- Herausgeber: John Wiley & Sons
- Kategorie: Fachliteratur
- Sprache: Englisch
Provides an easy-to-read introduction to the area of polymer flooding to improve oil production The production and utilization of oil has transformed our world. However, dwindling reserves are forcing industry to manage resources more efficiently, while searching for alternative fuel sources that are sustainable and environmentally friendly. Polymer flooding is an enhanced oil recovery technique that improves sweep, reduces water production, and improves recovery in geological reservoirs. This book summarizes the key factors associated with polymers and polymer flooding--from the selection of the type of polymer through characterization techniques, to field design and implementation--and discusses the main issues to consider when deploying this technology to improve oil recovery from mature reservoirs. Essentials of Polymer Flooding Technique introduces the area of polymer flooding at a basic level for those new to petroleum production. It describes how polymers are used to improve efficiency of "chemical" floods (involving surfactants and alkaline solutions). The book also offers a concise view of several key polymer-flooding topics that can't be found elsewhere. These are in the areas of pilot project design, field project engineering (water quality, oxygen removal, polymer dissolution equipment, filtration, pumps and other equipment), produced water treatment, economics, and some of the important field case histories that appear in the last section. * Provides an easy to read introduction to polymer flooding to improve oil production whilst presenting the underlying mechanisms * Employs "In A Nutshell" key point summaries at the end of each chapter * Includes important field case studies to aid researchers in addressing time- and financial-consumption in dealing with this issue * Discusses field engineering strategies appropriate for professionals working in field operation projects Essentials of Polymer Flooding Technique is an enlightening book that will be of great interest to petroleum engineers, reservoir engineers, geoscientists, managers in petroleum industry, students in the petroleum industry, and researchers in chemical enhanced oil recovery methods.
Sie lesen das E-Book in den Legimi-Apps auf:
Seitenzahl: 331
Veröffentlichungsjahr: 2019
Ähnliche
Table of Contents
Cover
Preface
Abbreviations
About the Author
Introduction
Chapter one: Why Enhanced Oil Recovery?
1.1. What Is a Reservoir?
1.2. Hydrocarbon Recovery Mechanisms
1.3. Definitions of IOR and EOR
1.4. What Controls Oil Recovery?
1.5. Classification and Description of EOR Processes
1.6. Why EOR? Cost, Reserve Replacement, and Recovery Factors
References
Chapter two: Chemical Enhanced Oil Recovery Methods
2.1. Introduction
2.2. Chemical EOR Methods
References
Chapter three: Polymer Flooding
3.1. Introduction
3.2. Concept
3.3. Envelope of Application
3.4. Conclusions
References
Chapter four: Polymers
4.1. Introduction
4.2. Polyacrylamide – Generalities
4.3. Polymer Selection Guidelines
4.4. Polymer Characteristics and Rheology
4.5. Polymer Stability
4.6. Laboratory Evaluations
References
Chapter five: Polymer Flooding–Pilot Design
5.1. Reservoir Screening – Reminder
5.2. Pilot Design
5.3. Injectivity
5.4. Monitoring
5.5. Modeling
5.6. Quality Control
5.7. Specific Considerations for Offshore Implementation
References
Chapter six: Engineering
6.1. Preliminary Requirements
6.2. Injection Equipment for Emulsions
6.3. Injection Equipment for Powders
6.4. Field Development Approaches Onshore
6.5. Key Considerations for Offshore Implementation
6.6. ASP Process
6.7. From the Dissolution Point to the Wellhead
References
Chapter seven: Produced Water Treatment
7.1. Introduction
7.2. Generalities
7.3. Oil and Gas Separation
7.4. Water Treatment
7.5. Polymer Degradation
7.6. Conclusions and Discussion
References
Chapter eight: Economics
8.1. Introduction
8.2. Cost Overview
8.3. Example – Polymer Flooding
8.4. Examples – SP and ASP
8.5. Conclusions
References
Chapter nine: Field Cases
9.1. Introduction
9.2. Envelope of Application
9.3. Other Interesting Field Cases
9.4. Conclusions
References
Index
End User License Agreement
List of Tables
Chapter 2
Table 2.1 List of ASP floods, modified from [28].
Chapter 3
Table 3.1 Envelope of application for polymer injection in 1978 [15].
Table 3.2 Screening criteria after Sorbie [14].
Table 3.3 Current envelope of application for polymers in EOR.
Table 3.4 Parameters to consider when screening candidates for polymer flooding
Chapter 4
Table 4.1 Empiric correlation between average molecular weight and absolute rock...
Table 4.2 Examples of filter ratio procedures (from [14]).
Table 4.3 Example of basic specification for quality control of polymer in powde...
Chapter 6
Table 6.1 Comparison between powder and emulsion quantities required for two fie...
Chapter 7
Table 7.1 Cationic demand and coagulant addition required as a function of polym...
Table 7.2 Summary of existing water treatment technologies and their relative ef...
Chapter 8
Table 8.1 Example of water injection costs
Table 8.2 Cost split by category for waterflooding
Table 8.3 Typical range of costs for the chemicals used in enhanced oil recovery...
Table 8.4 Characteristics of the five‐spot pattern used in the calculations
Table 8.5 Summary of injection parameters for the five‐spot pattern – polymer in...
Table 8.6 Cost of recovery as a function of the percentage of extra oil recovere...
Table 8.7 Typical equipment‐related costs
Table 8.8 Summary of injection parameters – surfactant‐polymer injection
Table 8.9 Summary of injection parameters – alkali‐surfactant‐polymer injection
Table 8.10 Comparison of relative costs for P, SP, and ASP injections
Chapter 9
Table 9.1 Field characteristics of Eastern European field 1
Table 9.2 Field characteristics of Eastern European field 2
Table 9.3 Field characteristics of Brintnell‐Pelican Lake
Table 9.4 List of recent chemical EOR injections
List of Illustrations
Chapter 1
Figure 1.1 Petroleum system and oil‐bearing reservoirs.
Figure 1.2 Hydrocarbon recovery mechanisms
Figure 1.3 Areal and vertical sweep efficiency are parameters controlli...
Figure 1.4 Cyclic steam stimulation.
Figure 1.5 Steam flood process
Figure 1.6 In situ combustion process.
Figure 1.7 CO
2
miscible process.
Chapter 2
Figure 2.1
Figure 2.2 Comparison of polymer flooding and waterflood: the injection...
Figure 2.3 Comparison of polymer flooding and waterflood: the injection...
Figure 2.4 Schematic illustration of vertical conformance improvement d...
Figure 2.5 Schematic illustration of horizontal conformance improvement...
Figure 2.6 Mobilization of trapped oil during a surfactant‐polymer (SP)...
Figure 2.7 Hydrophilic lipophilic balance (HLB)
Figure 2.8 Categories of surfactants used in chemical EOR.
Figure 2.9 Alkali‐surfactant‐polymer process.
Figure 2.10 Looking for a Winsor III configuration. Salinity scan perfo...
Figure 2.11 ASP production response at Warner Mannville B Glauconitic s...
Figure 2.12 Comparison of gel treatment and polymer flooding. The gel t...
Figure 2.13 Delayed microgels – characteristics and principle of applic...
Chapter 3
Figure 3.1 Fractional flow curves for three mobility ratios and corres...
Figure 3.2 Flow profiles for two injection cases – unfavorable mobility...
Figure 3.3 Comparison of fluid distribution in a water‐wet and an oil‐w...
Figure 3.4 Impact of increasing salinity (and R
+
) on the viscosity of a...
Chapter 4
Figure 4.1 From monomers to polymers: the polymerization process
Figure 4.2 Acrylamide monomer
Figure 4.3 Acrylic acid monomer
Figure 4.4 ATBS monomer
Figure 4.5 Radical polymerization
Figure 4.6 Gel polymerization process
Figure 4.7 Inverse emulsion preparation. Emulsification steps: mixing o...
Figure 4.8 Powder vs. emulsion product forms.
Figure 4.9 Polymer molecular weight distribution.
Figure 4.10 Viscosity vs. temperature for thermoresponsive polymers.
Figure 4.11 Solvent viscosification process by polymer addition.
Figure 4.12 Viscosity variations vs. R
+
for polymers with increasing pe...
Figure 4.13 Apparent viscosity of a polyacrylamide solution as a functi...
Figure 4.14 Chemical degradation by free radical generated by the Red/O...
Figure 4.15 Mechanical degradation.
Figure 4.16 Long‐term stability of different polymer chemistries vs. te...
Figure 4.17 Emulsion inversion process: injection into a vortex.
Figure 4.18 Filter ratio test.
Figure 4.19 Repeatability of filter ratio tests with different nitrocel...
Figure 4.20 Brookfield viscometer and UL module.
Figure 4.21 Glove box.
Figure 4.22 Rheology of a polyacrylamide solution in a porous medium.
Figure 4.23 Determining retention and inaccessible pore volume with the...
Figure 4.24 Proposed mechanism for the use of polyacrylamide as a nitro...
Chapter 5
Figure 5.1 Polymer flooding: from design to implementation
Figure 5.2 Five‐spot and inverted five‐spot patterns
Figure 5.3 Pressure drop average vs. Reynolds number in a 4″ pipe. Comp...
Figure 5.4 Injectivity relative to water, assuming no fractures (extern...
Figure 5.5 Shear vs. distance from the wellbore
Figure 5.6 Hall plot – general description
Chapter 6
Figure 6.1 Example of a skid for polymer preparation
Figure 6.2 Floquip polymer slicing unit – overview
Figure 6.3 Picture of the inside of a skid (PSU at the front, maturatio...
Figure 6.4 Logistics for powder
Figure 6.5 Logistics for EM
Figure 6.6 View of a surfactant‐polymer injection pilot site
Figure 6.7 Inline viscometer
Chapter 7
Figure 7.1 Free‐water knockout tank
Figure 7.2 Deoiling test – use of optimized chemical compositions
Figure 7.3 Induced gas flotation device
Figure 7.4 Principle of walnut‐shell filters
Figure 7.5 Membrane filtration processes
Figure 7.6 Chemical degradation of a polymer solution with hypochlorite...
Figure 7.7 Mechanical degradation of two polymer solutions through a va...
Guide
Cover
Table of Contents
Begin Reading
Pages
iii
xv
xvi
xvii
xix
xx
xxi
xxii
xxiii
xxiii
xxv
xxvi
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
218
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
252
251
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
271
270
272
273
274
275
276
278
277
279
280
281
282
283
284
285
286
287
289
290
291
292
293
294
295
296
297
298
299
300
Essentials of Polymer Flooding Technique
Antoine Thomas
Copyright
This edition first published 2019
© 2019 John Wiley & Sons Ltd
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, except as permitted by law. Advice on how to obtain permission to reuse material from this title is available at http://www.wiley.com/go/permissions.
The right of Antoine Thomas to be identified as the author of this work has been asserted in accordance with law.
Registered Offices
John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, USA
John Wiley & Sons Ltd, The Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, UK
Editorial Office
111 River Street, Hoboken, NJ 07030, USA
For details of our global editorial offices, customer services, and more information about Wiley products visit us at www.wiley.com.
Wiley also publishes its books in a variety of electronic formats and by print‐on‐demand. Some content that appears in standard print versions of this book may not be available in other formats.
Limit of Liability/Disclaimer of Warranty
In view of ongoing research, equipment modifications, changes in governmental regulations, and the constant flow of information relating to the use of experimental reagents, equipment, and devices, the reader is urged to review and evaluate the information provided in the package insert or instructions for each chemical, piece of equipment, reagent, or device for, among other things, any changes in the instructions or indication of usage and for added warnings and precautions. While the publisher and authors have used their best efforts in preparing this work, they make no representations or warranties with respect to the accuracy or completeness of the contents of this work and specifically disclaim all warranties, including without limitation any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives, written sales materials or promotional statements for this work. The fact that an organization, website, or product is referred to in this work as a citation and/or potential source of further information does not mean that the publisher and authors endorse the information or services the organization, website, or product may provide or recommendations it may make. This work is sold with the understanding that the publisher is not engaged in rendering professional services. The advice and strategies contained herein may not be suitable for your situation. You should consult with a specialist where appropriate. Further, readers should be aware that websites listed in this work may have changed or disappeared between when this work was written and when it is read. Neither the publisher nor authors shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.
Library of Congress Cataloging‐in‐Publication Data applied for
ISBN: 9781119537588
A catalogue record for this book is available from the British Library.
Cover Design: Wiley
Cover Images: Polymer Flooding illustration © Cyrille Cizel, Graphiste provided courtesy of Antoine Thomas
Dedication
“...If you have an apple and I have an apple, and we swap apples - we each end up with only one apple. But if you and I have an idea and we swap ideas - we each end up with two ideas.”
Charles F. Brannan
Preface
Polymer flooding was first applied in the early 1960s. A spurt of applications of the process occurred between 1980 and 1986, but innovation was limited because those applications were dominated by tax considerations. However, beginning with the massive Daqing polymer flood in China in 1996, polymer flooding has experienced impressive innovation and growth in field applications. The author of this book works for a company (SNF) that was instrumental in most of the important field applications of polymer flooding throughout the world. As such, SNF acquired a unique perspective on the full range of topics associated with polymer flooding. That perspective is reflected in this book – especially in the last five chapters.
There are several key challenges whose solution would greatly aid the viability of polymer flooding. First, improvements are need in our ability to distribute the energy (induced pressure gradient) from a polymer drive deep into the reservoir (where the vast majority of oil resides). To date, this issue has largely been addressed by in‐fill drilling – that is, placing injection and production wells closer together. Use of parallel horizontal wells has also been of value here. Even so, with existing polymer floods, we often must induce fractures in injection wells to allow economic injection rates for the viscous fluids. Polymer flooding could benefit greatly from improved characterization, placement, and exploitation of fractures (natural and induced) in reservoirs. This is especially true in less‐permeable reservoirs.
A second major area for improvement is reducing retention (sometimes called adsorption) of polymers by the reservoir rock. The polymer must penetrate deep into the porous rock of the reservoir in order to contact and displace the oil. If too much polymer is retained by the rock, the polymer may never penetrate sufficiently into the reservoir. Polymer retention can easily account for the largest economic hurdle in a polymer flood. In the past, laboratory studies (especially on outcrop rock) have often been overly optimistic about retention – especially in less‐permeable rock and for associative polymers. Reduced polymer retention would be of great value.
A third important challenge is in expanding polymer flooding to hotter reservoirs. Great strides have been made in identifying monomers/polymers with sufficient stability for application in these reservoirs. However, the cost and viscosity associated with these polymers are often economically prohibitive. Improved manufacturing methods may be of substantial help here.
Treatment of produced polymer fluids is a fourth critical area for improvement. The viscous nature of polymer solutions often results in produced oil/water emulsions that are difficult to separate. Produced polymer has also been tied to other production problems. New methods to address these issues are needed. An ability to recycle produced polymers would also have value. Improved sampling of produced fluids is also needed, in that knowledge of whether the polymer propagates intact through a formation provides critical guidance to the operation and expansion of a polymer flood.
This book starts at a very basic level, for those with limited prior knowledge of petroleum production. The author's goal is to provide an easy‐to‐read introduction to the area of polymer flooding to improve oil production. The book also describes polymers to improve efficiency of chemical floods (involving surfactants and alkaline solutions). Chapters are short and end with a “nutshell” summary so the reader can quickly grasp the fundamentals. Each chapter also contains key references to allow more detailed examination of individual topics. The first few chapters provide brief introductions to oil recovery, chemical flooding methods, and polymer flooding. Chapter 4 lays out the important characteristics of polymers used for polymer flooding and important tests for their evaluation. Here, it is easy to overlook a crucial contribution that was made to polymer flooding technology by polymer manufacturers. In 1986, when oil prices collapsed from ~$30/bbl to ~$16/bbl, HPAM polymers typically cost about $2/lb. Most oil companies abandoned development of enhanced oil recovery processes because the chorus of oil company managers was, “Chemical flooding for oil recovery will never be viable because the price of polymers (and other chemicals) is tied to oil prices.” However, because of innovations by polymer manufacturers, HPAM prices were commonly around $1/lb in 2012 when oil prices were over $100/bbl.
Chapters 5 through 9 provide a concise view of several key polymer‐flooding topics that can't be found elsewhere. These are in the areas of pilot project design, field project engineering (water quality, oxygen removal, polymer dissolution equipment, filtration, pumps, and other equipment), produced water treatment, economics, and some important field case histories. Overall, this book is essential reading for anyone considering implementation of a polymer flood or chemical flood.
Randy Seright
January 2018
Abbreviations
«
Inches
$
Dollars
%
Percent
°C
Degrees Celsius
μ
Dynamic viscosity
μm
Micrometer
3D
Three dimensions
AIBN
Azobisisobutyronitrile
AMPS
Acrylamido‐2‐methylpropane sulfonic acid
API
American Petroleum Institute
AS
Alkali polymer injection
ASP
Alkali‐surfactant‐polymer injection
ATBS
Acrylamide tertiary butyl sulfonic acid
atm
Atmospheres
bbl
Barrels
BCF
Bioconcentration factor
bpd
Barrels per day
C
30
Molecule composed of 30 carbon atoms
CAPEX
Capital expenditures
CDG
Colloidal dispersion gel
CEOR
Chemical enhanced oil recovery
cm
Centimeters
cm
3
Cubic centimeters
cP
Centipoise
CSS
Cyclic steam simulation
D
Darcy
d
Days
Da
Daltons
DGF
Dissolved gas flotation
DOE
Department of Energy
DR
Drag reduction
EDTA
Ethylenediaminetetraacetic acid
EFSA
European food safety authority
Eh
Oxido‐reduction potential
EOR
Enhanced oil recovery
ERDA
Energy Research and Development Administration
FCM
First‐contact‐miscible
Fe
Iron
FPSO
Floating production storage offloading
ft
Feet
ft/d
Feet/day
fw
Fractional flow
FWKO
Free‐water knockout tank
g
Grams
g/L
Grams per liter
g/mol
Grams per mol
GPC
Gel permeation chromatography
H2S
Hydrogen sulfide
HOCNF
Harmonized Offshore Chemical Notification Format
HLB
Hydrophilic lipophilic balance
HPAM
Anionic polyacrylamide
HSE
Health safety and environment
IFT
Interfacial tension
IGF
Induced gas flotation
IOR
Improved oil recovery
k
Permeability
kcal
Kilocalories
kg
Kilograms
L
Liters
LCST
Lower critical solution temperature
m
Meters
m.s
‐1
Meters per second
m
2
/g
Square meters per gram
mD
Millidarcys
MF
Microfiltration
mL
Milliliters
mm
Millimeters
mN
Millinewtons
mPa
Millipascals
Mw
Molecular weight
N
Newtons
nm
Manometers
NEC
No effect concentration
NPV
Net present value
NVP
N Vinylpyrrolidone
O/W
Oil‐in‐water
OECD
Organization for Economic Co‐operation and Development
OiW
Oil‐in‐water
OOIP
Oil originally in place
OPEX
Operational expenditures
P
Polymer injection
PAN
Polyacrylonitrile
PDI
Polydispersity index
pH
Potential of hydrogen
PLT
Production logging tool
ppb
Parts per billion
ppm
Parts per million
psi
Pounds per square inch
PSU
Polymer slicing unit
PV
Pore volume
PVDF
Polyvinylidene fluoride
Redox
Reduction/Oxidation
Rk
Residual resistance factor
Rm
Resistance factor
RO
Reverse osmosis
rpm
Rotations per minute
s
‐1
Reciprocal second
SAC
Strong acid cation membrane
Sor
Residual oil saturation
SP
Surfactant polymer injection
SPE
Society of Petroleum Engineers
Sw
Water saturation
SWCTT
Single well chemical tracer test
Swi
Initial water saturation
TDS
Total dissolved salts
th. bbl
Thousand barrels
THPS
Tetrakis hydroxymethyl phosphonium sulphate
UF
Ultrafiltration
USA
United States of America
UV
Ultraviolet
VRR
Void replacement ratio
W
Watts
W/O
Water‐in‐oil
WAC
Weak acid cation membrane
WOR
Water‐oil ratio
WSO
Water shut‐off
wt
Weight
η
Kinematic viscosity
About the Author
Antoine THOMAS holds an MSc in petroleum geosciences from the Ecole Nationale Supérieure de Géologie in Nancy, France (2009). He joined SNF in 2011 as a reservoir engineer dealing with polymer flooding project design, implementation, and assistance for customers worldwide. In 2013, he spent part of his time in the R&D department, building the core flooding capacities for SNF and managing R&D projects in enhanced oil recovery (EOR) and hydraulic fracturing. He moved to Moscow in 2018 to supervise the oil and gas business from a technical standpoint, while maintaining contact with all SNF subsidiaries. He has published several papers and enjoys giving public lectures to share important learnings about EOR and hydraulic fracturing.
Thank you to all SNF reviewers and contributors who participated in the production of this book, including: Pascal Remy, René Pich, Nicolas Gaillard, Christophe Rivas, Julien Bonnier, Rémi Marchal, Flavien Gathier, Thierry Duteil, Dennis Marroni, Olivier Braun, Cédrick Favéro, Jean‐Philippe Letullier … and the list continues. A special thank you to my North American reviewing team: Ryan Wilton, Kimberley McEwen, and Matthew Hopkins. Finally, a big thank you to Cyrille Cizel for putting everything together and creating the illustrations. Tremendous work.
Introduction
The energy spectrum of the world has changed dramatically over the last 100 years. Production and utilization of oil, the many offshoot industries it has spawned, and the technological advances developed have literally transformed the world as we see it today. The ubiquitous perception of abundant energy is also slowly changing, as the internet has brought information regarding the geopolitics of energy front and center.
However, have you ever asked people around you – your family, your friends, people at the fitness center – what percentage of oil can be extracted from a reservoir on average? Or, better yet, have you ever discussed with them their understanding of a geologic reservoir? You would probably be surprised to learn how many people think hydrocarbons can be recovered using a straw planted in a big, dark cavern full of oil or gas, or by shooting a bullet into the ground and having “black gold” bubble out. Moving from this fiction to reality requires education, science, time, and observation.
Moving hydrocarbons requires energy. The fossil fuels the world consumes on a daily basis are trapped in a porous material: an ancient, solid sponge formed by the accumulation of sediments over millions of years. What happens if you try to draw water from a sponge with a straw? It it slightly more difficult than simply pulling bulk fluid from a container. This same concept extends to hydrocarbon extraction.
Of the many available methods to produce hydrocarbon reserves, one involves water injection to sweep the oil toward producing wells. While widely deployed, this process (waterflooding) only helps recover approximately 35% of the oil contained in the giant “sponges.”
35%! Really? That's not much.
With 65% of the resource stranded in place, engineers and scientists have worked for decades to develop technical solutions to recover it. Enhanced oil recovery (EOR) technologies have been implemented in various fields around the world, always using a case‐by‐case approach. One such technique consists of injecting viscosified water into the formation to displace the oil, instead of regular water. The viscosity contrast between the injected water and the viscous oil creates instability and promotes water penetration through the oil or complete bypass of the oil via geological highways (i.e. where the sponge or reservoir has the largest connected pores, making the flow much more easily). Increasing the viscosity of the water through the addition of water‐soluble macromolecules (polymers) helps homogenize the displacement in the geologic formation: a larger volume of the sponge is contacted at the same time, leading to more efficient displacement and more oil being produced. This technique is called polymer flooding. It has been implemented since the late 1960s, with large commercial and technical success.
This book aims to summarize the key factors associated with polymers and polymer flooding – from the selection of the type of polymer through characterization techniques, to field design and implementation – discussing the main issues to consider when deploying this technology.
In an attempt to keep things simple, what follows is a pragmatic, rather than exhaustive, review of polymer flooding.
In terms of vocabulary, this is the last time you will read the word sponge; however, it is not the last time you will read the word viscosity!
Chapter oneWhy Enhanced Oil Recovery?
In this chapter, the different production stages of an oil‐bearing formation will be discussed with the goal of introducing enhanced oil recovery (EOR) techniques. Mainly, this chapter will discuss the common terminology used in the industry – which divides the life cycle of an asset into three stages (primary, secondary, and tertiary production) – to show the benefits of starting EOR techniques earlier in the development phase.
1.1. What Is a Reservoir?
The reservoir is an important component of a petroleum system. Oil and gas are formed from the decomposition of organic matter at high temperature and pressure in a source rock. Once formed, they can migrate upward until they either reach the surface and are degraded or are trapped by a seal or cap rock. If trapped, they tend to accumulate within a formation called a reservoir (Figure 1.1). Wells are drilled to reach this formation and start the extraction of the fluids.
Figure 1.1 Petroleum system and oil‐bearing reservoirs.
A reservoir can be defined as subsurface rock formation having sufficient porosity and permeability to store and transmit fluids. Sedimentary rocks are the main formations of interest since they usually have higher porosity than magmatic and metamorphic rocks. Two categories are distinguished: clastic and carbonate rocks. Clastic rocks are formed from other existing rocks after erosion, transport, sedimentation, and burial. Carbonate rocks are mainly biogenic by origin: that is, they result from the accumulation of algae or microorganism remainders.
A good conventional reservoir is one with porosity and permeability high enough to allow the fluid to flow without much additional energy other than fluid expansion, reservoir compaction, or water injection.
Much attention has recently been directed toward so‐called unconventional reservoirs, where it is necessary to adapt the technique to extract the hydrocarbons. This is the case for low permeability (tight) reservoirs or source rocks (shale gas and oil), where multi‐stage, hydraulic fracturing is required to create paths to allow for more facile fluid drainage.
1.2. Hydrocarbon Recovery Mechanisms
Hydrocarbon production is commonly divided into three phases: primary, secondary, and tertiary (Figure 1.2).
Figure 1.2 Hydrocarbon recovery mechanisms
Primary recovery simply refers to the volume of hydrocarbons produced due to the natural energy prevailing in the reservoir or through artificial lift (i.e. pumping) through a single well. Common mechanisms behind primary recovery are as follows:
Depletion drive
Gas cap drive
Gravity drainage
Rock and/or liquid expansion
Aquifer drive
The recovery factor at the end of this stage varies greatly depending upon reservoir and fluid characteristics. It can range from 5% to 40% or more in some cases. For heavy oil reservoirs or tight formations, the value is typically on the low end of this range.
Once the natural energy has been depleted, it is necessary to add energy to maintain or increase production levels to extract the remaining reserves. Thus, the secondary stage of recovery consists of introducing additional energy into the formation via one or several injection wells to drive or sweep the remaining fluids toward production wells. This secondary recovery process typically encompasses water or gas injections or the combination of both.
In the case of water injection, two main strategies may be implemented: (i) water injection for re‐pressurizing and revitalizing the reservoir energy, and (ii) repeating pattern of injectors and producers forming a waterflood.
The tertiary or enhanced recovery stage of development can be significantly increased, reaching 50–60% for the most favorable reservoirs. However, with worldwide recovery factors averaging 35%, the study of techniques to enhance recovery of the remaining 65% left inside the formation is justified. For cases where new reservoir development is undertaken, secondary recovery could be implemented as enhanced oil recovery processes if waterflooding is forgone for transition directly to an EOR process. This could include, for example, a reservoir that is produced on primary production for a short period, after which polymer flood or cyclic steam injection is directly applied.
1.2.1. Anecdote
Between 1965 and 1979, there were five documented attempts to stimulate the production from hydrocarbon reservoirs by detonating nuclear devices in reservoir strata [1]. Three tests were performed in the United States and two in Russia, both aiming at increasing production rates and ultimate recovery from reservoirs. Subsurface explosive devices from 2.3 to 100 kt were used at depths from 1200 to 2560 m, creating post‐shot problems: formation damage, radioactivity, creation of inflammable gases, and smaller‐than‐calculated fractured zones.
1.3. Definitions of IOR and EOR
Two acronyms are often encountered in the oil and gas industry when speaking about increasing the recovery of hydrocarbons: IOR for improved oil recovery and EOR for enhanced oil recovery [2 2 ]. IOR is a more general term, including any method toward increasing oil recovery (i.e. infill drilling, pressure support, operational and injection strategies, field redevelopment). EOR is usually considered a subset of IOR [3] and is often applied to reduce the oil saturation below the value obtained after waterflood, often referred to as the residual oil saturation (Sor) or, more specifically, residual oil saturation to waterflood (Sorw). Also, much interest has been focused on tertiary EOR. However, other definitions do not specifically tie this process to any specific production stage but rather include any method that can be used to increase the total recovery of any given field [4, 5].
1.4. What Controls Oil Recovery?
The efficiency of any recovery process can be defined by how much oil is contacted and displaced in a given reservoir (Figure 1.3). Recovery efficiency, E, is characterized as the product of two terms: (i) macroscopic sweep efficiency (mobilization at the reservoir scale, EV) and (ii) microscopic sweep efficiency (mobilization at the pore scale, ED – also known as the displacement efficiency[4]).
Figure 1.3 Areal and vertical sweep efficiency are parameters controlling oil recovery.
Macroscopic displacement efficiency relates to the volume of the reservoir contacted by the displacing fluid and is typically subdivided into areal and vertical macroscopic sweep efficiencies. This value is impacted by reservoir characteristics (geology, heterogeneities, fractures) and by fluid properties (viscosity, density). For example, it can be improved by maintaining a favorable mobility ratio between the displacing and displaced fluids by adding polymers to viscosify the injected water. This will be discussed in depth in subsequent chapters.
Microscopic displacement efficiency depends on the physical and chemical interactions that occur between the displacing fluid and oil. These include miscibility, wettability, and interfacial tension, which can be changed by adding specific additives to the injected fluid to dislodge the oil from the porous medium.
Equations (1.1) through (1.3) show the relationship and definition of all three efficiencies. ED and EV are typically expressed as fractions.
where Soi, So, and Sor are the initial oil saturation, oil saturation at time t, and residual oil saturation, respectively. Similarly, the initial and current oil formation volume factors, Boi and Bo, represent the volume correction for expansion when fluids are brought to the surface. The terms Vp and Npwf refer to the pore volume (void space containing fluids) and volume of oil recovered during waterflood, respectively.
It is obviously desirable for any EOR process that the values of ED, EV and, therefore, E, are maximized. From a practical standpoint, fluids that possess the ability to enhance both microscopic and macroscopic sweep efficiencies are difficult to develop. Many hurdles can be faced in developing and implementing such a fluid, including the following:
Understanding of the reservoir's heterogeneities, geology, fractures, etc. Processes successfully designed in the laboratory can fail in the field because of geological factors and poor reservoir understanding.
Flow in porous media and fluid interactions (mixing, shearing, adsorption of chemicals, etc.).
Availability of the fluid or formulation, chemicals, etc. If the field considered is large, the volume of required chemicals can be
tremendous
and become an important limiting factor. Manufacturing, supply, logistics, and handling are the critical points to be assessed during the feasibility study, as these govern the actual delivery of chemicals to the remote site.
The choice of the most suitable EOR method requires an upfront clarification of expectations. Given the many uncertainties encountered throughout the process, it is illusory to expect a perfect EOR fluid formulation. De‐risking can be achieved step‐by‐step through pilot tests and pragmatic approaches aimed at solving one problem at a time. A pilot project will be a critical step before considering full‐field development.
1.5. Classification and Description of EOR Processes
EOR methods can be classified in several categories whose exact number depends on the authors and criteria. Green and Willhite [4] considered five categories (mobility‐control, chemical, miscible, thermal, and other processes such as microbial EOR), while Lake [5] described three main subdivisions (thermal, chemical, and solvent methods). A good compromise would be four categories with thermal, chemical, miscible, and other EOR methods (microbial). Although this book is exclusively devoted to chemical methods and polymer flooding in particular, a brief description of each recovery technique will be given next.
1.5.1. Thermal Processes
Thermal processes include hot water injection, steam injection, and in situ combustion. Steam is used in two different ways: cyclic steam stimulation (CSS, Figure 1.4) or steam flood (Figure 1.5). Oil production is increased mainly due to thermal heat transfer, resulting in several mechanisms including oil viscosity reduction, oil swelling, and steam flashing.
Figure 1.4 Cyclic steam stimulation.
Figure 1.5 Steam flood process
For in situ combustion processes (Figure 1.6), air injection is implemented to generate thermal energy within the reservoir, and oil is recovered via viscosity reduction, fluid vaporization (light‐end solvents, CO2), or thermal cracking [6].
Figure 1.6 In situ combustion process.
1.5.2. Chemical Processes
This category includes the injection of water‐soluble polymers, surfactants, and alkali alone or in combination, as well as other chemical cocktails such as microgels and nanogels, aimed at improving oil recovery from a given reservoir via conformance control. Polymers are used to viscosify the injection water and improve the overall sweep efficiency, E. Surfactants (surface active agents) are designed to lower the interfacial tension (IFT) between oil and water, mobilizing capillary‐trapped oil. Alkali is used to synergistically improve the efficiency of surfactants via several mechanisms that will not be described in this section.
Microgels and nanogels are chemical technologies containing small polymer particles whose main goal is to decrease the permeability of thief zones, diverting the water to previously unswept areas. Their design and use is complex and requires a good reservoir understanding.
1.5.3. Miscible Processes
The objective here is to displace the oil with a fluid that is miscible in it, forming a single phase that can be moved through the reservoir (Figure 1.7). Green and Willhite [4] describe two categories:
First‐contact‐miscible
(
FCM
)
. The injected fluid is directly miscible with the oil at the conditions of pressure and temperature encountered in the formation (i.e. liquefied petroleum gas);
Multiple‐contact‐miscible
(
MCM
)
. The injected fluid is not miscible with the oil in the reservoir at first contact. Miscibility occurs when the proper conditions of pressure, temperature, and composition are reached (i.e. carbon dioxide); see
Figure 1.7
.
Figure 1.7 CO2 miscible process.
Screening criteria for the applicability of each method will not be discussed here. References are given at the end of the chapter for further reading.
1.6. Why EOR? Cost, Reserve Replacement, and Recovery Factors
The budgets assigned to EOR developments often compete with other expenses, especially in terms of capital required for exploration (looking for undiscovered fields), new infill drills, injector conversions, maintenance programs (pump replacements, workovers) etc. However, several factors must be considered when evaluating EOR techniques against other development options [3]:
Worldwide oil demand is forecast to increase in the long term.
