Carbon sulfide boils at 46 °C at atmospheric pressure; its vapor is considered an ideal gas; its enthalpy of vaporization under these conditions is 85 cal/g and remains constant between −73 °C and 46 °C.
1) a) Calculate the vapor tensions of the sulfide at temperatures: −73 °C, −45 °C, −23 °C, −5 °C and 28 °C.
b) Compare these results with these below, obtained experimentally, by calculating the relative error for each temperature.
P
(mmHg)
1
10
40
100
400
T
(°C)
−73
−45
−23
−5
28
2) Explain the difference between the measured and calculated values, and justify the direction of variation of the error.
Answers: (1) (a) ; (b) and (2) see corrections.
The vapor pressure curve of benzene is given experimentally by values in the following table:
T
(K)
262
285
299
301
340
350
360
P
(mmHg)
10
50
100
250
500
700
1,000
We aim to determine the entropy and enthalpy of vaporization of benzene at its boiling point, assuming that benzene vapor is an ideal gas.
1) Plot the curve
P
= f(
T
) using the scale (1 cm ↔ 40 mmHg and 1 cm ↔ 5 K).
2) Deduce the boiling point.
3) Calculate the entropy of vaporization at this temperature; is this result consistent with that predicted by Trouton’s rule?
4) Calculate the enthalpy of vaporization at this boiling point.
Answers: (1) See corrections; (2) Tb.= 79.35 °C; (3) ΔS = 20.51 u.e; yes; (4) ΔH = 7,229.63 cal/mol.
Liquid benzene(1)/toluene(2) mixtures form, at atmospheric pressure, an ideal solution in all proportions.
Draw a diagram of the liquid/vapor equilibrium, by calculating the titers of the vapor and liquid at the following temperatures: 83.1 °C, 86.1 °C, 89.1 °C, 92.1 °C, 95.1 °C, 98.1 °C, 101.1 °C, 104.1 °C and 107.1 °C.
Data:
Benzene
Toluene
T
b
(°C)
80.10
110.60
Δ
H
f
(cal/mol)
7,353
8,000
Answer: See corrections.
At 400 K, two liquid bodies (1) and (2) have the respective vapor pressures and ; at this temperature, their mixture is azeotropic with a vapor pressure of 900 torr and the composition of body (1) in the liquid phase is 0.2 at equilibrium.
1) Calculate the values of the partial pressures of this solution at
T
= 400 K.
2) Calculate the activity coefficients and activities of the solution at
T
= 400 K.
Answers: (1) P1 = 180 torr and P2 = 720 torr; (2) γ1 = 0.90 and γ2 = 0.50; a1 = 0.18 and a2 = 0.40.
The diagram for the vapor tension of the Br(1)/CCl4(2) mixture was proposed by Barthel at 0 °C; an azeotrope was found with the molar titer of bromine of x1 = 0.857 and vapor tension P = 71.2 mmHg.
1) Choose an appropriate development with two parameters A and B.
2) Calculate A and B, and write the relations giving the activity coefficients of each constituent in the solution.
3) Calculate these coefficients for a mixture with a molar titer of Bromine equal to 0.7 and deduce the composition of the vapor phase.
Data: At 0 °C, the vapor tensions of the pure bodies are and .
Answers: (1) See corrections; (2) A = 0.076; B = 1.308; and ; (3) γ1 =1.525; γ2 = 0.961 and y1 = 0.58.
The methyl ethyl ketone(1)/water(2) system is characterized by an azeotrope whose temperature, pressure and composition were measured. The results are given in the following table:
T
(K)
489.2
453.8
412.1
385.3
346.4
P
(atm)
34.02
17.01
6.804
3.402
1.000
x
MEK
0.410
0.456
0.508
0.572
0.655
The saturation pressure of each component is given by the relation whose coefficients are given in the following table:
Tc
(K)
Pc
(atm)
A
B
C
MEK (1)
535.6
41.0
9.9653
3,150.42
36.65
H
2
O (2)
647.3
217.6
11.6703
3,816.44
46.13
1) Using the Van Laar and Redlich–Kwong equations, estimate the free energy of the mixture at different titers for the five proposed temperatures in the first table.
2) What can be deduced?
3) Represent this energy as a function of the MEK titer.
Answers: (1) ; (2) existence of a solubility deficiency at three lower temperatures; (3) see corrections.
Quinoline C9H7N is prepared by the extraction of the reactive medium with steam, due to their immiscibility.
1) Calculate the boiling point of
H
2
O
/
C
9
H
7
N
at pressure of 740 torr.
2) Calculate the maximum mass of quinoline extracted by 1 kg of steam at 740 torr.
Data:
T (°C)
98.0
98.5
99.0
99.5
100.0
707.27
720.15
733.24
746.52
760.00
7.62
7.80
7.97
8.15
8.35
Answers: (1) Tb = 98.95 °C; (2) m = 77.52 g.
The Mediterranean Sea is characterized by a salinity of 35 g/L. We will boil this sea water at the boiling point of pure water at 1 atm.
1) Calculate the vapor pressure
P
at this boiling point.
2) At what pressure will this water be in equilibrium with ice at 0 °C like pure water at 1 atm?
3) Conclusion.
Data: MNa = 23 g/mol; MCl = 35.5 g/mol; ρs = 916.8 g/L; ρl = 1,000 g/L and at Pa = 1 atm = 1.013 bar, we obtain: Tb = 373.15 K and Tf = 273.15 K.
Answers: (1) P = 0.9916 bar; (2) P = −2.97 × 107 Pa; (3) see corrections.
Here, we study the binary mixture ethylbenzene(1)/C(2), where C is a compound whose melting point is 325 K and standard enthalpy of melting is 15,000 cal/mol.
Measuring the vapor pressure of ethylbenzene over the binary mixtures at 350 K gives the following values:
x
1
0.1
0.3
0.5
0.7
0.9
1.0
P
(torr)
3.35
12.5
29.5
59.2
96.7
111.4
The activity coefficient of ethylbenzene is represented by the expression:
1) Calculate the value of the activity coefficient of liquid compound C when
x
1
=
x
2
, knowing that the initial solidification temperature of the solution defined by
x
1
= x
2
is 315 K.
2) Calculate the value of the activity coefficient of liquid compound C under these conditions.
3) Calculate the partial molar enthalpy of mixing and the partial molar entropy of excess of component C in this equimolar solution.
Answers: (1) γ2 = 0.739; (2) γ2 = 0.957; (3) and .
The system 1,4-dioxane(1)/water(2) at 70°C and 390 mmHg gives an azeotrope whose dioxane titer is 0.514, whereas at T = 35 °C and P = 80.8 mmHg, the azeotrope has the titer x1 = 0.599. Assuming the system is ideal and that the vapor obeys the ideal gas law, calculate by means of the Wilson equation:
1) the equilibrium curve at 70 °C;
2) the activity coefficients at infinite dilution;
3) the activity coefficients and the excess Gibbs free energy for different titers;
4) the bubble pressure and vapor composition at equilibrium for a mixture with a water titer of 0.2 at
T
= 70 °C;
5) the equilibrium conditions of the mixture with a water titer of 0.749 at
T
= 50 °C, knowing the experiment gives
P
= 160.8 mmHg and
y
1
= 0.505; estimate the enthalpy and entropy of excess.
Data: vwater = 18.1 cm3/mol; v1−4 D = 85.3 cm3/mol; P of saturation: ; .
Answers: (1) See corrections; (2) and ; (3) see corrections; (4) P = 374.5 mmHg; y1 = 0.443; (5) P = 154.9 mmHg and y1 = 0.4487; and .
If we plot the boiling point diagram of the chloroform(1)/acetone(2) binary from the following experimental data: at T = 35.8 °C, there is an azeotrope with a vapor tension of P = 247.5 torr for a composition x = 0.387; at this T, the vapor tensions of the pure bodies are and ; at atmospheric pressure, the boiling points of the pure bodies are and ; the enthalpy of mixing hm of the equimolar binary at 25 °C is − 145.0±1.0 cal.
1) Establish an approximate relation for the vapor pressure of each pure body as a function of
T
.
2) Assuming that the excess Gibbs free energy obeys the following equation , where A and B are independent of composition; establish an expression for the activity coefficients of each constituent in the solution.
3) Show that you can determine the activity coefficients of both constituents from the azeotrope data at this point and deduce the values of A and B.
4) Can the values of A and B be considered to be independent of
T
? What does this hypothesis assume? Is it compatible with the value of the enthalpy of mixing at 25 °C?
5) Calculate the total pressure and titer of the vapor over the liquid equimolar mixture at 60 °C.
6) Establish the equation for the McCabe–Thiele curve at a total pressure of 1 atm.
Answers: (1) ; ; (2) and ; (3) A = −666.7 cal/mol; B = 1.284 cal/mol; (4) gex = −145 cal; (5) P = 627.2 torr; (6) see corrections.
Experimental measurements relative to isopropanol(1) and dioxane(2) solutions confirmed the validity of the Antoine equation , where T is expressed in °C and the saturation vapor pressure of the pure component (i), is expressed in torr. Using these, we can obtain the values of the following parameters at the normal boiling points:
T
b
(°C)
A
i
B
i
C
i
Isopropanol
82.4
8.3113
1,686.8
228.2
Dioxane
101.3
7.2180
1,424.4
227.1
This experimental data obtained at a total P pressure of 1 atm are shown in the table below:
x
1
y
1
T
(°C)
h
m
0.05
0.115
99.2
74
0.10
0.22
96.9
140
0.20
0.385
93.10
248
0.30
0.505
90.15
325
0.40
0.59
87.9
372
0.50
0.663
86.40
395
0.60
0.729
85.25
395
0.70
0.788
84.35
355
0.80
0.849
83.6
300
0.90
0.919
82.95
205
0.95
0.957
82.60
130
These components do in fact behave like ideal gases in the vapor phase.
1) Estimate the standard enthalpy of vaporization of both pure components, specifying any assumptions.
2) Calculate an approximate limit value for the partial molar enthalpy of the dioxane mixture when
x
1
→1.
3) Note that 24 moles of (1) are mixed with 16 moles of (2) at
T
= 85.80 °C; calculate the number of moles of each body, in each phase at equilibrium, under a total pressure of 1 atm.
4)
k
i
and
a
ij
are the equilibrium coefficient of constituent (i) and its relative volatility with respect to constituent (j) defined, respectively, by: and .
a) What is the value of
α
ij
when there is an azeotrope?
b) Establish the relation whereby
α
ij
only depends on
T
and
x
i
.
c) Determine the limit value of
α
12
when
x
1
→1 at
T
= 82.4 °C.
d) Deduce the limit value of
γ
2
when
x
1
→1 at the same temperature.
5) Establish the relation describing the variation in
α
12
as a function of
T
at constant composition in the liquid phase (assuming that
h
ex
and
s
ex
do not vary with
T
).
6) From the previously established results:
a) at what
T
will we obtain an azeotrope for
x
1
= 1?
b) therefore what would be the total pressure?
c) at what
T
would we obtain an azeotrope for
x
1
= 0.55 and what would be the total pressure?
Answers: (1) ; ; (2) ; (3) n1l = 14.67 and n1v = 9.33; n2l = 12 and n2v = 4; (4) (a) αij = 1; (b) see corrections; (c) α12 = 1.08; (d) ; (5) ; (6) (a) T = 351.9 K; (b) P = 503.2 torr; (c) T = 282.75 K; P = 21.4 torr.
During lead manufacturing operations, bismuth, which makes it brittle, must be removed by the action of magnesium. Lead is thus obtained with traces of this expensive metal, a part of which is recovered by prolonged pumping of steam at 850 K, using a pumping unit which makes it possible to reach and maintain a pressure P of 3 × 10−4 torr. The thermodynamic properties of the Pb(1)/Mg(2) liquid binary mixtures are represented at 833 K by the following expressions:
1) Show that the vapor pressure of liquid
Mg
super cooled at 850 K is 0.59 torr.
2) Calculate the limit value of the activity coefficient of
Mg
in
Pb
at 850 K.
3) Estimate within 1% the titer of
Mg
, which remains in the lead after the prolonged pumping.
Data: At 850 K: and ; standard variables:
T
f
(K)
Pb
600.6
1 140
Mg
923
2 140
Answers: (1) ; (2) ; (3) x2 = 6.45 ×10−4.
Inhaling Hg vapor can cause a serious condition, known as “hydrargyrism”. International standards are set at 0.1 mg/m3 for the maximum tolerable concentration of Hg vapor in air to man.
We therefore consider the physical equilibrium to be: Hgliq ⇄ Hgvap, whose saturation vapor pressure as a function of T is written as: , where and are variations in enthalpy and entropy of evaporation, respectively.
1) Calculate the approximate temperature of evaporation of
Hg
at a pressure of 1 atm, disregarding any heat capacity effects.
2) a) Give the expressions of and as a function of
T
, taking into account the heat capacities.
b) Deduce the new expression of log .
c) Verify that the boiling point of
Hg
is close to 361 °C under 1 atm.
Mercury vapors, assumed to behave like ideal gases, are regularly distributed into the atmosphere.
3) a) Calculate the saturation vapor pressure of
Hg
at 25 °C.
b) What mass of
Hg
vapor is there per m
3
of air in the presence of liquid Hg at 25 °C?
c) Under these conditions, is it wise to leave uncovered a flask of liquid mercury in a laboratory?
Data:
Standard values
C
p
(cal.mol
-1
.K
-1
)
Hg
liquid
0
18.5
6.66
Hg
vapor
14.54
41.8
4.98
MHg = 200.6 g/mol.
Answers: (1) Tb = 350.88 °C # 351 °C; (2) (a) and ; (b) ; (c) T = 361 °C = 634.15 K; logP = 0.001 # 0, which verifies that Tb ≈ 361 °C; (3) (a) P = 2.25 × 10−3 torr; (b) m = 24 mg/m3; (c) see corrections.
Air is considered as a mixture of N2 and O2, which is separated in numerous industrial applications. We propose to construct the liquid/vapor diagram, at constant atmospheric pressure, of N2(1)/O2(2) mixture whose liquid solutions are assumed to be ideal.
The literature gives, for each pure body, the following expressions, linking saturation vapor pressure (in torr) to temperature (in Kelvin): and .
1) a) Determine for each body the standard temperature of vaporization.
b) Calculate the latent heat of vaporization of
N
2
and
O
2
.
In the isobaric diagram (T, x and y), with abscissa of x1 for the liquid phase and y1 for the vapor phase, we consider that for a determined temperature, the phases (l) and (v) are in equilibrium at a total pressure of 1 atm.
2) a) Express
x
1
and
y
1
as a function of
P
, and .
b) Calculate the
x
1
of points −193 °C and −188 °C on the boiling point curve and
y
1
on the dew point curve.
c) Draw the diagram (scale: 1 cm ↔ 1 °C; 1 cm ↔ 0.05) specifying the significance of the domains separated by the curves.
Liquid air, composed of 24.3% of oxygen by mass, is heated to its boiling point at 1 atm.
3) a) From the previous diagram, deduce the boiling point and the composition of the vapor at equilibrium with the liquid at this temperature.
b) Explain the principle behind the fractional distillation of air.
Answers: (1) (a) Tv1 = −196.14 °C and Tv2 = −183.13 °C; (b) and ; (2) (a) and ; (b) (x1 = 0.61; y1 = 0.88)−193 and (x1 = 0.23; y1 = 0.56)−188; (c) see corrections; (3) (a) Tb. ≈ −194.5 °C; x2 = 0.22 and x1 = 0.95; (b) see corrections.
We know that the vapor tension, or saturation vapor pressure, of a liquid is always a function of temperature. Now we aim to study the liquid/gas equilibrium of benzene, assuming that in the gaseous state, it obeys the ideal gas law and the molar heat capacities at constant pressure remain constant between 80 °C and 25 °C.
1) Calculate the enthalpy of vaporization of benzene at 25 °C, disregarding the molar volume of liquid benzene.
2) In mmHg/K and Pa/K, what is the slope of the liquid/gas equilibrium curve of benzene at its boiling point under a pressure of 1 atm?
3) Calculate in mmHg the vapor tension of benzene at 25 °C, disregarding the variation in enthalpy of vaporization between 80 °C and 20 °C.
4) What are the saturation molar volumes of the vapor at 80 °C and 25 °C?
5) Determine the equation that expresses the saturation molar volume of the vapor as a function of pressure.
6) What is the variation in enthalpy of 1 mole of liquid at equilibrium with the vapor between 80 °C and 25 °C?
Data: Tb = 80 °C; ; Cpl = 33 cal/mol.K and CPv = 20 cal/mol.K.
Answers: (1) ΔHv(25) = 8,056 cal/mol; (2) ; (3) P(25) =117.08 mmHg; (4) v(80) = 28.96 l; v(25) = 158.71 L; (5) ; 6) .
The physical characteristics of a nitrogen molecule are given in the table below, and its vapor pressure is 96.4 mmHg at −200.90 °C and 561.3 mmHg at −198.30 °C.
T
f
(°C)
T
b
(°C)
T
C
(°C)
P
C
(atm)
v
(L)
M
(g)
M
spc
(g.cm
-3
)
−210
−195.85
−147.15
33.5
20
28
0.3110
1) Plot the diagram of the pure body “
N
2
” specifically indicating:
a) all points given in the following table;
A
B
C
D
E
T
(K)
50
5
126
100
130
P
(atm)
1
75
33.5
35
35
b) the state of nitrogen in different domains formed by the equilibrium curves.
2) a) Indicate on the diagram the points A, B, C, D and E:
A
B
C
D
E
T
(K)
50
5
126
100
130
P
(atm)
1
75
33.5
35
35
b) What is the state and variance in the system at these points?
3) Calculate the average variation in enthalpy during the vaporization of one mole of nitrogen:
a) between 63.2 K and 74.8 K;
b) between 74.8 K and
T
b
;
c) explain the difference between both values.
Consider the transformation: N2liq ⇄ N2gas at 77.3 K and under 1 atm, assuming that N2 behaves like an ideal gas and disregarding the volume of the liquid with respect to the gas.
4) What are the variations in free enthalpy and molar entropy?
In reality, nitrogen is not an ideal gas; but its behavior does obey the Van der Waals equation: .
5) a) Give the meaning of the constants a and b, and calculate their values.
b) Deduce the expression of the Van der Waals equation.
6) What is the relative error of
V
and
P
when nitrogen is deemed an ideal gas under standard conditions?
Answers: (1) (a) and (b) See corrections; (2) (a) and (b) see corrections; (3) (a) ΔHv = 1,426.6 cal/mol; (b) ΔHv
