Human Oral Mucosa: Development, Structure and Function is a new text that reflects the considerable increase in knowledge of oral mucosa that has occurred in recent years. Our understanding of the structure of oral mucosa is now established at a molecular rather than a tissue or cellular level. This in turn has revealed a level of function that was previously not suspected, including a sophisticated barrier to the penetration of exogenous materials, and the synthesis of specific antimicrobial compounds, representing components of the innate immune system. There is also a growing realization of commonality in structure and function between regions of oral mucosa and the mucosae of the esophagus and vagina. The aim of the present volume is to provide a more sophisticated text on human oral mucosa than presently exists in textbooks and to bring together information that is otherwise to be found in separate, specialist volumes into a comprehensive text. It relates structure at the molecular, cellular and tissue level to function and to clinical behavior. The volume is directed to advanced students and researchers in oral biology, as well as those in allied areas of investigation, such as dermatology, gynecology, internal medicine and pathology.

Leseprobe

Table of Contents

Cover

Table of Contents

Halftitle page

Title page

Copyright page

Preface

1 The functions of oral mucosa

1.1 ORAL MUCOSA: WHAT IS IT AND WHAT DOES IT DO?

1.2 FUNCTIONS OF THE ORAL MUCOSA

2 The organization of oral mucosa

2.1 CLINICAL FEATURES

2.2 COMPONENT TISSUES AND GLANDS

3 Oral epithelium

3.1 HISTOLOGICAL STRUCTURE OF ORAL EPITHELIUM

3.2 EPITHELIAL PROLIFERATION AND TURNOVER

3.3 MOLECULAR AND CELLULAR ORGANIZATION OF ORAL EPITHELIUM

3.4 NON-KERATINOCYTES IN THE ORAL EPITHELIUM

4 The interface between epithelium and connective tissue

4.1 ORGANIZATION OF THE NORMAL INTERFACE

4.2 IMMUNE-MEDIATED SUBEPITHELIAL BLISTERING DISEASES (IMSEBDS)

5 Connective tissue

5.1 LAMINA PROPRIA

5.2 BLOOD SUPPLY

5.3 NERVE SUPPLY

6 Regional differences in the oral mucosa

6.1 STRUCTURAL VARIATIONS IN DIFFERENT REGIONS

6.2 JUNCTIONS IN THE ORAL MUCOSA

7 Development and aging of the oral mucosa

7.1 DEVELOPMENTAL STAGES OF ORAL MUCOSA

7.2 THE CONTROL OF MUCOSAL DEVELOPMENT: EPITHELIAL–MESENCHYMAL INTERACTION

7.3 AGING

8 Barrier functions of oral mucosa

8.1 THE PERMEABILITY BARRIER

8.2 IMMUNOLOGIC BARRIER FUNCTION OF ORAL MUCOSA

9 Homologies in structure and function among mucosae: oral, esophageal, and vaginal mucosa

9.1 ESOPHAGUS

9.2 VAGINA

9.3 ORGANIZATION OF THE TISSUES OF ESOPHAGUS AND VAGINA

9.4 NON-KERATINOCYTES IN ESOPHAGEAL AND VAGINAL MUCOSA

9.5 INFLAMMATORY CELLS

Index

Human Oral Mucosa

Development, Structure, and Function

This edition first published 2011 © 2011 by Christopher Squier and Kim A. Brogden

Wiley-Blackwell is an imprint of John Wiley & Sons, formed by the merger of Wiley’s global Scientific, Technical and Medical business with Blackwell Publishing.

Registered office: John Wiley & Sons Ltd, The Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, UK

Editorial offices: 2121 State Avenue, Ames, Iowa 50014-8300, USA

The Atrium, Southern Gate, Chichester, West Sussex, PO19 8SQ, UK

9600 Garsington Road, Oxford, OX4 2DQ, UK

For details of our global editorial offices, for customer services and for information about how to apply for permission to reuse the copyright material in this book please see our website at www.wiley.com/wiley-blackwell.

Authorization to photocopy items for internal or personal use, or the internal or personal use of specific clients, is granted by Blackwell Publishing, provided that the base fee is paid directly to the Copyright Clearance Center, 222 Rosewood Drive, Danvers, MA 01923. For those organizations that have been granted a photocopy license by CCC, a separate system of payments has been arranged. The fee codes for users of the Transactional Reporting Service are ISBN-13: 978-0-8138-1486-5/2011.

Designations used by companies to distinguish their products are often claimed as trademarks. All brand names and product names used in this book are trade names, service marks, trademarks or registered trademarks of their respective owners. The publisher is not associated with any product or vendor mentioned in this book. This publication is designed to provide accurate and authoritative information in regard to the subject matter covered. It is sold on the understanding that the publisher is not engaged in rendering professional services. If professional advice or other expert assistance is required, the services of a competent professional should be sought.

Library of Congress Cataloging-in-Publication Data

Available with the Library of Congress

A catalogue record for this book is available from the British Library.

This book is published in the following electronic formats: ePDF 9780470959725; ePub 9780470959732

Preface

It is almost 35 years since the first edition of Human Oral Mucosa: Development, Structure, and Function was published by Blackwell Scientific Publications. When this volume originally appeared, the intent was to provide a more comprehensive account of the oral mucosa than was available in textbooks of histology and dental anatomy at the time. Reviews of the volume were favorable, and it was evident that it met the needs not only of dental students but also of dental practitioners and academic pathologists and dermatologists.

One of the reasons, therefore, for proposing the present volume was to provide a more sophisticated text on oral mucosa than presently exists in textbooks or in any separate, specialist volume. In the absence of alternate texts, it seemed appropriate to update the original text to reflect the considerable increase in our knowledge of oral mucosa that has occurred in recent years. Our understanding of the structure of oral mucosa is now established at a molecular rather than a tissue or cellular level. This in turn has revealed a level of function that was previously not suspected, including, for example, a sophisticated barrier to the penetration of exogenous materials, and the synthesis of specific antimicrobial compounds, representing components of the innate immune system. There is also a growing realization of commonality in structure and function between stratified squamous mucosae such as those of oral mucosa, the esophagus, and the vagina.

The new edition of Human Oral Mucosa, like its predecessor, is directed principally to graduate students and residents in the oral health sciences, although it will be of value to specialists in allied areas such as dermatology, internal medicine, gynecology, and pathology. In the absence of other specialist volumes in this area, we believe that it will also serve as a reference for researchers working in oral science, particularly those interested in oral infections, inflammation, HIV pathogenesis, and oral immunization.

To revise a work after such a lengthy interval reflects the encouragement and enthusiasm of our publisher and, in particular, Sophia Joyce of Wiley-Blackwell. Locally, we have had generous support from our institution and valuable input from colleagues, particularly Philip Wertz, and Catherine Davis, of Proctor and Gamble, who carefully reviewed the final chapter. Finally, we acknowledge the meticulous work of Mary Mantz who cheerfully organized the numerous figures and references for the new edition.

Christopher Squier

Kim Brogden

1

The functions of oral mucosa

1.1 ORAL MUCOSA: WHAT IS IT AND WHAT DOES IT DO?

Oral mucosa is a mucous membrane, a term used to describe the moist linings of body cavities that communicate with the exterior. These include the oral cavity, nasal passages, pharynx, gastrointestinal tract, and urinogenital regions. In the oral cavity, this lining is called the oral mucous membrane or oral mucosa. The exterior of the body has a dry covering, the skin, which is continuous with oral mucosa at the lips. Structurally, the oral mucosa resembles the skin in some respects and is very similar to the mucous membranes of the esophagus, cervix, and vagina (which will be considered in a subsequent chapter) but is totally different from the gastrointestinal mucosa.

Despite these differences, skin and the different mucosae all consist of two structurally different tissue components: a covering epithelium and an underlying connective tissue. These tissues function together so the various mucosae and skin can be considered as organs.

Form follows function, and it is easier to understand the complex structure of a tissue or organ when its function is known. This is particularly true of the oral mucosa, whose structure reflects a variety of functional adaptations. The major adaptations are a result of evolutionary changes that have taken place over a long time. However, small and usually reversible changes in structure of oral mucosa may be seen in response to function during the lifetime of an individual, but these are not heritable. The functions of oral mucosa and the tissue components subserving those functions are summarized in Table 1.1.

Table 1.1 Functions of the oral mucosa.

1.2 FUNCTIONS OF THE ORAL MUCOSA

The oral mucosa has a variety of functions of which the most important is protection of the deeper tissues and glands of the oral cavity. Other functions include sensory perception, synthesis, and secretion from glands located in the mucosa and an esthetic role represented by the mucocutaneous junction.

1.2.1 Protection

As a surface lining, the oral mucosa separates and protects deeper tissues and organs in the oral region from the environment of the oral cavity. The normal activities of seizing, biting, and chewing food expose the oral soft tissues to mechanical forces (compression, stretching, shearing) and surface abrasions (from hard particles in the diet). The oral mucosa shows a number of adaptations of both the epithelium and the connective tissue to withstand these mechanical insults. Furthermore, there is normally a resident population of microorganisms within the oral cavity that would cause infection if they gained access to the tissues. Many of these organisms also produce substances that have a toxic effect on tissues. The epithelium of the oral mucosa acts as the major barrier to penetration and also contributes to the immunoprotective system of the mucosa.

1.2.2 Sensation

The sensory function of the oral mucosa is important because it provides considerable information about events within the oral cavity, whereas the lips and tongue perceive stimuli outside the mouth. In the mouth, pharynx and epiglottis are receptors that respond to temperature, touch, and pain; there also are the taste buds, which are not found anywhere else in the body. These signal the traditional taste sensations of sweet, salty, sour, bitter, and umami (or savory), although it has been suggested recently that there is a “fat” taste (Laugerette et al., 2007). Certain receptors in the oral mucosa probably respond to the “taste” of water and signal the satisfaction of thirst (de Araujo et al., 2003). Reflexes such as swallowing, gagging, retching, and salivating are also initiated by receptors in the oral mucosa.

1.2.3 Secretion

The major secretion associated with the oral mucosa is saliva, produced by the salivary glands, which contributes to the maintenance of a moist surface. The major salivary glands are situated distant from the mucosa, and their secretions pass through the mucosa via long ducts; however, many minor salivary glands are associated with the oral mucosa. Sebaceous glands are frequently present in the oral mucosa, and their secretions may have antimicrobial properties (see Chapter 2). Salivary glands secrete histatins, a family of low-molecular-weight histidine-rich proteins with antimicrobial activities. Oral epithelium is also capable of secreting a variety of antimicrobial factors such as defensins and cathelicidins, which participate in various aspects of innate immunity. These are described in Chapter 8.

1.2.4 Thermal Regulation

In some animals (such as the dog), considerable body heat is dissipated through the oral mucosa by panting; for these animals, the mucosa plays a major role in the regulation of body temperature. The human oral mucosa, however, plays practically no role in regulating body temperature, and there are no obvious specializations of the blood vessels for controlling heat transfer such as arteriovenous shunts.

1.2.5 Esthetics

Skin color, texture, and appearance play an important role in signaling individual characteristics such as age, health, ethnicity, and so on. The oral mucosa is not normally visible except for the region where it joins the skin. Here, the vermilion zone of the lips represents a significant esthetic component, frequently enhanced with cosmetics in females.

REFERENCES

de Araujo, I.E., Kringelbach, M.L., Rolls, E.T., and McGlone, F. (2003) Human cortical responses to water in the mouth, and the effects of thirst. J Neurophysiol 90(3):1865–1876.

Laugerette, F., Gaillard, D., Passilly-Degrace, P., Niot, I., and Besnard, P. (2007) Do we taste fat? Biochimie 89:265–269.

2

The organization of oral mucosa

The oral cavity consists of two parts: an outer vestibule, bounded by the lips and cheeks, and the oral cavity proper, separated from the vestibule by the alveolus bearing the teeth and gingiva. The superior zone of the oral cavity proper is formed by the hard and soft palates, and the floor of the mouth and base of the tongue form the inferior border. Posteriorly, the oral cavity is bounded by the pillars of the fauces and the tonsils. The oral mucosa shows considerable structural variation in different regions of the oral cavity, but three main types of mucosa can be recognized, identified according to their primary function: masticatory mucosa, lining mucosa, and specialized mucosa. The anatomic location of each type is shown diagrammatically in Figure 2.1, and the types are fully described later in the chapter. Quantitatively, the larger part of the oral mucosa is represented by lining mucosa, amounting to approximately 60% of the total area, with masticatory mucosa and specialized mucosa occupying relatively smaller areas.

Figure 2.1 The anatomic locations of the three main types of mucosa in the oral cavity. Masticatory mucosa is shown by black shading; lining mucosa by gray shading; specialized mucosa by the stippled area.

(Modified from Roed-Petersen and Renstrup, 1969, Acta Odontol Scand 27:681.)

2.1 CLINICAL FEATURES

Although the oral mucosa is continuous with the skin, it differs considerably in appearance. Generally it is more deeply colored, most obviously at the lips (where the bright vermilion zone contrasts with the skin tone). This coloration represents the combined effect of a number of factors: the concentration and state of dilation of capillaries in the underlying connective tissue, the thickness of the epithelium, the degree of keratinization, and the amount of melanin pigment in the epithelium. Color gives an indication as to the clinical condition of the mucosa; inflamed tissues are red, because of dilation of the blood vessels, whereas normal healthy tissues are a paler pink (Fig. 2.2A).

Figure 2.2 The oral mucosa lining part of the vestibule. (A) The attached gingiva (G) is pale, and stippling is most evident in the interproximal regions (arrows). There is an abrupt junction (indicated by the dashed line) between the gingival and the alveolar mucosa (AM) which merges with the labial mucosa (LM). (B) Vermilion zone adjoining the labial mucosa. Several small globules on the mucosa (arrows) represent sites of secretion, where minor salivary gland ducts open to the surface.

Other features that distinguish the oral mucosa from skin are its moist surface and the absence of appendages. Skin contains numerous hair follicles, sebaceous glands, and sweat glands, whereas the glandular component of oral mucosa is represented primarily by the minor salivary glands. These are concentrated in various regions of the oral cavity, and the openings of their ducts at the mucosal surface are sometimes evident on clinical examination after drying the surface (Fig. 2.2B).

Sebaceous glands are present on the lips, labial mucosa, and buccal mucosa in over three quarters of adults and have been described occasionally in the alveolar mucosa and dorsum of the tongue. They are not associated with hair follicles and are sometimes called sebaceous follicles. Clinically, they appear as pale yellow spots (Fig. 2.3A), sometimes called Fordyce’s spots (or granules) or Fordyce’s disease, although they do not represent a pathologic condition.

Figure 2.3 Sebaceous glands in human buccal mucosa. (A) The “granular” appearance is clearly evident on the buccal mucosal surface. (B) Histological section of a sebaceous gland showing the secretory portion (S) and the duct (D) opening at the surface. (Photograph courtesy of Dr. M.W. Finkelstein.)

The surface of the oral mucosa tends to be smoother and have fewer folds or wrinkles than the skin, but topographic features are readily apparent on clinical examination. The most obvious are the different papillae on the dorsum of the tongue and the transverse ridges (or rugae) of the hard palate. The healthy gingiva shows a pattern of fine surface stippling, consisting of small indentations of the mucosal surface (Fig. 2.2A). In approximately 10% of the population, a slight whitish ridge occurs along the buccal mucosa in the occlusal plane of the teeth. This line, sometimes called the linea alba (white line), is a keratinized region and may represent the epithelial reaction to abrasion from rough tooth restorations or cheek biting.

The oral mucosa varies considerably in its firmness and texture. The lining mucosa of the lips and cheeks, for example, is soft and pliable, whereas the gingiva and hard palate are covered by a firm, immobile layer. These differences have important clinical implications when it comes to giving local injections of anesthetics or taking biopsies of oral mucosa. Fluid can be easily introduced into loose lining mucosa, but injection into the masticatory mucosa is more difficult and can be painful for the patient. Lining mucosa gapes when surgically incised (Fig. 2.4A) and frequently requires suturing, whereas masticatory mucosa, being more firmly attached, may not (Fig. 2.4B). Similarly, the accumulation of fluid with inflammation is obvious and painful in masticatory mucosa, but in lining mucosa the fluid disperses, and inflammation may not be so evident or as painful.

Figure 2.4 Wounds in soft palate and gingiva. (A) A small (4 mm) biopsy wound in soft palate, a lining mucosa, results in a wound that has gaped. (B) Incisions in masticatory mucosa (attached gingiva) show little gaping of the wound. (Photograph courtesy of Dr. Georgia Johnson.)

2.2 COMPONENT TISSUES AND GLANDS

The two main tissue components of the oral mucosa are a stratified squamous epithelium, called the oral epithelium, and an underlying connective tissue layer, called the lamina propria (Fig. 2.5). In the skin these two tissues are known by slightly different terminology: epidermis and dermis. The interface between epithelium and connective tissue is usually irregular, and upward projections of connective tissue, called the connective tissue papillae, interdigitate with epithelial ridges or pegs, sometimes called the rete ridges or pegs (see Fig. 2.5). In a histological section, the interface between epithelium and connective tissue appears as a structureless layer about 1–2 μm thick, termed the basement membrane (see Fig. 2.5B). At the ultrastructural level, this region has a complex structure (described later).

Figure 2.5 (A) Diagram of the main tissue components of oral mucosa. (B) Histological section of hard palate to show the tissue components depicted in (A).

((A) from Squier and Finkelstein, 2003, Copyright Mosby.)

Although the junction between oral epithelium and lamina propria is obvious, that between the oral mucosa and underlying tissue, or submucosa, is less easy to recognize. In the gastrointestinal tract and esophagus, the lining mucosa is clearly separated from underlying tissues by a layer of smooth muscle and elastic fibers, the muscularis mucosae, and in functional terms may allow for some isolation of the internal lining from movements of the outer muscular layers of the intestine.

The oral mucosa has no muscularis mucosae, and clearly identifying the boundary between it and the underlying tissues is difficult. In regions such as the cheeks, lips, and parts of the hard palate, there is a layer of loose fatty or glandular connective tissue containing the major blood vessels and nerves supplying the mucosa that separates it from underlying bone or muscle. This represents the submucosa (Fig. 2.6A), and its composition determines the flexibility of the attachment of oral mucosa to the underlying structures. In regions such as the gingiva and parts of the hard palate, oral mucosa is attached directly to the periosteum of underlying bone, with no intervening submucosa (Fig. 2.6B). This arrangement is called a mucoperiosteum and provides a firm, inelastic attachment.

Figure 2.6 Arrangement of major tissue components in (A) masticatory mucosa (mucoperiosteum) and (B) lining mucosa.

The minor salivary glands are situated in the submucosa of the mucosa. Sebaceous glands are less frequent than salivary glands; they lie in the lamina propria and have the same structure as those present in the skin. They produce a fatty secretion, sebum, the function of which is unclear in the oral cavity, although some claim it may lubricate the surface of the mucosa so that it slides easily against the teeth. Studies on skin suggest that sebum may have important antimicrobial properties (Drake et al., 2008), and there is some evidence for this role in oral mucosa (Wertz, P.W., personal communication).

In several regions of the oral cavity there are nodules of lymphoid tissue consisting of crypts formed by invaginations of the epithelium into the lamina propria. Capillaries in the connective tissue express adhesion molecules such as the endothelial cell leukocyte adhesion molecule (ELAM), intercellular adhesion molecule (ICAM), and vascular cell adhesion molecule (VCAM), which facilitate the trafficking of leukocytes from the blood. As a result, these areas are extensively infiltrated by lymphocytes and plasma cells. Because of their ability to mount immunologic reactions, such cells play an important role in combating infections of the oral tissues. The largest accumulations of lymphoid tissue are found in the posterior part of the oral cavity, where they form the lingual, palatine, and pharyngeal tonsils, often known collectively as Waldeyer’s ring. Small lymphoid nodules may also sometimes occur in the mucosa of the soft palate, the ventral surface of the tongue, and the floor of the mouth.

REFERENCES

Drake, D.R., Brogden, K.A., Dawson, D.V., and Wertz, P.W. (2008) Thematic review series: skin lipids. Antimicrobial lipids at the skin surface. J Lipid Res 49(1):4–11.

Roed-Petersen, B., and Renstrup, G. (1969) A topographical classification of the oral mucosa suitable for electronic data processing. Its application to 560 leukoplakias. Acta Odontol Scand 27:681.

Squier, C.A., and Finkelstein, M.W. (2003) Oral mucosa. In: Ten Cate’s Oral Histology: Development, Structure and Function (A. Nanci, ed.) pp. 329–375. Mosby, St. Louis, MO.

3

Oral epithelium

At the surface of the oral mucosa, the oral epithelium constitutes the primary barrier between the oral environment and deeper tissues. It is a stratified squamous epithelium consisting of cells tightly attached to each other and arranged in a number of distinct layers or strata. Based on the appearance in histological sections and staining with specific markers such as keratin antibodies (see section on Molecular and cellular basis of differentiation), oral epithelium can be divided into two types: keratinized epithelium, covering areas of masticatory mucosa, such as hard palate and gingiva, and non-keratinized epithelium, covering areas of lining mucosa such as cheeks, soft palate, floor of mouth. The histological appearance of these tissues is described below in more detail.
