Beschreibung

With the current explosion in network traffic, and mounting pressure on operators' business case, Self-Organizing Networks (SON) play a crucial role. They are conceived to minimize human intervention in engineering processes and at the same time improve system performance to maximize Return-on-Investment (ROI) and secure customer loyalty. Written by leading experts in the planning and optimization of Multi-Technology and Multi-Vendor wireless networks, this book describes the architecture of Multi-Technology SON for GSM, UMTS and LTE, along with the enabling technologies for SON planning, optimization and healing. This is presented mainly from a technology point of view, but also covers some critical business aspects, such as the ROI of the proposed SON functionalities and Use Cases. Key features: * Follows a truly Multi-Technology approach: covering not only LTE, but also GSM and UMTS, including architectural considerations of deploying SON in today's GSM and UMTS networks * Features detailed discussions about the relevant trade-offs in each Use Case * Includes field results of today's GSM and UMTS SON implementations in live networks * Addresses the calculation of ROI for Multi-Technology SON, contributing to a more complete and strategic view of the SON paradigm This book will appeal to network planners, optimization engineers, technical/strategy managers with operators and R&D/system engineers at infrastructure and software vendors. It will also be a useful resource for postgraduate students and researchers in automated wireless network planning and optimization.

Leseprobe

Contents

Foreword

Preface

Acknowledgements

List of Contributors

List of Abbreviations

1 Operating Mobile Broadband Networks

1.1. The Challenge of Mobile Traffic Growth

1.2. Capacity and Coverage Crunch

1.3. Meeting the Challenge – the Network Operator Toolkit

1.4. Self-Organizing Networks (SON)

1.5. Summary and Book Contents

1.6. References

2 The Self-Organizing Networks (SON) Paradigm

2.1. Motivation and Targets from NGMN*

2.2. SON Use Cases*

2.3. SON versus Radio Resource Management

2.4. SON in 3GPP

2.5. SON in the Research Community

2.6. References

3 Multi-Technology SON

3.1. Drivers for Multi-Technology SON

3.2. Architectures for Multi-Technology SON

3.3. References

4 Multi-Technology Self-Planning

4.1. Self-Planning Requirements for 2G, 3G and LTE

4.2. Cross-Technology Constraints for Self-Planning

4.3. Self-Planning as an Integrated Process

4.4. Planning versus Optimization

4.5. Information Sources for Self-Planning

4.6. Automated Capacity Planning

4.7. Automated Transmission Planning

4.8. Automated Site Selection and RF Planning

4.9. Automated Neighbor Planning

4.10. Automated Spectrum Planning for GSM/GPRS/EDGE

4.11. Automated Planning of 3G Scrambling Codes

4.12. Automated Planning of LTE Physical Cell Identifiers

4.13. References

5 Multi-Technology Self-Optimization

5.1. Self-Optimization Requirements for 2G, 3G and LTE

5.2. Cross-Technology Constraints for Self-Optimization

5.3. Optimization Technologies

5.4. Sources for Automated Optimization of Cellular Networks

5.5. Self-Planning versus Open-Loop Self-Optimization

5.6. Architectures for Automated and Autonomous Optimization

5.7. Open-Loop, Automated Self-Optimization of Cellular Networks

5.8. Closed-Loop, Autonomous Self-Optimization of 2G Networks

5.9. Closed-Loop, Autonomous Self-Optimization of 3G Networks

5.10. Closed-Loop, Autonomous Self-Optimization of LTE Networks

5.11. Autonomous Load Balancing for Multi-Technology Networks

5.12. Multi-Technology Energy Saving for Green IT

5.13. Coexistence with Network Management Systems

5.14. Multi-Vendor Self-Optimization

5.15. References

6 Multi-Technology Self-Healing

6.1. Self-Healing Requirements for 2G, 3G and LTE

6.2. The Self-Healing Process

6.3. Inputs for Self-Healing

6.4. Self-Healing for Multi-Layer 2G Networks

6.5. Self-Healing for Multi-Layer 3G Networks

6.6. Self-Healing for Multi-Layer LTE Networks

6.7. Multi-Vendor Self-Healing

6.8. References

7 Return on Investment (ROI) for Multi-Technology SON

7.1. Overview of SON Benefits

7.2. General Model for ROI Calculation

7.3. Case Study: ROI for Self-Planning

7.4. Case Study: ROI for Self-Optimization

7.5. Case Study: ROI for Self-Healing

7.6. References

Appendix A Geo-Location Technology for UMTS

A.1. Introduction

A.2. Observed Time Differences (OTDs)

A.3. Algorithm Description

A.4. Scenario and Working Assumptions

A.5. Results

A.6. Concluding Remarks

A.7. References

Appendix B X-Map Estimation for LTE*

B.1. Introduction

B.2. X-Map Estimation Approach

B.3. Simulation Results

B.4. References

Index

This edition first published 2012© 2012 John Wiley & Sons, Ltd

Registered OfficeJohn Wiley & Sons Ltd, The Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, United Kingdom

For details of our global editorial offices, for customer services and for information about how to apply for permission to reuse the copyright material in this book please see our website at www.wiley.com.

The right of the author to be identified as the author of this work has been asserted in accordance with the Copyright, Designs and Patents Act 1988.

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, except as permitted by the UK Copyright, Designs and Patents Act 1988, without the prior permission of the publisher.

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic books.

Designations used by companies to distinguish their products are often claimed as trademarks. All brand names and product names used in this book are trade names, service marks, trademarks or registered trademarks of their respective owners. The publisher is not associated with any product or vendor mentioned in this book. This publication is designed to provide accurate and authoritative information in regard to the subject matter covered. It is sold on the understanding that the publisher is not engaged in rendering professional services. If professional advice or other expert assistance is required, the services of a competent professional should be sought.

Library of Congress Cataloging-in-Publication Data

Self-organizing networks : self-planning, self-optimization and self-healing for GSM, UMTS and LTE / editors, Juan Ramiro, Khalid Hamied.p. cm.Includes index.Summary: “The book offers a multi-technology approach as it will consider the implications of the different SON requirements for 2G and 3G networks, as well as 4G wireless technologies”– Provided by publisher.

ISBN 978-0-470-97352-3 (hardback)1. Wireless communication systems–Automatic control. 2. Self-organizing systems. I. Ramiro, Juan.II. Hamied, Khalid.TK5103.2.S46 2011003′.7–dc23

2011025918

A catalogue record for this book is available from the British Library.

Print ISBN: 9780470973523 (H/B)ePDF ISBN: 9781119954217oBook ISBN: 9781119954224ePub ISBN: 9781119960928mobi ISBN: 9781119960935

Foreword

Consumer uptake of mobile broadband represents the fastest adoption of any technology that our society has ever experienced. Faster than the Internet and earlier generations of mobile communications, the widespread use and acceptance of smartphone technology has been phenomenal. Tablets, Android devices, iPhones, application stores, social media and the data exchanges between end-users and clouds are all growing at near breakneck speed, and operators (our customers) are challenged to keep pace. Together as an industry, we are charged with providing the necessary bandwidth and capacity that people everywhere are coming to expect and anticipate.

The 4G LTE networks provide an incredible customer experience. I live in Stockholm, Sweden, and have had access to the LTE/4G network since TeliaSonera first launched it. It was the first commercial launch of an LTE network anywhere, and I was privileged to be a part of it. As a 4G subscriber, I have come to depend on the best possible connections wherever I find myself in the world. The same is true for subscribers of 3G/2G networks. Best possible connectivity plays an important role in my experience as a customer, and, like most customers, I expect it to work seamlessly.

Another important consideration of the 2G/3G evolution to LTE is the affordable operation of these overlaid multi-standard networks, during a time when operators are required to reduce operational expenditures. Most operators need to keep their OPEX at a constant level or even squeeze out additional operational efficiencies while they are enhancing their service capabilities and data capacity. Many opportunities including machine to machine (m2m) services are extremely price sensitive and cannot take off in full force until certain price thresholds are attained. The forecasted demand is clear, and therefore we must plan accordingly.

Densification of the network, smaller cells and more heterogeneous networks (HetNets) are coming rapidly. We anticipate that this ongoing change will bring more multi-standard demands and multi-vendor challenges. Efficient and effective operations must overcome such complexity, which is growing not linearly, but by factors. The only way these challenges can be cost-effectively, efficiently and humanely overcome is through the use of more automated and autonomous systems – such as Self-Organizing Networks (SON), and that is what this book is all about.

The opportunities we have are tremendous. We are enabling innovation while empowering people, businesses and society. This book is part of the story, and provides a good place to begin this ongoing discussion. There is certainly a lot more to come. You can count on it.

Ulf EwaldssonVice President, Head of Ericsson RadioStockholm, Sweden

Preface

This book provides an in-depth description of multi-technology Self-Organizing Networks (SON) for 2G, 3G and Long Term Evolution (LTE), and presents critical business aspects of the proposed SON functionalities. Multi-technology SON allows operators to completely transform and streamline their operations, and extends the automation-related operational savings to all radio access technologies. The availability of a multi-technology SON solution results in more comprehensive, holistic and powerful optimization strategies that deal with several radio access technologies simultaneously.

The book is primarily aimed at engineers who manage or optimize mobile networks, though major network operators, business leaders and professionals of academia will also derive value from the included chapters. With the deployment of LTE, most operators will have three simultaneous radio access technologies to manage, which will add extra pressure to their already tight cost structures. Deploying and operating cellular networks is a complex task that comprises many activities, such as planning, dimensioning, installation, testing, prelaunch optimization, postlaunch optimization, comprehensive performance monitoring, failure mitigation, failure correction and general maintenance. Today, such critical activities are extremely labor-intensive and, hence, costly and prone to errors, which may result in customer dissatisfaction and increased churn.

In order to alleviate this situation, clear requirements have been stated by the Next Generation Mobile Networks (NGMN) Alliance to enable a set of functionalities for automated Self-Organization of LTE networks, so that human intervention is minimized in the planning, deployment, optimization and maintenance activities of these new networks. Subsequently, the support for this new network management paradigm is being translated into concrete functionalities, interfaces and procedures during the standardization of E-UTRAN in the Third Generation Partnership Project (3GPP).

The objective of this book is to discuss the state-of-the-art engineering and automation practices realizing the SON paradigm for multi-technology and multi-vendor wireless infrastructure. Each chapter has been carefully organized to give the reader a comprehensive, layered understanding of SON development and deployment with a glimpse into the industry’s natural trending to automated engineering functions that optimize cellular network performance and maximize efficiency.

The layout of the book is structured as follows. Chapter 1 discusses the challenges associated with the explosive growth in mobile broadband and analyzes potential solutions. This chapter also introduces the unique solution that SON techniques provide in contemporary 2G/3G networks. Chapter 2 provides a high-level overview of SON by covering NGMN objectives and 3GPP activities. Advanced readers desiring a more comprehensive view of the 3GPP activities are encouraged to go directly to the 3GPP references provided within the chapter for the updated status of SON support in the standards. Chapter 3 mainly describes an architecture for multi-technology SON and provides a conceptual framework to coordinate SON functions.

Chapters 4, 5 and 6 cover the multi-vendor and multi-technology aspects of the Self-Planning, Self-Optimization and Self-Healing of wireless networks, respectively, covering processes, algorithms and enabling technologies for these activities. Engineers who manage or optimize mobile networks (operators’ engineers and consultants) may be very interested in the material contained in these chapters.

Chapter 7 provides a model for Return-on-Investment (ROI) of the proposed SON functionalities and Use Cases. The included model can be applied to build business cases and provide ROI analyses for optimization projects. Chapter 7 would be of interest to managers, executives and sales professionals at operators and vendors.

Appendix A discusses geo-location technology for UMTS and describes the use and application of observed time differences (OTDs) for geo-location. Finally, Appendix B provides an overview of the X-map estimation for LTE and detailed simulation results of two different approaches for a given scenario.

Acknowledgements

First of all, the editors would like to thank all those who contributed to this book: Mehdi Amirijoo, Mark Austin, Rubén Cruz, Juan Carlos del Río, Patricia Delgado Quijada, Andreas Eisenblätter, Nizar Faour, Rafael Ángel García, Juanjo Guerrero, Gustavo Hylander, Thomas Kürner, Frank Lehser, Remco Litjens, Andreas Lobinger, Raúl Moya, Javier Muñoz, Christos Neophytou, Michaela Neuland, José Outes, Salvador Pedraza, Gabriel Ramos, Miguel A. Regueira Caumel, Philippe Renaut, Javier Romero, Lars Christoph Schmelz, Octavian Stan, Szymon Stefański, Ken Stewart, John Turk, Carlos Úbeda and Josko Zec. Moreover, we would like to express our gratitude to Neil Scully for facilitating all contributions from the SOCRATES project.

We also thank our colleagues at Ericsson for their continued support and encouragement and for providing suggestions and comments on the content. Special thanks to Josko Zec, Alejandro Gil, Miguel A. Regueira Caumel, Paul Cowling and Kai Heikkinen.

Additionally, the great assistance provided by Miguel A. Regueira Caumel, Marina Cañete and Jennifer Johnson during the editing process is greatly appreciated. During these months, the guidance and support provided by the great team at John Wiley & Sons, Ltd. has made a difference. Special thanks to Mark Hammond, Sophia Travis, Mariam Cheok, Lynette James and Suvesh Subramanian for all the help they provided.

Finally, we are immensely grateful to our families for their patience and support during the weekend and holiday editing work.

Juan Ramiro and Khalid Hamied

List of Contributors

Mehdi Amirijoo Ericsson, Linköping, SwedenMark David AustinAT&T, Atlanta, GA, USARubén CruzEricsson, Málaga, SpainJuan Carlos del Río RomeroEricsson, Madrid, SpainPatricia Delgado QuijadaEricsson, Málaga, SpainAndreas Eisenblätteratesio, Berlin, GermanyNizar FaourEricsson, Atlanta, GA, USARafael Ángel García GaraluzEricsson, Málaga, SpainJuan José Guerrero GarcíaEricsson, Málaga, SpainKhalid HamiedEricsson, Atlanta, GA, USAGustavo Hylander AguileraEricsson, Stockholm, SwedenThomas KürnerTU Braunschweig, Braunschweig, GermanyFrank LehserDeutsche Telekom AG, Bonn, GermanyRemco LitjensTNO, Delft, The NetherlandsAndreas LobingerNokia Siemens Networks, Munich, GermanyManuel Raúl Moya de la RubiaEricsson, Málaga, SpainJavier MuñozEricsson, Málaga, SpainChristos NeophytouEricsson, Atlanta, GA, USAMichaela NeulandTU Braunschweig, Braunschweig,GermanyJosé Outes CarneroEricsson, Málaga, SpainSalvador PedrazaEricsson, Málaga, SpainJuan Ramiro MorenoEricsson, Málaga, SpainGabriel Ramos EscañoEricsson, Málaga, SpainMiguel Angel Regueira CaumelEricsson, Málaga, SpainPhilippe RenautEricsson, Málaga, SpainJavier RomeroEricsson, Málaga, SpainLars Christoph SchmelzNokia Siemens Networks, Munich, GermanyOctavian StanEricsson, Atlanta, GA, USASzymon StefańskiNokia Siemens Networks, Wrocław, PolandKenneth StewartMotorola, Libertyville, IL, USAJohn TurkVodafone, Newbury, United KingdomCarlos Úbeda CastellanosEricsson, Madrid, SpainJosko ZecEricsson, Atlanta, GA, USA

List of Abbreviations

2G2nd Generation3G3rd Generation3GPPThird Generation Partnership Project3GPP2Third Generation Partnership Project 24G4th GenerationA/CAir ConditioningAACAdvance Audio CodingAAC-ELDAAC Enhanced Low DelayAAC-LDAAC Low DelayACAdmission ControlACRAdjacent Channel RejectionAFPAutomatic Frequency PlanningaGWaccess GatewayAINIATM Inter-Network InterfaceAMRAdaptive Multi-RateAMR-NBAMR NarrowbandAMR-WBAMR WidebandANRAutomatic Neighbor RelationAPAccess PointAPIApplication Programming InterfaceARFCNAbsolute Radio Frequency Channel NumberARPAddress Resolution ProtocolARPUAverage Revenue Per UserASActive SetATCAncillary Terrestrial ComponentATMAsynchronous Transfer ModeAVCAdvance Video CodingAWSAdvanced Wireless ServicesBALBCCH Allocation ListBCCBase Station Color CodeBCCHBroadcast Control ChannelBCHBroadcast ChannelBERBit Error RateBLERBlock Error RateBSCBase Station ControllerBSICBase Station Identity CodeBTSBase Transceiver StationBWABroadband Wireless AccessC/ICarrier-to-InterferenceCAGRCompounded Annual Growth RateCAPEXCapital ExpenditureCBSCarrier Branded ServicesCCOCapacity and Coverage OptimizationCDFCumulative Distribution FunctionCDMACode Division Multiple AccessCDRCharging Data RecordCEChannel ElementCFCash FlowCGICell Global IdentifierCLPCFast Close-Loop Power ControlCMConfiguration ManagementCNCore NetworkCOCCell Outage CompensationCODCell Outage DetectionCOMCell Outage ManagementCPCContinuous Packet ConnectivityCPICHCommon Pilot ChannelCPUCentral Processing UnitCQIChannel Quality IndicatorCRCCyclic Redundancy CheckCSCircuit SwitchedCSFRCall Setup Failure RateCSGClosed Subscriber GroupCTCall TracesCTCore network and TerminalsCWContinuous WaveDCRDropped Call RateDHCPDynamic Host Configuration ProtocolDLDownlinkDMDomain ManagerDNSDomain Name SystemDO-BEV-DO Revision BDO-CEV-DO Revision CDRXDiscontinuous ReceptionDSPDigital Signal ProcessingDSSDirect Sequence Spread SpectrumEBITDAEarnings Before Interest, Taxes, Depreciation and AmortizationECGIEvolved Cell Global IdentifierE-DCHEnhanced Dedicated ChannelEDGEEnhanced Data rates for GSM EvolutionEFLEffective Frequency LoadEGPRSEnhanced General Packet Radio ServiceEIGRPEnhanced Interior Gateway Routing ProtocolEMElement ManagereNodeBenhanced NodeBESEnergy SavingE-SMLCEvolved Serving Mobile Location CentreE-UTRAEvolved Universal Terrestrial Radio AccessE-UTRANEvolved Universal Terrestrial Radio Access NetworkEV-DOEvolution Data OptimizedEVRCEnhanced Variable Rate CodecEVSEnhance Voice ServiceFACHForward Access ChannelFCCFederal Communications CommissionFDDFrequency Division DuplexFERFrame Erasure RateFFRFull Frequency ReuseFLVFlash VideoFMFault ManagementFPCFractional Power ControlGBGigabyteGERANGSM EDGE Radio Access NetworkGGSNGateway GPRS Serving NodeGNSSGlobal Navigation Satellite SystemGoSGrade of ServiceGPRSGeneral Packet Radio ServiceGPSGlobal Positioning SystemGSMGlobal System for Mobile CommunicationsGUIGraphical User InterfaceHCLHierarchical Cell LayoutHDMIHigh-Definition Multimedia InterfaceHFRHard Frequency ReuseHIHealth IndicatorHIIHigh Interference IndicatorHLSHTTP Live SteamingHOHandOverHRHalf RateHRPDHigh Rate Packet DataHSDPAHigh Speed Downlink Packet AccessHSDPA+High Speed Downlink Packet Access EvolutionHSNHopping Sequence NumberHSPAHigh Speed Packet AccessHSPA+High Speed Packet Access EvolutionHS-PDSCHHigh Speed Physical Downlink Shared ChannelHS-SCCHHigh Speed Shared Control ChannelHSUPAHigh Speed Uplink Packet AccessHTTPHyper Text Transfer ProtocolHEVCHigh Efficiency Video CodecHWHardwareIAFIntra-frequency neighbor-relatedICInterference ControlICICInter-Cell Interference CoordinationIDIdentityIECInternational Electrotechnical ComissionIEEEInstitute of Electrical and Electronics EngineersIEFInter-frequency neighbor-relatedIGRPInterior Gateway Routing ProtocolIMInterference MatrixIMT-AdvancedInternational Mobile Telecommunications - AdvancedIoTInterfrence-over-ThermalIPInternet ProtocoliRATinter-Radio Access TechnologyISGInter-system (to GSM) neighbor-relatedISLInter-system (to LTE) neighbor-relatedISMIndustrial, Scientific and MedicalISOInternational Organization for standarizationITInformation TechnologyItf-NNorthbound InterfaceITUInternational Telecommunications UnionITU-TITU-StandarizationJCT-VCJoint Collaborative Team on Video CodingKPIKey Performance IndicatorLACLocation Area CodeLBOLoad Balance OptimizationLIPALocal IP AccessLLCLink Layer ControlLMULocation and Measurement UnitLOSLine-of-SightLTELong Term EvolutionMAHOMobile Assisted HandOverMAIOMobile Allocation Index OffsetMALMobile Allocation ListMCMonte CarloMCSModulation and Coding SchemeMDTMinimization of Drive TestsMGWMedia GatewayMIBManagement Information BaseMIMOMultiple Input Multiple OutputMLBMobility Load Balancingmmman monthMMEMobility Management EntityMMLMan-Machine LanguageMMRMobile Measurement RecordingsMMSMulti-media Messaging ServiceMOManaged ObjectMP3MPEG-1 Layer-3MP4MPEG-4 Part 14MPEG-4Motion Picture Expert Group Layer-4 VideoMRMeasurement ReportMROMobility Robustness OptimizationMSCMobile Switching CentreMSSMobile Satellite ServiceMS-SPRingMultiplex Section-Shared Protection RingNBPNational Broadband PlanNENetwork ElementNEMNetwork Element ManagerNGMNNext Generation Mobile NetworksNIINational Information InfrastructureNLOSNon-Line-of-SightNMNetwork ManagerNMSNetwork Management SystemNP-hardNon-deterministic Polynomial-time hardNPVNet Present ValueNRNeighbor RelationNRTNeighbor Relation TableO&MOperation And MaintenanceOFDMOrthogonal Frequency Division MultiplexingOFDMAOrthogonal Frequency Division Multiple AccessOIOverload IndicatorOIPFOpen IPTV ForumOLPCOuter-Loop Power ControlOPEXOperational ExpenditureOSOperations SystemOSPFOpen Shortest Path FirstOSSOperations Support SystemOTDObserved Time DifferenceOTDOAObserved Time Difference Of ArrivalPCCPCHPrimary Common Control Physical ChannelPCGProject Coordination GroupPCHPaging ChannelPCIPhysical Cell IdentifierPCMPulse Code ModulationPCUPacket Control UnitPDPropagation DelayPDFProbability Density FunctionPDHPlesiochronous Digital HierarchyPDPPacket Data ProtocolPLMNPublic Land Mobile NetworkPMPerformance ManagementPNNIPrivate Network-to-Network InterafacePRACHPhysical Random Access ChannelPRBPhysical Resource BlockPSPacket SwitchedPSCPrimary Scrambling CodeQAMQuadrature Amplitude ModulationQoSQuality of ServiceR6Release 6R99Release 99RABRadio Access BearerRACRouting Area CodeRACHRandom Access ChannelRANRadio Access NetworkRASRemote Azimuth SteeringRATRadio Access TechnologyRBResource BlockRETRemote Electrical TiltRFRadio FrequencyRLCRadio Link ControlRLFRadio Link FailureRLSRecursive Least SquaresRMURAN Measurement UnitRNCRadio Network ControllerRNTPRelative Narrowband Transmit PowerROIReturn On InvestmentRRCRadio Resource ControlRRMRadio Resource ManagementRSReference SignalRSCPReceived Signal Code PowerRSLReceived Signal LevelRSRPReference Signal Received PowerRSRQReference Signal Received QualityRSSIReceived Signal Strength IndicatorRTMPReal Time Messaging ProtocolRTPReal-time Transport ProtocolRTSPReal Time Streaming ProtocolRxLevReceived signal LevelRxQualReceived signal QualitySAService and system AspectsSASimulated AnnealingSACCHSlow Associated Control ChannelSAESystem Architecture EvolutionSCScrambling CodeSC-FDMASingle Carrier Frequency Division Multiple AccessSNCPSubnetwork Connection ProtectionSDCCHStandalone Dedicated Control ChannelSDHSynchronous Digital HierarchySeNBSource eNodeBSFRSoft Frequency ReuseSGSNService GPRS Serving NodeS-GWServing GatewaySHOSoft HandOverSIBSystem Information BlockSINRSignal to Interference-plus-Noise RatioSIRSignal-to-Interference-RatioSMSShort Message ServiceSMSCSMS CenterSNRSignal to Noise RatioSONSelf-Organizing NetworksSONETSynchronous Optical NetworkSS7Signalling System #7SSCSecondary Synchronization CodesS-SCHSecondary Synchronization ChannelSTPSignaling Transfer PointSWSoftwareTATiming AdvanceTACTracking Area CodeTCHTraffic ChannelTCITarget Cell IdentifierTDDTime Division DuplexTDMATime Division Multiple AccessTeNBTarget eNodeBTMTeleManagementTNLTransport Network LayerTRXTransceiverTSTroubleShootingTSGTechnical Specification GroupTTITransmission Time IntervalTVWSTelevision White SpaceUARFCNUTRA Absolute Radio Frequency Channel NumberUDPUser Datagram ProtocolUEUser EquipmentUICCUniversal Integrated Circuit CardULUplinkUMTSUniversal Mobile Telecommunications SystemUTRAUniversal Terrestrial Radio AccessUTRANUniversal Terrestrial Radio Access NetworkVBRVariable Bit RateVCEGVideo Coding Experts GroupVIPVery Important PersonVLANVirtual Local Area NetworkVoIPVoice over IPWANWide Area NetworkWCDMAWideband Code Division Multiple AccessWCSWireless Communications ServiceWEPWired Equivalent PrivacyWGWorking GroupWIWork ItemWiFiWireless FidelityWiMAXWorldwide Interoperability for Microwave AccessWISPrWireless Internet Service Provider roamingWLANWireless Local Area NetworkWMAWindows Media AudioWPAWi-Fi Protected AccessWPA2Wi-Fi Protected Access 2WVGAWide Video Graphics ArrayXMLExtensible Markup Language

1

Operating Mobile Broadband Networks

Ken Stewart, Juan Ramiro and Khalid Hamied

1.1. The Challenge of Mobile Traffic Growth

The optimization of cellular network performance and the maximization of its efficiency has long been an objective of wireless network providers. Since the introduction of GSM in the late 1980s, the growth of traffic (and revenue per user) over wireless networks as the first 2G and 3G networks were deployed remained positive and relatively predictable. For those networks, voice and messaging services such as Short Message Service (SMS) and Multi-media Messaging Service (MMS) were dominating traffic. However, in the first decade of the twenty-first century, the deployment of high-performance wide-area wireless packet data networks, such as 3GPP HSPA and 3GPP2 HRPD, has combined with advances in Digital Signal Processing (DSP) capability, multi-media source coding, streaming protocols and low-power high-resolution displays to deliver the so-called smartphone. This device has fundamentally changed the trajectory of traffic growth over broadband wireless networks.

In June 2010, The Nielsen Company reported ([1], Figure 1.1) an annual increase between Q1-2009 and Q1-2010 of 230% in average smartphone data consumption. Nielsen further reported that some users were approaching 2 GB per month in total data usage, and that the top 6% of smartphone users were consuming nearly 50% of total data bandwidth. Therefore, as more users emulate the behavior of leading adopters, further growth in per-user data consumption is expected to follow. Most significant of all, from the perspective of future growth, Nielsen estimated that the penetration rate of smartphones into the US market was only 23%. Indeed, of those users, almost 1/4 generated zero data traffic, while 1/3 had simply not subscribed to a data plan at all. This suggests a latent demand for data connectivity and that networks are only beginning to see the onset of smartphone-induced load.

Figure 1.1 2009 and 2010 smartphone data usage distribution. Reproduced by permission of © 2010 The Nielsen Company.

Figure 1.2 Total wireless mobile network traffic growth. Reproduced from © 2010 Cisco VNI Mobile.

The Nielsen Company’s data is generally consistent with that reported by major network operators, particularly with respect to the wide distribution of user data consumption rates. For example, in June 2010, AT&T reported [2] that while the least active 65% of AT&T’s smartphone subscribers used, on average, less than 200 MB of data per month, the top 2% of subscribers used more than 2 GB.

Although AT&T did not comment on future network traffic growth, others such as Cisco Systems have done so [3]. In Cisco’s view, total wireless mobile network traffic growth (Figure 1.2) will exceed a Compounded Annual Growth Rate (CAGR) in excess of 100% per annum in the period 2010–2014, with video traffic providing as much as 2/3 of total traffic. In other words, on an annualized basis, total network traffic will double until at least the middle of the decade. This suggests that, as compared to 2009, if not prevented by factors such as limited-data subscription plans or insufficient spectrum, a 64-fold increase in total network traffic will result by 2015.

Figure 1.3 Traffic generation by smartphone type. Reproduced by permission of © 2010 The Nielsen Company.

1.1.1. Differences between Smartphones

Even amongst those users who are equipped with smartphones, there is a wide disparity in data usage. There are a number of factors which influence the amount of data generated per device, including the user interface, applications available to the user (driven by operating system popularity), subscriber data plan, configuration of services using data link push and keep-alive techniques, etc. It is possible, however, to establish general trends by looking closely at measured data volumes on a per device basis. For example, in the 2010 Nielsen data depicted in Figure 1.3, along with the Palm Pre, the market-leading Motorola Droid and Apple iPhone 3GS devices both generated very significant data volumes, consistent with the rich set of experiences enabled by each platform. On average, both of these leading devices were generating around 400 MB of monthly data traffic per subscriber. This is well in excess of the average behavior of all devices (Average device) of around 90 MB per month, and even the average smartphone monthly consumption of 240 MB.

Figure 1.3 further suggests that the core capabilities of smartphone devices are also important in establishing data consumption. Table 1.1 lists selected capabilities of influential smartphone devices launched in 2009/10, including a subset of the most significant devices from Figure 1.3. A comparison of the Motorola Droid and Cliq devices shows a progressive increase in application processor, screen resolution and multi-media capabilities that would tend to drive the difference in user data consumption for each device observed in Figure 1.3.

Table 1.1 Contemporary smartphone capabilities

Source: Motorola 2010

The same general trend is observable in Table 1.1 for vendors other than Motorola such as Apple and HTC. It is worth noting that Table 1.1 spans a relatively short device launch period of only approximately two years.

1.1.2. Driving Data Traffic – Streaming Media and Other Services

The advent of streaming media services such as those offered by Pandora and YouTube has had a major impact on device data consumption.

Internet audio streaming (Internet radio) using, amongst others, streaming MPEG-1 Audio Layer-3 (MP3), Windows Media Audio (WMA), Flash Video (FLV) or Real Audio formats, and using protocols such as Real-time Transport Protocol (RTP), Real Time Streaming Protocol (RTSP), Real Time Messaging Protocol (RTMP), User Datagram Protocol (UDP) and HyperText Transfer Protocol (HTTP), has been deployed on the wired Internet since the late 1990s. Since 2005, however, despite the increasing enforcement of royalty-driven limitation on streaming, the advent of genre-based streaming services such as Pandora or even subscription services such as XM Radio Online has further increased the popularity of this type of service.

Depending on service type, server-client rate adaptation strategy and subscription policy, typical data rates for audio streaming services range from 56–192 kbps, yielding a per user consumption rate of ∼25–85 MB/hr. This significant data consumption rate is most impactful when combined with the observed user behavior of invoking an audio streaming service and then permitting the stream to continue as a background audio service for an extended period (often several hours in duration) while executing other tasks.

Video streaming services represent another major source of network load. Services here are generally very well known, and include YouTube, Hulu, TV.com, etc. YouTube, which is a typical example of such a service, generally uses FLV or MP4 containers, plus MPEG-4 AVC (H.264) video encoding with stereo audio encoded using Advance Audio Coding (AAC). Typical served rates are 85–500 kbps (i.e. ∼38–220 MB/hr), with a limit on total content duration (e.g. 10 min) and size (e.g. 2 GB) depending on the relationship between the entity uploading the source content and the streaming service provider.

Recently, the aforementioned services have become available for the wireless Internet due to the rich set of features implanted by smartphones. As a consequence, the large data volumes associated with these data services have to be carried by wireless radio networks, causing mounting pressure on the available wireless infrastructure.

1.2. Capacity and Coverage Crunch

Mobile data traffic is growing extensively and it is projected that a 64-fold increase in total network traffic will result by 2015 as discussed in Section 1.1. This explosive growth in mobile broadband places serious demands and requirements on wireless radio networks and the supporting transport infrastructure. The most obvious requirement is the massive capacity expansions and the necessary coverage extensions that need to be provided while meeting the required Quality of Service (QoS).

In general, traffic growth is healthy if network operators can charge for it proportionally and if they can provide sufficient network capacity to cope with that growth. It is worthwhile noting, however, that these capacity expansions are required at a time when operators’ Capital Expenditure (CAPEX) and Operational Expenditure (OPEX) budgets are limited and Average Revenue Per User (ARPU) growth is saturated.

The following sections provide an overview of techniques and solutions available to help wireless operators address the challenges associated with the explosive traffic growth.

1.3. Meeting the Challenge – the Network Operator Toolkit

Fortunately, network operators have a wide variety of techniques available to deal with the challenge of mobile data growth. First, operators can employ economic incentives to modify user behavior by adjusting tariff structures. Another approach is to improve network capacity through the deployment of advanced Radio Access Technologies (RATs), such as 3GPP Long Term Evolution (LTE). This approach, and the significant CAPEX associated with it, is often combined with the acquisition of new spectrum. Interest in the use of WiFi companion networks and offloading techniques has recently grown, along with preliminary deployments of innovative network elements such as femto cells or home base stations. The optimization of protocol design and traffic shaping methods, together with the deployment of advanced source coding techniques, has recently become popular. Finally, and most significantly for the purpose of this book, there has been intensive interest in the optimization of existing radio network assets and there has been huge interest in expanding the scope of Self-Organizing Networks (SON) to cover 2G and 3G. This last approach has the added attraction of relatively low capital and operational investment.

1.3.1. Tariff Structures

With the increasing adoption of smartphones, the era of unlimited data plans may be coming to an end. For example, in June 2010, AT&T publicly announced [2] two limited data plans: DataPlus and DataPro. Under the AT&T DataPlus plan, users were offered a total of 200 MB of data for US$15 per month, with an additional 200 MB of data available for use within the billing cycle for a further US$15 fee. Under the companion DataPro plan, 2 GB of data were included in the basic US$25 fee, with a further 1 GB available for use within the billing cycle at the cost of an additional US$10. New Apple iPad users were mapped to the AT&T DataPro plan, and the antecedent unlimited plan was phased out.

AT&T is, of course, not unique in taking this approach, and similar trends can be seen in other networks and geographic regions. For example, in June 2010, O2 announced [4] that new and upgrading users would be mapped to a selection of data plans offering between 500 MB and 1 GB per month of data usage for £25–60, with additional data available for approximately £10 per GB, depending on the selected data bolt-on product. Notably, however, in Asia, after a period of expansion for data-limited plans, competitive pressure is re-establishing unlimited data offerings, at least for a period, by operators such as SK Telecom [5].

Limited data plans apply generically to all traffic transported by the network. However, new opportunities may also be emerging for network operators seeking to limit specific traffic flows from/to certain Internet Protocol (IP) addresses and port numbers, for technical or business reasons. These may include, for example, ports used by streaming media services or other data-intensive traffic sources. Alternatively, network operators may seek to limit traffic originating from particular applications, or indeed traffic exchanged with competing service providers could be limited or mapped to lower QoS classes. These approaches are the subject of intensive regulatory scrutiny. In the US, for example, the April 2010 Federal Court ruling on so-called net neutrality [6] may encourage more efforts by network operators to intervene in traffic flows, but further legislative or regulatory activity is very likely.

Figure 1.4 Evolution of WAN radio access. Reproduced by permission of © 2010 Motorola.

1.3.2. Advanced Radio Access Technologies

With the exception of green field deployments, the opportunity for network operators and device vendors to migrate towards network RATs with improved spectral efficiency is heavily dependent on existing commitments and compatible legacy technologies. This is illustrated in Figure 1.4, which shows the respective evolution of wide area RATs from the roots of GSM, CDMA and IEEE 802.16d into HSPA+, LTE, EV-DO and WiMAX. As the figure shows, the strategic landscape surrounding broadband wireless is in some ways becoming simpler with the deployment of 4G networks. For example, at present, the EV-DO family of technologies appears to have limited prospects for widespread deployment of the EV-DO Revision B (DO-B) and EV-DO Revision C (DO-C) variants, and consequently, although EV-DO technology will remain operational for many years, unless there is some shift in the strategic landscape, the evolutionary track for EV-DO is effectively terminating. Similarly, with the commencement of work in 3GPP [7] to support deployment of LTE in the U.S. 2.5 GHz band, further commitment to WiMAX 2.0 may be limited, although Q3-2010 commitments by Indian operators following the Indian 3G and Broadband Wireless Access (BWA) spectrum auctions to both WiMAX and to LTE Time Division Duplex (TDD) mode suggest that the long-term future of WiMAX may be undecided.

Table 1.2 HSPA+ and LTE evolution – device capability summary

Source: Motorola 2010

Table 1.3 Comparison of HSPA+ and LTE spectral efficiency

Source: Motorola 2010

All of this appears to position 3GPP LTE, both Frequency Division Duplex (FDD) and TDD variants, and 3GPP HSPA+ as the critical Wide Area Network (WAN) RATs for the next decade, and even beyond, as enabled by the International Mobile Telecommunications – Advanced (IMT-Advanced) process, provided regional technology programs remain aligned to these central threads.

Focusing further on HSPA+ and LTE, it should first be noted that there is no formal definition for HSPA+. Since the High Speed Uplink Packet Access (HSUPA) companion specification to the 3GPP Release 5 High Speed Downlink Packet Access (HSDPA) was completed in 3GPP Release 6, it is reasonable to categorize networks or devices supporting one or more HSPA features from 3GPP Releases 7 through Release 9 to be HSPA+. Practically speaking, however, and leaving aside some relatively minor layer 2 efficiency improvements and the useful device power-consumption enhancements offered by the Continuous Packet Connectivity (CPC) feature, the major HSPA+ capacity-enhancing components offered by Release 7 are downlink dual-stream Multiple Input Multiple Output (MIMO) and 64-Quadrature Amplitude Modulation (QAM) capability (see Table 1.2), thus resulting in support for peak rates in excess of 10 Mbps. Notably, the deployment of MIMO-capable HSPA+ networks and devices appears increasingly unlikely due to infrastructure and legacy device equalizer limitations, leaving 64-QAM as the principal Release 7 HSPA+ enhancement.

This permits the comparison of spectral efficiency of a 10 MHz LTE Release 8 network and an HSPA+ network, which appears in Table 1.3. Here, Release 8 HSPA+ dual-carrier feature has been incorporated into HSPA+ results in order to permit direct comparison of the same 10 MHz FDD pair. It can be seen from the results that the performance of HSPA+ networks is comparable to that of LTE with the deployment of dual-port receivers denoted by 1 × 2 in Table 1.3 (one transmit antenna at the base station and two antennas at the handset providing receive diversity).

This defines the strategy of many 3G operators today – to execute selected upgrading of HSPA infrastructure, including the critical backhaul capacity elements, to support HSPA+ and hence to support device rates up to 21 Mbps (HSDPA Category 14) or more, while seeking to deploy LTE at the earliest date consistent with LTE device maturity and cost competitiveness. Here, it is worth noting that (as indicated in Figure 1.5) the total installed base of devices supporting at least one LTE band will not represent a truly significant fraction of total mobile devices before 2015. Accordingly, it is reasonable to assume that the migration of data traffic to higher performance wide area RATs will be gradual, and it may take until the end of decade 2010–2020 before the majority of worldwide operational terminals are LTE-capable.

Figure 1.5 Total subscriber device capabilities by year. Reproduced by permission of © 2009 Strategy Analytics.

1.3.3. Femto Cells

A key component is the emergence of femto cells (or home base stations) deployed either in enterprise or domestic environments. Although deployments of femto cells conformant to conventional macro-cellular core specifications are completely feasible, several enhancements to basic femto operation have been specified by 3GPP and other standards development organizations (including WiMAX Forum and Femto Forum). In 3GPP, this has included the definition of Closed Subscriber Groups (CSGs) who have been granted access to restricted femto cells, methods for easily identifying femto cells during radio resource management procedures (e.g. via CSG-specific synchronization sequences), and enhanced mobility procedures for handing-off devices more reliably into a CSG femto cell. Upper-layer support for Local IP Access (LIPA) to local network resources has been added to 3GPP Release 10. Nevertheless, despite significant potential, the rollout of femto cells for domestic environments, such as Vodafone’s Sure Signal or AT&T’s Femtocell brands, has had a limited impact from the perspective of network load management and reduction. Rather, femto cell marketing to date has emphasized enhancement of coverage-limited network access to voice services. Accordingly, with limited adoption so far, and reuse of operators’ core licensed spectrum required in any case, femto cells are unlikely to make a significant contribution to network unloading before 2012–13.

1.3.4. Acquisition and Activation of New Spectrum

The identification, clearing and activation of new spectrum for mobile services, and the efficient refarming of existing spectrum, are problems receiving intense scrutiny by regulators in all three International Telecommunications Union (ITU) regions.

In ITU Region 2 (Americas), in March 2010, the United States announced, as part of the National Broadband Plan (NBP) [8], the intention to make available 500 MHz of additional spectrum for mobile broadband services by 2020, with 300 MHz to be made available by 2015. Assets in this case include a 20 MHz allocation in the 2.3 GHz Wireless Communications Service (WCS) band, disposition of the remaining 10 MHz (Block D) of spectrum from the 700 MHz auction of 2008, Federal Communications Commission (FCC) Auction 73, and a further 60 MHz of spectrum comprising mainly elements of the Advanced Wireless Services (AWS) band (generally, in the range of 1755–2200 MHz). In addition, a further 90 MHz of Mobile Satellite Service (MSS) spectrum from L- and S-bands would be made available under Ancillary Terrestrial Component (ATC) regulation (where devices supporting terrestrial broadband service must also support a satellite component). Perhaps most significant is the possibility of an additional 120 MHz of spectrum to be reallocated from broadcast use to mobile services.

In ITU Region 1 (Europe, Africa and Middle East), there is also considerable activity leading to new spectrum deployments. One example is the auction of 190 MHz of spectrum at 2.6 GHz (generally, in conformance to the band structure envisaged by the ECC/DEC(05)05 European directive) conducted in 2008–2010 by Norway, Sweden, Finland, Germany, Netherlands and Denmark, with other European countries expected to follow in 2010 or 2011. Perhaps most significant, however, is the German auction in May 2010 of 360 MHz of spectrum located mainly in the 800 MHz and 2.6 GHz bands yielding 2 × 10 MHz each at 800 MHz for Vodafone, T-Mobile and O2 plus awards at 2.6 GHz to Vodafone (2 × 20 MHz FDD, 25 MHz TDD), T-Mobile (2 × 20 MHz FDD, 5 MHz TDD), O2 (2 × 20 MHz FDD, 10 MHz TDD) and E-Plus (2 × 10 MHz FDD, 10 MHz TDD).

In ITU Region 3 (Asia), a similar narrative has evolved. In China, for example, band proposals for 700 MHz mobile operation (698–806 MHz) include options for allocation of the entire band for unpaired operation (i.e. TDD mode), or a split in allocation between paired (FDD, 698–746 MHz) and unpaired (TDD, 746–806 MHz) modes. It is unlikely, however, that this spectrum will be released before 2015. More immediate opportunities for new spectrum in China include 100 MHz available in the 2300–2400 MHz band plus up to 190 MHz of spectrum in the 2.6 GHz band (2500–2690 MHz). Of these, the 2300–2400 MHz spectrum was designated for unpaired operation as early as 2002, and has been used successfully for LTE-TDD trials at the Shanghai Expo of 2010. However, coexistence concerns with other services may limit future deployment in that band to indoor use. This has led to increased interest in the 2.6 GHz band, where, amongst other possibilities, alignment with the European or U.S. 2.6 GHz band plans has been considered, along with an alternative all-TDD designation favoring LTE-TDD mode. Similar commitment to release spectrum, albeit on a smaller scale, has emerged for the same bands in India, resulting most recently in the Indian 3G and BWA spectrum auction.

Clearly, the acquisition of new spectrum offers a major opportunity to enhance network capacity. Notably, however, the acquisition of spectrum can be highly capital-intensive. For example, the German auction of May 2010 yielded total bid amounts of €4300 million. Further, the activation of new spectrum can involve costs to relocate users or services, and the provision of additional radio hardware and transmission backhaul at sites where the new spectrum is to be activated. All of this suggests that, while new licensed spectrum is a critical component to resolving network capacity shortages, it is generally a costly option, available only on a medium- to long-term basis.

1.3.5. Companion Networks, Offloading and Traffic Management

The cost of new licensed spectrum has led to renewed interest in the resources offered by unlicensed spectrum, such as the US 2.4 GHz Industrial, Scientific and Medical (ISM) band, the 5 GHz National Information Infrastructure (NII) band and the 700 MHz Television White Space (TVWS) band. Many major network operators now lease access to WiFi from WiFi network service aggregators (where one or more distinctive WiFi hotspot networks are gathered under a single brand and are accessible using a single set of access credentials), or operate public WiFi hotspot networks that are cobranded as companion networks to the operator’s primary wide area broadband network. Authentication protocols such as Wireless Internet Service Provider roaming (WISPr) are usually applied, in combination with either Wired Equivalent Privacy (WEP) or, more frequently, WiFi Protected Access (WPA) and WiFi Protected Access 2 (WPA2) authentication methods using user- or operator-supplied credentials stored on the device or UICC-based1 credentials. Significantly, access to such WiFi networks is increasingly offered without additional charge as an element of a broader wide area data plan.

Almost all contemporary smartphones support WiFi connectivity. This allows operators to offload a significant portion of growing data traffic from their primary WAN network onto their WiFi network. Leaving aside the consequent increased load on WiFi networks and the resulting interference, there are a number of obstacles here. First, enabling the device’s WiFi interface on a continuous basis can lead to elevated device electric current drain and reduced battery life, with consequent user dissatisfaction. Second, the spatial density of the operator’s hotspot network is often not sufficient to provide service coverage on a contiguous basis, despite hotspot collocation with transport or social centers (e.g. airports, cafes, etc.). For example, in one Chicago suburb, the spatial separation between WiFi hotspots associated with one 3G network was around 4 km, roughly twice that of the companion 3G network intersite separation, and therefore the opportunity to conveniently connect to a hotspot can be limited. Finally, some operator services, such as operator branded messaging or media services, referred to here as Carrier Branded Services (CBS), must have access on a trusted basis to the operator’s core network in order to execute authentication functions.

The problem with low battery life can be overcome by using appropriate power management techniques in both the WiFi associated and non-associated states. The low spatial density of WiFi hotspots implies that many or even most data-offloading WiFi connections will be established in the user’s home or enterprise. This raises questions about the capability2 of those networks. Answers for these questions can be found through privacy-appropriate surveying techniques3. Summary results of a public WiFi Access Point (AP) beacon survey conducted by Motorola in Q2-2010 appear in Table 1.4. It can be seen that although more than 90% of public WiFi APs conform to the 802.11g amendment, few 802.11n APs were deployed at the time of the survey. Significantly, most APs were deployed in the 83 MHz of spectrum available in the 2.4 GHz ISM band, which, for practical purposes, can support a maximum of three 20 MHz 802.11 carriers. Almost no APs were operational in the 5 GHz band, which, at least in the US, offers a total of 550 MHz of spectrum, suggesting that, as smartphones increasingly support 5 GHz WiFi access, this approach to network offloading has real prospects for growth.

Table 1.4 Public WiFi AP survey summary – Q2-2010

Source: Motorola 2010

Figure 1.6 Offloading architecture – Type I. Reproduced by permission of © 2010 Motorola.

Finally, the difficulties related to accessing the operator’s core network on a trusted basis can be resolved by using appropriate routing and tunneling techniques. There are several approaches to achieve this. In one of them, illustrated in Figure 1.6, the device maintains WAN (i.e. 3G/4G) and WiFi connections simultaneously. This permits the bulk of non-CBS data to transfer over the WiFi connection, while access to CBS data may occur over the secured WAN network. An evolution of this approach appears in Figure 1.7. In this architecture, the operator has invested in additional network-edge routers capable of terminating a secure tunnel originating in the device over the unsecure WiFi network. As a result, additional CBS-specific traffic may enter the operator’s core network over the unsecure WiFi connection, with the remaining traffic terminating directly in the Internet.

Figure 1.7 Offloading architecture – Type II. Reproduced by permission of © 2010 Motorola.

1.3.6. Advanced Source Coding

New approaches to source coding also offer the prospect for improvements in network efficiency. Traditionally, cellular systems have looked into speech coding efficiency as a baseline measure of source coding performance. Here, notwithstanding the evolution of the CDMA Enhanced Variable Rate Codec (EVRC) family to the EVRC-C variant, the migration of CDMA operators to LTE appears likely to bring EVRC evolution to a close. At the same time, the need for improved voice quality means that a number of 3G operators, most notably T-Mobile International and France Telecom/Orange, are now migrating from the well-established 3GPP-specified Adaptive Multi-Rate NarrowBand (AMR-NB) codec (covering the audio range of 200 Hz to 3.5 kHz) to the evolved AMR WideBand (AMR-WB/G.722.2) codec (50 Hz to 7.0 kHz). This brings a corresponding increase in bit rate from 5.9–12.2 kbps (AMR-NB) to 12.65 kbps (AMR-WB) and above.

Fortunately, recent work in ITU-Telecommunication (ITU-T) SG-16 [9] on the G.718 codec, which can maintain bitstream compatibility with AMR-WB, indicates it is possible to achieve quality levels normally associated with AMR-WB at 12.65 kbps by using G.718 with 8 kbps. This is, in part, the motivation for the 3GPP Enhanced Voice Service (EVS) work [10]. Significantly, however, the 3GPP EVS specification is unlikely to be complete before 2011 and is unlikely to be operational before 2012. Accordingly, in the medium-term, speech source coding rates will not diminish in the period up to 2012, but may well increase as AMR-WB is deployed.

Figure 1.8 MPEG-4 and MPEG-2 quality versus time. Source: Motorola 2010.

When operating in the range of 32–64 kbps, the performance of the G.718 and EVS codecs begin to overlap with that of the AAC codec family specified by the International Organization for Standardization (ISO) and the International Electrotechnical Commission (IEC), most notably the AAC Low Delay (AAC-LD) and AAC Enhanced Low Delay (AAC-ELD) variants. Recent operator assessments (e.g. [11]) suggest, however, that neither of these codecs offer efficiency advantages over G.718 or the emerging EVS specification, with proprietary codecs such as SiLK (Skype) or Speex reported to operate at significantly poorer efficiencies. For medium- to high-rate audio coding applications (i.e. bit rates in the range of 32–256 kbps), smartphones such as the Motorola Droid X or the Apple iPhone make available MP3, AAC and AAC+ codecs. At these audio coding rates, there is little evidence at present that work in ISO/IEC or 3GPP will lead to significant improvements in efficiency in the near-term. Rather, the trend towards super-wideband (50 Hz to 14 kHz) and full-band (20 Hz to 20 kHz) codec operation, and potentially towards support for surround sound in WAN networks [12] suggests that in the next decade improved audio source coding will not lead to significant reduction in network load, but rather will emphasize improved quality and enhanced services.

Clearly, however, from the traffic growth information presented above, more efficient encoding of video traffic would have the greatest impact on total network load. Again, there appears to be limited opportunity for significant fundamental improvements in the near term. This is largely due to diminishing incremental improvements in the performance of the ITU/ISO/IEC MPEG-4 AVC/H.264 video codec (Figure 1.8).

Most significantly, while there is a clear recognition that further improvements in video coding efficiency are essential, it will clearly take time to achieve this. For example, ISO/IEC MPEG and ITU-T Video Coding Experts Group (VCEG) have established the Joint Collaborative Team on Video Coding (JCT-VC) to deliver a High Efficiency Video Coding (HEVC/H.265) specification [13], with the goal of achieving roughly a twofold improvement in encoding efficiency for the same or lower computational complexity. Subjective assessment, however, of initial proposals for HEVC commenced in March 2010 [14], with the date for completion of the specification targeted at Q3-2012. This suggests the earliest possible widespread deployment date of fully compliant HEVC codecs would be 2013.

At the same time, the advent of AVC/H.264-enabled 3D-video will tend to push streaming rates even higher. Moreover, and unrelated to 3D-video, smartphone and converged computing or tablet device (e.g. iPad) screen resolutions and rendering capabilities continue to increase. For example, the Motorola Droid X smartphone introduced in July 2010 offers a 4.3” (10.9 cm) Wide Video Graphics Array (WVGA) (480 × 854) display combined with a High-Definition Multi-media Interface (HDMI) port and the ability to render 720p AVC/H.264 content. The converged computing Apple iPad (launched in April 2010) correspondingly offers a 9.7” (24.6 cm) display supporting 1024 × 768 resolution, and AVC/H.264 video up to 720p format at 30 frames per second.

Accordingly, as such devices further penetrate broadband wireless markets, and in the obvious absence of a radical improvement in video coding efficiency, operators will continue to migrate network servers towards more efficient use of existing codec techniques (such as AVC/H.264) [15]. Opportunities for such advanced streaming procedures include proprietary methods such as Microsoft Smooth Streaming, Apple HTTP Live Steaming (HLS) and standardized approaches such as ongoing efforts in Open IPTV Forum (OIPF) and 3GPP [16]. Nevertheless, while such approaches will improve video rate adaptation (to better suit channel conditions or access technology) and will offer trick play features in an efficient way, they will not fundamentally reduce the growth of video traffic, although they may offer enhanced means of maintaining adequate video quality within specific data-rate constraints.

1.4. Self-Organizing Networks (SON)

All capacity expansion techniques that have been discussed so far are valid paths, and operators’ strategies need to rely on them to cope with growing data volumes and demanding customer expectations (in terms of QoS and service cost). Nonetheless, the techniques that are available today involve outstanding capital outlays, and therefore it is worth reflecting on whether the current infrastructure is being operated at its full performance potential before considering network expansions or evolutions.

Going back to basics, it is important to remember that, for example, the Universal Mobile Telecommunications System (UMTS) is a complex technology in which coverage, capacity and quality are deeply coupled to each other. There are many optimization levers that currently remain untouched or, at best case, fine-tuned at network level, i.e. with the same settings for all different cells. The bottom line is that, even though a UMTS network may be delivering acceptable Key Performance Indicators (KPIs), most likely there is still room for increasing its capacity, just by carefully tuning the different settings on a cell-by-cell basis.

The idea to carry out adaptive network optimization on a per sector (or even per adjacency) basis is part of the SON paradigm, which has been defined around a set of clear requirements formulated by the Next Generation Mobile Networks (NGMN) Alliance [17]. The objective of the SON proposal is to enable a set of functionalities for automated Self-Organization of LTE networks, so that human intervention is minimized in the planning, deployment, optimization and maintenance activities of these new networks. Subsequently, the support for this new network management paradigm is being translated into concrete functionalities, interfaces and procedures during the standardization of Evolved Universal Terrestrial Radio Access Network (E-UTRAN) in 3GPP.

The SON Use Cases can be structured in different ways. As will be discussed in Chapter 2, one of the possible high-level classifications is the following:

Self-Planning: derivation of the settings for a new network node, including the selection of the site location and the specification of the hardware configuration, but excluding site acquisition and preparation.Self-Deployment: preparation, installation, authentication and delivery of a status report of a new network node. It includes all procedures to bring a new node into commercial operation, except for the ones included in the Self-Planning category, which generate inputs for the Self-Deployment phase.Self-Optimization: utilization of measurements and performance indicators collected by the User Equipments (UEs) and the base stations in order to auto-tune the network settings. This process is performed in the operational state, which is defined as the state where the Radio Frequency (RF) interface is commercially active (i.e. when the cell is not barred/reserved).Self-Healing: execution of the routine actions that keep the network operational and/or prevent disruptive problems from arising. This includes the necessary software and hardware upgrades or replacements.

Whereas current commercial and standardization efforts are mainly focused on the introduction and Self-Organization of LTE networks, there is significant value associated with the extension of the scope of Self-Planning, Self-Optimization and Self-Healing to cover GSM/GPRS/EDGE and UMTS/HSPA RATs. The implications of multi-technology SON are massive. On one hand, the adoption of a multi-technology approach allows operators to completely transform and streamline their operations, not only applying an innovative, automated approach to the new additional LTE network layer, but also extending the automation-related operational savings to all RATs, thereby harmonizing the whole network management approach and boosting operational efficiency. On the other hand, the availability of a multi-technology SON solution can lead to more comprehensive, holistic and powerful optimization strategies that deal with several RATs simultaneously.

Practical experience shows that the application of 3G SON technologies in current UMTS infrastructure can yield a capacity gain of 50% without carrying out any CAPEX expansion.

1.5. Summary and Book Contents

In summary, as smartphones continue to proliferate, there is a clear and present need to improve the efficiency and capacity of contemporary broadband networks. Fortunately, there is a wide variety of options available to network operators, ranging from evolution in network technology such as improved backhaul and the use of enhanced RATs such (e.g. HSPA+ and LTE), through acquisition of new spectrum, offloading to companion networks (e.g. WiFi) and the application of advanced source coding along with traffic shaping methods.

Equally clearly, however, no single approach will resolve the challenge caused by the exponential growth in network traffic. Critically for the present purpose, the approaches discussed in Section 1.3 are either capital intensive (e.g. new spectrum acquisition or network deployment) or are associated with extended time horizons (e.g. new source coding technology breakthroughs) or both. Therefore, SON techniques and functions have a unique role to play. They can be deployed today, at moderate to low cost, in contemporary 2G and 3G networks to increase operational efficiency with little or no delay. SON techniques will, of course, evolve to support LTE.

Figure 1.9 Book contents map.

The main purpose of this book is to describe multi-technology SON for 2G, 3G and LTE, and to cover the best practice deployment of Self-Organizing Networks that support multi-vendor and multi-technology wireless infrastructures. This will be done mainly from a technology point of view, but also covering some critical business aspects, such as the Return On Investment (ROI) of the proposed SON functionalities and Use Cases. Figure 1.9 provides a conceptual map summarizing the contents of the book. Chapter 2 provides an overview of the SON paradigm covering NGMN objectives and the activities in 3GPP and the research community. Chapter 3 covers the multi-technology aspects of SON, from main drivers to a layered architecture for multi-vendor support. Chapters 4, 5 and 6 cover the multi-vendor and multi-technology (2G, 3G and LTE) aspects of the Self-Planning, Self-Optimization and Self-Healing of wireless networks, respectively. Finally, critical business aspects, such as the ROI of the proposed SON functionalities and Use Cases are presented in Chapter 7.

1.6. References

[1] The Nielsen Company (2010) Quantifying the Mobile Data Tsunami and its Implications, 30 June 2010, http://blog.nielsen.com (accessed 3 June 2011).

[2] AT&T Press Release (2010) AT&T Announces New Lower-Priced Wireless Data Plans to Make Mobile Internet More Affordable to More People, 2 June 2010, http://www.att.com (accessed 3 June 2011).

[3] Cisco (2010) Cisco Visual Networking Index: Global Mobile Data Traffic Forecast Update 2009–2014, 9 February 2010, http://www.cisco.com (accessed 3 June 2011).

[4] O2 Press Release (2010) O2 Introduces New Mobile Data Pricing Model, 10 June 2010, http://mediacentre.o2.co.uk (accessed 3 June 2011).

[5] SK Telecom Press Release (2010) SK Telecom Unveils Innovative Measures to Boost Customer Benefits, 14 July 2010, http://www.sktelecom.com (accessed 3 June 2011).

[6] US Court of Appeals Ruling, District of Columbia (2010) Comcast vs. US FCC, 6 April 2010, http://pacer.cadc.uscourts.gov/common/opinions/201004/08-1291-1238302.pdf (accessed 3 June 2011).

[7] 3GPP, RAN Plenary Meeting #49, RP-100701 (2010)
