The most complete, one-stop reference for fiber optic sensor theory and application Optical Fiber Sensors: Fundamentals for Development of Optimized Devices constitutes the most complete, comprehensive, and up-to-date reference on the development of optical fiber sensors. Edited by two respected experts in the field and authored by experienced engineers and scientists, the book acts as a guide and a reference for an audience ranging from graduate students to researchers and engineers in the field of fiber optic sensors. The book discusses the fundamentals and foundations of fiber optic sensor technology and provides real-world examples to illuminate and illustrate the concepts found within. In addition to the basic concepts necessary to understand this technology, Optical Fiber Sensors includes chapters on: * Distributed sensing with Rayleigh, Raman and Brillouin scattering methods * Biomechanical sensing * Gas and volatile organic compound sensors * Application of nanotechnology to optical fiber sensors * Health care and clinical diagnosis * And others Graduate students as well as professionals who work with optical fiber sensors will find this volume to be an indispensable resource and reference.

Leseprobe

IEEE Press

445 Hoes Lane

Piscataway, NJ 08854

IEEE Press Editorial Board

Ekram Hossain, Editor in Chief

Jón Atli Benediktsson

David Alan Grier

Elya B. Joffe

Xiaoou Li

Peter Lian

Andreas Molisch

Saeid Nahavandi

Jeffrey Reed

Diomidis Spinellis

Sarah Spurgeon

Ahmet Murat Tekalp

Optical Fibre Sensors

Fundamentals for Development of Optimized Devices

Edited by

Ignacio Del VillarIgnacio R. Matias

IEEE Press Series on SensorsVladimir Lumelsky, Series Editor

Copyright © 2021 by The Institute of Electrical and Electronics Engineers, Inc. All rights reserved.

Published by John Wiley & Sons, Inc., Hoboken, New Jersey.

Published simultaneously in Canada.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, scanning, or otherwise, except as permitted under Section 107 or 108 of the 1976 United States Copyright Act, without either the prior written permission of the Publisher, or authorization through payment of the appropriate per‐copy fee to the Copyright Clearance Center, Inc., 222 Rosewood Drive, Danvers, MA 01923, (978) 750‐8400, fax (978) 750‐4470, or on the web at www.copyright.com. Requests to the Publisher for permission should be addressed to the Permissions Department, John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, (201) 748‐6011, fax (201) 748‐6008, or online at http://www.wiley.com/go/permission.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives or written sales materials. The advice and strategies contained herein may not be suitable for your situation. You should consult with a professional where appropriate. Neither the publisher nor author shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

For general information on our other products and services or for technical support, please contact our Customer Care Department within the United States at (800) 762‐2974, outside the United States at (317) 572‐3993 or fax (317) 572‐4002.

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic formats. For more information about Wiley products, visit our web site at www.wiley.com.

Library of Congress Cataloging‐in‐Publication Data:

Names: Del Villar, Ignacio, 1978‐ editor. | Matias, Ignacio R., 1966–editor. | Institute of Electrical and Electronics Engineers.Title: Optical fibre sensors : fundamentals for development of optimized devices / edited by Ignacio Del Villar, Ignacio R. Matias.Other titles: Optical fibre sensors (John Wiley & Sons)Description: Hoboken, New Jersey : Wiley‐IEEE Press, [2021] | Series: IEEE Press series on sensors | Includes bibliographical references and index.Identifiers: LCCN 2020020787 (print) | LCCN 2020020788 (ebook) | ISBN 9781119534761 (cloth) | ISBN 9781119534778 (adobe pdf) | ISBN 9781119534792 (epub)Subjects: LCSH: Optical fibre detectors.Classification: LCC TA1815 .O696 2021 (print) | LCC TA1815 (ebook) | DDC 621.36/92–dc23LC record available at https://lccn.loc.gov/2020020787LC ebook record available at https://lccn.loc.gov/2020020788

Cover Design: WileyCover Image: © MirageC/Getty Images

List of Contributors

Francesco BaldiniInstitute of Applied Physics “Nello Carrara” (IFAC)National Research Council (CNR)FlorenceItaly

Francesco ChiavaioliInstitute of Applied Physics “Nello Carrara” (IFAC)National Research Council (CNR)FlorenceItaly

Marco ConsalesOptoelectronics GroupDepartment of EngineeringUniversity of SannioBeneventoItaly

Brian CulshawDepartment of Electronic and Electrical EngineeringUniversity of Strathclyd, GlasgowScotland, UK

Andrea CusanoOptoelectronics GroupDepartment of EngineeringUniversity of SannioBeneventoItaly

Jean Carlos Cardozo da SilvaGraduate Program in Electrical and Computer EngineeringFederal University of Technology‐Paraná Brazil

Ignacio Del VillarDepartment of Electrical, Electronic and Communications EngineeringPublic University of NavarrePamplonaSpain

César ElosuaDepartment of Electrical, Electronic and Communications EngineeringPublic University of NavarrePamplonaSpain

José Rodolfo GalvãoGraduate Program in Electrical and Computer EngineeringFederal University of Technology‐Paraná Brazill

Ambra GiannettiInstitute of Applied Physics “Nello Carrara” (IFAC)National Research Council (CNR)Florence, Italy

Sillas HadjiloucasDepartment of Biomedical EngineeringUniversity of ReadingReading, UK

Arthur H. HartogWorthy Photonics LtdWinchester, UK

T. Hien NguyenPhotonics and Instrumentation Research CentreCity University of LondonLondon, UK

Alessandra KalinowskiGraduate Program in Electrical and Computer EngineeringFederal University of Technology‐Paraná Brazil

Kamil KosielŁukasiewicz Research Network – Institute of Electron TechnologyAl. Lotników 32/46, 02-668 Warsaw Poland

Alayn LoayssaDepartment of Electrical, Electronic and Communications EngineeringPublic University of NavarrePamplona, Spain

Diego Lopez‐TorresDepartment of Electrical, Electronic and Communications Engineering,Public University of Navarre,Pamplona, Spain

Dajuan LyuNational Engineering Laboratory for Fibre Optic Sensing Technology (NEL‐FOST)Wuhan University of TechnologyWuhan, China

Cicero MartelliGraduate Program in Electrical and Computer EngineeringFederal University of Technology‐Paraná Brazil

Ignacio R. MatiasInstitute of Smart CitiesPublic University of NavarrePamplona, Spain

Carlo MolardiSchool of EngineeringNazarbayev UniversityAstanaKazakhstan

Talita PaesGraduate Program in Electrical and Computer EngineeringFederal University of Technology‐Paraná Brazil

Marco N. PetrovichOptoelectronics Research CentreUniversity of SouthamptonSouthampton, UK

Marco PiscoOptoelectronics GroupDepartment of EngineeringUniversity of SannioBenevento, Italy

Armando RicciardiOptoelectronics GroupDepartment of EngineeringUniversity of SannioBenevento, Italy

Mateusz ŚmietanaInstitute of Microelectronics and OptoelectronicsWarsaw University of Technology KoszykowaWarsaw, Poland

Tong SunPhotonics and Instrumentation Research CentreCity University of LondonLondon, UK

Daniele TosiSchool of Engineering, Nazarbayev University, Astana, KazakhstanandLaboratory of Biosensors and BioinstrumentsNational Laboratory AstanaAstana, Kazakhstan

Minghong YangNational Engineering Laboratory for Fibre Optic Sensing Technology (NEL‐FOST), Wuhan University of TechnologyWuhan, China

Acknowledgment

As editors, we would like to express our gratitude to all the members of Wiley‐IEEE Press for their assistance and help.

Also special thanks to the wonderful team of authors that have written the chapters of the book. To our collaborators in the Public University of Navarra: Alayn Loayssa, Diego López, and César Elosua, we must add a list of prestigious authors that cover multiple countries all over the world: Minghong Yang and Dajuan Lyu, from the National Engineering Laboratory for Fibre Optic Sensing Technology (NEL‐FOST) Wuhan University of Technology, Wuhan (China); Daniele Tosi and Carlo Molardi, from the Nazarbayev University, School of Engineering, Astana (Kazakhstan); Arthur H. Hartog, from the Worthy Photonics Ltd, Winchester (UK); Cicero Martelli, Jean Carlos Cardozo da Silva, Alessandra Kalinowski, José Rodolfo Galvão, and Talita Paes, from Universidade Tecnológica Federal do Paraná (Brasil); T. Hien Nguyen and Tong Sun, from the Photonics and Instrumentation Research Centre, City, University of London (UK); Armando Ricciardi, Marco Consales, Marco Pisco, and Andrea Cusano, from the Optoelectronics Group, Department of Engineering, University of Sannio, (Italy); Francesco Chiavaioli, Ambra Giannetti, and Francesco Baldini, from the Institute of Applied Physics ‘Nello Carrara’ (IFAC), Sesto Fiorentino (Italy); Sillas Hadjiloucas, from the Department of Biomedical Engineering, University of Reading (UK); Kamil Kosiel and Mateusz Śmietana, respectively from the Łukasiewicz Research Network‐Instytut Technologii Elektronowej in Warsaw (Poland) and from the Institute of Microelectronics and Optoelectronics in the Warsaw University of Technology (Poland); Marco N. Petrovich, from the University of Strathclyde, Royal College Building, Glasgow, Scotland, (UK); and Brian Culshaw, from the Optoelectronics Research Centre, University of Southampton, (UK).

We would like also to thank our families and friends, because without their support this project would not have been possible.

Finally, just as members of this optical fibre sensor community, we want to thank the dedication to all those who pioneered this more than half a century ago and to those who will continue to do so, because this road is made by walking and, fortunately, the goal is every closer.

About the Editors

Ignacio Del Villar, PhD, is an Associate Professor in the Electrical, Electronic and Communications Engineering Department at the Public University of Navarra, Spain, where he teaches on electronics and industrial communications. He is a member of the IEEE and an Associate Editor of different journals. In addition, he has participated in multiple research projects and co‐authored more than 150 papers, conferences, and book chapters related to fibre‐optic sensors.

Ignacio R. Matias, PhD, is the Scientific Director of the Institute of Smart Cities and Professor of the Electrical, Electronic and Communications Department at the Public University of Navarra, Spain. He was one of the Associate Editors who founded the IEEE Sensors Journal, promoting fibre‐optic sensors since then through conferences, special issues, awards, books, etc. He has co‐authored more than 500 book chapters, journal and conference papers related to optical fibre sensors. He is currently member‐at‐large at the IEEE Sensors Council AdCom.

1Introduction

Ignacio R. Matias1 and Ignacio Del Villar2

1 Institute of Smart Cities, Public University of Navarre, Pamplona, Spain

2 Department of Electrical, Electronic and Communications Engineering, Public University of Navarre Pamplona, Spain

The optical telegraph, invented in 1791 by Claude Chappe, consisted of a network of stations that allowed the transmission of information at a speed of one symbol in two minutes between Paris and Lille (i.e. 230 km) [1]. Each station monitored, with the aid of a telescope, the character that was represented with a wooden semaphore in the previous station. This system was widely used for about 50 years because it was much faster than sending messages by letter, but it required direct vision between each couple of consecutive stations. Consequently, bad weather, or simply the night, prevented its utilization. These are the main reasons why with the invention of the electrical telegraph, a system based on a guided electrical signal, the utilization of the optical telegraph came soon to an end.

However, in parallel to the invention of the electrical telegraph, in 1841, the path towards optical guiding was started with an important discovery by two French researchers, Jean Daniel Colladon and Jacques Babinet, who independently demonstrated that it was possible to guide light in a curved waveguide [2]. Colladon proved this with light rays trapped in a water jet by total internal reflection, whereas Babinet did the same in a bent glass rod.

Another breakthrough occurred in 1966, when Charles Kao (he received the Nobel Prize in Physics in 2009) and George Hockham published a work demonstrating that the attenuation in optical fibres available at the time was caused by impurities, rather than fundamental physical effects such as scattering. They pointed out that fibres with low loss could be manufactured by using high‐purity glass [3, 4]. This idea was proved in the North American company Corning in 1970, with the development of an optical fibre with losses lower than 20 dB/km. Soon afterwards, in 1977, losses were reduced to such a point that General Telephone and Electronics could carry live telephone traffic, 6 Mbit/s, in Long Beach, California, whereas the Bell System could transmit a 45 Mbit/s fibre link in the downtown Chicago phone system. Since that year optical fibre has become the most widely used guided medium in the twentieth century, mainly thanks to the huge bandwidth it presents compared with other guided communication media such as twisted pair and coaxial cable.

Optical communication is the main application of optical fibre. However, there is a second domain where this structure can be used: sensors. Despite the impact of optical fibre in the domain of sensors not being as big as in communications, their presence in the global market cannot be neglected. Indeed, it is the natural and ideal platform in terms of integrating the sensor in the communication system.

Optical fibre sensors (OFSs) can be classified in many different ways. The main classification concerns to the location where the light is modulated, existing in two groups: extrinsic and intrinsic OFSs. In both cases there is a parameter (physical, chemical, biological, etc.) that modulates light. However, the difference is that in an extrinsic OFSs light is guided to the interaction region, extrinsic to the optical fibre, where light is modulated, and after this modulation light is collected again in the optical waveguide, whereas in an intrinsic OFS light is always guided by the optical fibre. In Figure 1.1 the difference between an intrinsic and an extrinsic OFS is shown. In the case of an extrinsic sensor, light is modulated outside of the fibre by a liquid (its properties may change as a function of temperature, for instance), whereas in the case of the intrinsic sensor, a fibre has been spliced to two other fibres (one input and one output fibre), which allows an enhanced interaction with the outer medium. In this case, a liquid modulates the light at the same time it is being transmitted through the fibre.

Figure 1.1 (a) Extrinsic sensor: light is modulated outside of the fibre. (b) Intrinsic sensor: light is modulated while it is transmitted through the fibre.

Probably the first OFS was the fibrescope. In 1930 Heinrich Lamm, a German medical student, assembled a bundle of optical fibres to carry an image. His purpose was to use the device for obtaining images of inaccessible parts of the body. He tried to patent the device, but John Logie Baird and Clarence W. Hansell had patented a similar idea some years before. The quality of the images that Lamm obtained was not good, but he is the first researcher that experimentally achieved this breakthrough in the history of optical sensors. Afterwards, in 1954, the Englishman Harold H. Hopkins and the Indian Narinder S. Kapany presented results of better quality on the same principle [5].

Some years later, in 1967, the first effective demonstration of a fibre‐optic sensor, the Fotonic sensor, was published [6]. The device was also based on a fibre bundle. However, this time the arrangement was different. Some of the fibres emitted light, and some others did not. The fibre bundle illuminated a surface in front of the fibre, and some part of light was coupled to the fibres that did not transmit light. The amount of light reflected back depended on the distance between the fibre bundle end and the surface. Consequently, the device could be used as a displacement sensor (Figure 1.2).

This type of sensor was the basis for the commercialization of the MTI Fotonic sensor. In the 1980s, the MTI 2000 version allowed monitoring vibration and displacement. Nowadays it is still sold under the version MTI 2100, which is the same concept but with improved characteristics such as the ability to operate in cryogenic, vacuum, high pressure, or in high magnetic field and harsh environments. The resolution has also been improved from 1 nm in the MTI 2000 to 0.25 nm with the MTI 2100 and frequency response from direct‐coupled (dc) to 150 kHz in the MTI 2000 up to dc‐500 kHz in the MTI 2100.

The concept used in the Fotonic sensor was also the basis for detection of intracranial pressure by using a surface that is a diaphragm that can be deformed by the action of pressure. Depending on the pressure, the surface is deformed, and in this way, the light coupled back to the receiving fibre is modulated. The commercialized device was called Camino ICP Monitor.

Interferometric fibre sensors emerged in the 1970s, the most successful one among them being the optical fibre gyroscope (OFG) (see Figure 1.3). The basic principle was very simple. Light from a laser is split by a beam splitter and enters the fibre on both ends. Both beams go out of the fibre and a photodetector receives them. Thanks to the Sagnac effect, both beams interfere constructively and destructively depending on the rotation speed of the device. The first publication dates from the year 1976 [7]. Since that moment the device has been improved with additional elements such as polarization control, but the initial concept is still maintained. The true benefit of the OFG over traditional spinning‐mass gyros is that it has no moving parts. As a result, OFGs are faster, tougher, more reliable and demand far less maintenance. That is why they have become an essential component in platform stabilizing systems, for example, for large satellite antennas, in missile guidance, in subsea navigation, and in aircraft stabilization and navigation, and a host of other applications [8]. It moves about 1000 million US$ per year according to MarketsandMarkets: Fibre Optics Gyroscope Market by Sensing Axis (1, 2, and 3), Device (Gyrocompass, Inertial Measurement Unit, Inertial Navigation System, and Attitude Heading Reference System), Application, and Geography – Global Forecast to 2022.

Figure 1.2 (a–c) Fotonic sensor setup with a fibre bundle composed of one transmitting and one receiving fibre: (a) with the surface too close and hence only a small part is coupled back to the receiving fibre; (b) with the surface at the optimal position for a highest coupling; and (c) with the surface too far and hence a great part of light is lost and not coupled to the receiving fibre. (d) MTI 2100 diagram showing the power detected as a function of the distance (the maximum is obtained when the distance is neither too big nor too small).

Figure 1.3 (a) Simplified setup: light from a laser is split by a beam splitter and enters the fibre on both ends. The two beams go out of the fibre and the photodetector receives them. Due to the Sagnac effect, both beams interfere constructively and destructively depending on the rotation speed of the device. (b) Commercial optical fibre gyro with a size comparable to a coin (from KVH website).

Based on the acousto‐optic effect, it was possible also to develop hydrophones, OFSs that could detect acoustic waves when immersed in water. One of the first approaches was based on interferometry [9], by combining the signals transmitted by an optical fibre that was not immersed in water with the signal reflected at the end facet of another optical fibre immersed in water. By exciting an acoustic wave in front of the fibre immersed in water, it was possible to observe variations in the detected signal. Though it has not been a commercial success like OFG, this application still attracts interest, and the utilization of a Fabry–Pérot cavity (i.e. a coating on the end facet of the optical fibre immersed in water) allows avoiding the use of the reference fibre because in this way an interferometric pattern in the optical spectrum is generated. The setup is depicted in Figure 1.4, and a commercial device is available at the company Precision Acoustics. Its immunity from electromagnetic radiation makes it particularly suited for high‐frequency measurements in hostile fields.

Figure 1.4 Optical setup for a Fabry–Pérot hydrophone [10]. OSC is oscilloscope, PD photodiode, PG pulse generator, PZT piezoelectric transducer, and TLD tunable laser diode.

Source: Reproduced with permission of Elsevier.

As we can see, this property was also included in the Fotonic sensor and is one of the key advantages of optical fibres in general. However, in order to make a fibre optical sensor the first option of an end user, more advantages are required compared with the rest of sensors in the market. In the case of the OFG, the key property was that it was not necessary to use moving parts, which means long duration and fast response.

A second OFS success was the measurement of current and voltage with the aid of the Faraday effect [11, 12]. As an example, ABB has developed a commercial device called fibre‐optic current sensor (FOCS), which can be used instead of magnetic systems due to its exceptional accuracy and reliability. It can measure uni‐ or bidirectional DC currents of up to 600 kA with an accuracy of ±0.1% of the measured value (Figure 1.5).

Strain gauges are another well‐known application where optical fibres can be used. The first work was published in 1978 [13]. SOFO, from the company Smartec, is a commercial example that can be used for surface mounting or embedding in concrete and mortars. It is ideal for long‐term structural deformation monitoring and presents a 20‐year track record in field applications.

Figure 1.5 (a) Basic principle of optical fibre sensors: the polarization of the input light in and optical fibre is rotated by the action of the magnetic field generated around a line transmitting current. (b) Commercial ABB FOCS sensor.

In addition, the invention of optical fibre Bragg gratings (FBGs) in 1978 [14] widened even more the possibilities of OFSs in terms of detection of strain, because the path was open to include multiple Bragg gratings in the same optical fibre, each one operating at a different wavelength, and to use a multiplexing technology (developed in parallel back in 1980 [15]), to analyse each signal separately. This can be used to monitor strain at multiple points in aircrafts, tunnels, etc., in what is typically called structural health monitoring [16]. The first commercial Bragg grating sensors were available in 1995, and since that moment many companies have commercialized their own FBGs.

However, despite it being possible, unlike electronic gauges, to include multiple strain OFSs in the same wire and despite strain OFSs being less sensitive to vibration or heat and far more reliable than electronic gauges, they have not achieved a commercial success comparable with the OFG. Here we can see a good example of the problem that faces OFSs: there is an electronic competitor, the metallic strain gauge, that nowadays is more widespread than optical fibre gauges because engineers are more familiarized with electronic technology. Like OFSs, electronic sensors have also become popular thanks to another technology, electronics, and to the vast utilization of copper wire for communications. Moreover, the computer, the basic unit in the information technology era, is also based on electronics. All this has made it possible for electronic sensors to nearly monopolize the domain of sensors. Therefore, it is necessary to find applications where optical fibre makes a difference compared with the electronic counterpart.

In this sense, it is important to consider the advantages and disadvantages of optical fibre. The main good points of optical fibre are [17, 18]:

Small size (its diameter is typically around 100 μm, which allows embedding in many structures) and lightweight.

Low losses, which allow remote sensing.

Anti‐electromagnetic interference and anti‐radio‐frequency interference.

No electrical biasing is required to guide light, so the resulting sensors are passive, which is very relevant in environments with an explosion risk.

High bandwidth, which allows multiplexing and multi‐parameter sensing,

Distributed sensing in optical fibre communication lines: it is possible to develop modulation techniques that allow physical quantities to be measured along the fibre itself.

However, there are also important concerns [18], which are being progressively solved as the technology matures:

Cost

Complexity in interrogation systems

Unfamiliarity of the end user with the technology

By taking a look at these properties, it is easy to understand why the most successful type of OFS, in terms of covering the sensors market, is distributed sensing. First, it is possible with optical fibre to make distributed measurements over distances up to several tens of kilometres, an ability that is unique to fibre optics. A second advantage of those mentioned above is the small diameter of optical fibre, which allows embedding it in tunnels, bridges, or concrete constructions [19, 20], and, once installed, the initial cost is compensated with a continuous monitoring of variables such as strain, temperature, or vibration, an operation that may last years and that does not affect the optical fibre it is embedded in. This explains its success in the following domains:

Civil engineering: leakage of dams and river embankments, monitoring of cracks in bridges and other concrete structures; structural health monitoring of large civil projects; and fire monitoring and safety alarms for roads, subways, tunnels, etc. [

21

].

Petrochemical: detection of oil and natural gas transmission pipelines or storage tank leaks; temperature monitoring of oil depots, oil pipes, and oil tanks; and detection of fault points.

Power cable: detection and monitoring of surface temperature of power cable and location of accident points; temperature monitoring of power plants and substations; and detection of fault points and fire alarms.

Aerospace: monitoring of aircraft pressure, temperature, fuel level, and landing gear status; temperature and strain monitoring of composite skins; and measurement of stress and temperature of aircraft jet turbine engine systems [

22

].

Distributed sensing technology can be classified in two groups: quasi‐distributed (multiplexing FBGs like in Figure 1.6 are a good example) and distributed sensing [24]. A comparison between both technologies is presented in Figure 1.7. With quasi‐distributed sensing, discrete points can be monitored, whereas with distributed sensing changes in any point in the optical fibre path length can be detected. Effective gauge lengths of the order of 1 m are common, and there are some that go to even shorter discrimination lengths [8]. Regarding purely distributed sensing, the first works date from the 1980s [25, 26], and since that moment up to now, the utilization of Rayleigh, Brillouin, and Raman scattering for remotely detecting changes in a parameter at a specific point has been widely explored [22, 27, 28].

The optical time‐domain reflectometer (OTDR) is the typical commercial device, though there are many types of detectors such as the example presented in Figure 1.7c for sensing an acoustic field. The basic principle of this type of device is the injection of a series of optical pulses into the fibre and the further detection of light that is scattered or reflected back from points along the fibre. These points may be splices, failures, or even changes introduced by variables such as temperature (in this last case the system can be used to detect a fire), strain, or vibration. Since that moment many companies have focused on distributed sensing, such as Omnisens, Sensornet, Silixa, Fotec, Luna, OptaSense, or Future Fibre Technologies, just to mention a few.

In 2017 their market was more than 1 billion US dollars, and it is expected to grow at a 10.4% annual growth rate through 2026. The main application is the oil and gas vertical segment, which occupied a 60.9% share of the global distributed fibre‐optic sensor market in 2015. But also pipelines, intrusion detection and security, transport, and infrastructures are other important domains where this technology is used.

Figure 1.6 (a) Single fibre Bragg grating. (b) Multiple fibre Bragg gratings in a multiplexed system monitored with an interrogator. (c) Applications of FBG arrays for monitoring strain in different points of an aircraft and for developing a smart textile [23].

Consequently, it can be concluded that optical fibre distributed sensors, along with the gyro, are the two most successful OFSs and both cases can serve as an example to follow towards new commercial opportunities.

In addition to this, OFS research during the last years has focused on two important fields: the fabrication of specialty fibres, where the main breakthrough took place in 1996 with the first microstructured optical fibres [29], and the improvement of nanodeposition techniques [30, 31], which has permitted OFSs to be used in the domain of gas, chemical, and biological sensors [32–37]. The explanation is simple. The optical fibre transmits light, and light can be modulated by parameters that affect the guidance of light through the optical fibre such as strain, temperature, or surrounding medium refractive index. Consequently, if the deposition of a material on the optical fibre modulates the transmission of light through the fibre, sensitive materials will modulate the transmission of light through the optical fibre as a function of almost any parameter (i.e. any environmental variables, chemical or biological species, etc.). Moreover, nanotechnology is evolving so much that a lab on fibre can be developed with optimized sensitivity to one or several parameters [38] (Figure 1.8). This positions OFSs in the strategic field of nanophotonics. Even an array of nanoantennas has been deposited on the tip of an optical fibre to enhance the Raman scattering detection [39].

Figure 1.7 (a) Quasi‐distributed sensing (with FBGs). (b) Distributed sensing. (c) Commercial distributed sensor for detection of an acoustic field from Silixa.

Figure 1.8 Combination of nanotechnology with optical fibre. Deposition of nanostructures: around the fibre, inside the fibre (in the holes of holey fibre), and on the tip of optical fibre (in a probe in reflection configuration).

Source: With permission from [40] © Wiley.

Other important fields are human structural health monitoring, also called biomechanics [41–43], or the development of optical fibre composed of new materials. In this sense, it is well known that the use of plastic optical fibre (also called polymer optical fibre) is an economic alternative to silica fibre in optical communications. Though it has disadvantages, such as higher losses, this technology can be transferred also to optical fibre sensing for the same purpose: low‐cost solutions. In addition, the polymer itself presents some different mechanical and thermal properties, which allows new possibilities for the development of multi‐parameter sensors, new modulation schemes, and embedded systems for several target applications (e.g. textiles, composite and concrete integration) [44]. The success of plastic optic fibre suggests the exploration of other materials that can be used for harsh environment applications, as it will be shown in one of the chapters of the book. Moreover, OFS technology has evolved so much that even a spider silk optical sensor has been developed for detection of chemical vapours [45]. So the question arises as to why not even metamaterials could be used in OFSs [46].

Considering the current research lines of OFS technology and the commercial devices that are already available, this book will aim for providing the reader with the key concepts towards transforming research into final products. The success of distributed OFSs and the gyro must be followed by others along the twenty‐first century, and to this purpose we will combine basic concepts, such as the elements that compose an OFS setup and how light propagates through optical fibre, along with the latest progress of OFSs in multiple important domains of the modern society.

To this purpose, the book will be divided into these sections:

Chapter 2 offers the basics for understanding light propagation in optical fibre: single‐mode and multimode fibres under both a geometric optics and wave theory perspective. As a special and challenging case, the propagation through microstructured optical fibre will also be discussed. Finally, some ideas on propagation of light through specialty optical fibres optimized for sensing will be presented.

Chapter 3 describes the key elements that are necessary for an OFS setup (i.e. the optical source, the detector, light coupling, splices, etc.).

Chapters 4 and 5 present different detection techniques: intensity modulation, polarimetric sensors, phase modulation (interferometers), wavelength modulation, and detection based on Rayleigh, Raman, and Brillouin scattering.

Chapters 5–7 focus on applications of distributed sensing: structural health monitoring, biomechanical sensing, and the gas and oil industry (this group is the most successful domain of application of OFSs).

Chapters 8–11 present other important domains such the application of nanotechnology towards improving the performance of OFSs, gas and volatile organic compound sensors, chemical sensors, and biosensors.

Finally, Chapter 12 addresses the important topic of interaction of light with matter with a biomedical perspective. Chapter 13 shows detection in harsh environments, one of the domains where optical fibre can more successfully compete with other technologies. Chapter 14 concludes the book with a thorough analysis of the future trends of OFSs.

References

1

Dilhac, J.‐M. (2001). The telegraph of claude chappe: an optical telecommunication network for the 18th century.

IEEE Conference on the History of Telecommunications,

St. John’s, Newfoundland, Canada (25–27 July 2001).

2

Johnston, W.K. (2004). The birth of fibreoptics from light guiding.

J. Endourol.

18 (5): 425–426.

3

Kao, K.C. and Hockham, G.A. (1966). Dielectric‐fibre surface waveguides for optical frequencies.

Proc. Inst. Electr. Eng.

: 1151–1158.

4

Natarajan, V. (2010). The 2009 nobel prize in physics: honoring achievements in optics that have changed modern life.

Resonance

15 (8): 723–732.

5

Hopkins, H.H. and Kapany, N.S. (1954). A flexible fibrescope, using static scanning.

Nature

173 (4392): 39–41.

6

Menadier, C. and Kissinger, C. (1967). The fotonic sensor.

Instrum. Control Syst.

40: 114–120.

7

Vali, V. and Shorthill, R.W. (1976). Fibre ring interferometer.

Appl. Opt.

15 (5): 1099–1100.

8

Culshaw, B. and Kersey, A. (2008). Fibre‐optic sensing: a historical perspective.

J. Lightwave Technol.

26 (9): 1064–1078.

9

Bucaro, J.A., Dardy, H.D., and Carome, E.F. (1977). Fibre‐optic hydrophone.

J. Acoust. Soc. Am.

62: 1302–1304.

10

Kim, K.S., Mizuno, Y., and Nakamura, K. (2014). Fibre‐optic ultrasonic hydrophone using short Fabry‐Perot cavity with multilayer reflectors deposited on small stub.

Ultrasonics

54 (4): 1047–1051.

11

Rogers, A.J. (1973). Optical technique for measurement of current and high voltage.

Proc. Inst. Electr. Eng.

120 (2): 261–267.

12

Rogers, A.J. (1979). Optical measurement of current and voltage on power systems.

Electr. Power Appl.

2 (4): 120–124.

13

Butter, C.D. and Hocker, G.B. (1978). Fibre optics strain gauge.

Appl. Opt.

17 (18): 2867–2869.

14

Hill, K.O., Fujii, Y., Johnson, D.C., and Kawasaki, B.S. (1978). Photosensitivity in optical fibre waveguides: application to reflection filter fabrication.

Appl. Phys. Lett.

32 (10): 647–649.

15

Nelson, A.R., McMahon, D.H., and Gravel, R.L. (1980). Passive multiplexing system for fibre‐optic sensors.

Appl. Opt.
