Nanoparticulate Drug Delivery Systems E-Book

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Sprache: Englisch

Seitenzahl: 598

Veröffentlichungsjahr: 2013

Beschreibung

Frank discussions of opportunities and challenges point the way to new, more effective drug delivery systems Interest in nanomedicine has grown tremendously, fueled by the expectation that continued research will lead to the safe, efficient, and cost-effective delivery of drugs or imaging agents to human tissues and organs. The field, however, has faced several challenges attempting to translate novel ideas into clinical benefits. With contributions from an international team of leading nanomedicine researchers, this book provides a practical assessment of the possibilities and the challenges of modern nanomedicine that will enable the development of clinically effective nanoparticulate drug delivery products and systems. Nanoparticulate Drug Delivery Systems focuses on the rationales and preclinical evaluation of new nanoparticulate drug carriers that have yet to be thoroughly reviewed in the literature. The first chapter sets the stage with a general overview of targeted nanomedicine. The book then explores new and promising nanoparticulate drug delivery systems, including: * Lipid nanoparticles for the delivery of nucleic acids * Multifunctional dendritic nanocarriers * Polymer drug nanoconjugates Next, the book presents new opportunities and challenges for nanoparticulate drug delivery systems, including: * Clearance of nanoparticles during circulation * Drug delivery strategies for combatting multiple drug resistance * Toxicological assessment of nanomedicine Chapters offer state-of-the-technology reviews with extensive references to facilitate further investigation. Moreover, each chapter concludes with an expert assessment of remaining challenges, pointing the way to solutions and new avenues of research. With its frank discussions of opportunities and challenges, Nanoparticulate Drug Delivery Systems sets a solid foundation for new research leading to the discovery and development of better nanomedicines.

Leseprobe

Contents

Cover

Title Page

Copyright

Preface

Contributors

Editor

Chapter 1: Tumor-Targeted Nanoparticles: State-of-the-Art and Remaining Challenges

1.1 Introduction

1.2 Functions of Nanoparticles

1.3 Tumor-Targeted Nanoparticles

1.4 Remaining Challenges in the Development of Tumor-Targeted Nanoparticles

1.5 Future Perspectives

References

Chapter 2: Applications of Ligand-Engineered Nanomedicines

2.1 Introduction

2.2 Ligand-Mediated Delivery

2.3 Current Challenges in Clinical Development of Ligand-Modified Nanomedicine

2.4 Conclusions

References

Chapter 3: Lipid Nanoparticles for the Delivery of Nucleic Acids

3.1 Introduction

3.2 Barriers to Systemic Gene Delivery

3.3 Components of LNPs

3.4 Formulations of the LNP for Nucleic Acids Encapsulation

3.5 Organ-Specific Delivery of Nucleic Acids with LNPs

3.6 Current Challenges to the Development of LNPs

3.7 Future Perspectives

References

Chapter 4: Photosensitive Liposomes as Potential Targeted Therapeutic Agents

4.1 Introduction

4.2 Experimental Procedures

4.3 Results and Discussion

4.4 Conclusions

4.5 Prospects for Light-Activated Liposomal Drug Delivery

References

Chapter 5: Multifunctional Dendritic Nanocarriers: The Architecture and Applications in Targeted Drug Delivery

5.1 Recent Advances in Dendritic Nanomaterials

5.2 Effects of Dendritic Architectures on Biological Systems

5.3 Functionalization of Dendritic Structures Via Surface Modification

5.4 Dendrimer-Based Therapeutic and Diagnostic Approaches

5.5 Dendron-Based Hybrid Nanomaterials

5.6 Future Perspectives

References

Chapter 6: Chitosan-Based Nanoparticles for Biomedical Applications

6.1 Chitosan As a Biopolymer

6.2 Chitosan Nanoparticles for Imaging

6.3 Chitosan Nanoparticles for Therapy

6.4 Promises, Limitations, and Future Perspectives of Chitosan Nanoparticles

References

Chapter 7: Polymer–Drug Nanoconjugates

7.1 Introduction

7.2 Current Status of Nanoencapsulates and Polymer–Drug Conjugates

7.3 Nanoconjugates: Design and Synthesis

7.4 Nanoconjugates: Formulation and Potential Application

7.5 Conclusions and Outlook

References

Chapter 8: Nanocrystals Production, Characterization, and Application for Cancer Therapy

8.1 Introduction

8.2 Nanocrystal Production

8.3 Particle Stabilization

8.4 Particle Characterization

8.5 Nanocrystals for Cancer Therapy

8.6 Future Perspectives

References

Chapter 9: Clearance of Nanoparticles During Circulation

9.1 Introduction

9.2 Nanoparticle-Based Drug Carriers in Cancer Therapy

9.3 Biological Clearance of Nanoparticles

9.4 Strategies to Minimize the Biological Clearance of Nanoparticles

9.5 Future Perspectives

References

Chapter 10: Drug Delivery Strategies for Combating Multiple Drug Resistance

10.1 Introduction

10.2 Pathways to Drug Resistance

10.3 Combating MDR

10.4 Future Perspectives

References

Chapter 11: Intracellular Trafficking of Nanoparticles: Implications for Therapeutic Efficacy of the Encapsulated Drug

11.1 Introduction

11.2 Pathways of Cellular Entry

11.3 Intracellular Fate of Internalized Nanoparticles

11.4 In-Depth Elucidation of Intracellular Trafficking Events Entails High Resolution Imaging Techniques

11.5 Future Perspectives

References

Chapter 12: Toxicological Assessment of Nanomedicine

12.1 Introduction

12.2 Safety of Commonly Used Nanoconstructs in Nanomedicine

12.3 Evaluation of Nanomaterial Toxicity

12.4 Conclusions

References

Index

Copyright © 2013 by John Wiley & Sons, Inc. All rights reserved.

Published by John Wiley & Sons, Inc., Hoboken, New Jersey.

Published simultaneously in Canada.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, scanning, or otherwise, except as permitted under Section 107 or 108 of the 1976 United States Copyright Act, without either the prior written permission of the Publisher, or authorization through payment of the appropriate per-copy fee to the Copyright Clearance Center, Inc., 222 Rosewood Drive, Danvers, MA 01923, (978) 750–8400, fax [phone], or on the web at www.copyright.com. Requests to the Publisher for permission should be addressed to the Permissions Department, John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, (201) 748–6011, fax [phone], or online at http://www.wiley.com/go/permission.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives or written sales materials. The advice and strategies contained herein may not be suitable for your situation. You should consult with a professional where appropriate. Neither the publisher nor author shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

For general information on our other products and services or for technical support, please contact our Customer Care Department within the United States at (800) 762–2974, outside the United States at (317) 572–3993 or fax [phone].

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic formats. For more information about Wiley products, visit our web site at www.wiley.com.

Library of Congress Cataloging-in-Publication Data:

Nanoparticulate drug delivery systems; strategies, technologies, and applications / edited by Yoon Yeo

Includes bibliographic references and index.

ISBN 978-1-118-14887-7 (cloth)

Preface

Enthusiasm for nanomedicine has grown exponentially over the years with an expectation that nanomedicine will enable the delivery of drugs or imaging agents to tissues and organs that they would otherwise not reach effectively. Early nanomedicine indeed addressed several critical problems inherent to some drugs, such as poor solubility and toxic side effects. Liposomal doxorubicin, micelle formulations of paclitaxel, and protein-bound paclitaxel are now used in clinical practice. At the same time, new approaches have continuously emerged with the view to develop ever more sophisticated, multifunctional nanoparticulate systems for more effective diagnosis and safe therapy of diseases.

On the other hand, this field has faced several challenges in translating novel ideas into clinical benefits. For example, the “active targeting” strategy, originally expected to increase tumor accumulation of nanoparticles by orders of magnitude, has fallen short of the expectations. Polymeric micelles or nanoparticles, designed to circulate in the blood for a prolonged period of time, are unstable in the presence of amphiphilic biological components, losing their ability to reach target tissues in intact form. Consequently, despite the increasing complexity, newer nanoparticle systems bring about only modest therapeutic benefits, failing to gain significant attention from commercial, clinical, and/or regulatory sectors. In order to further advance the field of nanomedicine and to develop clinically effective products, it is necessary to make a practical assessment of the potential and challenges of modern nanomedicines.

This book brings together a collection of recent nanomedicine technologies and discusses their promises and the remaining challenges. It does not intend to duplicate the existing compilations of established nanoparticle systems, nor does it attempt to broaden the topic to systems that are less relevant to drug delivery. Therefore, instead of covering established nanoparticulate systems that have been described in a number of recent books and review articles, we focus on the rationales and preclinical evaluation of relatively new nanoparticulate drug carriers.

The chapters of this book are organized with two goals in mind. The first chapter presents a general overview of targeted nanomedicine. Chapters 2–8 discuss nanoparticulate drug delivery systems that have gained increasing recognition in the recent literature. Chapters 9–12 discuss new opportunities and barriers in the biology relevant to drug delivery based on nanomedicine. Each chapter reviews a state of the art of the topic with extensive references and concludes with an open assessment of the remaining challenges. I hope that this arrangement helps readers to formulate innovative nanomedicine systems and to design evaluation strategies without reliving the existing experiences, be they positive or negative.

As the editor of this book, I am most appreciative of the insightful and comprehensive contributions of the chapter authors. Special thanks go to all the authors, who immediately agreed to contribute their time and effort, and have endured reminders and editing requests. I would also like to thank the staff members of the publisher, Wiley-Blackwell, especially Jonathan T. Rose, for their patience and support. It is my hope that this book will serve as a starting point for stimulating discussions and new experimentations toward the development of better nanomedicines that can translate in the near future into clinical benefits for patients.

Yoon Yeo

Contributors

Jin Woo Bae, Department of Biopharmaceutical Sciences, College of Pharmacy, University of Illinois, Chicago, IL, USA

You Han Bae, Department of Pharmaceutics, University of Utah, Salt Lake City, UT, USA

Gaurav Bajaj, Division of Clinical Pharmacology and Therapeutics, The Children's Hospital of Philadelphia, Philadelphia, PA, USA

Jianjun Cheng, Department of Materials Science and Engineering, University of Illinois at Urbana−Champaign, Urbana, IL, USA

Ji-Xin Cheng, Weldon School of Biomedical Engineering, Purdue University, West Lafayette, IN, USA

Kuiwon Choi, Center for Theragnosis, Biomedical Research Institute, Korea Institute of Science and Technology, Seongbuk-gu, Seoul, Republic of Korea

Nathan P. Gabrielson, Department of Materials Science and Engineering, University of Illinois at Urbana−Champaign, Urbana, IL, USA

Oleg V. Gerasimov, Department of Chemistry, Purdue University, West Lafayette, IN, USA

Khaled Greish, Department of Pharmacology and Toxicology, Otago School of Medical Sciences, University of Otago, Dunedin, New Zealand; Department of Oncology, Faculty of Medicine, Suez Canal University, Egypt

Christin P. Hollis, College of Pharmacy, University of Kentucky, Lexington, KY, USA

Seungpyo Hong, Department of Biopharmaceutical Sciences, College of Pharmacy, University of Illinois, Chicago, IL, USA

Leaf Huang, Division of Molecular Pharmaceutics and Center for Nanotechnology in Drug Delivery, Eshelman School of Pharmacy, University of North Carolina at Chapel Hill, Chapel Hill, NC, USA

Kwangmeyung Kim, Center for Theragnosis, Biomedical Research Institute, Korea Institute of Science and Technology, Seongbuk-gu, Seoul, Republic of Korea

Heebeom Koo, Center for Theragnosis, Biomedical Research Institute, Korea Institute of Science and Technology, Seongbuk-gu, Seoul, Republic of Korea

Ick Chan Kwon, Center for Theragnosis, Biomedical Research Institute, Korea Institute of Science and Technology, Seongbuk-gu, Seoul, Republic of Korea

Sangbin Lee, School of Life Sciences and Biotechnology, Korea University, Seoul, South Korea

Seung-Young Lee, Weldon School of Biomedical Engineering, Purdue University, West Lafayette, IN, USA

Tonglei Li, Department of Industrial and Physical Pharmacy, Purdue University, West Lafayette, IN, USA

Hayley Nehoff, Department of Pharmacology and Toxicology, Otago School of Medical Sciences, University of Otago, Dunedin, New Zealand

Joseph W. Nichols, Department of Bioengineering, University of Utah, Salt Lake City, UT, USA

Lin Niu, Department of Pharmaceutics, College of Pharmacy, University of Minnesota, Minneapolis, MN, USA

Yu-Kyoung Oh, College of Pharmacy, Seoul National University, Daehak-dong, Seoul, South Korea

Jayanth Panyam, Department of Pharmaceutics, College of Pharmacy, University of Minnesota, Minneapolis, MN, USA; Masonic Cancer Center, University of Minnesota, Minneapolis, MN, USA

Joo Yeon Park, College of Pharmacy, Seoul National University, Daehak-dong, Seoul, South Korea

Ryan M. Pearson, Department of Biopharmaceutical Sciences, College of Pharmacy, University of Illinois, Chicago, IL, USA

Marquita Qualls, Department of Chemistry, Purdue University, West Lafayette, IN, USA

Lee Dong Roh, College of Pharmacy, Seoul National University, Daehak-dong, Seoul, South Korea

Gayong Shim, College of Pharmacy, Seoul National University, Daehak-dong, Seoul, South Korea

Pochi Shum, Department of Chemistry, Purdue University, West Lafayette, IN, USA

Li Tang, Department of Materials Science and Engineering, University of Illinois at Urbana−Champaign, Urbana, IL, USA

Sebastien Taurin, Department of Pharmacology and Toxicology, Otago School of Medical Sciences, University of Otago, Dunedin, New Zealand

David H. Thompson, Department of Chemistry, Purdue University, West Lafayette, IN, USA

Rong Tong, Department of Chemical Engineering, Massachusetts Institute of Technology, Cambridge, MA, USA Laboratory for Biomaterials and Drug Delivery, Department of Anesthesiology, Division of Critical Care Medicine, Children's Hospital Boston, Harvard Medical School, Boston, MA, USA

Yuhua Wang, Division of Molecular Pharmaceutics and Center for Nanotechnology in Drug Delivery, Eshelman School of Pharmacy, University of North Carolina at Chapel Hill, Chapel Hill, NC, USA

Yoon Yeo, Department of Industrial and Physical Pharmacy, Purdue University, West Lafayette, IN, USA

Qian Yin, Department of Materials Science and Engineering, University of Illinois at Urbana−Champaign, Urbana, IL, USA

Editor

Yoon Yeo, Ph.D., is an Assistant Professor of Industrial and Physical Pharmacy at the College of Pharmacy, with a joint appointment as Assistant Professor at the Weldon School of Biomedical Engineering, at Purdue University. She earned her B.S. in Pharmacy and M.S. in Microbial Chemistry at Seoul National University in Korea, and her Ph.D. in Pharmaceutics at Purdue University in the United States. She completed postdoctoral training in Chemical Engineering at Massachusetts Institute of Technology and returned to Purdue as a faculty member. Her research focuses on nanoparticle surface engineering for drug delivery to solid tumors, inhalable drug/gene delivery for cystic fibrosis therapy, and functional biomaterials based on carbohydrates. Dr. Yeo has published 52 peer-reviewed papers and 7 book chapters, and received the NSF CAREER Award (2011) and New Investigator Awards from the American Association of Pharmaceutical Scientists (2009) and American Association of Colleges of Pharmacy (2008).

1

Tumor-Targeted Nanoparticles: State-of-the-Art and Remaining Challenges

Gaurav Bajaj

Division of Clinical Pharmacology and Therapeutics, The Children's Hospital of Philadelphia, Philadelphia, PA, USA

Yoon Yeo

Department of Industrial and Physical Pharmacy, Purdue University, West Lafayette, IN, USA

1.1 Introduction

Bringing a drug only to target tissues without spilling any molecule in unwanted places would be an ideal goal for any pharmacological therapies [1]. Owing to the dose-limiting side effects of chemotherapy, a number of drug delivery strategies have been developed in the context of cancer, where “targeted” therapy is most anticipated. Most tumor-targeted drug delivery systems are based on the fact that cancer cells express various molecular markers that are distinguished from those of normal cells. In particular, nanomedicines have received enormous attention in the past decades as a potential tool to increase the selectivity of chemotherapy and diagnosis, due to the small size conducive to circulation and the large surface area to volume ratio that facilitates surface functionalization. Several nanomedicine products have been launched in the market or in the clinical development stage as summarized in Table 1.1. Newer approaches are actively developed to increase target selectivity, although the number of targeted nanomedicines that reached the later phase of clinical trials is relatively low considering the prevalent excitement and the investment made till date [2].

Table 1.1 Nanomedicines on the Market or in Phase II/III Clinical Development.

This chapter discusses the rationale of targeted nanomedicines, different approaches to achieve this goal, current challenges, and considerations for their future development. Here, nanomedicines refer to particulate materials with a diameter in nanometer scale, prepared with natural or synthetic polymers, lipids, or inorganic solids, in the form of polymer–drug conjugates, liposomes, polymeric nanoparticles (NPs) or micelles, dendrimers, nanotubes, nanocrystals, nanorods, nanoshells, or nanocages [2]. Nanomedicines used as a carrier of a drug are often called nanocarriers. Nanoparticles and nanocarriers are also interchangeably used. We will use the term “nanoparticles” to represent various types of nanocarriers in this chapter.

1.2 Functions of Nanoparticles

Fates of a drug entering circulation largely depend on the properties of the drug. Small hydrophilic drug molecules do not bind to proteins in the blood and are quickly eliminated from the body. Hydrophobic drugs are eliminated relatively slowly through kidneys due to plasma protein binding, metabolized in the liver to a hydrophilic metabolite, and then eliminated from the body. On the other hand, the disposition and clearance of drugs encapsulated in NPs depend relatively less on the drug itself than on the properties of NPs during circulation [39].

Systemically administered NPs should be stable enough to retain a drug during circulation and able to extravasate at the target tissues and release the drug in the target tissues and/or inside the target cells to exert an action. Advancement in the nanotechnology has made it possible to incorporate therapeutic drugs in various types of NPs. NPs have contributed to the delivery of poorly water-soluble drugs and improving the bioavailability of drugs with poor stability [2, 40, 41]. One of the major concerns in cancer chemotherapy is multidrug resistance as most anticancer drugs are substrates of drug efflux transporters such as P-glycoprotein. NPs can be designed to overcome the resistance by bypassing efflux transporters [2, 42]. Most significantly, NPs have gained enormous interest as a way of increasing drug delivery to target tissues, in particular, tumors. A detailed discussion of the use of NPs in drug delivery is available in other review articles [2, 43].

NPs can be combined with contrast or imaging agents to visualize pathological tissues and monitor the progression of diseases [44]. Liposomes, micelles, and dendrimers are used to carry paramagnetic ions of indium-111 (), technetium (), manganese (Mn), and gadolinium (Gd). Semiconductor quantum dots or gold NPs have been widely explored for target-specific imaging as combined with various functionalization strategies [45–47].

1.3 Tumor-Targeted Nanoparticles

Several strategies have been employed to achieve tumor-targeted drug delivery based on NPs. We briefly introduce these targeting strategies before we discuss challenges in translating NPs to commercial products.

1.3.1 Passive Targeting

Delivering anticancer agents to the tumors is a multistep process. Drugs delivered into the bloodstream should reach intratumoral region from systemic circulation by crossing tumor vasculature so that drug molecules have access to the tumor cells and stroma. Many solid tumors are characterized by leaky vasculature and poor lymphatic drainage [43]. New vasculature in the tumor is formed to sustain the tumor growth and provide nutrients; however, the structure is usually abnormal and defective with holes ranging from 400 to 600 nm in diameter [48–50]. The defective structure of blood vessels surrounding tumors allows NPs to extravasate and accumulate in the tumor tissues. The impaired lymphatic drainage further helps retain NPs in the tumors. Therefore, NPs with a size less than the cutoff of holes in the vasculature have a selective advantage in reaching tumors. This phenomenon is referred to as the enhanced permeability and retention (EPR) effect [51–53].

For NPs to take advantage of the EPR effect, it is important that the NPs circulate for a long period of time. It is widely known that NPs with hydrophobic or charged surfaces are readily opsonized and taken up by the reticuloendothelial system (RES), which is responsible for clearing macromolecules or particles present in the blood before they reach the target tissues [54, 55]. Therefore, most NPs are surface-modified with a hydrophilic and electrically neutral polymer such as polyethylene glycol (PEG) (PEGylated) [54, 56, 57]. The PEGylated surface is resistant to protein binding and thus avoids the recognition by the RES [55, 58, 59]. For long-term circulation and effective extravasation via leaky vasculature of tumors, ~50–300 nm is considered an optimal size [60, 61].

1.3.2 Active Targeting

Active targeting strategy was developed to further enhance tumor accumulation of NPs beyond the level possible with long-circulating NPs. Here, NP surface is decorated with targeting ligands that can actively bind to cell receptors overexpressed on the tumor cells [2, 49, 62–65]. Frequently used targeting ligands include antibodies, peptides, nucleic acids, and small molecular weight ligands binding to specific receptors [2, 65, 66]. For example, NPs are conjugated with the monoclonal antibody teratuzumab or herceptin to target HER2 receptor on breast cancer cells [59, 67]. A docetaxel-NP formulation containing a small molecule ligand which targets prostate-specific membrane antigen has recently entered a Phase I clinical trial [68].

The rationale of active targeting is that a specific interaction between targeting molecules and cell receptors will increase the amount of NPs retained in tumors. An example is shown in a biodistribution study of -labeled polymeric micelle NPs [69]. Nontargeted NPs (25 nm) were rapidly cleared from plasma as compared to nontargeted NPs with a size of 60 nm, resulting in twofold less total tumor accumulation. On the other hand, another 25 nm NPs functionalized with epidermal growth factor achieved a greater tumor accumulation than nontargeted ones in mice with tumors overexpressing EGF-receptors, reaching the same level as that of 60 nm nontargeted NPs [69]. However, it should be borne in mind that the contribution of a targeting ligand is predicated on the extravasation of NPs to the tumors; thus, the ability to survive circulation for a long period of time still remains one of the most important requirements in the active targeting strategy. For effective active targeting, the density of target receptors should be in range of 104 or 105 copies per cell [2, 70]. In addition to the number of binding sites, binding affinity also plays an important role. Multivalency of ligands can further enhance the affinity for target cells [71]. Receptors in a cell are internalized via different pathways and go through a continuous process of recycling [72]. NPs with targeting ligands can be internalized via the receptor-mediated endocytosis pathways and release drugs inside the cells.

1.3.3 Target-Activated Systems

Target-activated systems refer to NPs that remain stable until they reach target tissues and are activated by the extracellular or intracellular cues [64, 73]. The NPs are designed to circulate similar to passively targeted NPs and transform to a more cell-interactive form in response to conditions unique to tumor tissues or intracellular environments. These conditions include acidic pH or enzymes abundant in the tumor extracellular matrix (ECM).

1.3.3.1 pH-Activated Systems

NPs responsive to acidic pH can be classified into two categories: one activated in the tumor ECM, which may have a pH as low as ~6, and the other activated in the intracellular lysosomes, which acidifies to pH 4–5. Tumors exhibit a slightly acidic pH in the range 6.8–7.2 compared to the physiological pH of 7.4 [74]. This acidity is due to the accumulation of lactic acid, induced by the increased glycolysis of tumor cells [75]. The acidosis of tumor is further enhanced as tumors develop hypoxia, which induces or selects for hyperglycolic cells [76]. The pH-sensitive NPs are composed of polymers, which are protonated at acidic pHs. Upon protonation of the polymer, the NPs are disintegrated to release drugs or change the surface properties to enter cells [64, 77].

Most NPs entering cells via receptor-mediated endocytosis pathways end up in endosomes, which undergo a maturation process into late endosomes and lysosomes [72]. The luminal pH in these vesicles is acidic, varying from pH 6 (endosomes), pH 5–6 (late endosomes), to pH 4.5 (lysosomes) [72]. NPs are designed to escape the vesicles and/or release the payload in response to the low pH. Polycationic polymers such as polyethyleneimine or fusogenic peptides can be used in the formulations [78]. On entering the cell, a drug should reach its final destination to produce an action, which can be a nucleus or other organelles such as mitochondria, lysosome, and endoplasmic reticulum. NP trafficking to the specific organelles may be achieved by the use of specific peptide sequences [47, 79].

1.3.3.2 Enzymatically Activated Systems

Enzymes overexpressed in the tumor microenvironment are used for activating the NPs at tumor sites. An example of such enzymes is matrix metalloproteinases (MMPs) [80, 81], which play a critical role in the invasion of tumor cells and angiogenesis [82]. Several studies have employed MMPs for removing the PEG protection of NP surface at the tumor sites [83–85]. In these approaches, PEG is linked to the NP surface via a peptide linker sensitive to MMPs. Recently, cathepsin B has been utilized to activate a nanoprobe in a tumor-specific manner [86]. Cathepsin B is a lysosomal cysteine protease that plays a role in tumor progression [87]. The nanoprobe consists of glycol chitosan conjugated with a cathepsin B substrate peptide, a near infrared fluorescent dye, and a dark quencher, which self-assemble into 280 nm NPs. Upon the entrance into tumor cells, the cathepsin B substrate peptide is cleaved by intracellular cathepsin B, allowing for dequenching of the dye and emission of the fluorescence signals [86].

1.4 Remaining Challenges in the Development of Tumor-Targeted Nanoparticles

Several NP products, such as liposomes and polymer–drug conjugates, are currently in the market or in the late stage of development process, improving therapeutic efficacy and safety profiles of chemotherapeutics [36, 40]. A large number of targeted NPs have been developed in the last three decades in an attempt to further improve the efficacy of NP-based therapy. However, several challenges remain to be overcome for developing NPs that can attract commercial interest and achieve significant clinical outcomes. Current limitations and challenges in the advancement of nanomedicine have been thoroughly discussed in recent review articles [36, 60, 88–92].

1.4.1 NP Stability

Stability of circulating NPs matters in at least two contexts. NPs carrying a drug must survive the body's natural ability to clear the NPs and should be able to retain a drug during circulation. The former requirement is largely addressed by surface modification with a “stealth” coating with polymers such as PEG. However, recent studies have identified potential disadvantages of PEG [73]. For example, PEG can interfere with NP–cell interactions [93] and endosomal escape of NPs [93] after the disposition of NPs. It is also suggested that PEGylated liposomes are implicated with immune responses, which lead to an accelerated blood clearance of the second dose liposomes [94, 95]. Alternative polymers or surface protection strategies are actively explored [73].

Stable retention of a drug during circulation is another important challenge. Despite the thermodynamic stability in buffers, some polymeric micelles or matrix-type NPs have been shown to quickly disintegrate and/or leak the payload upon contact with various blood components [64, 96–98]. Chen et al. demonstrated that polymeric micelles composed of PEG-poly(D,L-lactic acid) block-copolymer dissociated and released the encapsulated fluorescent dyes within 15 min after intravenous injection [96]. Another study showed that a drug and the carrier (liposomes) exhibited different pharmacokinetics in blood, indicating that the drug was escaping the carrier prematurely [99]. The instability of NPs in circulation is a significant (yet often neglected) problem in the development stage. Success of a new NP system depends on the availability of a method that can reliably predict the stability of NPs in a biological environment.

1.4.2 Heterogeneous Tumor Vasculature

Tumor accumulation of NPs mainly depends on their passive extravasation via the leaky vasculature feeding the tumors. While the defective architecture of tumor vasculature is widely exploited by the NP-based drug delivery, it is often ignored that the tumor blood vessels are heterogeneous [100, 101] and do not exhibit the same degree of leakiness [102]. The heterogeneity of the EPR effect is even greater when different tumor models are compared. A biodistribution study of -labeled PEGylated liposomes in 17 patients with locally advanced cancers showed that the levels of tumor liposome uptake varied from 0.5% to 3.6% of injected dose (ID) at 72 h, which translated into 2.7–53% of ID/kg of tumor (ID/kg) [103]. This study also showed that the tumor uptake of liposomes varied significantly with the site of the primary tumors, from 5.3 ± 2.6% ID/kg in breast cancers, 18.3 ± 5.7% ID/kg in lung tumors, to 33.0 ± 15.8% ID/kg in head and neck cancers [103]. Therefore, NPs relying on the EPR effect alone are unlikely to achieve reliable and predictable clinical outcomes.

1.4.3 NP Distribution in Tumors

The lack of functional lymphatics and the high vascular permeability result in elevation of the pressure in the interstitial tissue of solid tumors [104]. Furthermore, tumors develop various conditions to increase the stiffness of tissue [105]. The high interstitial fluid pressure and the stiffness of the tissue interfere with migration of a drug in tumor, limiting its effect on the central region of the tumor, a potential source of tumor relapse and metastasis [106–108].

Drug delivery with NPs is more significantly influenced by this challenge because of the size and surface properties [105]. Goodman et al. predicted that movement of 100–200 nm NPs in tumor spheroids would be much restricted even with the treatment of an ECM-degrading enzyme [109]. It was also experimentally demonstrated that the intratumoral distribution of 60 nm polymeric micelles was limited and localized in proximity to the blood vessel [69]. The size restriction is particularly problematic in the treatment of tumors with hypovascular and hypopermeable properties such as pancreatic tumors [110]. In the case of NPs employing active targeting strategy, high affinity binding to the receptors can lead to the “binding site barrier effect” in solid tumors, where the NP–receptor interactions may prevent migration of NPs to the interior of tissues [2, 69, 111, 112]. While an active targeting strategy has the potential to improve the delivery of drugs through the intracellular uptake of NPs, the effect may be limited to the periphery of tumors when the size and binding site barrier play a dominant role in intratumoral disposition of the NPs.

1.4.4 Regulatory Considerations

The unique properties of NPs enabled by the size and surface pose different safety issues than free drugs and larger dosage forms [113]. The U.S. Food and Drug Administration's Nanotechnology Task Force, formed in August 2006, solicited the agency's action to develop a regulatory guidance for manufacturers and researchers [114]. However, much remains uncertain as to how their safety should be tested and how much time and cost will be required for the approval of NP products, especially those designed with multiple functionalities. Such uncertainties negatively influence the investors and development partners, when the new product brings about only mild improvement over existing products.

New drug products must pass the regulatory scrutiny that examines their safety, effectiveness, and potential hazards. Reproducibility and predictability of the product's performance are the most important quality criteria under any test methods and models. Accordingly, it is important to ensure that NPs have consistent properties, such as size, charge, shape, and density of surface functional groups. Increasing complexity of a formulation increases the difficulty of quality control as well as the development cost. Therefore, the current effort to develop new types of NPs must undergo a careful cost–benefit analysis prior to a significant investment.

1.5 Future Perspectives

Several recent studies attempt to address the challenges discussed so far [105]. For example, Maeda et al. proposed the use of drugs that artificially augment the EPR effect [102]. Angiotensin II was used to elevate systemic blood pressure [115], and nitroglycerin or other agents inducing nitric oxide production were used to facilitate vascular blood flow and permeability [116]. These approaches have shown the potential to overcome the heterogeneity of the EPR effect. To overcome the limitations in NP distribution in tumors, ECM-degrading enzymes such as hyaluronidase and collagenase were proposed as a potential aid to reduce the stiffness of ECM and the interstitial fluid pressure [109, 117]. While ongoing studies are likely to make these challenges under control, additional issues await future efforts. Here we discuss the remaining homework for the advancement of nanomedicine.

1.5.1 In Vitro Models

Preclinical studies of anticancer drugs and NPs are first carried out in cell culture models. The cell culture model is a convenient and inexpensive way of screening the effectiveness of a drug or an NP formulation. However, it is not unusual that these drugs and NPs showing great efficacy in cell culture models are often proven much less effective in vivo. The lack of predictability is due in part to the fact that a single cell population grown in a two-dimensional (2D) layer barely reflects the nature of human tumors, which involves an intricate cross talk between different cell populations and three-dimensional (3D) organization of cells and ECM [118]. There is an increasing understanding of the significance of 3D architecture of tumors, cell populations, matrix composition and mechanics, and the gradients of signaling materials in modeling tumors in vitro. Accordingly, active efforts are made to build more realistic in vitro tumor models [119–121]. Lessons learned from tissue engineering and regenerative medicine are urgently solicited in these efforts.

1.5.2 In Vivo Models

Owing to the relatively low cost and well-established protocols, mouse models with allograft or human xenograft tumors are widely used in the evaluation of in vivo performance of NPs. In these models, cancer cells are inoculated (typically subcutaneously) in immunodeficient mice, allowed to grow into visually identifiable tumors, and treated with a new formulation to examine the pharmacokinetics, biodistribution, and pharmacological effects. However, several cases show that the results of preclinical studies are poorly correlated with Phase III outcomes. For example, in a preclinical study with mice bearing C-26 colon carcinoma, PEGylated liposomes carrying doxorubicin achieved significant survival benefits than free doxorubicin, attributable to their accumulation in tumors [122]. On the other hand, the PEGylated liposomal doxorubin was at best equivalent to free doxorubin in clinical efficacy (progression-free survival and overall survival) in a randomized Phase III trial with metastatic breast cancer patients [123]. In another example, a macromolecular conjugate of PTX and poly(l-glutamic acid) (PTX poliglumex) demonstrated a prolonged circulation half-life and greater tumor uptake and antitumor activity as compared to Taxol (PTX solubilized with Cremophor EL) at the same dose in a mouse model with syngeneic ovarian carcinoma [124]. However, the developer officially withdrew its application for a marketing authorization of PTX poliglumex for the first-line treatment of lung cancer patients because of the lack of therapeutic advantages over the comparators and unexplained toxicity [125].
