Tunnel Field-effect Transistors (TFET) E-Book

Jagadesh Kumar Mamidala

• Herausgeber: John Wiley & Sons
• Kategorie: Wissenschaft und neue Technologien
• Sprache: Englisch

Seitenzahl: 275

Veröffentlichungsjahr: 2016

Beschreibung

Research into Tunneling Field Effect Transistors (TFETs) has developed significantly in recent times, indicating their significance in low power integrated circuits. This book describes the qualitative and quantitative fundamental concepts of TFET functioning, the essential components of the problem of modelling the TFET, and outlines the most commonly used mathematical approaches for the same in a lucid language. Divided into eight chapters, the topics covered include: Quantum Mechanics, Basics of Tunneling, The Tunnel FET, Drain current modelling of Tunnel FET: The task and its challenges, Modeling the Surface Potential in TFETs, Modelling the Drain Current, and Device simulation using Technology Computer Aided Design (TCAD). The information is well organized, describing different phenomena in the TFETs using simple and logical explanations. Key features: * Enables readers to understand the basic concepts of TFET functioning and modelling in order to read, understand, and critically analyse current research on the topic with ease. * Includes state-of-the-art work on TFETs, attempting to cover all the recent research articles published on the subject. * Discusses the basic physics behind tunneling, as well as the device physics of the TFETs. * Provides detailed discussion on device simulations along with device physics so as to enable researchers to carry forward their study on TFETs. Primarily targeted at new and practicing researchers and post graduate students, the book would particularly be useful for researchers who are working in the area of compact and analytical modelling of semiconductor devices.

Leseprobe

Tunnel Field-Effect Transistors (TFET)

Modelling and Simulation

Jagadesh Kumar Mamidala

Indian Institute of Technology (IIT), Delhi, India

Rajat Vishnoi

Indian Institute of Technology (IIT), Delhi, India

Pratyush Pandey

University of Notre Dame, Indiana, USA

This edition first published 2017© 2017 John Wiley & Sons, Ltd

Registered OfficeJohn Wiley & Sons, Ltd, The Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, United Kingdom

For details of our global editorial offices, for customer services and for information about how to apply for permission to reuse the copyright material in this book please see our website at www.wiley.com.

The right of the author to be identified as the author of this work has been asserted in accordance with the Copyright, Designs and Patents Act 1988.

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, except as permitted by the UK Copyright, Designs and Patents Act 1988, without the prior permission of the publisher.

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic books.

Designations used by companies to distinguish their products are often claimed as trademarks. All brand names and product names used in this book are trade names, service marks, trademarks or registered trademarks of their respective owners. The publisher is not associated with any product or vendor mentioned in this book.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. It is sold on the understanding that the publisher is not engaged in rendering professional services and neither the publisher nor the author shall be liable for damages arising herefrom. If professional advice or other expert assistance is required, the services of a competent professional should be sought.

Library of Congress Cataloging-in-Publication Data

Names: Kumar, Mamidala Jagadesh, author. | Vishnoi, Rajat, author. | Pandey, Pratyush, author.Title: Tunnel field-effect transistors (TFET) : modelling and simulations / Jagadesh Kumar Mamidala, Rajat Vishnoi and Pratyush Pandey.Description: 1 | Hoboken : Wiley, 2016. | Includes bibliographical references and index.Identifiers: LCCN 2016023165 (print) | LCCN 2016041464 (ebook) | ISBN 9781119246299 (hardback) | ISBN 9781119246282 (pdf) | ISBN 9781119246305 (epub)Subjects: LCSH: Tunnel field-effect transistors. | Integrated circuits-Design and construction. | Nanostructured materials. | Low voltage integrated circuits. | BISAC: TECHNOLOGY & ENGINEERING / Electronics / Semiconductors.Classification: LCC TK7871.95 .K86 2016 (print) | LCC TK7871.95 (ebook) | DDC 621.3815/284–dc23LC record available at https://lccn.loc.gov/2016023165

A catalogue record for this book is available from the British Library.

Preface

Overview

Just as a human body is made up of millions of biological cells, an integrated circuit is made up of millions of transistors. Transistors are the basic building blocks of all modern electronic gadgets. Ever since the advent of CMOS circuits, the dimensions of the transistor have been continuously scaled down in order to pack more logic on to a silicon wafer and also to reduce power consumption in the circuits. In recent years, with mobile devices becoming popular, the search for low power devices with steep switching characteristics has become important. Highly scaled MOSFETs are rendered unsuitable for low power applications due to a thermal limit on their switching. Hence, the Tunnel Field Effect Transistor (TFET) is being explored extensively for low power applications. A TFET has a steep switching characteristic as it works on the phenomena of band-to-band tunnelling. Over the past few years, TFETs have been heavily researched by various notable groups in the field of semiconductor devices across the globe.

This book provides a comprehensive guide for those who are beginning their study on TFETs and also as a guide for those who wish to design integrated circuits based on TFETs. The book covers the essential physics behind the functioning of the TFETs and also the device modelling of TFETs, for the purpose of circuit design and simulation. It begins with studying the basic principles of quantum mechanics and then builds up to the physics behind the quantum mechanical phenomena of band-to-band tunnelling. This is followed by studying the basic functioning of TFETs and their different structural configurations. After explaining the functioning of TFETs, the book describes different approaches used by researchers for developing the drain current models for TFETs. Finally, to help new researchers in the field of TFETs, the book describes the process of carrying out numerical simulations of TFETs using the TCAD tool Silvaco ATLAS. Numerical simulations are helpful tools for studying the behaviour of any semiconductor device without getting into the complex process of fabrication and characterisation.

Key feature in relation to existing literature

This book is the first comprehensive literature on TFETs, which are very popular transistors and have been extensively studied in recent years; they are going to be important building blocks for low power solid state circuits in the future. It is a one-stop volume for studying TFETs for someone who has a basic knowledge of MOSFET physics. It covers the physics behind the phenomena of tunnelling as well as the device physics of TFETs. It also has a unique feature of describing device simulation along with device physics so as to enable readers to do further research on TFETs.

The presentation of the book is clear and accurate and is written in simple language. The book endeavours to explain different phenomena in the TFETs using simple and logical explanations so as to enable the reader to get a real feel for the functioning of the device. Also, each and every aspect of the TFET has been compared to that of the MOSFET so that the facts presented in the book make more sense to the entire semiconductor device fraternity and help in the integration of the TFET with the prevailing technology in the industry. The book also attempts to cover all the recent research articles published on TFETs so as to make sure that, along with covering the basics, it also covers state of the art work on TFETs.

1Quantum mechanics

1.1 Introduction to quantum mechanics

Before attempting to investigate the workings of a tunnelling field-effect transistor, it is essential to be familiar with the concept of tunnelling. Tunnelling is a quantum phenomenon, with no counterpart in the everyday physics one encounters, or the physics that one applies while dealing with devices a few hundred nanometres in length. The initial two chapters will, therefore, help us develop an understanding of quantum phenomena. In this chapter, we will present an introduction to the field of quantum mechanics and the next chapter will discuss the phenomenon of tunnelling in detail.

The chapter begins with a description of a landmark experiment that conclusively proved the wave nature of particles, after which we will study the concept of wavefunctions and how to use Schrodinger’s equation to obtain them. A few basic problems will be presented so that the readers may familiarise themselves with basic quantum concepts.

1.1.1 The double slit experiment

There are many experiments that led to the conception of quantum mechanics – blackbody radiation, the Stern Gerlach experiment, the photoelectric effect, the line spectrum, etc. However, for our purposes we will concentrate on one of the landmark experiments, that is the double slit experiment, which demonstrated the fundamental quantum nature (i.e. both wave and particle) of electrons.

You would have read that only waves can undergo superposition, and not particles. Superposition is the fundamental principle behind the occurrence of interference – therefore, if something exhibits interference, it must have a wave nature. The double slit experiment is famously associated with Thomas Young, who used it for the first time in the early nineteenth century to prove the wave nature of light. Before this experiment was performed, light had been associated with a particle nature (since the times of Newton), and the fact that it underwent interference was conclusive proof of its wave nature.

However, the behaviour of light that led Newton and others to believe that it had a particle nature could not be reconciled with this newly formed wave picture. It took another century of research and experiments to establish a rather astonishing result regarding the behaviour of light – that it displays both particle and wave natures. The particle nature leads to phenomena such as the photoelectric effect and rectilinear propagation of light in ray optics; the wave nature explained the interference and diffraction of light.

While this dual nature (that is both particle and wave natures) of light was being worked out, many people were, independently, studying the behaviour of subatomic particles. Phenomenon like the discrete line spectrum of hydrogen, the observed distribution of blackbody radiation, etc., could not be explained by any established theory. Theoretical physicists were in a quandary. At this point, de Broglie hypothesised that, just like light, particles possess a dual nature as well. When de Broglie made this hypothesis, there was little evidence to support his claim. A few years later, Davisson and Germer experimentally observed that electrons underwent diffraction just as light did. These were landmark moments in the history of physics – de Broglie received the Nobel Prize in physics (the second time it was awarded for a PhD thesis) and, later, so did Davisson and Germer. While the Davisson–Germer experiment was the first to establish the dual nature of matter, the double slit interference experiment is far easier to conceptually grasp and visualise, which is why we will use it to embark on our study of quantum phenomena.

The setup of an electron interferometer used in the double slit experiment is conceptually quite similar to that of a light interferometer (Figure 1.1). A parallel beam of electrons is incident on a screen with two slits. The electrons that pass through the slits impinge upon the optical screen, where their incidence is captured by a visible spot. First, let us think of these electrons as if they were the kind of particles we observe in our daily lives (classical particles) and see how they should behave. All the electrons in the initial beam have the same speed and direction of motion and they are heading towards the screen with two slits. All the electrons that hit this screen are blocked, except for the ones passing right through the slits. These electrons that passed through the slits should have no reason to change either their speed or the direction of their motion. They do not “know” that there was a screen in the first place – they pass through unaffected. They subsequently keep heading straight and hit the final screen as illustrated in Figure 1.1(a). Two narrow bands are formed on the screen, corresponding to the two thin beams of electrons that passed unaffected through the two small slits.

Figure 1.1(a) Classically predicted electron pattern. It can be seen that interference fringes are experimentally observed, as opposed to the classically predicted pattern. This establishes the wave-like behaviour of electrons, (b) experimentally observed electron pattern.

Now let us take a look at what was actually observed in the experiment. There was an interference pattern on the screen, as shown in Figure 1.1(b), a pattern uncannily similar to what is observed when we perform the same experiment with light instead of electrons. At this juncture, you might hypothesise this behaviour to result from some sort of statistical phenomenon due to the large number of electrons. However, the experiment is far from finished, and further strangeness lies ahead.

Let us now adjust the electron source so that instead of a beam of electrons it sends a single electron at a time. This time, we find something even more extraordinary – after a lot of electrons have hit the screen, the same interference pattern builds up as in the case of a beam of many electrons. There is no way this electron “knows” that it has been preceded by, or it will be followed by, another electron. What, then, could be happening? The answer is even more puzzling than the question, and will take you quite a while to come to terms with – each and every electron is undergoing interference with itself. This is what leads to the final conclusion that not just aggregates of particles but each and every particle exhibits a wave nature. To make this point clear, let us modify the experiment such that we are able to find out through which slit each electron passes. Independent of how we find out which slit each electron passes through, we get exactly the same result, that is the interference pattern vanishes and we get the pattern shown in Figure 1.1(a), as predicted by classical mechanics. Think about this very carefully, because this point merits serious investigation. For a wave to show interference, there need to be two sources – the two slits in this case. Thus, for a single electron to show interference, it must be passing through both slits. However, this is not possible! At the very least, we cannot imagine such a situation. It is only reasonable to assume that the electron either goes through one slit or the other, but the moment we impose such a restriction on the electron, we are thinking of it as a classical particle. By just knowing which slit the electron is going through, and thereby imposing the condition that it will pass through either one slit or the other, we are restricting it to behave like a classical particle. While the mathematical foundations will be laid later in this chapter, for now the reader should try and grasp the underlying concept – the quantum electron passes through both the slits; it is a superposition of these two states (corresponding to passing through the upper or lower slit). You may think that the electron actually passes through either of the two slits and due to limitations of our experimental techniques, we do not know which slit it passes through. This is not the case – the electron is indeed passing through both the slits. This counterintuitive phenomenon is at the very root of quantum mechanics and it will take some time for us to be familiar with this kind of approach. You cannot ask of the quantum electron (or any general quantum particle), “Which slit does it pass through?” The question in itself is wrong. It passes through both. It should be noted that this wave nature of a particle becomes appreciable only at very small sizes, such as a few nanometres.

1.1.2 Basic concepts of quantum mechanics

1.1.2.1 Wavefunctions

The behaviour of classical particles can be fully explained by describing how their position changes with time. This information would be sufficient to give us the trajectory, the velocity, the momentum and the acceleration of the particle. However, what of the quantum particle? Surely, the electron that passed through both slits of the double slit experiment cannot be assigned a precise location. This leads us to the realisation that we need some new method to describe the quantum particle. The rest of this chapter is devoted to formulating a mathematical picture that is able to capture the unusual behaviour of quantum particles.

The search for this new method of description was helped by the knowledge that the quantum behaviour of particles closely resembled the behaviour displayed by waves. Waves of many kinds – electromagnetic waves, sound waves, etc. – had been extensively studied, and all these waves were described by wave equations. These equations described the behaviour of a wave at every point in space, and at all times. For example, in the case of sound waves, the wave equation described the displacement ( ) of each particle as a function of time:

(1.1)

Similarly, for an electromagnetic wave, the wave equations described the electric () or magnetic () field at each and every point as a function of time:

(1.2)

(1.3)

Taking the cue from these equations, physicists assigned a similar wave equation to the quantum particle. This equation was called the wavefunction of the quantum particle and was usually denoted by the Greek symbol ψ
