Processing and Properties of Advanced Ceramics and Composites VI E-Book

• Herausgeber: John Wiley & Sons
• Kategorie: Fachliteratur
• Serie: Ceramic Transaction Series
• Sprache: Englisch

Seitenzahl: 591

Veröffentlichungsjahr: 2014

Beschreibung

Contains 32 papers from the following seven 2013 Materials Science and Technology (MS&T'13) symposia:

• Innovative Processing and Synthesis of Ceramics, Glasses and Composites
• Advances in Ceramic Matrix Composites
• Advanced Materials for Harsh Environments
• Advances in Dielectric Materials and Electronic Devices
• Controlled Synthesis, Processing, and Applications of Structure and Functional Nanomaterials
• Rustum Roy Memorial Symposium: Processing and Performance of Materials Using Microwaves, Electric and Magnetic Fields, Ultrasound, Lasers, and Mechanical Work
• Solution Based Processing for Ceramic Materials

Leseprobe

Contents

Cover

Half Title page

Title page

Copyright page

Preface

Ceramic Matrix Composites

Fabrication of Novel ZrO2(Y2O3)-Al2O3 Ceramics Having High Strength and Toughness by Pulsed Electric-Current Pressure Sintering (PECPS) of SOL-GEL Derived Solid Solution Powders

Abstract

Introduction

Experimental Procedure

Evaluation of Samples

Results and Discussion

Conclusions

Acknowledgments

References

SiC Manufacture via Reactive Infiltration

Abstract

1 Introduction

2 Experimental Procedure

3. Results and Discusion

4. Conclusions

5. Acknowledgements

References

Fabrication and Characterization of Conductive Glass Composites with Networks of Silicon Carbide Whiskers

Abstract

Introduction

Experiment

Discussion

Conclusions

Acknowledgments

References

Alumina-Titanium Composites with Improved Fracture Toughness and Electrical Conductivity

Abstract

Introduction

Experimental

Results

Conclusions

References

Fracture Toughness Enhancement of Mullite-Ceramics Reinforced with Metals

Abstract

Introduction

Experimental

Results

Conclusions

References

Innovative Processing

Steel-Ceramic Laminates Made by Tape Casting — Processing and Interfaces

Abstract

Introduction

Experimental

Results

Conclusions

References

Comparison of Wax Extraction Methods Used In Synthetic Granular Composite Sport Surfaces

Abstract

Introduction

Experimental

Results and Discussion

Conclusions

Acknowledgements

References

Synthesis and Magnetic Properties of Ni-Cu Nano-Magnetic Ceramics

Abstract

Introduction

Experimental Procedure

Results and Discussion

Conclusions

Acknowledgments

References

A Study of Armour Related Properties of Ceramic

Abstract

Introduction

Experimental Details

Results and Discussion

Conclusion

References

A Novel Dip Coating Method for Reaction Bonding of Aluminum on Alumina

Abstract

Introduction

Experimental

Results

Discussion

Conclusions

Acknowledgement

Reference

Processing and Microstructural Characterization of Sintered Lanthanum Aluminate Obtained by Two Different Routes

Abstract

Introduction

Experimental Procedure

Result and Discussion

Conclusions

References

Controlled Synthesis, Processing, and Applications of Structural and Functional Nanomaterials

Plasma Enhanced Chemical Vapor Deposition Of Noble Metal Catalysts on Mesoporous Biomorphic Carbon

Abstract

Introduction

Experimental

Results and Discussion

Conclusion

Acknowledgements

References

Titanium Dioxide Nanocomposites — Synthesis and Photocatalysis

Abstract

Introduction

Experimental

Results and Discussion

Conclusions

References

Magnetic Synthesis and Characterization of Superparamagnetic Nanoparticles Iron Oxide Stabilized with Dextran

Abstract

1. Introduction

2. Experimental

3. Results and Discussion

4. Conclusions

Acknowledgements

References

Magnetic and Mössbauer Behavior of Iron Oxide Nanoparticles Stabilized with Polyethylene Glycol

Abstract

1. Introduction

2. Experimental

3. Results and Discussion

4. Conclusions

Acknowledgements

References

Synthesis of Diamond and Vertically Aligned Carbon Nanotube Double-Layered Nanostructures by Hot Filament Chemical Vapor Deposition

Abstract

Introduction

Experimental

Results and Discussion

Conclusions

Acknowledgements

References

Electronic and Functional Ceramics

Photoluminescence of Fe-Doped INP Single Crystals Produced with Various Wafer Processes

Abstract

Introduction

Experimental Procedure

Results and Discussion

Conclusion

Acknowledgements

References

Configurations, Characteristics and Applications of Novel Varistor-Transistor Hybrid Devices Using Pseudobrookite Oxide Semiconductor Ceramic Substrates

Abstract

I. Introduction

II. Determination of Varistor Characteristics: 2-points And 3-Points

III. Transistor Devices and Properties

IV. Conclusions

Acknowledgments

References

Microstructural Design of Piezoelectric ZnO thin Films as High Frequency Resonators

Abstract

Introduction

Experimental

Results and Discussion

Conclusion

Acknowledgment

References

Novel Method of Researching and Developing Piezoelectric Ceramics by Measuring Acoustic Wave Velocities

Abstract

Introduction

Experimental Procedure

Results and Discussion

Conclusions

Acknowledgments

References

Vacancy Modeling in Lead Titanate and Lead Zirconate Titanate

Abstract

Introduction

Materials and Methods

Results

Conclusions

References

Materials for Harsh Environments

Influence of the Cure Wet on Mechanical and Physical Chemical Mortar

Abstract

1. Introduction

2. Experimental Program

3. Testing Procedures

4. Results and Discussion

5. Carbonation

Conclusions

Footnotes

References

The Dicalcium Phosphate Dihydrate Fixator and Stabilizer of Glutaraldehyde

Abstract

1. Introduction

2. Materials and Methods

3. Results and Discussion

4. Conclusion

References

Morphological and Electrochemical Interactions of Admixed Zn-SnO2 Composites Electro-Deposited on Mild Steel

Abstract

Introduction

Experimental Procedure

Results and Discussion

Conclusions

Acknowledgement

References

New Lean Alloy Alternatives for 300 Series Stainless Steels

Abstract

Introduction

1 Investigations

2 Results

3 Discussion

4 Conclusions

Acknowledgements

References

Ceramic Materials in Carbonate Fuel Cell

Abstract

Introduction and Product Status

Ceramic Materials in DFC

Cell Active Components (Electrode and Elecrtrolyte MATRIX)

Cell Hardware Protective Coating

Ceramic Materials in Stack Module and BOP

Conclusion

Acknowledgement

References

Processing and Performance of Materials Using Microwaves, Electric and Magnetic Fields

Microstructure and Magnetoelectric Properties of Microwave Sintered CoFe2O4-PZT Particulate Composite Synthesized in SITU

Abstract

Introduction

Experimental

Results and Discussion

Conclusions

Acknowledgements

References

Structure and Magnetic Property of FeAl2O4 Synthesized by Microwave Heating

Abstract

Introduction

Experimental Procedure

Results and Discussion

Conclusion

Acknowledgement

Reference

High Frequency Microwave Sintering of A Nanostructured Varistor Composition

Abstract

Introduction

Experimental Procedure

Results and Discussion

Conclusions

Acknowledgements

References

An Explanation of Microwave Effects by Expansion of Transit State Theories with Disturbed Velocity Distributions by Microwave

1. Introduction

2. Excitation of Ultrasound Wave by External Microwave

3. Perturbations Coupled to Collision-Less Energy Transfers by Electro-Kinetic Wave

4. Eyring Model with Perturbed Velocity Function and the Extra Energy Path

Acknowledgments

Reference

Synthesis of Divalent SN Compounds Under Microwave Non-Equilibrium Reaction Field

Abstract

Introduction

Experimental

Results and Discussion

Conclusion

Acknowledgements

References

Understanding Non-Thermal Microwave Effects in Materials Processing — A Classical Non-Quantum Approach

Abstract

Introduction

Work Input to Solid-Dielectrics Under CPR Microwave Irradiation

Resonant EM Work, Free Energy, Reactivity and Non-Thermal Microwave Effects

Summary

Concluding Remark

Footnotes

References

Application of Microwave Heating for Reduction of Tricalcium Phosphate with Carbon

Abstract

1. Introduction

2. Experimental

3. Results and Discussion

4. Conclusions

5. Acknowledgement

References

Exchange of Cs ION in Clay Minerals by Microwave Application

Abstract

Introduction

Experimental

Results

Discussion

Conclusions

Acknowledgement

References

Microwave Autogenous Firing of Structural Ceramics

Abstract

Introduction

Pilot Plant Development

Proposed Continuous Hybrid MWAF Process

Conclusions

Acknowledgments

References

Influence of Powerful Microwaves on the Termite Coptotermes Formosanus- Impact of Powerful Microwaves on Insects

Abstract

Introduction

Experiment

Results & Discussion

References

Author Index

Processing and Properties of Advanced Ceramics and Composites VI

Copyright © 2014 by The American Ceramic Society. All rights reserved.

Published by John Wiley & Sons, Inc., Hoboken, New Jersey.Published simultaneously in Canada.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, scanning, or otherwise, except as permitted under Section 107 or 108 of the 1976 United States Copyright Act, without either the prior written permission of the Publisher, or authorization through payment of the appropriate per-copy fee to the Copyright Clearance Center, Inc., 222 Rosewood Drive, Danvers, MA 01923, [phone], fax [phone], or on the web at www.copyright.com. Requests to the Publisher for permission should be addressed to the Permissions Department, John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, [phone], fax [phone], or online at http://www.wiley.com/go/permission.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives or written sales materials. The advice and strategies contained herein may not be suitable for your situation. You should consult with a professional where appropriate. Neither the publisher nor author shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

For general information on our other products and services or for technical support, please contact our Customer Care Department within the United States at [phone], outside the United States at [phone] or fax [phone].

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic formats. For more information about Wiley products, visit our web site at www.wiley.com.

Library of Congress Cataloging-in-Publication Data is available.

ISBN: 978-1-118-99549-5ISSN: 1042-1122

Preface

This volume contains papers presented at seven international symposia held during the Materials Science & Technology 2013 Conference (MS&T’13), October 27-31, 2013 at the Palais des congress, in Montréal, Quebec, Canada. The symposia in this volume include: Innovative Processing and Synthesis of Ceramics, Glasses and Composites; Advances in Ceramic Matrix Composites; Advanced Materials for Harsh Environments; Advances in Dielectric Materials and Electronic Devices; Controlled Synthesis, Processing, and Applications of Structural and Functional Nanomaterials; Rustum Roy Memorial Symposium on Processing and Performance of Materials Using Microwaves, Electric, and Magnetic Fields; and Solution-Based Processing for Ceramic Materials.

These conference symposia provided a forum for scientists, engineers, and technologists to discuss and exchange state-of-the-art ideas, information, and technology on advanced methods and approaches for processing, synthesis, characterization, and applications of ceramics, glasses, and composites.

Thirty-six papers that were discussed at these symposia are included in this proceeding volume. Each manuscript was peer-reviewed using The American Ceramic Society’s review process.

The editors wish to extend their gratitude and appreciation to all the authors for their submissions and revisions of manuscripts, to all the participants and session chairs for their time and effort, and to all the reviewers for their valuable comments and suggestions.

We hope that this volume will serve as a useful reference for the professionals working in the field of synthesis and processing of ceramics and composites as well as their properties.

J.P. SINGH

NAROTTAM P. BANSAL

AMAR S. BHALLA

MORSI M. MAHMOUD

NAVIN JOSE MANJOORAN

GURPREET SINGH

JACQUES LAMON

SUNG R. CHOI

GARY PICKRELL

KATHY LU

GEOFF BRENNECKA

TAKASHI GOTO

Ceramic Matrix Composites

FABRICATION OF NOVEL ZrO2(Y2O3)-Al2O3 CERAMICS HAVING HIGH STRENGTH AND TOUGHNESS BY PULSED ELECTRIC-CURRENT PRESSURE SINTERING (PECPS) OF SOL-GEL DERIVED SOLID SOLUTION POWDERS

Ken Hirota*1, Kengo Shibaya1, Masaki Kato*1, and Hideki Taguchi2

*1 Faculty of Science and Engineering, Doshisha University, Kyo-Tanabe Kyoto 610-0321, Japan

2 The Graduate School of Natural Science and Technology (Science), Okayama University, Okayama 700-8530, Japan

Keywords: Zirconium oxide; Aluminum oxide; Yttrium oxide; Pulsed electric-current pressure sintering (PECPS); Mechanical properties

ABSTRACT

ZrO2 based ceramics containing 25 mol% Al2O3 and 0.90~1.125 mol% Y2O3, i.e., ZrO2(1.2~1.5 mol%Y2O3)−25mol%Al2O3 have been fabricated at 1523 to 1623 K (1250~1350°C) for 10 min under 60 MPa in Ar by pulsed electric-current pressure sintering (PECPS) of sol-gel derived cubic ZrO2 solid solution (ss) powders. Dense tetragonal-ZrO2 (t-ZrO2) phase composite ceramics (≥99.5%) sintered at 1623 K (1350°C), being composed of ≤~ϕ200 nm grains, revealed high bending strength σb ≥1.5 GPa and high fracture toughness KIC ≥15.5 MPa·m1/2 simultaneously. Precise investigation has been performed on the relationship between their microstructures and mechanical properties, the former of which depend on the content of Y2O3 and calcining temperatures. SEM/TEM observations cleared that these improved mechanical properties might be originated from homogeneous distribution of α-Al2O3 particles around the dense t-ZrO2 grain matrix; the precipitation of α-Al2O3 could be achieved by adopting the (ss) powders and PECPS. The Y2O3 content in fine ZrO2 grains has much effect of controlling the stress-induced transformation toughening of tetragonal to monoclinic ZrO2.

INTRODUCTION

Since the discovery of ZrO2-toughening mechanism based on the stress-induced transformation from tetragonal to monoclinic phases by Garvi [1], partially stabilized zirconia (PSZ) with a small amount of Y2O3 addition has been much focused, and many studies have been performed on the fabrication of other stabilizer added dense PSZ. In addition to these, ZrO2(Y2O3) based and ZrO2(Y2O3)/Al2O3 composite ceramics fabricated using hot pressing (HP) and hot isostatic pressing (HIP) have been developed [2-6]. On the other hand, the solid solution (ss) in the ZrO2-Al2O3 system has not been paid attention; because it was believed that the ZrO2-Al2O3 system did not form the ss even at higher temperatures. However, since the report by Alper [7] on the formation of ZrO2 (ss) containing 7mol% Al2O3, the sol-gel derived ZrO2(ss) powders were prepared and then 75mol%ZrO2-25mol%Al2O3(ss) powders were HIP sintered at 1373 K (1100°C) under 196 MPa for 1 h [8]. Their mechanical properties were evaluated; fracture toughness KIC of 23 MPa·m1/2 was achieved, however, their three-point bending strength σb was remained as low as 570 MPa. After that, there has been no report on the fabrication of dense monolithic or composite ceramics that show high σb ≥GPa and high KIC ≥20 MPa·m1/2 at the same time. If bulk ceramics having both high σb and high KIC simultaneously are developed, they can cast aside the concept of “Ceramics are brittle” and spread their application fields widely.

In the present study, we have prepared ZrO2(Y2O3)-Al2O3(ss) nanometer-sized powders by the sol-gel method and densified them with a pulsed electric-current pressure sintering (PECPS) [9], which method is suitable for the fabrication of high-strength dense ceramics consisting of small grain matrix. In addition, to achieve high fracture toughness, we took into account of the transformation toughening of ZrO2. Based on these concepts, we have considered as follows; 1) the sintering method has been changed from the conventional electric furnace, HP and HIP to PECPS with an extreme high heating rate under strong electric pulse field, which means PECPS would make it possible to fabricate dense ceramics composed of fine grains; 2) we have already achieved high KIC ceramics in the ZrO2-Al2O3 systems [8]; 3) in the ZrO2(Y2O3)-Al2O3(ss) powders, Al2O3 also would act as partially stabilizer in the ZrO2 based ceramics; and 4) it has been reported that 25mo% Al2O3 addition improves the bending strength of ZrO2(Y2O3) ceramics [10,11]. Then, we have selected the composition of ZrO2 (1.2~1.5mol%Y2O3)-25mol% Al2O3 from the conventional ZrO2(2.0 ~3.0mol%Y2O3) which has been used as the high-toughness ceramics.

EXPERIMENTAL PROCEDURE

Preparation of ZrO2(Y2O3)- 25mol%Al2O3 ceramics

The preparation of ZrO2(Y2O3)-25mol%Al2O3 solid solution (ss) powders and the fabrication of dense ceramics using these powders are described in previous our paper [8]. The (ss) powders with the composition of 75mol%ZrO2 (1.2~1.5mol%Y2O3)-25mol%Al2O3 [ZrO2:Y2O3:Al2O3=74.10~73.875:0.9~1.125:25.0 mol%] were prepared using Zr(OC3H7)4 (~99.9% pure), Y(OC3H7)3 (~99.9% pure), and Al(OC3H7)3 (~99.9% pure), as starting materials [8,12]. The as-prepared powder (precursor) was calcined at 1093K (820°C) for 75mol%ZrO2(1.5mol%Y2O3)-25mol%Al2O3 (henceforth, abbreviate as ZrO2(1.5Y)-25 mol% Al2O3 and denote as [1.5Y]) and 1138 K (865°C), 1153 K (880°C) and 1168 K (895°C) for ZrO2(1.2Y)-25mol%Al2O3 ([1.2Y]) composition powders for 1 h in air. As will be described latter, these temperatures were determined based on the crystallization temperatures about 1088 K(815°C) and 1133 K(860°C) for 1.5Y and 1.2Y powders, respectively, from the results of XRD and DTA/TG analyses.

Calcined powder compacts after CIPing at 245 MPa for 3 min were sintered with a pulsed electric-current pressure sintering (PECPS: SPS-5104A, SPS SYNTEX INC., Tokyo, Japan) (on-off interval=12:2) with a heating rate of 100 K·min−1 (1.667 K/s), at 1523 to 1623 K (1250~1350°C) under 60 MPa in Ar using a carbon mold (ϕ40-ϕ16-30h mm) and plunger (ϕ39.9-40h mm).

EVALUATION OF SAMPLES

Microstructures

Thermal analysis of precursors was conducted using a differential thermal analysis and thermal gravimetry (DT-TG 60H, Shimadzu, Kyoto, Japan) in air with a heating rate of 10 K·min−1 (0.1667 K·s−1). Crystalline phases were identified by X-ray diffraction (XRD) analysis (CuKα radiation, Rint 2000, Rigaku, Osaka, Japan). The volume fraction of the monoclinic ZrO2 (m- ZrO2) phase for the test samples was determined from the intensity ratio of the monoclinic (111) and (11-1) diffraction lines to the tetragonal (111) line by XRD analysis [13]. Bulk densities (Dobs) of sintered ceramics after polishing with a diamond paste (nominal size ϕ1~3 μm) were evaluated by Archimedes method. Theoretical densities (Dx) of ceramics were calculated as follows; the lattice parameters of t-ZrO2 phase were estimated to be a=0.360520~0.360657 and c=0.518758~0.518948 nm, and those of m-ZrO2 phase also were a=0.519003~0.518014, b=0.514807~0.5169561, c=0.535040~0.535023 nm, and =98.6960~98.8594° using Rietveld analysis [14], Then the values of Dx(t-ZrO2(1.5Y))=6.0510 and Dx(m-ZrO2(1.5Y))=5.7725 Mg·m−3 were obtained. From the t/m-ZrO2 volume ratios and the values of Dx(α-Al2O3)=3.987 Mg·m−3 (JCPDS: #10-0173), the Dx values of composite ceramics were calculated. Both Dx(t-ZrO2(1.2Y)) and Dx(m-ZrO2(1.2Y)) were assumed to be the same as Dx(t-ZrO2(1.5Y)) and Dx(m-ZrO2(1.5Y)), respectively, because of a small difference in Y2O3 addition.

Microstructural observation on the as-prepared and calcined powders, and the fractured or polished surfaces of ceramics were conducted using a field emission-type transmission electron microscope (FE-TEM, JEM-2100F, JEOL Ltd., Tokyo, Japan) and a scanning electron microscope (FE-SEM, JSM-7001FD, JEOL Ltd.) equipped with an energy dispersive spectroscopy (EDS, JED-2300/T and JED-2300/F, JEOL Ltd., respectively). Before TEM observation, the specimens were processed into thinner using a focused ion beam (FIB, FB-2200, Hitachi High-Tech Fielding Co. Ltd., Tokyo, Japan). The grain sizes were determined by an intercept method [15].

Mechanical properties

After crystalline phase identification, test bars (~3 × 3.5 × 11 mm3) for mechanical-property measurements were cut from the ceramics with a diamond cutting-blade and then their four sides were polished to mirror surface with a diamond paste (nominal particle size ϕ1-3 μm). Three-point bending strength (σb) was evaluated with a cross-head speed of 0.5 mm · min−1 and an 8 mm-span length using WC jigs. Vickers hardness (Hv) and fracture toughness (KIC) were evaluated using a Vickers hardness tester (HMV, Shimadzu) with an applying load of 19.6 N and a duration time of 15 s for the former, and the indentation fracture method (IF) with Niihara’s equation using a Vickers hardness tester (VMT-7, Matsuzawa, Osaka, Japan) with applying load of 196 N and a duration time of 15 s for the latter [16,17].

RESULTS AND DISCUSSION

Characterization of powders and ceramics

Fig. 1 (a) shows a TEM photograph of as-prepared 1.2Y powder; thin fine hallow powders with a particle size of around 0.6 nm was observed.

Figure 1. TEM photographs of ZrO2(1.2Y)-25mol%Al2O3 powders; (a) as-prepared and calcined for 1 h in air at (b) 865, (c) 880, and (d) 895°C.

DTA-TG curves of this powder were measured (Fig.2); a strong endothermic peak around 1133 K (860°C) was detected. The same as-prepared 1.2Y powder was analyzed using XRD (Fig. 3 (i)); amorphous pattern was observed. And after calcined at 1138 K (865°C) for 1 h, the sample revealed crystallized cubic ZrO2 phase (Fig. 3(ii)); no other crystalline compounds, such as α-Al2O3 and tetragonal- (t-) or monoclinic- (m-) ZrO2 phases, were found; informing that cubic (c-) ZrO2 solid solution (ss) was crystallized (formed) from the amorphous powder. From this result, it is clear that amorphous solid solution powder transformed into c-ZrO2(ss) at crystallization temperature Tx of 1133 K (860°C). Furthermore, 1.2Y powder was calcined at 1153 K (880°C) and 1168 K (895°C) for 1 h to investigate the relationship between the calcined temperatures and the microstructures/mechanical properties of sintered ceramics.

Figure 2. DTA-TG curves of as-prepared ZrO2 (1.2Y) −25mol%Al2O3 (ss) powder.

Figure 3. XRD patterns for ZrO2(1.2Y)-25 mol% Al2O3 (ss) samples: (i) as-prepared, (ii) calcined at 865°C for 1 h in air and (iii) sintered at 1300°C by PECPS.

Fig. 1 (b)-(d) show the TEM photographs of calcined powders; the particle shape becomes clear and the particle size Ps increased from 0.6 (amorphous) to 6.0 (865°C), 6.2 (880°C) and 6.4 nm (895°C) monotonously. As the same manner, 1.5Y powder crystallized from amorphous (ss) to c-ZrO2(ss) at Tx of 1093 K (820°C).

Microstructures and mechanical properties of ceramics

Calcined powder compacts were densified using a PECPS as already described. Fig. 3(iii) shows representative XRD pattern of the polished surface of 1.2Y ceramics sintered at 1300°C from 865°C-calcined powder; a main phase changed from c-ZrO2(ss) to t-ZrO2, mZrO2 and α-Al2O3. Diffraction peaks are indexed based on each PDF file (t-ZrO2:#48-0024, mZrO2:#37-1481, α-Al2O3:#10-0173). From these XRD line intensity data, t-ZrO2 vol% was calculated using Garvie & Nicholson’s equation [13]; in the present study, main phase of other ceramics is also t-ZrO2, as will be shown in the latter.

Fig. 4 displays the representative microstructural parameters, such as (a) t-ZrO2 phase volume ratio t-ZrO2 (vol%), (b) average grain sizes Gs, (c) bulk density Dobs, and relative density of Dobs/Dx of the 1.2Y ceramics using 865°C calcined powder. Little change in t-ZrO2 (vol%) is observed and stable around 96.5vol% as shown in XRD pattern on 1300°C sintered ceramics (Fi. 3 (iii)), however, the Gs increased rapidly with increasing sintering temperature more than 1325°C. On the other hand, Dobs and Dobs/Dx revealed the maximum values at 1300°C; the value of Dobs/Dx reached ≥ 99.5%. The mechanical properties of 1.2Y ceramics sintered at 1300 and 1350°C are shown as a function of calcining temperatures (Fig. 5).

Figure 4. Microstructural properties of ZrO2(1.2Y)- 25 mol%Al2O3 composites fabricated from 865°C calcined powders.

Figure 5. (a) Bending strength σb, (b) Vickers hardness Hv, (c) fracture toughness KIC of ZrO2(1.2Y)-25mol%Al2O3 ceramics sintered at 1300°C or 1350°C for 10 min under 60 MPa as a function of calcining temperature.

Bending strength σb of ceramics in Fig. 5(a) reveals two distinctive characteristics; i) higher (1350°C) sintering temperature gave high values, ii) there is much calcining temperature dependence of σb, especially, in the high-temperature sintered (1350°C) ceramics. It should be noted that the best σb value reached ~15.5 GPa with the ZrO2(1.2Y)-25mol%Al2O3 ceramics. On the contrary, Vickers hardness Hv (in Fig. 5 (b)) demonstrates an inverse tendency on sintering temperature: low-temperature (1300°C) sintered ceramics reveal higher Hv value of ~14.8 GPa, this might be originated from the small grain sizes induced by low temperature sintering. In Fig. 5 (c), very important property for engineering ceramics, fracture toughness KIC, is displayed as a function of calcining temperature. At a glance, almost nearly the same tendency as shown in σb is observed; i) higher the sintering temperature, higher KIC values. And ii) lower- calcining temperature resulted in higher KIC, which reached ~16.0 MPa·m1/2.

Here, up to now it has been believed that both high strength and high toughness of ceramics could not be performed, as if there is a “trade-off relation” between them. However, both high σb (≥15.5 GPa) and KIC (≥16.0 MPa·m1/2) have been achieved in the same ceramics simultaneously for the first time.

To investigate the calcination temperature dependence of mechanical properties above mentioned, their microstructures, especially focused on the distribution and size of α-Al2O3 grains because we thought that strength and toughness have been much affected by the guest grains in the composite ceramics. Fig. 6 (a)-(c) display the SEM photographs of polished surfaces of 1.2Y ceramics fabricated from various calcining powders, indicating dense and homogeneous microstructures irrespective calcining temperature. However, in Fig. 6 (d)-(f), there is some difference among them, higher the calcination temperature, smaller the grain size and homogenous the α-Al2O3 black grains. In general, the dense ceramics composed of fine grains can reveal higher strength. These photographs proved the dependence of calcining temperature on the mechanical properties in Fig. 5(a).

Figure 6. SEM photographs of the polished flat surfaces of ZrO2(1.2Y)-25mol%Al2O3 ceramics sintered at 1350°C using the powders calcined at (a,d) 865°, (b,e) 880°, and (c,f) 895°C for 1 h in air. (a)~(e): low and (d)~(f) high magnifications.

In Fig. 7, the mechanical properties (σb, Hv, KIC) of two kinds of ceramics, 1.5Y and 1.2Y, are displayed as a function of sintering temperature. First of all, it is recognized easily that 1.5Y ceramics show higher values, except for Hv, in all sintering temperature. 1.5Y ceramics demonstrate extreme high strength σb up to ~1.6 GPa at the same time high KIC value of ~18.4 MPa·m/1/2. Furthermore, when we focus on the KIC value, 1.5Y ceramics reveal marvelous value more than 20 MPa·m1/2, i.e., ~21.3 MPa·m/1/2, in addition, their σb value reaches ~13.3 GPa. A little bit “trade-off relation” is observed in the 1.5Y ceramics. Thus, note that dense tetragonal-ZrO2 (t-ZrO2) phase composite ceramics (≥99.5%) sintered at 1623 K (1350°C), being composed of ≤ ~ϕ200 nm grains, revealed high bending strength σb ≥1.5 GPa and high fracture toughness KIC ≥ 15.5 MPa·m1/2 simultaneously.

Figure 7. Mechanical properties of (a) bending strength σb, (b) Vickers hardness Hv, and (c) fracture toughness KIC for (i) ZrO2(1.5Y)-25 mol%Al2O3 and (ii) ZrO2(1.2Y)-25mol% Al2O3 composites.

FE-SEM microstructural observation on the fracture surfaces of 1.2Y-1300°C (Fig. 8(a)), 1.2Y-1350°C (Fig. 8(b)), 1.5Y-1300°C (Fig. 8(c)), and 1.5Y-1350°C (Fig. 8(d)) has been performed; these ceramics have been fabricated from 865°C-calcined 1.2Y and 820°C-calcined 1.5Y powders, respectively. These ceramics show dense texture and are consisted of fine grains (100-200 nm); here, we easily take notice of the grain size difference between 1.2Y-1350°C and 1.5Y-1350°C ceramics. This microstructural difference also support that the higher strength could be achieve in 1.5Y-1350°C ceramics due to the smaller grain size. FE-TEM equipped with EDS analysis was used to investigate the microstructures precisely from the viewpoint of grain’s chemical composition. Fig. 9 (a) and (b) show the microstructure of 1.5Y ceramics sintered at 1300°C and elemental EDS-line analysis data on the same position, respectively; from (a) it is clear that dense microstructure consisting of large/small black and white grains was observed. Black and white grains correspond to ZrO2 and Al2O3, respectively, which is in inverse to the SEM photographs. In Fig. 9 (b) of the EDS analysis along the upper line elemental spectra of Zr, Y, O, and Al are shown from the upper to the bottom. From these analytical results, it was cleared that black or grey grains contained Zr, Y, and O, and whittle grains Al and O.

Figure 8. SEM photographs for the facture surfaces of ZrO2(Y2O3) -25mol% Al2O3 composites.

Figure 9. FE-TEM photographs for the (a) microstructural observation and (b) + line EDS analysis on ZrO2(1.5Y)-25mol% Al2O3 ceramics sintered at 1300°C, and ZrO2(1.2Y) -25mol%Al2O3 sintered at 1350°C using the calcined powders at (c) 865, (d) 880. and (e) 895°C for 1 h in air.

In addition, small white Al2O3 grains (ϕ100 nm) were dispersed immediately external to the ZrO2 grains, which was the results of partial precipitation from the (ss) particles containing Y and Al. In another portion, Al element was recognized; this means that a small amount of Al was remained within the ZrO2 grains, forming the (ss) grains. These Al2O3 grains might have much effect on the stabilization of ZrO2. However, Y2O3 grains were not recognized from EDS line analysis; they stayed within the ZrO2 grains to stabilize t-ZrO2 phase.

Fig. 10 summarizes the effect of Y2O3 content on the mechanical properties, (a) fracture toughness KIC and (b) Vickers hardness Hv, of ZrO2-Al2O3 ceramics fabricated from solid solution powders; data obtained from our previous experiments are also plotted in Fig. 10, strength σb is omitted because the value of b is much affected by the relative density, and grain sizes. Off course, these curves are much different from the previous studies [18-20] in the point of the best Y2O3 content on the mechanical properties is a little bit small. This might be explained by the stabilizing effect from a small amount of Al2O3 remained in ZrO2 grains.

Figure 10. (a) KIC and (b) Hv of ZrO2-25mol%Al2O3 ceramics sintered at 1300~1350°C for 10 min under 50-60MPa in Ar as a function of Y2O3 content of sintered at 1300°C for 10 min under 50~60MPa.

CONCLUSIONS

By utilizing both sol-gel derived (ss) powders and PECPS, it has been possible to fabricate dense novel ZrO2-based ceramics which consisted of submicron meter-size grains with a small amount of (ss) grain, in addition to a homogeneous distribution of α-Al2O3 close to fine t-ZrO2 grains. These ceramics showed extreme high strength and high toughness simultaneously, which has been ever reported. These properties can introduce the ceramics into the wide industrial applications.

ACKNOWLEDGMENTS

This work was financially supported by the Ministry of Education, Culture, Sports, Science and Technology, Japan, the project S1311036.

REFERENCES

1R. C. Garvie, R. H. J. Hannink and R. T. Pascoe, Ceramic Steel?, Nature (London), 258, (5537), 703-704 (1975).

2T. K. Gupta, F. F. Lange and J. H. Bechtold, Effect of stress-induced phase transformation on the properties of polycrystalline zirconia containing metastable tetragonal phase, J. Mater. Sci., 13, 1464-1470 (1978).

3N. Claussen, Stress Induced Transformation of Tetragonal ZrO2 Particles in Ceramic Matrices, J. Am. Ceram. Soc., 61, 85-86 (1978).

4R. Ruhle, N. Clausen and A. H. Heuer, Microstructural studies of Y2O3-containning tetragonal ZrO2 polycrystal (Y-TZP), in Advances in Ceramics, 12, American Ceramic Society, Ohio, 352 (1984).

5S. Hori, M. Yoshimura and S. Somiya, Strength-toughness relations in sintered and isostatically hot-pressed ZrO2-toughned Al2O3, J. Am. Ceram. Soc., 69, 169-172(1986).

6T. Masaki, Mechanical properties of toughened ZrO2-Y2O3 ceramics, J. Am. Ceram. Soc., 69, 638-640 (1986).

7A. M. Alper, Inter-relationship of phase equilibria, microstructure, and properties in fusion-cast ceramics, Fig. 2, p. 339 in Science of Ceramics, 3, edited by G.H. Stewart, Academic Press, London, U.K. (1967).

8S. Inamura, M. Miyamoto, Y. Imaida, M. Takagwa, K. Hirota and O. Yamaguchi, High fracture toughness of ZrO2 solid- solution ceramics with nanometre grain size in the system ZrO2–Al2O3, J. Mater. Sci, Let., 12, 1368-1370 (1993).

9M. Tokita, Trend in Advanced SPS Spark Plasma System and Technology, J. Soc. Powder Tech. Jpn., 30, 790–804 (1993).

10T. Tsukuma, K. Ueda, and M. Shimada, Strength and fracture toughness of isostatically hot-pressed composites of Al2O3 and Y2O3-partially-stabilised ZrO2, J. Am. Ceram. Soc., 68, C-4 − C-5 (1985).

11K. Tsukuma, K. Ueda, K. Matsushita, and M. Shimada, High-temperature strength of Y2O3-partially-sabilized ZrO2/Al2O3 composites, J. Am. Ceram. Soc., 68, C-56 − C-58 (1985).

12D-Y. Lee, D-J. Kim, H-J. Hwang, Mechanical Properties of Hot Isostatic Pressed (Y, Nb)-TZP/Al2O3 Ceramics, J. Korean Ceram. Soc., 36, 1381-1389 (1999).

13R. C. Garvie and P. S. Nicholson, Phase analysis in Zirconia Systems, J. Am. Ceram. Soc., 55, 303-305 (1972).

14Rietveld, program ‘RIETAN’, http://fujioizumi.verse.jp/

15M. I. Mendelson, Average Grain Size in Polycrystalline Ceramics, J. Am. Ceram. Soc., 52, 443–446 (1969).

16K. Niihara, R. Morena and D. P. H. Hasselman, Evaluation of KIC of Brittle Solids by the Indentation Method with Low Crack-to-Indent Ratios, J. Mater. Sci. Lett., 1, 13-16 (1982).

17A. G. Evans and E. A. Charles, Fracture toughness determination by indentation, J. Am. Ceram. Soc., 59, 371-372 (1976).

18F. F. Lange, Transformation toughening − Part 3 Experimental observations in the ZrO2-Y2O3 system, J. Mater. Sci., 17, 240-246 (1982).

19F. F. Lange, Transformation toughening − Part 4 Fabrication, fracture toughness and strength of Al2O3- ZrO2 composites, J. Mater. Sci., 17, 247-254 (1982).

20R. Shikata, Y. Urata, T. Shiono, T. Nishikawa, Strengthening of Y-PSZ-Al2O3 composite ceramics, J. Jpn. Soc. Powder Powder Metall., 37, 357-361 (1990).

SiC MANUFACTURE VIA REACTIVE INFILTRATION

Mario Caccia and Javier Narciso

Instituto Universitario de Materiales de Alicante. Alicante University. Alicante. Spain [email protected]

ABSTRACT:

Silicon Carbide (SiC) is one of the most important advanced ceramic, due to its unique set of electrical, optical, thermal and mechanical properties. The main barrier nowadays to wider the use of SiC is its manufacturing process, which requires very high temperatures (above 2000 °C) and pressures (> 100 MPa), is time consuming and allows a non well control of the final product quality. Out of all the procedures available, reactive infiltration has proven to be the most profitable, for it minimizes temperature (1500 °C), pressure (0.1 MPa) and processing time, while enhancing product quality control. Another advantage of this method is that it is a near net shape method. Reactive infiltration consists in infiltrating a carbon porous preform with liquid silicon. During the infiltration silicon reacts with carbon to produce SiC. In the present work, we have successfully performed reactive infiltration in different carbon performs, from highly porous foams to dense carbon fiber or bulk SiC pieces. For these infiltrations, the reaction parameters, temperature, in the range 1400-1550°C, and reaction time, in the range 1-8 hours, have been studied and optimized. The evolution of the reaction and the quality of the final products obtained were assessed via different microscopy techniques and physical properties.

1 INTRODUCTION

Silicon Carbide (SiC) is an advanced ceramic of great industrial interest for it can be used in a wide range of applications. This functionality is due to the combination of excellent thermal, mechanical, chemical, electrical and optical properties1-7. This material has been traditionally used for polishing and cutting applications. However, the technological advances and the capability to obtain SiC single crystals have opened a whole new specter of applications, e.g. in electronics, high wear resistance C/SiC composites or the most promising ones, metal/SiC composites to be used as heatsinks8-10. These novel applications require larger SiC bodies with more complex geometries which cannot be easily obtained using traditional ceramic powder sintering methods. Since SiC is a covalent solid with low diffusion capacity, sintering with total elimination of porosity is not possible. Many methods exist to densify SiC powder though. Among this methods hot isostactic pressing (HIP) is the one that produces the best quality material. This process requires very high temperatures, above 2000 °C, and high pressures, around 200 MPa, is also time consuming, and thus very expensive. An alternative method to obtain almost non porous and larger SiC pieces is reactive infiltration. This procedure consists of infiltrating a carbon porous preform with liquid silicon, so that it reacts with the carbon skeleton during the infiltration, to produce SiC, according to equation 1.

(Eq.1)

This method allows working with less severe reaction conditions. For instance no additional pressure is required since the infiltration is spontaneous, driven by capillary forces and controlled by the reaction. Reaction temperature is around 1500 °C, much lower than for other synthesis routes. An additional benefit of this method is its near net shape capability. This technique also allows to bond SiC powder particles together. For this purpose, a green preform containing the SiC particles bonded with a suitable carbon precursor like phenolic resin or pitch must be manufactured. The green preform must be then carbonized, and infiltrated with liquid silicon to obtain the SiC, also known as reaction bonded silicon carbide (RBSC). In this work this technique has been used to bond not only silicon carbide particles of different sizes together, but also to bind carbon fibers in a ceramic matrix transforming a carbon/carbon composite into a SiC/carbon composite.

SiC formation is expansive (there is an approximately 58% volume increase when a mole of amorphous carbon reacts to form a mole of SiC1), so in order to avoid choking-off of the pores during infiltration, the carbon preform must have a minimum density and pore diameter, being around 38% for amorphous carbon and 58% for graphitic carbon, with pore diameters between 1-2 μm11-13.

In the present work, a great variety of carbon preforms commercially available, were infiltrated to obtain SiC materials. The reaction product quality was assessed with different microscopy techniques, physical and mechanical properties. The reaction parameters, temperature, and dwell time, were studied and optimized for each type of preform.

2 EXPERIMENTAL PROCEDURE

2.1 MATERIALS

In the present study, four type of carbon preforms were used. These preforms were supplied by different companies and present singular geometries and microstructures as it can be observed in figure 1. The preforms used, its main characteristics and the suppliers are listed in table 1.

Figure 1. Different carbon preforms used for SiC composite manufacture.

Table 1. List of carbon preforms used its main characteristics.

High purity Si 99.995% supplied by Sigma Aldrich was used for infiltration tests.

2.2 INFILTRATION TESTS

Infiltrations were carried out in an horizontal tube furnace (Carbolite STF 16/75/450), in an argon atmosphere with a flow rate of 60 cm3/min and a heating rate of 3 °C/min. Different reaction temperatures (1450-1550 °C) and dwell times (1-8 hours) were tested. Sample and silicon were put inside the furnace in an alumina boat-shaped crucible, which was previously coated with a bore nitride layer to prevent the reaction between silicon and the crucible.

2.3 MICROSTRUCTURE

Samples were cut in smaller pieces using a slow speed cutting saw Isomet from Buehler with a diamond wafer 15LC, embedded in phenolic resin and polished with proper materialographic techniques14 summarized in table 2.

Table 2. Polishing procedure followed for microscopy evaluation of samples

Microstructure was assessed with optical microscopy using reflected light in an optical microscope model PM3 from Olympus. Images were taken with a digital camera from Sony, model SSC-DC58AP using different magnifications (5x, 10x, 20x, 50x).

The porosity and pore size distribution of original preforms were characterized with mercury intrusion porosimetry using a Micrometrics Autopore IV 9500 device. Crystalline phases, both in the original preforms and in the SiC composites obtained, were identified with X ray diffraction tests, carried out in an X-Ray diffractometer Brucker model D8 advance equipped with a Cu cathode and Ni filter. Monochromatic Cu Kα radiation (λ=1.5406 Å) was used. The device operated at 40 kV and 40 mA and in the angular scanning, from 10° to 80°, a step of 0.1° and a preset time of 3 s were used. To overcome the non-planarity of the samples a Göbel mirror was used in order to work properly with a parallel optical beam. Skeletal density (ρs) was determined with helium picnometry using a Micrometrics Acupyc 1330TC device. Bulk density was measured using Archimedes’ method using an AG204 delta range analytical balance from Mettler Toledo with a suitable kit.

3. RESULTS AND DISCUSION

3.1 GREEN PREFORM CHARACTERIZATION

The mean pore diameter (Dm), open porosity (P), skeletal (ρs) and bulk (ρb) densities of the carbon preforms are listed in table 2.

It can be observed in table 3, that all preforms, except CF, exhibit a suitable porosity and a mean pore diameter to ensure complete infiltration without pore blocking. Even though CF preforms have a mean pore diameter wide enough to be infiltrated, the cumulative mercury plot (Figure 2) shows a wide distribution of pore sizes. Furthermore pore size distribution (Figure 3) shows that the CF preform contains pores of around 1-3 μm, which may be blocked during early stages of the infiltration. The rest of the preforms present a narrow pore size distribution around the mean value as depicted in figure 3.

Table 3. Characteristics of the carbon preforms

Figure 2. Mercury cumulative intruded volume vs pressure plot obtained with mercury porosimetry for all green preforms.

Figure 3. Pore size distribution for (a) CF, (b) G, (c)F and (d) SiC/C green preforms, obtained with mercury porosimetry. Plots show the logarithm of differential intruded volume vs the pore diameter.

Taking into account that carbon fibers have a diameter of around 7 μm, when packed and oriented in one direction, they leave a star-shaped pore of around 3 μm diameter so the small pores mentioned before correspond to the holes between the fibers. The larger porosity corresponds to holes left between the fiber domains which are randomly oriented. This microstructure can be seen in figure 4, where carbon fibers are spotted as circles or ellipses depending on their orientation. Small star-shaped pores are observed between the fibers, some of them filled with the carbonized binder.

Figure 4. Cross section of a green CF preform obtained with optical microscopy.

3.2 EFFECT OF REACTION TEMPERATURE ON THE DENSITY OF THE COMPOSITES

The infiltration results at different temperatures are listed in table 4. The effectiveness of the infiltration was assessed by measuring the density of the composites. A complete infiltration corresponds to a density near the theoretical, which depends on the composition of the preform. For its calculation, an ideal final composition is assumed, in which all carbon has reacted to form SiC.

Table 4. Infiltration results at different reaction temperatures. Dwell time was 1 hour in all experiments

As seen in table 3, each preform exhibits a different behavior with temperature, and also present different optimal infiltration temperatures. CF preforms did not reach the theoretical density at any of the reaction temperatures. This may be due to the narrowing or blocking of the small pores mentioned before. Graphite preforms almost reached theoretical density at low temperature, and showed a decrease in density when increasing infiltration temperature because unreacted silicon seems to escape open porosity at higher temperatures. Foam preforms reached theoretical density at 1500 °C and show no further improvements with increasing reaction temperature. Finally SiC/C preforms did not reach the theoretical density for any reaction temperature. Since they mean pore diameter is close to the infiltration limit, this may be due to a pore narrowing or blocking during the first stages of the process.

3.3 EFFECT OF DWELL TIME ON THE DENSITY OF THE COMPOSITES

The infiltration results at different dwell times are listed in table 5. The effectiveness of the infiltration was assessed by measuring the density of the composite.

Table 5. Infiltration results at different dwell times. Reaction temperature was 1550 °C in all experiments

As observed in table 4 CF preforms do not reach the expected density after infiltration for any of the dwell times tested. As suggested by results at different temperatures, small pores may be blocked during early stages of infiltration, hindering the process, leaving unreacted carbon and open porosity. Graphite preforms show best results for short dwell times, probably because samples are too permeable and unreacted silicon which fills open porosity, escapes it at long dwell times. Foam preforms, which had reached desired density for 1 hour residence time, show increasing density with longer dwell times. This is due to the filling of larger pores with unreacted silicon. This phenomenon is observed in optical microscopy images, shown in the next section. SiC/C samples did not reach the theoretical maximum density until 8 hour dwell time was applied. This can be explained with a pore diameter reduction due to SiC formation. Infiltration at 1550°C with a dwell time of 8 hours was able to produce a product with a density of 2.98 g/cm3, close enough to the desired density (3.00 g/cm3). Small open porosity (mean pore diameter 1.30 μm) makes infiltration process slow requiring thus high temperatures to reduce viscosity of melted Si, and high dwell times.

Some authors8 have determined that the infiltration rate in SiC formation, if a viscous flow model is considered (equation 2), is influenced by the pore morphology and size. The C + Si reaction affects the infiltration kinetics because it decreases the effective pore radius (reff)16-17, slowing the infiltration rate. If the pore size is too small or if it presents an ink bottle morphology, after reaction the pore may even be closed or become inaccessible.

Other authors8 have recently found that reactive infiltration, as infiltration with silicon of carbon, does not follow a viscous flow kinetic model like equation 2, but presents a linear behavior between infiltration depth and time. The infiltration rate observed by these authors is slower than predicted by a viscous flow model, because the SiC formation is reducing or even closing small porosity. These last model would explain the high dwell times required for SiC-C preforms to fully infiltrate, and the lack of success in infiltrating CF preforms. According to the results obtained by Calderon et. al.17 the relationship between the spreading rate (Us) and the infiltration rate (Ui) of silicon on vitrous carbon is 0.75. The spreading rate of Si on vitreous carbon is 0.77 μm/s. The calculated infiltration rate is then 0.58 μm/s. Taking into account that the average thickness of preforms is 5 mm, the time required for infiltrating the whole preform would be 2.4 hours (a bit higher if tortuosity of the pore system is considered). Results show that SiC-C samples require far greater dwell times (8 hours) to reach the desired density after infiltration and CF preforms do not reach it at all. The SiC layer that forms on vitreous carbon has a thickness of around 1 μm8, so considering that the mean pore size of SiC-C preforms is 1.30 μm, and that CF preforms posses 2-3 μm pores, SiC formation may be decreasing the pore size in a great deal. When reducing pore diameter, viscous forces may gain importance, becoming the limiting factor of infiltration, and reducing infiltration rate.

3.4 MICROSTRUCTURE OF THE COMPOSITES

Figures 6-9 show optical microscopy images of the different composites obtained. Figure shows the microstructure of SiC/Carbon fiber composites, where SiC is observed to be surrounding fiber groups replacing the binder. Unreacted silicon is observed in white, filling open porosity. Remaining open porosity is depicted in black, and unreacted carbon can be observed between some fibers.

Figure 6. Optical microscopy images of the composites obtained from CF preforms at 1550 °C and 8 hours dwell time.

Figure 7. Optical microscopy images of the composites obtained from G preforms at 1450 °C and 1 hours dwell time.

Figure 8. Optical microscopy images of the composites obtained from CF preforms at 1500 °C and 3 hours dwell time.

Figure 9. Optical microscopy images of the composites obtained from SiC/C preforms at 1550°C amd 8 hours dwell time.

In figure 7 the microstructure of SiC/Si composites obtained from G preforms can be observed. A high conversion C/SiC conversion rate and a great content in unreacted silicon is observed. Since the initial porosity of the carbon preform is much higher than the optimal value determined elsewhere13 this amount of silicon is expected. However, some unreacted silicon seems to escape the preform leaving a considerable amount of open pores behind.

The microstructure of SiC foams is depicted in figure 8. The foam branches present a homogeneous bimodal mixture of SiC crystals embed in a finer SiC matrix. Besides from the desired millimetric open porosity of the foam, the branches show negligible remaining open porosity after infiltration.

Figure 9 shows the microstructure of the SiC obtained by infiltrating the SiC/C preforms. This material is composed of a bimodal mixture of α-SiC crystals in a fine SiC matrix and presents negligible open porosity. The presence of unreacted Si is detected in XRD, but is not appreciated in optical microscopy, leading to think that the amount of free silicon is very low.

4. CONCLUSIONS

Different SiC composite materials were manufactured with a great variety of microstructures. For each type of carbon preform used, different optimal reaction conditions (temperature and dwell time) were found. In some preforms, mainly in CF preforms, problems during infiltration were found, caused by pore blocking during the reaction.

5. ACKNOWLEDGEMENTS

Authors would like to gratefully acknowledge the financial support received from the Generalitat Valenciana (PROMETEO/2009/002-FEDER) and the the European Union’s Seventh Framework Programme (FP7/2007-2013) under the HELM project, grant agreement no. 280464.

REFERENCES

1. Voytovych R., Bougiouri V., Calderon, N.R., Narciso J., Eustathopoulos N.; Acta Materialia, 2008, 56: 2237-2246

2. Calderon N.R., Martinez-Escandell M., Narciso J., Rodriguez-Reinoso, F.; Journal of the European Ceramic Society, 2009, 29: 465-472

3. W.F. Knippenber; Philips Research Reports, 18, (1963), 161.

4. Calderon N.R.; Martinez-Escandell M.; Narciso, J., Rodriguez-Reinoso, F.; Journal of the American Ceramic Society, 2010, 93: 1003-1009

5. Srinivasan M., Wachtman J.B.; Boston; London : Academic Press, 1989, 159.

6. Acheson E.G.; US Patent 492767, 1893

7. Matsunami H.; Kimoto T., Materials Science and Engineering, 1997, R20, 125

8. Prieto, R.; Molina, J. M.; Narciso, J.; Louis E.; Composites part A-Applied Science and Manufacturing, 2011, 42: 1970-1977

9. Molina J.M., Saravanan R.A., Arpon, R., Garcia-Cordovilla C., Louis E., Narciso J.; Acta Materialia, 2002, 50: 247-257

10. Arpon R., Molina J.M., Saravanan R.A., Garcia-Cordovilla C., Louis E., Narciso J; Acta Materialia, 2003, 51: 3145-3156

11. Wang, Y., Tan, S., Jiang, D.; Carbon, 2004; 42:1833-1839

12. Singh, M. and Behrendt, D.R.; Materials Science and Engineering A, 1995, 194: 193-200

13. Calderon, N.R., Martinez-Escandell, M., Narciso, J., Rodriíguez-Reinoso, F., Carbon, 2009, 47:2200-2210

14. Elssner, G.; Hoven, H.; Kiessler, G.; Wellner, P.; Ceramics and Ceramics composites: Materialographic preparation (1999), Elsevier, Amsterdam

15. Bougiouri, V., Voytovych, R., Rojo-Calderon N., Narciso, J., Eustathopoulos N.; Scripta Materialia 2006; 54:1875-1878

16. Einset, E.O.; Journal of American Ceramic Society 1994; 79:333

17. Sangsuwan, P., Tewari, N.S., Gatica, J.E., Singh, M., Dickerson R.; Metallurgical and Materials Transaction 1999, 30: 933

FABRICATION AND CHARACTERIZATION OF CONDUCTIVE GLASS COMPOSITES WITH NETWORKS OF SILICON CARBIDE WHISKERS

Timothy L. Pruyn1 and Rosario A. Gerhardt1

1Georgia Institute of Technology771 Ferst DriveAtlanta, GA 30332, U.S.A.

ABSTRACT

In this study, borosilicate glass composites were fabricated using glass microspheres and silicon carbide whiskers (SiCw). These composites have a great deal of potential application in microwave heating and EMI shielding. The microsphere/SiCw composites were fabricated by hot pressing at relatively low temperatures and pressures in order to control the viscous flow of the glass so that it would segregate the SiCw to specific areas in the composite. This resulted in the formation of percolating SiCw, networks at volume fractions around 5-7.5% and a change in about 5-6 orders of magnitude in resistivity, which is typical for these types of composites. Since the SiCw have a large aspect ratio, the electrical properties were measured in both the parallel and perpendicular direction. Due to the processing method that was intended to form segregated networks, the difference in the resistivity along the two directions was not that large and the small disparities that exist at certain concentrations is likely due to a slight flattening of some of the glass particles due to the hot pressing.

INTRODUCTION

Composites containing silicon carbide whiskers (SiCw) have unique frequency dielectric properties that make them very useful as electromagnetic absorbers such as grills and grates in microwave heating and cooking.1,2 Typically these composites, often made with matrix materials such as alumina and mullite, have resulted in the electrical and dielectric properties depending on the preferred orientation of the whiskers and the direction of the electrical measurements.3–5 The concentrations needed to create a percolated network of physically touching whiskers are high for these ceramic composites (>10% SiCw) and also require high temperatures to process (>1600°C).3-5

Previous work in our group demonstrated that segregated networks of antimony tin oxide (ATO) nanoparticles inside glass could be made.6,7 The ATO segregated to the boundaries between the glass particles and resulted in percolation at low concentrations of the ATO, while still having a drop in the resistivity of about 11-12 orders of magnitude.6,7 The main concept behind the processing is to control the particle size distribution and the viscosity of the glass. SiCw has not previously been attempted as the filler with this type of processing method using glass as the matrix. Neither has a microstructure that has the SiCw, forming a physically touching percolated segregated network located along the glass boundaries ever been made before.

There are several considerations in applying this method to creating a composite that has percolated networks of SiCw. The first is controlling the viscosity of the glass during the formation of these networks, which is crucial since the viscosity has to be low enough that it will consolidate the composite. The viscosity also has to be high enough that it would prevent the SiCw from penetrating the glass and instead remains on the surface of the glass particle as it is consolidated. The intention of this is to arrange the SiCw during processing so the whiskers will be confined to a specific region of the glass. The whiskers themselves will not sinter with one another so the contact that these whiskers make with one another is very important, which is one of the reasons for segregating these whiskers instead of having them be isolated in a region of glass. This should help with the formation of the percolated SiCw network, but also the arrangement of the whiskers due to this processing should reduce the asymmetry of the electrical and dielectric properties due to preferred orientation of the whiskers that often result in ceramic composites that have been hot pressed.1-5,8,9. Also with the alumina composites the processing temperature needed to create a dense composite with these whiskers is often in the range of 1500-1750 °C at the peak sintering temperature.5 With these glass composites both the time and temperature needed to consolidate these composites is substantially less. Not only would this type of composite be useful in microwave heating application, but the electromagnetic absorbing properties of the SiCw would also be useful in a variety of electromagnetic shielding applications. In this study, the electrical properties will be examined since it can give a good indication of the type of microstructure that is forming in these composites, especially when they form continuous/percolated networks.

EXPERIMENT

In this study, the glass matrix was Pyrex® borosilicate glass microspheres (GL-0179) obtained from Mo-Sci Spec. Products L.L.C. (Rolla, MO). The microspheres had a narrow particle size distribution in the 30-50 μm range. Examination with optical microscopy, shown in Figure 1 (a-b) showed that they were mostly spherical with some microspheres having some defects in them such as bubbles. SiCw (SC-9M) from Advanced Composite Materials L.L.C. (Greer, SC) was used as the filler material. The whiskers are single crystal rods of the cubic SiC β-polytype. Each rod has a large aspect ratio since it is about 0.5 μm in diameter and about 10-15 μm long. This size was fairly uniform as can be seen in Figure 1(c-d).

Figure 1. (a) Optical micrograph of borosilicate glass microspheres. (b) Higher magnification image of (a) showing the uniform shape and size of these microspheres. (c) SEM micrograph of SiCw (d) Higher magnification image of (c) showing the diameter of the whiskers.

Mixtures of the two powders were prepared using a ball mill with 5 mm alumina media (99.5%) for four hours, which dispersed the SiCw among the glass microspheres. Compositions were prepared based on parts per hundred, glass (phr) of SiCw and are listed in Table I. The vol% and theoretical density were calculated using mixing rules.

Table I. Composition of the Glass/SiCw, Composites and the Resulting Relative Density.

SIC

w

Concentration

Relative Density (%)

Phr

Vol %

1.00 × 10

−3

1.10 × 10

−3

99.78 ± 0.02

1.00 × 10

−1

1.10 × 10

−1

99.85 ± 0.09

2.50 × 10

−1

2.73 × 10

−1

99.37 ± 0.04

2.50 × 10

0

2.63 × 10

0

98.43 ± 0.49

5.00 × 10

0

5.20 × 10

0

97.88 ± 1.59

7.50 × 10

0

7.60 × 10

0

95.43 ± 0.29

1.00 × 10

1

9.88 × 10

0

94.10 ± 0.39

1.25 × 10

1

1.21 × 10

1

93.81 ± 1.16

The composites were fabricated using a hot press (Astro Press) at Advanced Composite Materials (ACM) L.L.C. The powder mixtures were placed in a graphite die lined with graphite foil. The die had an inner diameter of 28 mm. At least 3 samples were made for each composition. The heating schedule used involved heating the glass from room temperature to 550°C at a rate of 17.5°C/min under a flowing nitrogen atmosphere. The temperature was held for 10 minutes before being ramped up to 675°C at a rate of 12.5°C/min. The peak temperature of 675°C was held for 10 minutes before the shell was cooled down to 300°C at a rate of about 20°C/min. After this, the die was allowed to further cool by raising the shell of the hot press. During this heating schedule a uniaxial pressure was applied at a rate of 0.36 MPa/min until a pressure of 12.5 MPa was reached. Once this point was reached this pressure was held until the end of the heating schedule, 300°C, was reached. The first hold at 550 °C is at the glass transition range and the second hold at 675°C is halfway between the glass transition range and the softening point of this glass.10 The densities of the specimens were determined via the Archimedes method.

The microstructure was imaged with a FEI Quanta 200 SEM as well as an XSB 411 optical microscope. Samples selected for imaging were sectioned into half and quarter wedges and polished with silicon carbide grit and alumina media. Samples both parallel and perpendicular to the hot pressing direction were examined. Since these types of composites often have conducting boundaries with large regions of glass, the composite samples were coated with a thin layer of silver palladium to prevent charging during SEM imaging.

Electrical Characterization
