Mechanics of Dislocation Fields E-Book

Claude Fressengeas

• Herausgeber: John Wiley & Sons
• Kategorie: Fachliteratur
• Sprache: Englisch

Seitenzahl: 345

Veröffentlichungsjahr: 2017

Beschreibung

Accompanying the present trend of engineering systems aimed at size reduction and design at microscopic/nanoscopic length scales, Mechanics of Dislocation Fields describes the self-organization of dislocation ensembles at small length scales and its consequences on the overall mechanical behavior of crystalline bodies. The account of the fundamental interactions between the dislocations and other microscopic crystal defects is based on the use of smooth field quantities and powerful tools from the mathematical theory of partial differential equations. The resulting theory is able to describe the emergence of dislocation microstructures and their evolution along complex loading paths. Scale transitions are performed between the properties of the dislocation ensembles and the mechanical behavior of the body. Several variants of this overall scheme are examined which focus on dislocation cores, electromechanical interactions of dislocations with electric charges in dielectric materials, the intermittency and scale-invariance of dislocation activity, grain-to-grain interactions in polycrystals, size effects on mechanical behavior and path dependence of strain hardening.

Leseprobe

Table of Contents

Cover

Title

Copyright

Acknowledgements

Introduction

I.1. Background and motivation

I.2. Objectives

I.3. Organization

I.4. Notations

1 Continuous Dislocation Modeling

1.1. Introduction

1.2. Lattice incompatibility

1.3. Burgers vector

1.4. Compatibility conditions

1.5. Dislocation fields

1.6. Tangential continuity at interfaces

1.7. Curvatures and rotational incompatibiliy

1.8. Incompatibility tensor

1.9. Conclusion

1.10. Problems

1.11. Solutions

2 Elasto-static Field Equations

2.1. Introduction

2.2. Elasto-static solution to field equations

2.3. Straight screw dislocation in a linear isotropic elastic medium

2.4. Straight edge dislocation in a linear isotropic elastic medium

2.5. Conclusion

2.6. Problems

2.7. Solutions

3 Dislocation Transport

3.1. Introduction

3.2. Dislocation flux and plastic distortion rate

3.3. Coarse graining

3.4. Compatibility versus incompatibility of plasticity

3.5. Tangential continuity of plastic distortion rate

3.6. Transport equations

3.7. Transport waves

3.8. Numerical algorithms for dislocation transport

3.9. Conclusion

3.10. Problems

3.11. Solutions

4 Constitutive Relations

4.1. Introduction

4.2. Dissipation

4.3. Pressure independence

4.4. Dislocation climb versus dislocation glide

4.5. Viscoplastic relationships

4.6. Coarse graining

4.7. Contact with conventional crystal plasticity

5 Elasto-plastic Field Equations

5.1. Introduction

5.2. Fundamental field equations

5.3. Boundary conditions

5.4. Coarse graining

5.5. Resolution algorithm

5.6. Reduced field equations

5.7. Augmented crystal plasticity

5.8. Dynamics of a twist boundary

5.9. Conclusion

5.10. Problems

5.11. Solutions

6 Case Studies

6.1. Introduction

6.2. Dislocation core structure

6.3. Piezoelectricity and dislocations

6.4. Intermittent plasticity

6.5. Effects of size on mechanical response

6.6. Complex loading paths

6.7. Strain localization

7 Review and Conclusions

7.1. Comparisons with conventional crystal plasticity

7.2. Alternative approaches

7.3. Shortcomings and extensions

7.4. Final remarks

Appendix: Complements

A.1. Stokes’ theorem

A.2. Characterization of the compatibility of a tensor field

A.3. Stokes-Helmholtz decomposition

A.4. Second-order Riemann-Graves operator

Bibliography

Index

End User License Agreement

List of Tables

6 Case Studies

Table 6.1.

Al numerical constants used in the simulations

Table 6.2.

Numerical constants used in the model

Table 6.3.

Material parameters used in the three-dimensional

Cu

whisker simulation

Table 6.4.

Initial and boundary conditions, and complementary material parameters in two-dimensional simulations

Table 6.5.

Numerical constants and initial conditions used in the model

Table 6.6.

Numerical constants used in the model

Table 6.7.

Initial conditions

Guide

Cover

Table of Contents

Begin Reading

Pages

C1

iii

iv

v

ix

xi

xii

xiii

xiv

xv

xvi

xvii

xviii

xix

xx

xxi

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

217

218

G1

G2

G3

G4

e1

Mechanics of Dislocation Fields

Claude Fressengeas

First published 2017 in Great Britain and the United States by ISTE Ltd and John Wiley & Sons, Inc.

Apart from any fair dealing for the purposes of research or private study, or criticism or review, as permitted under the Copyright, Designs and Patents Act 1988, this publication may only be reproduced, stored or transmitted, in any form or by any means, with the prior permission in writing of the publishers, or in the case of reprographic reproduction in accordance with the terms and licenses issued by the CLA. Enquiries concerning reproduction outside these terms should be sent to the publishers at the undermentioned address:

ISTE Ltd27-37 St George’s RoadLondon SW19 4EUUK

www.iste.co.uk

John Wiley & Sons, Inc.111 River StreetHoboken, NJ 07030USA

www.wiley.com

© ISTE Ltd 2017

The rights of Claude Fressengeas to be identified as the author of this work have been asserted by him in accordance with the Copyright, Designs and Patents Act 1988.

Library of Congress Control Number: 2017944822

British Library Cataloguing-in-Publication Data

A CIP record for this book is available from the British Library

ISBN 978-1-84821-375-3

Acknowledgements

I am indebted to my colleagues: Amit Acharya, Garani Ananthakrishna, Armand J. Beaudoin and Ladislas P. Kubin for the numerous discussions on the plasticity of crystalline materials that inspired the work which finally led to writing this book. I also warmly thank my numerous collaborators: first of all, Vincent Taupin who shared most of this work, and Benoît Beausir, Stéphane Berbenni, Laurent Capolungo, Juliette Chevy, Patrick Cordier, Sylvie Demouchy, Komlan S. Djaka, Paul Duval, Denis Entemeyer, Tatiana Lebedkina, Mikhail Lebyodkin, Russell J. McDonald, Maurine Montagnat, Thiebaud Richeton, Xiaoyu Sun, Satya Varadhan, Pascal Ventura, Guofeng Wang and Jérôme Weiss, who participated in joint publications, and whose work significantly contributed to the contents of the present book. Be they all ensured of my gratitude.

Introduction

I.1. Background and motivation

The plasticity of crystalline materials is a dynamic phenomenon resulting from the motion under stress of crystal defects known as dislocations. Such a statement is grounded on numerous convincing observations, and it is widely accepted by the scientific community for materials having a sufficient number of independent slip systems and, in polycrystals, if grain size is sufficiently large to allow dislocation glide. Nevertheless, the conventional theories of plasticity have been using macroscopic variables whose definition does not involve the notion of dislocation. This paradoxical situation arises from the enormous range covered by the length scales used in the description of plasticity, from the elementary lattice spacing in atomistic descriptions to the meter scale in engineering studies. It may indeed have seemed impossible to account for the astounding complexity of the dynamics of dislocation ensembles at microscale in describing the mechanical properties of engineering structures. Justifications offered for such a simplification have usually found their origin in perfect disorder assumptions. Namely, plastic strain has been regarded as resulting from a very large number of randomly distributed elementary dislocation glide events, showing no order whatsoever at any intermediate length scale and time scale. Hence, deriving the mechanical properties arising from the mutual interactions of dislocations simply requires averaging procedures on any space and time domain.

Dislocation climb and grain boundary mechanisms, such as grain boundary migration, grain boundary rotation and dislocation emission, also contribute to plasticity to some extent depending on the local temperature and strain rate, on the slip system availability, the grain size and orientation, the defects density and mobility, the loading history, etc. For example, when the grain size lies in the tens of nanometers range as in nanocrystalline metallic materials, the role of dislocation glide is limited and grain boundary-mediated plasticity prevails, because the fraction of matter directly affected by grain boundaries becomes very large. Similarly, the lack of independent slip systems hampers the role of dislocation glide. According to the von Mises criterion [VON 28], at least five independent slip systems are needed for arbitrary plastic flow to occur homogeneously by dislocation glide, and this requirement is relaxed to four slip systems if the flow is inhomogeneous [HUT 83]. For instance, dislocation glide is restricted to only three independent slip systems in orthorhombic olivine, by far the most abundant (about 60–70%) and the weakest mineral in Earth’s upper mantle under a wide range of thermo-mechanical conditions. Therefore, olivine aggregates do not fulfill Hutchinson’s relaxed criterion, and additional plasticity mechanisms are needed to accommodate arbitrary deformation of the upper mantle [COR 14].

A straightforward jump by simple averaging from microscopic to macroscopic scale has long been the prevailing idea in mechanical sciences as well as in the materials science community when dislocation glide is predominant. This point of view may be justified, for example in bcc metals at low temperature, where the motion of dislocations is subject to large lattice friction. It reaches its limits when the elastic interactions between dislocations become the order of the interactions with other obstacles to their motion (lattice friction, solute atmospheres, precipitates, etc.). Since dislocation densities commonly increase during material loading, such a situation is met sooner or later as plastic strain increases. The field of elastic interactions between dislocations then becomes able to generate collective behavior and self-organized phenomena in the form of dislocation patterns emerging through ordered spatio-temporal dynamic regimes, with characteristic length scales and time scales [KUB 02]. Numerous examples of dislocation patterns, involving dislocation-rich and dislocation-poor regions, are observed in optical or electronic microscopy. Such is the case of the dislocation walls formed in cyclic loading (see Figure I.1), of dislocation cells (Figure I.2) and localized slip bands on the surface of single crystals (Figure I.3), with characteristic length scales in the μ m range.

Figure I.1.Dislocation walls inSisingle crystal cyclically loaded in tension - compression at high temperature [LEG 04]

Figure I.2.Optical micrography of giant dislocation cells afterGaAscrystal growth. Note that the average cell size varies in inverse proportion to stress. Inset: dislocation cells through X-ray imaging, dark areas are the images of lattice distortion around dislocations [NEU 01]

Figure I.3.Slip lines on the surface ofCu30at%Znsingle crystal strained in tension at 19.4% and 77K [ZAI 06]

Similar spatial structures can also be inferred from the complex temporal behavior inherent to deformation curves in certain metallic alloys (Portevin-Le Chatelier effect, Lüders bands, etc.) [KUB 02]. In such conditions, the simple averaging procedures alluded to above are no longer justified, and the conventional theories of elastoplasticity are unable to account for the emerging patterns because they lack the relevant internal length scales.

Although time intermittency of plasticity was described as early as 1932 in Zn single crystals [BEC 32], the prevailing interpretation in the material science literature has also been that intermittent fluctuations add at random to a smooth net response in time, when averaging over sufficiently large time scales. This is again consistent with an assumption of perfect disorder of the plastic activity. A fundamentally different understanding emerged during the last few decades when statistical analysis of these fluctuations became available, that of a scale-invariant phenomenon characterized by power law distributions of fluctuation size, and correlations in space and time [BRI 08, DIM 06, WEI 97, MIG 01, WEI 07]. Thus, simple averaging procedures in time have again been dismissed and elasto-plastic theories able to account for such correlations have been promoted.

The conventional elastic constitutive relationships are referred to as “local” because they relate the stresses and elastic strains at the same point in the body. Such relationships have been found insufficient to account for the emergence of self-organization phenomena at intermediate length scales, because the solutions they induce to boundary value problems are scale independent. The fundamental reason for scale independence is, as suggested above, the lack of an internal physical length scale to be compared with the body’s dimensions. As opposed to local relationships, “nonlocal” elastic constitutive laws link the stresses at a given point in the body to the elastic strains in a neighborhood of this point. The extent of the neighborhood provides (or limits) the characteristic length scale of the elastic response of the body. Convolution integrals may be used to further formalize nonlocality [ERI 02], but a first approach has consisted of simply using strain gradients obtained from Taylor expansions of these integrals, and introducing the necessary length scales in a phenomenological way into the constitutive equations [AIF 84, FLE 94, FOR 97, NIX 98]. Such approaches are usually referred to as “strain gradient” theories of elastoplasticity. They may be useful in the characterization of the emerging patterns, but the identification of the involved length scales may sometimes raise difficulties. The notion that appropriate, physically based ingredients for a dynamic elasto-plastic description of the emerging patterns could be the dislocation density fields is quite recent [ACH 01, TEO 70], although these measures of crystal distortion incompatibility had been defined and used much earlier in elasto-static calculations [KOS 79, KRÖ 58, KRÖ 80, MUR 63, NYE 53]. Being areal renditions of a vectorial closure defect along a closed path integral, namely the Burgers vector obtained in integrating the plastic distortion along the Burgers circuit, dislocation densities are scale-dependent quantities. Hence, when used in the solution of boundary value problems, they induce a characteristic ratio between the resolution length scale adopted for their introduction and the size of the envisioned body. Clearly, this resolution length scale has to be much smaller than the size of the crystal defect pattern to be described in order to obtain accurate results on the spatio-temporal dynamics of the latter. However, there is no mandatory rule, and the choice of the resolution length scale depends on the accuracy demanded from the description. Hence, a phenomenon deemed “non-local” in a fine-scale solution scheme may well be seen as “local” when the scale of resolution is vastly enlarged. Thus, the dislocation density-based framework is intrinsically nonlocal, but the resolution length must be properly chosen, depending on the problem at hand. In addition, nonlocality of the framework cannot be substituted for nonlocal material behavior.
