Energy Harvesting Communications E-Book

Yunfei Chen

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Serie: Wiley - IEEE
• Sprache: Englisch

Seitenzahl: 537

Veröffentlichungsjahr: 2018

Beschreibung

Provides a systematic overview of a hot research area, examining the principles and theories of energy harvesting communications This book provides a detailed and advanced level introduction to the fundamentals of energy harvesting techniques and their use in state-of-the-art communications systems. It fills the gap in the market by covering both basic techniques in energy harvesting and advanced topics in wireless communications. More importantly, it discusses the application of energy harvesting in communications systems to give readers at different levels a full understanding of these most recent advances in communications technologies. The first half of Energy Harvesting Communications: Principles and Theories focuses on the challenges brought by energy harvesting in communications. The second part of the book looks at different communications applications enhanced by energy harvesting. It offers in-depth chapters that: discuss different energy sources harvested for communications; examine the energy harvesters used for widely used sources; study the physical layer and upper layer of the energy harvesting communications device; and investigate wireless powered communications, energy harvesting cognitive radios, and energy harvesting relaying as applications. * Methodically examines the state-of-the-art of energy harvesting techniques * Provides comprehensive coverage from basic energy harvesting sources and devices to the end users of these sources and devices * Looks at the fundamental principles of energy harvesting communications, and biomedical application and intra-body communications * Written in a linear order so that beginners can learn the subject and experienced users can attain a broader view Written by a renowned expert in the field, Energy Harvesting Communications: Principles and Theories is an excellent resource for students, researchers, and others interested in the subject.

Leseprobe

Table of Contents

Cover

Preface

Acronyms

1 Introduction

1.1 Background

1.2 Relationship with Green Communications

1.3 Potential Applications

1.4 Outline of Chapters

2 Energy Sources

2.1 Introduction

2.2 Types of Sources

2.3 Predictive Models of Sources

2.4 Summary

3 Energy Harvesters

3.1 Introduction

3.2 Photovoltaic Panels

3.3 Radio Frequency Energy Harvester

3.4 Overall Models

3.5 Battery and Supercapacitor

3.6 Summary

4 Physical Layer Techniques

4.1 Introduction

4.2 Effect of Energy Harvesting

4.3 Energy Harvesting Detection

4.4 Energy Harvesting Estimation

4.5 Energy Transmission Waveform

4.6 Other Issues and Techniques

4.7 Summary

5 Upper Layer Techniques

5.1 Introduction

5.2 Media Access Control Protocols

5.3 Routing Protocols

5.4 Other Issues in the Upper Layers

5.5 Summary

6 Wireless Powered Communications

6.1 Introduction

6.2 Types of Wireless Powered Communications

6.3 Simultaneous Wireless Information and Power Transfer

6.4 Hybrid Access Point

6.5 Power Beacon

6.6 Other Issues

6.7 An Example: Wireless Powered Sensor Networks

6.8 Summary

7 Energy Harvesting Cognitive Radios

7.1 Introduction

7.2 Conventional Cognitive Radio

7.3 Types of Energy Harvesting Cognitive Radio

7.4 From the Secondary Base Station

7.5 From the Primary User

7.6 From the Ambient Environment

7.7 Information Energy Cooperation

7.8 Other Important Issues

7.9 Summary

8 Energy Harvesting Relaying

8.1 Introduction

8.2 Conventional Relaying

8.3 Types of Energy Harvesting Relaying

8.4 From the Ambient Environment

8.5 From the Power Transmitter

8.6 From the Source

8.7 Other Important Issues

8.8 Summary

References

Index

End User License Agreement

List of Tables

Chapter 2

Table 2.1 Typical amount of energy from different sources.

Chapter 3

Table 3.1 Fitted parameters for some energy harvesters.

Chapter 7

Table 7.1 CR systems with different energy sources for PU and CR.

Table 7.2 List of channel gains.

Chapter 8

Table 8.1 Energy harvesting relaying systems with different energy sources.

List of Illustrations

Chapter 1

Figure 1.1 Relationship between energy harvesting communications and green comm...

Figure 1.2 Organization of chapters in the book.

Chapter 2

Figure 2.1 Some commonly used energy sources for energy harvesting wireless com...

Figure 2.2 Example measurements of ambient RF energy at different time instants ...

Figure 2.3 Time series of measured power in the 3G band from 1805 to 1880 MHz in...

Figure 2.4 Comparison of prediction errors for different machine learning algori...

Figure 2.5 Effect of prediction error on wasted and missed energy using linear r...

Figure 2.6 Comparison of predicted and measured power using the wavelets method ...

Chapter 3

Figure 3.1 Diagram of a typical PV cell.

Figure 3.2 Comparison of three one‐diode models.

Figure 3.3 Comparison of three two‐diode models.

Figure 3.4 Diagram of a typical RF energy harvester.

Figure 3.5 Three different matching networks: (a) transformer; (b) parallel coil...

Figure 3.6 Comparison of the fitting methods in 3.22 and 3.23 with the experimen...

Figure 3.7 Comparison of the Fourier model and the experimental value for freque...

Figure 3.8 Comparison of the Fourier model and the experimental value for distan...

Figure 3.9 Comparison of the actual power and predicted power using linear regre...

Figure 3.10 Two‐state Markov chain model.

Chapter 4

Figure 4.1 Diagrams of (a) OSI and (b) TCP/IP models.

Figure 4.2

versus

in Rayleigh fading channels when

dB.

Figure 4.3

versus

in Rayleigh fading channels when

dB.

Figure 4.4

versus

in Rician fading channels when

dB and

.

Figure 4.5

versus

in Rayleigh fading channels when

dB.

Figure 4.6
