Introduction to Raman Spectroscopy
I'm picking up good vibrations
She's giving me the excitations
Good, (bop bop) good vibrations
The Beach Boys, ‘Good Vibrations’, 1966
It was on 28 February 1928 that Sir C.V. Raman and K.S. Krishnan for the first time succeeded in demonstrating the inelastic scattering of light by a fluid. For this work, in 1930, Raman was honoured with the Nobel Prize. At the time, they used filtered sunlight to excite the molecules and photographic plates were used to record the spectrum. It took about 24 hours to record a spectrum of a beaker with ca. 600 ml of pure liquid. Knowing this, it is clear that Raman spectroscopy for a long time was only limited to specialised research laboratories and that the technique was considered as a curiosum. Today, Raman spectroscopy has moved out of the highly specialised laboratories and is available not only in many research institutions, but also as a reliable technique for quality control or even for sorting out plastics in the recycling industry.
Indeed, in today's research, Raman spectroscopy is appreciated for many different reasons. First, the technique is a relatively fast method and well-suited to investigating solids, liquids, solutions and even gases, depending on the experimental set-up used. For the analysis of solids often barely—if any—sample preparation is needed: just position it under the microscope and focus the laser beam. Liquids can be measured through glass vials and, as opposed to infrared spectroscopy, the presence of water does not hamper the measurements. Small portable spectrometers are now available and fibre optics probe heads allow us to record spectra from a distance, which is useful for analysis in harsh conditions or for the investigation of, for instance, explosives. Mobile analysis allows objects to be in situ and in a noninvasive way. Micro-Raman spectroscopy is one of the rare spectroscopic methods that enables us to obtain molecular information at the micrometer-scale. Chemometrics can be used during Raman spectroscopy studies, and molecules are easily interpreted by using automated algorithms for searching spectral libraries.
Current Raman spectroscopy research is very different from the approach adopted in the early days. Instrumentation has seriously evolved, and as a consequence sample sizes and measuring times are seriously reduced. Historically it has been seen that (r)evolutions in Raman spectroscopy research (e.g. new applications, access for a larger group of scientists, etc.) are often caused by the availability of new equipment or instrumental innovations. A first improvement since Raman's days was the introduction of mercury lamps as a source of excitation. However, measuring procedures and alignment remained quite complex and Raman spectroscopy was for a long period only used in restricted research areas, while infrared spectroscopy gained in importance. A big step forward in Raman research was in the 1960s, with the advent of the first lasers. The instrumentation was still quite expensive and aligning the sample and setting up of experiments was not straightforward. Often double or triple monochromators were used. At the end of the 1980s, new progress was caused by new instrumentation, such as the introduction of CCD (charge-coupled device) detectors, holographic filters, new optics (micro-Raman spectroscopy and fibre-optics) and the introduction of FT-Raman spectroscopy (Fourier-Transform Raman spectroscopy). Moreover, price reductions and the miniaturisation of instruments meant that Raman spectroscopy was no longer limited to a few specialised research laboratories, and the technique has become increasingly more common in fundamental research as well as in industry.
Throughout this book, several common applications of Raman spectroscopy are given. Many more can be found in the literature. In the following chapters we want to introduce you to this approach, firstly by introducing the fundamentals of the technique and thereafter by discussing some interferences and possibilities to enhance the Raman signal. In a later chapter we will discuss the main components of current Raman spectroscopy instrumentation, while in the final chapter we try indicate to the reader some of the common pitfalls and approaches when using this technique.
Summary
In this introductory chapter, the reader has been introduced to some historical aspects of Raman spectroscopy. By now, it should be clear that in the past, many advances and new applications were caused by improvements in Raman spectroscopy instrumentation, such as the introduction of lasers or sensitive detectors.
Further Reading
Lewis, I.R. and Edwards, H.H.M. (eds), Handbook of Raman Spectroscopy—From the Research Laboratory to the Process Line, Marcel Dekker, Inc., New York, 2001.
McCreery, R.L., Raman Spectroscopy for Chemical Analysis, John Wiley, New York, 2000.
Chapter 1
Theoretical Aspects
The theoretical background of the Raman effect is already extensively described in literature. The Raman effect can be considered as the inelastic scattering of electromagnetic radiation. During this interaction, energy is transferred between the photons and the molecular vibrations. Therefore, the scattered photons have a different energy to the incoming photons.
1.1 Classical Approach
When a molecule is positioned in an electrical field , an electrical dipole moment is induced. The relation between this induced dipole moment and the electrical field can be expressed as a power series:
1.1
In this equation, , and are tensors, which are named polarisability, hyperpolarisability and 2nd hyperpolarisability, respectively. Typically, they are in the range of ca. and . As these tensors each are a factor 10 billion less intense, the influence of these factors can in many cases be neglected.
The induced dipole moment can be thus considered as directly proportional to the electrical field and Equation (1.1) is reduced to:
1.2
When studying the Raman effect, the electrical field is caused by electromagnetic radiation. Indeed, light can be considered as an oscillating electrical field. The electrical field vector E on the moment t is described as:
1.3
with the vibrational frequency of the electromagnetic radiation.
In Equation (1.2) the polarisability is a tensor, which is dependent on the shape and dimensions of the chemical bond. As chemical bonds change during vibrations, the polarisability is dependent on the vibrations of the molecule. It can be said that the polarisability tensor is dependent on the normal coordinate Q of the molecule. This relationship can be expressed as a Taylor series:
1.4
and are the normal coordinates that correspond with the and normal vibration, corresponding with the vibrational frequencies and . In a first approximation, only the first two terms in this equation are maintained. This means that the different (normal) vibrations are considered as totally independent and no cross-terms are included in the equation. Thus, considering the normal vibration, Equation (1.4) is reduced to:
1.5
with the derivative of the polarisability tensor to the normal coordinate , under equilibrium conditions.
In a first approximation, the normal coordinate oscillates according to the harmonic oscillator (Intermezzo 1.1). The normal coordinate varies as a function of time according to:
1.6
with the amplitude of the normal vibration and a phase angle. Substitution of Equation (1.6) for Equation (1.5) gives:
1.7
When considering only the first two terms of the Taylor series (1.4), we assume that the polarisability tensor undergoes a harmonic oscillation, with a frequency , that equals the vibrational frequency of the normal coordinate of the molecule. By substituting Equations (1.7) and (1.3) in the (simplified) definition of the dipole moment (Equation (1.2)), we obtain:
1.8
By using the trigonometrical formula:
1.9
Equation (1.8) can be modified to:
1.10
Therefore, we can consider the induced dipole moment as a function of the vibrational frequencies of the molecule and of the incident radiation :
1.11
The induced dipole moment can be split into 3 components, each with a different frequency-dependence. The first term in Equation (1.11) corresponds to the elastic scattering of the electromagnetic radiation: the induced dipole moment has the same frequency (hence the same energy) as the incoming radiation. This type of scattering is called ‘Rayleigh scattering’, named after Lord Rayleigh (1842–1919), who used Rayleigh scattering to determine the size of a molecule. The 2nd and 3rd term in Equation (1.11) correspond to the inelastic scattering of light: Raman scattering. The 2nd term corresponds to a higher energy of the scattered radiation, compared to the incident beam (Anti-Stokes scattering), while the last term represents a lowering of the frequency (Stokes scattering).
When using Raman spectroscopy, an intense, monochromatic beam of electromagnetic radiation (usually a laser) is focussed on the sample, and the intensity of the scattered radiation is measured as a function of its wavelength. Usually, in a Raman spectrum the intensity is plotted as a function of the Raman wavenumber , expressed in , which is related to the difference in frequency between the scattered light and the incident electromagnetic radiation:
1.12
In this expression, the symbols and stand for the frequency of the scattered (measured) and incident radiation, respectively; c is the speed of light; wavenumbers are usually expressed in , so be careful when calculating them, as you need to use the appropriate units. Positive wavenumbers correspond with Stokes scattering, while negative wavenumbers correspond with anti-stokes scattering (see Figure 1.1).
Figure 1.1 Raman spectrum of the mineral realgar () in the anti-Stokes region, Rayleigh line and Stokes region. The actual intensity of the Rayleigh line is suppressed by a holographic filter in the spectrometer.
Figure Intermezzo 1.1 Harmonic oscillator.
1.2 Selection Rule
From Equation (1.10) it can be seen that the Raman effect only happens if . Therefore, during the considered normal vibration a change in polarisability should happen:
1.13
