GPS Satellite Surveying - Alfred Leick - E-Book

GPS Satellite Surveying E-Book

Alfred Leick

0,0
153,99 €

-100%
Sammeln Sie Punkte in unserem Gutscheinprogramm und kaufen Sie E-Books und Hörbücher mit bis zu 100% Rabatt.

Mehr erfahren.
Beschreibung

Employ the latest satellite positioning tech with this extensive guide GPS Satellite Surveying is the classic text on the subject, providing the most comprehensive coverage of global navigation satellite systems applications for surveying. Fully updated and expanded to reflect the field's latest developments, this new edition contains new information on GNSS antennas, Precise Point Positioning, Real-time Relative Positioning, Lattice Reduction, and much more. New contributors offer additional insight that greatly expands the book's reach, providing readers with complete, in-depth coverage of geodetic surveying using satellite technologies. The newest, most cutting-edge tools, technologies, and applications are explored in-depth to help readers stay up to date on best practices and preferred methods, giving them the understanding they need to consistently produce more reliable measurement. Global navigation satellite systems have an array of uses in military, civilian, and commercial applications. In surveying, GNSS receivers are used to position survey markers, buildings, and road construction as accurately as possible with less room for human error. GPS Satellite Surveying provides complete guidance toward the practical aspects of the field, helping readers to: * Get up to speed on the latest GPS/GNSS developments * Understand how satellite technology is applied to surveying * Examine in-depth information on adjustments and geodesy * Learn the fundamentals of positioning, lattice adjustment, antennas, and more The surveying field has seen quite an evolution of technology in the decade since the last edition's publication. This new edition covers it all, bringing the reader deep inside the latest tools and techniques being used on the job. Surveyors, engineers, geologists, and anyone looking to employ satellite positioning will find GPS Satellite Surveying to be of significant assistance.

Sie lesen das E-Book in den Legimi-Apps auf:

Android
iOS
von Legimi
zertifizierten E-Readern

Seitenzahl: 1261

Veröffentlichungsjahr: 2015

Bewertungen
0,0
0
0
0
0
0
Mehr Informationen
Mehr Informationen
Legimi prüft nicht, ob Rezensionen von Nutzern stammen, die den betreffenden Titel tatsächlich gekauft oder gelesen/gehört haben. Wir entfernen aber gefälschte Rezensionen.



Table of Contents

Title Page

Copyright

Preface

Author Biographies

Acknowledgments

Abbreviations

Commonly Used GNSS Abbreviations

Chapter 1: Introduction

Chapter 2: Least-Squares Adjustments

2.1 Elementary Considerations

2.2 Stochastic and Mathematical Models

2.3 Mixed Model

2.4 Sequential Mixed Model

2.5 Model Specifications

2.6 Minimal and Inner Constraints

2.7 Statistics in Least-Squares Adjustment

2.8 Reliability

2.9 Blunder Detection

2.10 Examples

2.11 Kalman Filtering

Chapter 3: Recursive Least Squares

3.1 Static Parameter

3.2 Static Parameters and Arbitrary Time-Varying Variables

3.3 Dynamic Constraints

3.4 Static Parameters and Dynamic Constraints

3.5 Static Parameter, Parameters Subject to Dynamic Constraints, and Arbitrary Time-Varying Parameters

Chapter 4: Geodesy

4.1 International Terrestrial Reference Frame

4.2 International Celestial Reference System

4.3 Datum

4.4 3D Geodetic Model

4.5 Ellipsoidal Model

4.6 Conformal Mapping Model

4.7 Summary

Chapter 5: Satellite Systems

5.1 Motion of Satellites

5.2 Global Positioning System

5.3 GLONASS

5.4 Galileo

5.5 QZSS

5.6 Beidou

5.7 IRNSS

5.8 SBAS: WAAS, EGNOS, GAGAN, MSAS, and SDCM

Chapter 6: GNSS Positioning Approaches

6.1 Observables

6.2 Operational Details

6.3 Navigation Solution

6.4 Relative Positioning

6.5 Ambiguity Fixing

6.6 Network-Supported Positioning

6.7 Triple-Frequency Solutions

6.8 Summary

Chapter 7: Real-Time Kinematics Relative Positioning

7.1 Multisystem Considerations

7.2 Undifferenced and Across-Receiver Difference Observations

7.3 Linearization and Hardware Bias Parameterization

7.4 RTK Algorithm for Static and Short Baselines

7.5 RTK Algorithm for Kinematic Rovers and Short Baselines

7.6 RTK Algorithm with Dynamic Model and Short Baselines

7.7 RTK Algorithm with Dynamic Model and Long Baselines

7.8 RTK Algorithms with Changing Number of Signals

7.9 Cycle Slip Detection and Isolation

7.10 Across-Receiver Ambiguity Fixing

7.11 Software Implementation

Chapter 8: Troposphere and Ionosphere

8.1 Overview

8.2 Tropospheric Refraction and Delay

8.3 Troposphere Absorption

8.4 Ionospheric Refraction

Chapter 9: GNSS Receiver Antennas

9.1 Elements of Electromagnetic Fields and Electromagnetic Waves

9.2 Antenna Pattern and Gain

9.3 Phase Center

9.4 Diffraction and Multipath

9.5 Transmission Lines

9.6 Signal-to-Noise Ratio

9.7 Antenna Types

Appendix A: General Background

A.1 Spherical Trigonometry

A.2 Rotation Matrices

A.3 Linear Algebra

A.4 Linearization

A.5 Statistics

Appendix B: The Ellipsoid

B.1 Geodetic Latitude, Longitude, and Height

B.2 Computation on the Ellipsoidal Surface

Appendix C: Conformal Mapping

C.1 Conformal Mapping of Planes

C.2 Conformal Mapping of General Surfaces

C.3 Isometric Plane

C.4 Popular Conformal Mappings

Appendix D: Vector Calculus and Delta Function

Appendix E: Electromagnetic Field Generated by Arbitrary Sources, Magnetic Currents, Boundary Conditions, and Images

Appendix F: Diffraction over Half-Plane

Appendix G: Single Cavity Mode Approximation with Patch Antenna Analysis

Appendix H: Patch Antennas with Artificial Dielectric Substrates

Appendix I: Convex Patch Array Geodetic Antenna

References

Author Index

Subject Index

End User License Agreement
