Serving as a review on non-local mechanics, this book provides an introduction to non-local elasticity theory for static, dynamic and stability analysis in a wide range of nanostructures. The authors draw on their own research experience to present fundamental and complex theories that are relevant across a wide range of nanomechanical systems, from the fundamentals of non-local mechanics to the latest research applications.

Leseprobe

Non-local Structural Mechanics

Danilo Karličić

Tony Murmu

Sondipon Adhikari

Michael McCarthy

Series Editor

Noël Challamel

First published 2016 in Great Britain and the United States by ISTE Ltd and John Wiley & Sons, Inc.

Apart from any fair dealing for the purposes of research or private study, or criticism or review, as permitted under the Copyright, Designs and Patents Act 1988, this publication may only be reproduced, stored or transmitted, in any form or by any means, with the prior permission in writing of the publishers, or in the case of reprographic reproduction in accordance with the terms and licenses issued by the CLA. Enquiries concerning reproduction outside these terms should be sent to the publishers at the undermentioned address:

ISTE Ltd

27-37 St George’s Road

London SW19 4EU

UK

www.iste.co.uk

John Wiley & Sons, Inc.

111 River Street

Hoboken, NJ 07030

USA

www.wiley.com

© ISTE Ltd 2016

The rights of Danilo Karličić, Tony Murmu, Sondipon Adhikari and Michael McCarthy to be identified as the authors of this work have been asserted by them in accordance with the Copyright, Designs and Patents Act 1988.

Library of Congress Control Number: 2015955807

British Library Cataloguing-in-Publication Data

A CIP record for this book is available from the British Library

ISBN 978-1-84821-522-1

Preface

Nanoscale experiments demonstrate that the mechanical properties of nanodimensional materials are much influenced by “size effects” or “scale effects”. Over the past decade, the non-local elasticity theory (non-local mechanics) has emerged as one widely promising size-dependant continuum theory. Significant progress has been made in fundamental and applied computational research in this area. The robust conventional local elasticity theory underpins the bulk of application of continuum mechanics in applied science and engineering since its inception in the early 19th Century. The utilization of the local elasticity theory in the context of nanoscale objects (such as carbon nanotube and graphene structures, etc.) has been questioned repeatedly in various research articles over the past decade. Non-local elasticity theory, pioneered from 1970s, can be applied over all scales and is considered to be more suitable for analyzing popular nanoscale objects such as carbon nanotube and graphene sheets.

This book is an initial comprehensive text to cover non-local elasticity theory for static, dynamic and stability analysis of a wide-ranging nanostructures. The authors have drawn on their own research experience to write this book. The text is written from a mechanics standpoint, comprising fundamental and complex theories that are relevant across a wide range of nanomechanical systems. The book introduces the reader to the fundamentals, as well as more in-depth aspects, of non-local mechanics and the associated latest research applications. The book brings together the vast research work for non-local mechanics in the context of nanoscale structures such as nanotubes and graphene sheets. The aim of this book is to systematically present the latest developments in the modeling and analysis of popular nanostructures. The authors have chosen to focus on the mathematical and computational aspects. This book will be relevant to aerospace, mechanical and civil engineering disciplines and various subdisciplines within them. The intended readers of this book include senior undergraduate students and graduate students doing projects or doctoral research in the field of small-scale structures. Researchers, professors and practicing engineers working in the field of small-scale structures will find this book useful.

There are very few books which are dedicated to non-local continuum mechanics, one of which is the classic book by Eringen from 1980s. Eringen’s book explains the fundamental and origin of non-local theory. The book by Gopalakrishnan and Narendar [GOP 13] is based on wave propagations in nanostructures where the non-local continuum mechanics is presented. The fundamentals of wave propagation in nanotubes and topics such as rotating nanotubes, coupled nanotubes and nanotubes are addressed in this book. A recent book by Elishakoff [ELI 12] discusses in some detail the fundamental aspects of non-local beam mechanics for nanostructures applications. These books represent the state-of-the art at the time of their publications. And the contents of non-local mechanics theory are limited. The aim of this present book is to devote all its chapters on applications of non-local mechanics to nanoscale structures. As a significant amount of work has recently gone into the research of non-local mechanics and many recent publications have been achieved, this book also covers some of these latest developments with an introduction to fundamentals in a concise way, focusing on theoretical and computational aspects, although some references to experimental works are given. This book aims to give science and engineering graduate students and researchers a detailed understanding of the methods of non-local analysis necessary for nanoscale structures.

Our book covers the essential fundamental applications and important references related to non-local mechanics theory. Chapter 1 gives an introduction to non-local elasticity mechanics. Vibration analysis of the simplest non-local elasticity theory which is the non-local rod theory is considered in Chapter 2. Chapter 3 considers non-local elastic beam theories in details. Important theories such as non-local Euler–Bernoulli beam theory, non-local Timoshenko beam theory and non-local Reddy beam theory are presented in the context of vibration and buckling. Chapter 4 gives an introduction of non-local mechanics to two-dimensional small-scale structures via non-local plate theories. Non-local mechanics applied to simple double-nanobeam system is considered in Chapter 5. Chapter 6 considers double-nanoplate-system based on non-local elasticity theory. Chapter 7 describes the applications of non-local mechanics to multiple nanostructures. Cases related to multiple-nanorod, multiple-nanobeam and multiple-nanoplates are addressed in the context of vibration and buckling. Chapter 8 takes up the topic of use of computational method such as finite element method under the umbrella of non-local mechanics. Finite element methods for dynamics of non-local systems are concisely addressed in this chapter. Examples such as axial vibration of nanorod, bending vibration of nanobeams and transverse vibration of nanoplates are presented. How the non-local finite element is applied to nanodimension structure such as single-walled carbon nanotube, double-walled carbon nanotube and single layer graphene sheets is illustrated. Chapter 9 gives a detailed description of dynamic finite element analysis of axially vibrating non-local rods. Cases of mechanical damping are addressed in this chapter. Chapter 10 describes an important application of non-local mechanics to graphene structures such as in the field of vibration-based mass nanosensors. As non-local mechanics theories are recently validated with the molecular dynamics simulations, in Chapter 11 we give an introduction to molecular dynamics for small-scale structures.

This book is a result of 7 years of research in the area of non-local mechanics theory. The book’s initial chapters began taking shape when Professor Adhikari and Dr Murmu were working on project of “scale dependent theory for nanomechanical systems” in Civil and Computational Engineering Center, University of Swansea, Wales, UK. Later chapters originated from research works with numerous colleagues, students, collaborators and mentors. We are deeply indebted to all of them for numerous stimulating scientific discussions, exchanges of ideas and in many occasions’ direct contributions toward the intellectual content of the book. The authors particularly like to thank Dr S. C. Pradhan (IIT Kharagpur), Professor P. Kozić (University of Niš), Professor M.I. Friswell (Swansea University), Dr Y. Lei (Chansha), Professor F. Scarpa (University of Bristol), Dr C. Wang (Swansea University), Professor W.A. Curtin (École Polytechnique Fédérale de Lausanne) and Dr M. Cajić (Serbian Academy of Sciences, Belgrade).

Besides the names mentioned here, I am thankful to many colleagues, fellow researchers and students working in this field of research around the world, whose names cannot be listed here. The lack of explicit mentions by no means implies that their contributions are any less important. The opinions presented in this book are entirely of the authors, and none of our colleagues, students, collaborators and mentors has any responsibility for any shortcomings.

Tony MURMU

Danilo KARLIČIĆ

Sondipon ADHIKARI

Michael MCCARTHY

October 2015

1Introduction to Non-local Elasticity

Recently, interest in nanotechnology is growing rapidly. The inventions of carbon nanotubes (CNTs) by Iijima [IIJ 91, IIJ 93] and successful extraction of graphene sheets [GEI 07] have motivated this interest. Because of its novel potential applications, recently nanomaterials have gained considerable attention among experimental, computational and theoretical research communities. As compared to more conventional materials, these nanomaterials possess superior mechanical, thermal, electrical and electronic properties [MOO 11]. Now, it is possible to arrange atoms into nanostructures that are only a few nanometers in size. For utilization and engineering of these nanoelements, proper experimental, computational and continuum mechanics-based methodologies are needed for future analysis in nanoengineering. One of the updated continuum mechanics methods for analysis of nanostructures is the non-local elasticity theory. In this chapter, we introduce some fundamental aspects to illustrate why nanostructures and non-local elasticity theory are important.

1.1. Why the non-local elasticity method for nanostructures?

The understanding of the mechanical response of nanoscale structures (small-scale structures of nanometer dimension), such as bending, vibration and buckling, is indispensable for the development and accurate design of nanostructures such as carbon nanotubes (CNTs) and graphene-based nanodevices. Figure 1.1 shows a single-walled CNT and single-walled graphene sheets. The dots in the figure represent carbon atoms. So far, experimentation on the study of actions of structures at the nanoscale is achievable, but quite difficult. Handling each and every parameter at the nanometer scale is a complicated task. Furthermore, computer simulation methods such as molecular dynamics (MD) modeling and simulation of nanostructures is computationally very expensive and time-consuming for macroscale material systems. Also, from an engineer’s perspective, we may not be expertise in MD as it involves more of a chemistry dealing with atoms, molecules, bonds and interatomic forces.

Figure 1.1.Schematic diagrams of a) single-walled carbon nanotubes and b) single-walled graphene sheets. The mechanical behavior of these nanoscale structures can be analyzed by non-local elasticity theory along with molecular dynamics and experimental work. For a color version of the figure, see www.iste.co.uk/murmu/non-local.zip

The experimentation and MD simulation for CNTs graphene and graphene-based systems are not always straightforward. So, how can these potential material nanostructures be effortlessly predicted in terms of bending, vibration, buckling and other studies for designing nanodevices (say in nanoelectromechanical systems, NEMS)? One approach is to utilize the enriched knowledge of available classical continuum mechanics. The continuum structural mechanics models continue to play an essential role in the mechanical study of CNT and graphene-based systems. Theories and design modules of macroscale structures, facilitated by engineers, are based on classical continuum models. The conventional local elasticity theory underpins the majority of application of continuum mechanics in applied science and engineering since its inception in the early 19th Century. However, the application of the local elasticity theory in the context of nanoscale objects has been repeatedly questioned in various research articles over the past decade. Classical continuum mechanics is a scale-effect-free theory and cannot be used in a nanoscale environment. Conventional continuum mechanics fails to predict size effects, which are present at small-length scales. At small scales, a material’s microstructure becomes increasingly significant and its influence can no longer be ignored. The size effects are related to atoms and molecules and their interactions. Thus, updated size-dependent continuum-based methods are required in modeling graphene as they offer much faster solutions than MD simulations, while being capable of incorporating size effects due to the discontinuous and non-homogeneous nature of real materials. One popular size-dependent method frequently used to model bending, vibration and buckling behavior of CNTs and graphene sheets is the non-local elasticity theory. Local elasticity is based on the behavior of localness (point) irrespective of the surrounding, while non-local elasticity takes into account the influence of the surrounding. This effect is more prominent and intuitive at the atomic scale (nanoscale) where an atom is affected by other surrounding atoms. The beauty of the non-local method is that it can capture atomistic effects at the nanoscale and yet impart results for the whole body.

The new structural non-local method can bridge the gap between MD and scale-effect-free continuum mechanics to provide a viable means of studying such important nanoscale objects beyond CNTs and graphene.

1.2. General modeling of nanostructures

Modeling and simulation of nanostructures such as CNTs, buckyballs, graphene and nanoelectromechanical systems are important for an optimum design. It is the scientific and engineering work involved in the analysis and design of nanostructures that support or oppose loads. By loads, we mean the forces (atomic or non-atomic), deformations or accelerations applied to the structure or its components. Load on nanostructure elements can be static as well as dynamic and its understanding is crucial. Examples of elementary nanostructural components which build up the complex structural systems (nanorobots, nanomachines and nanoelectro mechanical, nanocolumns, nanoplates (graphene sheets), nanoshells (CNTs), etc. The reliable structural modeling of nanoscale models will depend on the application of physical laws (e.g. quantum mechanics), correct mechanics (e.g. non-local mechanics), theories of materials science (e.g. lattice dynamics) and applied mathematics. This structural model will then be able to predict how nanostructures would support and resist imposed loads. The structural model will help in understanding its reliable performance over time and failure criterion under practical loads.

1.3. Overview of popular nanostructures

A nanostructure is a small object of intermediate size between molecular and microscopic (micrometer-sized) structures. The remarkable properties of nanostructures are the cause of intense research around the world. Therefore, these days an increasing number of nanoscale structures are being fabricated worldwide and are being employed as the building blocks in the emerging field of nanotechnology. Some of the nanoscale structures include nanoparticles, nanowires, nanobeams, nanorings, nanoribbons, nanoplates, nanotubes (CNTs), and components of nanomachines:

–

Nanoparticles:

these are small nano-objects considered as a whole unit with respect to its transport and properties. These particles exhibit size-dependant properties and have dimensions in the range of 1–100 nm. These nanoparticles can be incorporated into parent material to form advanced nanocomposites.

–

Nanobeams and nanorods:

these small-scale structures are categorized as one-dimensional nanostructures. These have applications in microelectromechanical systems (MEMS) and nanoelectromechanical systems (NEMS).

Figure 1.2(a)

shows the typical atomic force image of a nanorod of nanometer dimensions [WON 97].

–

Nanowires:

these are one-dimensional nanostructures with diameters in the range of nanometers. These nanowires generally have an aspect ratio, i.e length-to-diameter of 1,000 or more. They can be used to build the next generation of computing devices, improve solar cell devices, etc. A typical image of nanowire is shown in

Figure 1.2(b)

.

–

Nanoplates:

these are recognized as two-dimensional nanostructures. The nanoplates are a new subgroup of bottom-up grown nanostructures with a two-dimensional shape. Examples of thin nanoplates are graphene sheet, gold nanoplates [AH 05], etc. A typical image of nanoplate is shown in

Figure 1.2(c)

. The two-dimensional nanostructures have potential application in information storage, catalyst, transducers, solar cells, MEMS/NEMS and components in nanomachines, etc.

Figure 1.2.a) An atomic force microscope image of nanorod with 35.3 nm diameter around 600 nm in length (courtesy of [WON 97]; b) nanowires (image from www.efocuss.com); c) high-magnification scanning electron microscope of single-crystalline gold nanoplates [AH 05]; d) scanning electron micrographs of nanorings made of 100 nm diameter (courtesy of [ZHU 04]). For a color version of the figure, see www.iste.co.uk/murmu/non-local.zip

Figure 1.3.a) Scanning electron microscope of SWCNT grown on conical Si tip, b) MWCNT forest on glass substrate. Each rod-like element is the image of MWCNT with diameter of the order of tens of nanometers [DAI 02]

–

Nanorings:

a nanoring is a small ring-formed crystal. The diameter is between 50 nm and 1 μm. The nanorings could serve as nanometer-scale sensors, resonators and transducers. These small-scale structures could provide a unique platform for studying piezoelectric effects and other phenomena at the small scale.

Figure 1.2(d)

shows an image of nanorings taken from scanning electron microscope [ZHU 04].

–

Nanoribbons:

these are thin strips of nanosheets or unrolled single-walled CNTs. Nanoribbons such as graphene nanoribbons may be a technological alternative to silicon semi-conductors due its semi-conductive properties.

–

Nanotubes:

among several nanoscale structures, nanotubes have aroused great interest in the scientific community because of their exceptional mechanical, electronic, electrochemical and electrical properties. Nanotubes are long and thin cylinders of macromolecules composed of carbon atoms in a periodic hexagonal arrangement. Generally, two varieties of these tubes have been distinguished, the single-walled CNT denoted as SWCNT (

Figure 1.3(a)

) and the multi-walled CNT denoted as MWCNT (

Figure 1.3(b)

), the latter consisting of a set of concentric single-walled tubes nested inside. A double-walled CNT is shown in

Figure 1.4

.

Figure 1.4.Schematic diagram of double-wall carbon nanotubes. Study of bending, vibration and buckling of double-walled CNT is analyzed by using non-local elasticity as found in the scientific literature. In the later chapters, we show how the CNTs are modeled using non-local elasticity theory

Carbon nanotubes (CNTs) hold exciting promise in useful potential applications, as electrodes in supercapacitors, as cable materials for space elevators, as structural elements in nanoscale devices and reinforcing element in superstrong and conducting nanocomposites, biomedical, bioelectrical, superfast microelectronics, solar cells, etc.

Figure 1.5.Different types of carbon nanostructures

–

Other complex nanostructures:

other nanostructures include hybrid complex nanostructures such as CNTs with attached buckyballs (spherical fullerenes) at the tip or at the span (nanobud). As cylindrical fullerenes, known as CNTs, spherical fullerenes are referred to as buckyballs. Buckyballs are cage-like fused-ring polycyclic systems of carbon atoms. As nanobuds [ARA 12] can be obtained by adjoining fullerene to CNT span, buckyballs can be incorporated into the tip of CNTs. The nanobuds are new structures where spherical fullerenes are covalently bonded to the outer sidewalls of the underlying nanotube. By similar method, buckyballs can be fixed to the ends of nanotubes. When buckyballs are added to the both ends of nanotube, we obtain a nanodumbbell. These CNT-buckyball systems can be utilized as state-of-the-art filler materials for strong tough nanocomposites.

Figure 1.5

shows the different types of nanostructures.

1.4. Popular approaches for understanding nanostructures

The modeling and study of nanostructures such as graphene sheets can be done by various methods as depicted in Figure 1.6. Generally, the three popular methods by which the behavior of graphene is studied comprise experimental, MD simulation and continuum mechanics approach.

Figure 1.6.General approaches used to model and study nanostructures

1.5. Experimental methods

Some of the earlier and present day investigations on nanomaterials and nanostructures, such as CNTs and grapheme, are carried out by the experimental methods [HAN 11]. The details of experimental methods used are beyond the scope of this chapter. An experimental approach at the nanoscale is obviously a better way to analyze the behavior of grapheme as it is more realistic. However, in experimental study, controlling every parameter in nanoscale is a difficult task.

1.6. Molecular dynamics simulations

Due to the physical drawbacks and lack of scope for experimental method, many scientists and engineers resorted to atomistic-level simulation techniques. The behavior of graphene at atomistic levels can be simulated via the molecular dynamics (MD) [HAN 10, TAN 08]. MD simulation refers to expensive computer simulations depicting physical movements of atoms and molecules at the nanoscale. In an MD simulation, the motion of individual atoms within an assembly of N atoms or molecules is modeled on the basis of either a Newtonian deterministic dynamic or a Langevin-type stochastic dynamic, given the initial position coordinates and velocities of the atoms. Applying Newton’s equations of motion, the trajectories of molecules and atoms are determined. Potential functions are defined according to which particles will interact. In MD simulations, the forces between the particles and potential energy are defined by molecular mechanics force fields. The molecular simulation methods, however, suffer from the disadvantage that these are sophisticated, require larger computational resources, require solving large number of equations and are highly expensive and time-consuming [MUR 12b].

1.7. Continuum mechanics approach

Because the experimental and atomistic computational approach, though realistic, suffers from the drawback that it is computationally expensive, time-consuming and requires greater expertise, one alternative is to utilize the available knowledge of classical continuum mechanics. Can classical continuum mechanics deal with structures of nanoscale dimensions? To answer this, classical continuum modeling (e.g. classical Kirchhoff’s plate theories) of nanostructures such as graphene has thus received an increasing amount of attention. These continuum mechanics theories [AND 04] have thus started to play an important role in characterizing overall mechanical responses of nanoscale materials that are fundamental structural and functional building blocks in engineering nanostructures.

In continuum mechanics, the mechanical behavior of graphene is modeled as a continuous mass rather than as discrete particles and it is assumed that there is no empty space between particles (atoms). Theories of structures constructed on the foundation of continuum mechanics include Euler–Bernoulli beam theory, Timoshenko beam theory, Kirchoff’s plate theory, Mindlin plate theory, and classical shell theory, etc. Using Euler–Bernoulli beam theory and Timoshenko beam theory, modeling and prediction of mechanical response of CNTs have been attempted. The continuum (local elasticity) theory is based on the constitutive relation that stresses a point which depends on the strain at that point only.

1.8. Failure of classical continuum mechanics
