Beschreibung

Describing the fundamental physical properties of materials used in electronics, the thorough coverage of this book will facilitate an understanding of the technological processes used in the fabrication of electronic and photonic devices. The book opens with an introduction to the basic applied physics of simple electronic states and energy levels. Silicon and copper, the building blocks for many electronic devices, are used as examples. Next, more advanced theories are developed to better account for the electronic and optical behavior of ordered materials, such as diamond, and disordered materials, such as amorphous silicon. Finally, the principal quasi-particles (phonons, polarons, excitons, plasmons, and polaritons) that are fundamental to explaining phenomena such as component aging (phonons) and optical performance in terms of yield (excitons) or communication speed (polarons) are discussed.

Leseprobe

Table of Contents

Foreword

Introduction

Chapter 1: Introduction: Representations of Electron-Lattice Bonds

1.1. Introduction

1.2. Quantum mechanics: some basics

1.3. Bonds in solids: a free electron as the zero order approximation for a weak bond; and strong bonds

1.4. Complementary material: basic evidence for the appearance of bands in solids

Chapter 2: The Free Electron and State Density Functions

2.1. Overview of the free electron

2.2. Study of the stationary regime of small scale (enabling the establishment of nodes at extremities) symmetric wells (1D model)

2.3. Study of the stationary regime for asymmetric wells (1D model) with L ≈ a favoring the establishment of a stationary regime with nodes at extremities

2.4. Solutions that favor propagation: wide potential wells where L ≈ 1 mm, i.e. several orders greater than inter-atomic distances

2.5. State density function represented in energy space for free electrons in a 1D system

2.6. From electrons in a 3D system (potential box)

2.7. Problems

Chapter 3: The Origin of Band Structures within the Weak Band Approximation
