Visible Light Communications

Modulation and Signal Processing

Zhaocheng Wang

Qi Wang

Wei Huang

Zhengyuan Xu

Copyright © 2017 by The Institute of Electrical and Electronics Engineers, Inc. All rights reserved.

Published by John Wiley & Sons, Inc., Hoboken, New Jersey. Published simultaneously in Canada.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, scanning, or otherwise, except as permitted under Section 107 or 108 of the 1976 United States Copyright Act, without either the prior written permission of the Publisher, or authorization through payment of the appropriate per-copy fee to the Copyright Clearance Center, Inc., 222 Rosewood Drive, Danvers, MA 01923, [phone], fax [phone], or on the web at www.copyright.com. Requests to the Publisher for permission should be addressed to the Permissions Department, John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, [phone], fax [phone], or online at http://www.wiley.com/go/permission.

Limit of Liability/Disclaimer of Warranty: While the publisher and author have used their best efforts in preparing this book, they make no representations or warranties with respect to the accuracy or completeness of the contents of this book and specifically disclaim any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives or written sales materials. The advice and strategies contained herein may not be suitable for your situation. You should consult with a professional where appropriate. Neither the publisher nor author shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

For general information on our other products and services or for technical support, please contact our Customer Care Department within the United States at [phone], outside the United States at [phone] or fax [phone].

Wiley also publishes its books in a variety of electronic formats. Some content that appears in print may not be available in electronic formats. For more information about Wiley products, visit our web site at www.wiley.com.

Library of Congress Cataloging-in-Publication Data is available.

ISBN: 978-1-119-33138-4

CONTENTS

Preface

1 Introduction to Visible Light Communications

1.1 History

1.2 Advantages and applications

1.3 Overview of modulation and signal processing

1.4 Standards

References

2 Visible Light Communications: Channel and Capacity

2.1 LED characteristics

2.2 LED lighting constraints

2.3 Photodiode characteristics

2.4 Propagation links

2.5 Noise in VLC systems

2.6 Channel capacity

2.7 Conclusion

References

3 Single Carrier/Carrierless Modulation and Coding

3.1 Pulse amplitude modulation

3.2 Pulse position modulation

3.3 Carrierless amplitude phase modulation

3.4 Modulation and coding schemes for dimmable VLC

3.5 Conclusion

References

4 Multicarrier Modulation

4.1 Optical OFDM for visible light communications

4.2 Performance enhancement for optical OFDM

4.3 Spectrum- and power- efficient optical OFDM

4.4 Optical OFDM under lighting constraints

4.5 Conclusion

References

5 Multicolor Modulation

5.1 Color shift keying

5.2 CSK with coded modulation

5.3 Wavelength division multiplexing with predistorion

5.4 Conclusion

References

6 Optical MIMO

6.1 Non-imaging optical MIMO techniques

6.2 Imaging optical MIMO techniques

6.3 Multiuser precoding techniques

6.4 Optical MIMO-OFDM

6.5 Conclusion

References

7 Signal Processing and Optimization

7.1 Sum-rate maximization for the multi-chip based VLC system

7.2 Heterogeneous VLC-WiFi optimization

7.3 Signal estimation and modulation design for VLC with SDGN

7.4 Conclusion

References

8 Optical Camera Communication: Fundamentals

8.1 Why OCC

8.2 OCC applications: beyond imaging

8.3 Fundamentals of OCC

8.4 Capacity bounds for OCC

8.5 Outage capacity for OCC with misalignment

8.6 Conclusion

References

9 Optical Camera Communication: Modulation and System Design

9.1 Coding and decoding

9.2 Modulation schemes

9.3 System impairment factors

9.4 Synchronization in OCC

9.5 OCC system experimental platform

9.6 Conclusion

References

10 Index

IEEE PRESS SERIES ON DIGITAL AND MOBILE COMMUNICATION

EULA

List of Tables

Chapter 3

Table 3.1

Table 3.2

Chapter 5

Table 5.1

Table 5.2

Table 5.3

Table 5.4

Table 5.5

Chapter 6

Table 6.1

Table 6.2

Table 6.3

Table 6.4

Table 6.5

Chapter 7

Table 7.1

Table 7.2

Table 7.3

Chapter 8

Table 8.1

Table 8.2

Table 8.3

Table 8.4

Table 9.1

Guide

Cover

Table of Contents

Preface

Pages
