Synthetic Natural Gas E-Book

• Herausgeber: John Wiley & Sons
• Kategorie: Fachliteratur
• Sprache: Englisch

Seitenzahl: 620

Veröffentlichungsjahr: 2016

Beschreibung

Provides an overview of the different pathways to produce Synthetic Natural Gas * Covers technological, and economic aspects of this Synthetic Natural Gas * Details the most popular technologies and state-of-the-art of SNG technologies while also covering recent and future research trends * Covers the main process steps during conversion of coal and dry biomass to SNG: gasification, gas cleaning, methanation and gas upgrading * Describes a number of novel processes for the production of SNG with their specific combination of process steps as well as the boundary conditions * Covers important technical aspects of Power-to-Gas processes

Leseprobe

SYNTHETIC NATURAL GAS FROM COAL, DRY BIOMASS, AND POWER‐TO‐GAS APPLICATIONS

Edited by

TILMAN J. SCHILDHAUERSERGE M.A. BIOLLAZ

Paul Scherrer Institut, Villigen/Switzerland

Copyright © 2016 by John Wiley & Sons, Inc. All rights reserved

Published by John Wiley & Sons, Inc., Hoboken, New JerseyPublished simultaneously in Canada

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, scanning, or otherwise, except as permitted under Section 107 or 108 of the 1976 United States Copyright Act, without either the prior written permission of the Publisher, or authorization through payment of the appropriate per‐copy fee to the Copyright Clearance Center, Inc., 222 Rosewood Drive, Danvers, MA 01923, (978) 750‐8400, fax (978) 750‐4470, or on the web at www.copyright.com. Requests to the Publisher for permission should be addressed to the Permissions Department, John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, (201) 748‐6011, fax (201) 748‐6008, or online at http://www.wiley.com/go/permissions.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives or written sales materials. The advice and strategies contained herein may not be suitable for your situation. You should consult with a professional where appropriate. Neither the publisher nor author shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

For general information on our other products and services or for technical support, please contact our Customer Care Department within the United States at (800) 762‐2974, outside the United States at (317) 572‐3993 or fax (317) 572‐4002.

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic formats. For more information about Wiley products, visit our web site at www.wiley.com.

Library of Congress Cataloging‐in‐Publication Data:

Names: Schildhauer, Tilman J., editor. | Biollaz, Serge M.A., editor.Title: Synthetic natural gas from coal, dry biomass, and power‐to‐gas applications / [edited by] Tilman J. Schildhauer, Serge M.A. Biollaz.Description: Hoboken, New Jersey : John Wiley & Sons, 2016. | Includes bibliographical references and index.Identifiers: LCCN 2016006837 (print) | LCCN 2016014453 (ebook) | ISBN 9781118541814 (cloth) | ISBN 9781119191254 (pdf) | ISBN 9781119191360 (epub)Subjects: LCSH: Synthesis gas. | Coal gasification. | Biomass conversion. | Gas manufacture and works.Classification: LCC TP360 .S96 2016 (print) | LCC TP360 (ebook) | DDC 660/.2844–dc23LC record available at http://lccn.loc.gov/2016006837

LIST OF CONTRIBUTORS

Renato Baciocchi University of Rome Tor Vergata, Roma, Italy

Serge M.A. Biollaz Paul Scherrer Institut, Villigen, Switzerland

Jochen Brellochs Center for Solar Energy and Hydrogen Research (ZSW), Stuttgart, Germany

Giulia Costa University of Rome Tor Vergata, Roma, Italy

Volkmar Frick Center for Solar Energy and Hydrogen Research (ZSW), Stuttgart, Germany

Jörgen Held Renewable Energy Technology International AB, Lund, Sweden

Stefan Heyne Chalmers University of Technology, Göteborg, Sweden

Thomas Kienberger Montanuniversität Leoben, Leoben, Austria

Christian F.J. König Paul Scherrer Institut, Villigen, Switzerland

Lidia Lombardi Niccolò Cusano University, Roma, Italy

Maarten Nachtegaal Paul Scherrer Institut, Villigen, Switzerland

Luc P.L.M. Rabou Energieonderzoek Centrum Nederland, Petten, The Netherlands

Urs Rhyner AGRO Energie Schwyz, Schwyz, Switzerland

Tilman J. Schildhauer Paul Scherrer Institut, Villigen, Switzerland

Martin Seemann Chalmers University of Technology, Göteborg, Sweden

Michael Specht Center for Solar Energy and Hydrogen Research (ZSW), Stuttgart, Germany

Bernd Stürmer Center for Solar Energy and Hydrogen Research (ZSW), Stuttgart, Germany

Eric H.A.J. Van Dijk Energieonderzoek Centrum Nederland, Petten, The Netherlands

Bram Van der Drift Energieonderzoek Centrum Nederland, Petten, The Netherlands

Christiaan M. Van der Meijden Energieonderzoek Centrum Nederland, Petten, The Netherlands

Frédéric Vogel Paul Scherrer Institut, Villigen, Switzerland

Berend J. Vreugdenhil Energieonderzoek Centrum Nederland, Petten, The Netherlands

Christian Zuber Agnion Highterm Research GesmbH, Graz, Austria

Ulrich Zuberbühler Center for Solar Energy and Hydrogen Research (ZSW), Stuttgart, Germany

1INTRODUCTORY REMARKS

Tilman J. Schildhauer

1.1 WHY PRODUCE SYNTHETIC NATURAL GAS?

The answer to this question [which may also explain why one should read a book on synthetic natural gas (SNG) production] changes with time.

During the years from 1950 to the early 1980s, SNG production was an important topic, mainly in the United States, in the United Kingdom, and in Germany. The interest was caused by a couple of reasons. In these countries, a relative abundance of coal and the expected shortage of natural gas triggered several industrial initiatives, partly funded by public authorities, to develop processes from coal to SNG. Due to the oil crisis during the 1970s, the use of domestic coal rather than the import of oil became a second motivation. A third motivation is the possibility to make domestic (low quality) energy reserves available de‐centrally as an energy carrier for which the distribution infrastructure already exists and that allows for both clean and efficient use by consumers.

These boundary conditions lead in 1984 to the start‐up of the 1.5 GWSNG plant in Great Plains which is run by the Dakota Gas Company and converts lignite into SNG and many other products. This plant stayed the only commercial SNG production for nearly 30 years because, with the drop of the oil price in the mid1980s, the exploration of natural gas in the North Sea, and the gas pipelines between Russia and Europe, the interest in SNG from coal ceased.

Especially in the United States, the interest came back in the years after the turn of the millennium, now triggered by the again rising oil price and the meanwhile established use of CO2 (which is an inherent by‐product of coal to SNG plants) for enhanced oil recovery (EOR). Back then, a dozen coal to SNG projects were started, including EOR. Now, due to the rapidly increasing exploitation of the shale gas and the connected possibility for a significant reduction of CO2 emission, all the projects in the United States have been stopped.

However, all the mentioned motivations for SNG production, that is, shortage of domestic natural gas, use of domestic coal reserves which are far away from the highly populated areas, and the possibility for clean and efficient combustion, still prevail in China. Therefore, China is now by far the most important market for the production of SNG from coal. Three large plants have started operation, and further plants are planned or under construction.

In Europe, several aspects triggered a reconsideration of SNG production about 15 years ago. Due to its cleaner combustion and inherently lower CO2 emission, using natural gas in transportation (e.g., for CNG cars) is supported in many countries and has even been economically beneficial for the past few years due to the lower gas price. With the aim of the European Commission to replace up to 20% of European fuel consumption by biofuel, replacing natural gas partly with bio‐methane becomes necessary. So far, bio‐methane is mostly produced by up‐grading biogas from anaerobic digestion. However, due to the limited amount of substrate, this pathway cannot be increased much more and other sources of bio‐methane are sought.

Additionally, many European countries wish to use their domestic biomass resources for energy production in order to decrease CO2 emissions and the import of energy. A major part of the biomass is ligno‐cellulosic (mostly wood) and mainly used for heating, for example, in wood pellet heating. As the heat demand is generally decreasing due to better building insulation, the conversion of wood to high value forms of energy, that is, electricity and fuels, is of increasing interest. Like in the case of coal, conversion to fuels requires (so far) gasification as the first step. As shown by process simulations and the first demonstration plants, the conversion of wood to SNG can reach significantly higher efficiencies than conversion to liquid fuels.

Very recently, a third aspect began to gain greater importance, especially in Central Europe. Due to the increasing integration of stochastic renewable sources like photovoltaics and wind energy into electricity generation, the demand for balancing the electricity supply and the demand over spatial and temporal distances is increasing. For the future, even the seasonal storage of electricity may be necessary. Here, the production of SNG can play an important role. While the gasification of solid feedstocks is a more or less continuous process, the further conversion to electricity or SNG can be flexibly adjusted to the balancing needs of the electricity grid within so‐called polygeneration schemes.

Moreover, in times where the electricity production from renewables exceeds the actual demand in the electricity grid (a situation that today occasionally is observed in Central Europe and is expected to be more common in future), producing SNG could utilize the excess electricity instead of curtailing photovoltaics or wind turbines. In so‐called power to gas applications, hydrogen is produced from excess electricity by electrolysis of water and then converted to SNG by methanation of carbon oxides. As a source of carbon oxides, biogas, producer gas from (biomass) gasification, flue gas from industry, or even CO2 from the atmosphere can be considered, opening a pathway to produce SNG without solid feedstock that can be stored or transported over long distances within the existing natural gas infrastructure.

1.2 OVERVIEW

This book aims at a suitable overview over the different pathways to produce SNG (Figure 1.1).

Figure 1.1 The different pathways to produce SNG.

The first four chapters cover the main process steps during conversion of coal and dry biomass to SNG: gasification, gas cleaning, methanation, and gas upgrading. The main technology options will be highlighted and the impact of a technology choice for downstream processes and the complete process chain. In these chapters, especially in the chapter on methanation reactors, the state of the art coal to SNG processes are discussed in detail.

The following chapters describe a number of novel processes for the production of SNG with their specific combination of process steps as well as the boundary conditions for which the respective process was developed. These processes comprise those which are already in operation (e.g., the 20 MWSNG bio‐SNG production in Gothenburg, Sweden, or the 6 MWSNG power to gas plant in Werlte, Germany) and processes which are still under development.

The gasification chapter covers the thermodynamics of gasification and presents both coal and biomass gasification technologies.

The gas cleaning chapter discusses the impurities to be expected in gasification‐derived producer gas, explains the state of the art gas cleaning technologies, and focuses on the innovative gas cleaning steps which are developed for hot gas cleaning.

The chapter on methanation reactors presents the chemical reactions proceeding inside the reactors, their thermodynamic limitation and their reaction mechanisms. Further, an overview of the different reactor types with their advantages and challenges is given covering coal to SNG, biomass to SNG and power to gas processes. The last section of this chapter focuses on the modeling and simulation of methanation reactors, including the necessary experiments to determine reaction kinetics and to generate data for model validation.

The chapter on gas‐upgrading discusses technologies for gas drying, CO2 and hydrogen removal based on adsorption, absorption, and membranes and includes a techno‐economic comparison.

The chapter on the GoBiGas project (“Gothenburg Bio Gas”) presents the boundary conditions and technologies applied in the 20 MWSNG wood to SNG plant in Gothenburg, Sweden, which was commissioned in 2014.

The next chapter explains the development of the power to gas process at the Zentrum für solare Wasserstofferzeugung (ZSW), including the 6 MWSNG plant in Werlte, Germany.

The chapter on fluidised bed methanation describes the process development at the Paul Scherrer Institut aiming at a flexible technology for efficiently converting wood to SNG and for hydrogen conversion within power to gas applications.

The following chapter presents the technologies developed at the Energy Center of the Netherlands (ECN) for efficient SNG production from wood, especially their allothermal gasification technology (MILENA) and their broad experience with gas cleaning.

The chapter on hydrothermal gasification discusses the unique technology allowing for the simultaneous catalytic gasification and methanation of wet biomass under super‐critical conditions.

The chapter on agnion’s small scale SNG concept focuses on two novel technologies that allow for significant process simplification, especially in small scale bio‐SNG plants: the pressurized heatpipe reformer and the polytropic fixed bed methanation.

The last chapter offers a view on the research for even more simplified SNG processes, that is, for methanation steps that allow for integrated desulfurization and methanation.

The author of these lines wishes to express his gratitude, especially to the contributors of this book and to the persons at the publisher for their excellent work, but also to all colleagues, scientific collaborators, partners, friends and scientists in the community for many fruitful and interesting discussions. All of you bring the field forward and made this book possible.
