostrogradski and Stokes theorems (see Smirnow [2, pp. 177, 197]). Although these applications are repeated in almost all textbooks, we want to recapitulate them here in order to clarify the philosophy of the method adopted in the present study. To this end, consider, for example, (1.1c) and integrate it inside a volume ϑ bounded by planar boundaries of very small areas (see Fig. 1.1). Assume that D as well as its partial derivatives of the first orders are all continuous inside ϑ except on a regular surface ΔS. To avoid useless complexities, assume also that the field depends only on two space coordinates. Then a careless application (without regarding the validity conditions) of the Gauss–Ostrogradski theorem to

1.2a

yields

1.2b

Figure 1.1 A neighborhood of a surface of discontinuity.

Here Q stands for the total charge existing inside ϑ. If Q consists of the surface charge distributed with density ρS on S, then by making h → 0 in (1.2b) one gets

1.2c

or

1.2d

Here and show the values of the normal component of D which are observed when one approaches S from lower and upper sides, respectively.

Quite similarly, from (1.1a,b,d) one gets

1.2e

1.2f

1.2g

The field JS appearing in (1.2g) is the density of the surface current that flows on S.

The relations in (1.2.d–g) are the classical boundary conditions that are satisfied on the interface between two regions filled with different materials. They are in use since the first days of the Theory to find solutions of the electromagnetic problems, which are in complete agreements with experiments. But the mathematical analysis made to reveal them is obviously not legitimate. Indeed, in order for the Gauss–Ostrogradski and Stokes theorems to be applicable, the fields E, D, H, and B have to be continuous inside ϑ. But, as the results themselves show, this is not the case. However, as we have already stated, the results are correct from physics point of view. A few writers who are familiar with this contrast warn readers by indicating that the results to be obtained by this kind of faulty applications are assumed to be acceptable for physics. D. S. Jones [3, p. 46] and S. A. Schelkunoff [4] epitomize this group of meticulous scientists.* It goes without saying that this assumption is nothing but an additional postulate to the Maxwell equations. Regarding the swift developments in the contemporary technology, which create and use very different materials and geometries, one can easily grasp that this approach cannot enable one to overcome the difficulties completely. Hence one has to contrive a general and robust method.

One could also think that the difficulty in deriving (1.2d) resulted from the derivatives existing in (1.1c); if one started from the integral equation (Gauss' law)

1.3a

which is equivalent to (1.1c), one would not have the same difficulty. Indeed, in this case from (1.3a) one writes directly

1.3b

which, after applications of the Gauss–Ostrogradski theorem to the partial regions lying above and below the surface ΔS, yields (1.2d). But this approach too, which at first glance seems to be propitious to overcome the difficulty, has severe defects. For example, in the case when S consists of a double sheet that carries only dipoles, the right-hand side of (1.3b) becomes naught and claims , which is not correct.* Furthermore, in cases of material sheets that are represented, for example, by impedance or resistive or other more general type of boundary conditions one cannot guess the right-hand side of (1.3b).

To avoid the difficulties mentioned above, we propose to add the following assumption to the Maxwell equations [5]:

The results of this assumption (or postulate) will be seen after Chapter 2. Here we confine ourselves to make only the following remarks that are of importance.

i. This assumption not only legitimizes the use of the Dirac delta functions to represent surface (or line or point) charges and currents (i.e., ρ and J) but also claims that the field components E, D, H, and B are also distributions. In other words, the field components themselves can contain singular terms concentrated on certain surfaces.

ii. This assumption concerns not only the space coordinates and boundary conditions but also the time parameter and initial values. That means that the field components can involve also singular terms concentrated at certain isolated instants (such as flash of lightning).

iii. In 1873, when Maxwell had established his theory, as well as during the following 75 years, the concept of distribution did not exist in the scientific literature. It appeared after 1950 first in mathematics and then in physics and engineering sciences. Hence, the claim that the Maxwell equations are valid in the sense of distribution is in fact a new postulate added to the Maxwell Theory.

The arrangement of the present monograph is as follows: In Chapter 2 the concepts of distribution and derivatives in the sense of distribution are explained. Grad, curl, and div operators as well as distributions concentrated on a surface are discussed in some detail. In Chapter 3 the Maxwell equations are reconsidered and discussed in the framework of these new concepts. The so-called universal boundary conditions are derived as a natural result. Chapter 4 is devoted to an extensive analysis of the boundary conditions on a material sheet at rest. The so-called impedance and resistive-type particular conditions are discussed and their validity conditions are derived. The case of moving boundaries is considered in Chapter 5. In this chapter the connection with the Special Theory of Relativity is also established whenever the motion is uniform. Chapter 6 is devoted to the edge conditions on a wedge bounded by planar walls. In this chapter, one shows also that the origin of the logarithmic-type singularities is the confluence of two algebraic singularities. In Chapter 7, one considers the tip singularities that occur at the apex of a rotationally curved material cone. For this kind of geometry, also the logarithmic singularities are derived as a result of confluence of two algebraic singularities. In Chapter 8, one considers the temporal discontinuities localized at certain times.

Notes

†Line and point charges are also carried by certain appropriately defined surfaces.

*Michael White, Isaac Newton: The Last Sorcerer, Basic Books, New York, 1977, p. 5. See also Sir Isaac Newton's Theological Manuscripts, H. McLachlan (Ed.), Liverpool University Press, Liverpool, 1950, p. 17.

*Schelkunoff characterizes this kind of an approach to be “a proof which is not a proof but a swindle” (see Schelkunoff [4, Section 5]).

*Correct expression is . Here ρ1 stands for the density of the dipole distribution while λ is a parameter depending on the curvature of S and n is the unit normal vector to S [see Section 3.2.1, formula (3.19c)].

Chapter 2

Distributions and Derivatives in the Sense of Distribution

2.1 Functions and Distributions

Even in the early days of the second half of the nineteenth century, one had observed that the mathematics, especially the concepts of functions and derivatives which had been established and maturated during the eighteenth and nineteenth centuries and permitted us to investigate various natural phenomena with deep insight, is not sufficient to grasp certain singularities in natural phenomena. To overcome the difficulties, one tried, from time to time, to introduce some concepts and to derive some formulas that were not based on solid mathematical basis. For example, Gustav Robert Kirchhoff, a famous German physicist of the nineteenth century, had tried to define a force that acts on a very small area as follows [6]:
